Audi Q2
Date of manufacture
7/2016 – 2020 (Small SUV)
Platform
Volkswagen Group MQB platform
Manufacturing locations
Ingolstadt, Germany
Relizane, Algeria
Designer
Marc Lichte
Tags
Small SUV
German cars
The Audi Q2 is a small SUV that has been produced in two countries since 2016 - Germany and Algeria. It is built on the Volkswagen Group MQB platform and offers petrol and diesel engines. The most powerful model, the SQ2 quattro, has 221 kW and a top speed of 250 km/h with the best acceleration from 0-100 km/h in 4.8 seconds. The most economical variant, the 1.6 TDI 85kW, has a fuel consumption of 4.3 l/100 km and emissions of 114 g/km. The luggage compartment can hold 405 liters of cargo. In terms of safety, the EURONCAP awarded the Audi Q2 a rating of 5 out of 5 in 2016.
Car body style
Small SUV
Date of manufacture
7/2016 – 2020Internal designation
-Engine size
Petrol
Diesel
Technical data
Small SUV
| 1.0 TFSI ultra 85 kW | 1.0 TFSI ultra 85 kW | 30 TFSI 85kW | Gasoline Particulate Filter 30 TFSI 85kW | 30 TFSI 85kW | 1.4 TFSI COD 110kW | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | from 2018 to | from 2018 to | from 2018 to | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 3/12 | 4/16 |
| Engine displacement [cm³] | 999 | 999 | 999 | 999 | 999 | 1395 |
| Maximum output / speed [kW/min-1] | 85/5000-5500 | 85/5000-5500 | 85/5000-5500 | 85/5000-5500 | 85/5000-5500 | 110/5000-6000 |
| Maximum torque [Nm/min-1] | 200/2000-3500 | 200/2000-3500 | 200/2000-3500 | 200/2000-3500 | 200/2000-3500 | 250/1500-3500 |
| Bore and stroke [mm x mm] | 74,5 x 75,4 | 74,5 x 75,4 | 74,5 x 75,4 | 74,5 x 75,4 | 74,5 x 75,4 | 74,5 x 80,0 |
| Compression ratio | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 7 gear automatic | 6 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual |
| Drive specifications | - |
| - | - |
| - |
| Top speed [km/h] | 197 | 197 | 197 | 197 | 197 | 212 |
| Acceleration 0–100 km/h [s] | 10,1 | 10,3 | 10,1 | 10,1 | 10,3 | 8,5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,3-6,2 | 6,1-5,9 | 6,3-6,2 | 6,7-6,4 | 6,1-5,9 | 6,8-6,7 |
| Out of town [l] | 4,8-4,5 | 5,1-5,0 | 4,8-4,5 | 4,7-4,4 | 5,1-5,0 | 5,1-4,8 |
| Combined [l] | 5,4-5,1 | 5,4-5,3 | 5,4-5,1 | 5,4-5,1 | 5,4-5,3 | 5,8-5,5 |
| CO2 emissions [g/km] | 122-117 | 124-122 | 122-117 | 123-117 | 124-122 | 130-124 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | - | - | 6,5-5,9 | - | - |
| CO2 emissions [g/km] | - | - | - | 147-133 | - | - |
| Emission standard | Euro 6 | Euro 6 | Euro 6 | Euro 6d-TEMP | Euro 6 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1280 | 1315 | 1300 | 1300 | 1325 | 1340 |
| Overall weight [kg] | 1765 | 1800 | 1800 | 1815 | 1830 | 1825 |
| Maximum trailer weight unbraked/braked [kg] | 640/1300 | 650/1300 | 650/1300 | 650/1300 | 660/1300 | 670/1500 |
| Maximum front/rear axle load [kg] | - | - | 940/900 | - | 970/915 | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 60/- | 60/- | 60/- | 60/- | 60/- | 60/- |
| Boot volume [l] | 405 | 405 | 405 | 405 | 405 | 405 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1050 | -/1050 | -/1050 | -/1050 | -/1050 | -/1050 |
| Boot length [mm] | 779 | 779 | 779 | 779 | 779 | 779 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 740 | 740 | 740 | 740 | 740 | 740 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | -/940 | -/940 | -/940 | -/940 | -/940 | -/940 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | 0,32 | 0,32 | 0,32 | 0,31 |
| Front suspension | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser |
| Rear suspension | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar |
| Tyre dimensions front | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Tyre dimensions rear | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- |
| Overall length [mm] | 4191 | 4191 | 4191 | 4191 | 4191 | 4191 |
| Overall width without/including mirrors [mm] | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 |
| Overall height [mm] | 1508 | 1508 | 1508 | 1508 | 1508 | 1508 |
| Wheelbase [mm] | 2601 | 2601 | 2601 | 2601 | 2601 | 2601 |
| Front wheel track [mm] | 1547 | 1547 | 1547 | 1547 | 1547 | 1547 |
| Rear wheel track [mm] | 1541 | 1541 | 1541 | 1541 | 1541 | 1541 |
| Forward overhang [mm] | 828 | 828 | 828 | 828 | 828 | 828 |
