Alfa Romeo Giulietta
Date of manufacture
2016 – to this day (Five-door hatchback)
Platform
Fiat Compact platform
Manufacturing locations
Cassino, Italy
Designer
Centro Stile Alfa Romeo
Tags
C-segment
Italian cars
The Alfa Romeo Giulietta is a five-door hatchback first produced in 2016. This model from the Italian carmaker is built on the Fiat Compact platform and offers both petrol and diesel engines. The highest performance is achieved by the 1750 TBi 240k Quadrifoglio Verde (177 kW) with a maximum speed of 244 km/h. The most economical version is the 1.6 JTDm 120k with a fuel consumption of 3.9 l/100 km and emissions of 103 g/km. The luggage compartment has a capacity of 350 l. In terms of safety, the Alfa Romeo Giulietta was rated 3 out of 5 by EURONCAP in 2017.
Car body style
Five-door hatchback
after upgrade (facelift)
Date of manufacture
2016 – to this dayInternal designation
940
Technical data
Five-door hatchback
| 1.4TB 120HP | 1.4 TB MultiAir 150HP | 1.4 TB MultiAir 170HP | 1.4 TB MultiAir 170HP | 1750 TBi 240HP Quadrifoglio Verde | 1,6 JTDm 120HP | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1368 | 1368 | 1368 | 1368 | 1742 | 1598 |
| Maximum output / speed [kW/min-1] | 88/5000 | 110/5500 | 125/5500 | 125/5500 | 177/5750 | 88/3750 |
| Maximum torque [Nm/min-1] | 215/2500 | 250/2500 | 250/2500 | 250/2500 | 340/2000 | 320/1750 |
| Bore and stroke [mm x mm] | 72,0 x 84,0 | 72,0 x 84,0 | 72,0 x 84,0 | 72,0 x 84,0 | 83,0 x 80,5 | 79,5 x 80,5 |
| Compression ratio | 9,8:1 | 9,8:1 | 9,8:1 | 9,8:1 | 9,25:1 | 16,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications | - | - | - |
|
| - |
| Top speed [km/h] | 195 | 210 | 218 | 218 | 244 | 195 |
| Acceleration 0–100 km/h [s] | 9.4 | 8,2 | 7.8 | 7.6 | 6.0 | 10,0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8,9-9,2 | 7,4 | 7,4 | 6.3 | 9,5 | 4,9 |
| Out of town [l] | 6,2-6,4 | 4,4 | 4.4 | 4.1 | 5,2 | 3,3 |
| Combined [l] | 7,2-7,4 | 5,5 | 5,5 | 4,9 | 6,8 | 3,9 |
| CO2 emissions [g/km] | 164-170 | 127 | 127 | 114 | 162 | 103 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | - | - | - | - | - |
| CO2 emissions [g/km] | 190-170 | - | - | - | - | - |
| Emission standard | Euro 6 - EURO 6D-TEMP | Euro 6 | Euro 6 | Euro 6 | Euro 6 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1280 | 1290 | 1290 | 1310 | 1320 | 1310 |
| Overall weight [kg] | 1785 | 1795 | 1795 | 1810 | 1825 | 1815 |
| Maximum trailer weight unbraked/braked [kg] | 500/1300 | 500/1300 | 500/1300 | 500/1300 | 500/1000 | 500/1300 |
| Maximum front/rear axle load [kg] | 1100/850 | 1100/850 | 1100/850 | 1100/850 | 1100/850 | 1100/850 |
| Maximum vertical load on the tow bar [kg] | 60 | 60 | 60 | 60 | 60 | 60 |
| Maximum load on roof/carrier [kg] | 50/- | 50/- | 50/- | 50/- | 50/- | 50/- |
| Boot volume [l] | 350 | 350 | 350 | 350 | 350 | 350 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1045 | -/1045 | -/1045 | -/1045 | -/1045 | -/1045 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 205/55 R16 91V | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 | 205/55 R16 91V |
| Tyre dimensions rear | 205/55 R16 91V | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 | 205/55 R16 91V |
| Wheel size front | 7Jx16 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7.5Jx17 | 7Jx16 ET41 |
| Wheel size rear | 7Jx16 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7.5Jx17 | 7Jx16 ET41 |
| Brake dimensions front | 281x26 | 305x28 | 305x28 | 305x28 | 330x28 | 281x26 |
| Brake dimensions rear | 264x10 | 264x10 | 264x10 | 264x10 | 278x12 | 264x10 |
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9 | 10.9 | 10.9 | 10.9 | 10.9 | 10.9 |
| Overall length [mm] | 4351 | 4351 | 4351 | 4351 | 4351 | 4351 |
| Overall width without/including mirrors [mm] | 1798/- | 1798/- | 1798/- | 1798/- | 1798/- | 1798/- |
| Overall height [mm] | 1465 | 1465 | 1465 | 1465 | 1465 | 1465 |
| Wheelbase [mm] | 2634 | 2634 | 2634 | 2634 | 2634 | 2634 |
| Front wheel track [mm] | 1554 | 1554 | 1554 | 1554 | 1554 | 1554 |
| Rear wheel track [mm] | 1554 | 1554 | 1554 | 1554 | 1554 | 1554 |
| Forward overhang [mm] | 955 | 955 | 955 | 955 | 955 | 955 |
| Rear overhang [mm] | 762 | 762 | 762 | 762 | 762 | 762 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 980 | 980 | 980 | 980 | 980 | 980 |
| Headroom rear [mm] | 943 | 943 | 943 | 943 | 943 | 943 |
| Front elbow/shoulder width [mm] | -/1419 | -/1419 | -/1419 | -/1419 | -/1419 | -/1419 |
| Rear elbow/shoulder width [mm] | -/1343 | -/1343 | -/1343 | -/1343 | -/1343 | -/1343 |
| Legroom front knees/total [mm] | -/1033 | -/1033 | -/1033 | -/1033 | -/1033 | -/1033 |
| Legroom rear knees/total [mm] | -/901 | -/901 | -/901 | -/901 | -/901 | -/901 |
| 1,6 JTDm 120HP | 1,6 JTDm 120HP | 1,6 JTDm 120HP | 2,0 JTDm 150HP | 2,0 JTDm 170HP | 2,0 JTDm 175HP | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1956 | 1956 | 1956 |
| Maximum output / speed [kW/min-1] | 88/3750 | 88/3750 | 88/3750 | 110/3750 | 125/3750 | 129/3750 |
| Maximum torque [Nm/min-1] | 320/1750 | 320/1750 | 320/1750 | 380/1750 | 350/1750 | 350/1750 |
| Bore and stroke [mm x mm] | 79,5 x 80,5 | 79,5 x 80,5 | 79,5 x 80,5 | 83,0 x 90,4 | 83,0 x 90,4 | 83,0 x 90,4 |
| Compression ratio | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 195 | 195 | 195 | 210 | 214 | 219 |
| Acceleration 0–100 km/h [s] | 10,0 | 10,2 | 10,2 | 8,8 | 8,3 | 7.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,3-5,8 | 4,9 | 5,4-5,1 | 5,0 | 6,3-6,2 | 5.1 |
| Out of town [l] | 4,2-4,0 | 3,3 | 4,7-4,5 | 3,7 | 4,5-4,2 | 3,8 |
| Combined [l] | 5,0-4,7 | 3,9 | 4,9-4,7 | 4,2 | 5,2-4,9 | 4,3 |
| CO2 emissions [g/km] | 131-123 | 103 | 130-125 | 110 | 136-130 | 113 |
| Emission standard | EURO 6D-TEMP | Euro 6 | EURO 6D-TEMP | Euro 6 | EURO 6D-TEMP | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | 155-144 | - | 159-148 | - | 164-151 | - |
| Standby weight [kg] | 1310 | 1320 | 1320 | 1320 | 1335 | 1335 |
| Overall weight [kg] | 1815 | 1825 | 1825 | 1825 | 1920 | 1840 |
| Maximum trailer weight unbraked/braked [kg] | 500/1300 | 500/1300 | 500/600 | 500/1300 | 500/600 | 500/600 |
| Maximum front/rear axle load [kg] | 1100/850 | 1100/850 | 1100/850 | 1100/850 | - | 1100/850 |
| Maximum vertical load on the tow bar [kg] | 60 | 60 | 60 | 60 | 60 | 60 |
| Maximum load on roof/carrier [kg] | 50/- | 50/- | 50/- | 50/- | 50/- | 50/- |
| Boot volume [l] | 350 | 350 | 350 | 350 | 350 | 350 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1045 | -/1045 | -/1045 | -/1045 | -/1045 | -/1045 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | 12,5 | - | 12,5 | - | 12,5 | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 91W |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 225/45 R17 91W | 225/45 R17 91W | 225/45 R17 91W |
| Wheel size front | 7Jx16 ET41 | 7Jx16 ET41 | 7Jx16 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 |
| Wheel size rear | 7Jx16 ET41 | 7Jx16 ET41 | 7Jx16 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 | 7,5J x 17 ET41 |
| Brake dimensions front | 281x26 | 281x26 | 281x26 | 305x28 | 305x28 | 305x28 |
| Brake dimensions rear | 264x10 | 264x10 | 264x10 | 264x10 | 264x10 | 264x10 |
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9 | 10.9 | 10.9 | 10.9 | 10.9 | 10.9 |
| Overall length [mm] | 4351 | 4351 | 4351 | 4351 | 4351 | 4351 |
| Overall width without/including mirrors [mm] | 1798/- | 1798/- | 1798/- | 1798/- | 1798/- | 1798/- |
| Overall height [mm] | 1465 | 1465 | 1465 | 1465 | 1465 | 1465 |
| Wheelbase [mm] | 2634 | 2634 | 2634 | 2634 | 2634 | 2634 |
| Front wheel track [mm] | 1554 | 1554 | 1554 | 1554 | 1554 | 1554 |
| Rear wheel track [mm] | 1554 | 1554 | 1554 | 1554 | 1554 | 1554 |
| Forward overhang [mm] | 955 | 955 | 955 | 955 | 955 | 955 |
| Rear overhang [mm] | 762 | 762 | 762 | 762 | 762 | 762 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 980 | 980 | 980 | 980 | 980 | 980 |
| Headroom rear [mm] | 943 | 943 | 943 | 943 | 943 | 943 |
| Front elbow/shoulder width [mm] | -/1419 | -/1419 | -/1419 | -/1419 | -/1419 | -/1419 |
| Rear elbow/shoulder width [mm] | -/1343 | -/1343 | -/1343 | -/1343 | -/1343 | -/1343 |
| Legroom front knees/total [mm] | -/1033 | -/1033 | -/1033 | -/1033 | -/1033 | -/1033 |
| Legroom rear knees/total [mm] | -/901 | -/901 | -/901 | -/901 | -/901 | -/901 |