| Rear overhang [mm] | 762 | 762 | 762 | 762 | 762 | 762 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | 1029 |
| Headroom rear [mm] | 966 | 966 | 966 | 966 | 966 | 966 |
| Front elbow/shoulder width [mm] | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 |
| Rear elbow/shoulder width [mm] | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.4 TFSI COD 110kW | 35 TFSI 110kW | Gasoline Particulate Filter 35 TFSI 110kW | 35 TFSI 110kW | Gasoline Particulate Filter 35 TFSI 110kW | 2.0 TFSI 140kW quattro | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 2018 to | from 2018 to | from 2018 to | from 2018 to | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1395 | 1395 | 1498 | 1395 | 1498 | 1984 |
| Maximum output / speed [kW/min-1] | 110/5000-6000 | 110/5000-6000 | 110/5000-6000 | 110/5000-6000 | 110/5000-6000 | 140/4200-6000 |
| Maximum torque [Nm/min-1] | 250/1500-3500 | 250/1500-3500 | 250/1500-3500 | 250/1500-3500 | 250/1500-3500 | 320/1500-4100 |
| Bore and stroke [mm x mm] | 74,5 x 80,0 | 74,5 x 80,0 | 74,5 x 85,9 | 74,5 x 80,0 | 74,5 x 85,9 | 82,5 x 92,8 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,5:1 | 10,0:1 | 10,5:1 | 11,7:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | 4x4 |
| Gearbox | 7 gear automatic | 6 gear manual | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications |
| - | - |
|
|
|
| Top speed [km/h] | 212 | 212 | 212 | 212 | 212 | 228 |
| Acceleration 0–100 km/h [s] | 8,5 | 8,5 | 8,5 | 8,5 | 8,5 | 6,5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,5-6,3 | 7,3-7,0 | 6,9-6,8 | 7,1-6,4 | 6,6 | 8,1-7,9 |
| Out of town [l] | 4,9-4,6 | 5,0-4,7 | 4,8-4,6 | 4,8-4,5 | 4,6-4,4 | 5,5-5,1 |
| Combined [l] | 5,5-5,2 | 5,9-5,5 | 5,6-5,4 | 5,7-5,3 | 5,3-5,2 | 6,4-6,1 |
| CO2 emissions [g/km] | 125-119 | 133-126 | 128-123 | 129-110 | 122-119 | 146-139 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | - | 6,8-6,2 | - | 6,9-6,4 | - |
| CO2 emissions [g/km] | - | - | 154-140 | - | 156-144 | - |
| Emission standard | Euro 6 | Euro 6 | Euro 6d-TEMP | Euro 6 | Euro 6d-TEMP | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1355 | 1340 | 1340 | 1365 | 1365 | 1505 |
| Overall weight [kg] | 1840 | 1860 | 1860 | 1880 | 1880 | 1990 |
| Maximum trailer weight unbraked/braked [kg] | 670/1500 | 670/1500 | 670/1500 | 680/1500 | 680/1500 | 750/1500 |
| Maximum front/rear axle load [kg] | - | 980/955 | 980/955 | 1005/955 | 1005/955 | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 60/- | 60/- | 60/- | 60/- | 60/- | 60/- |
| Boot volume [l] | 405 | 405 | 405 | 405 | 405 | 355 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1050 | -/1050 | -/1050 | -/1050 | -/1050 | -/1000 |
| Boot length [mm] | 779 | 779 | 779 | 779 | 779 | 779 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 740 | 740 | 740 | 740 | 740 | 740 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | -/940 | -/940 | -/940 | -/940 | -/940 | -/940 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | 50 | 55 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0,31 | 0,31 | 0,31 | 0,31 | 0,31 | - |
| Front suspension | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser |
| Rear suspension | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | four-link |
| Tyre dimensions front | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Tyre dimensions rear | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- |
| Overall length [mm] | 4191 | 4191 | 4191 | 4191 | 4191 | 4191 |
| Overall width without/including mirrors [mm] | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 |
| Overall height [mm] | 1508 | 1508 | 1508 | 1508 | 1508 | 1508 |
| Wheelbase [mm] | 2601 | 2601 | 2601 | 2601 | 2601 | 2595 |
| Front wheel track [mm] | 1547 | 1547 | 1547 | 1547 | 1547 | 1547 |
| Rear wheel track [mm] | 1541 | 1541 | 1541 | 1541 | 1541 | 1548 |
| Forward overhang [mm] | 828 | 828 | 828 | 828 | 828 | 828 |
| Rear overhang [mm] | 762 | 762 | 762 | 762 | 762 | 768 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | 1029 |
| Headroom rear [mm] | 966 | 966 | 966 | 966 | 966 | 966 |
| Front elbow/shoulder width [mm] | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 |
| Rear elbow/shoulder width [mm] | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Gasoline Particulate Filter 2.0 TFSI 140kW quattro | SQ2 quattro | 1.6 TDI 85kW | 1.6 TDI 85kW | 2.0 TDI 110kW quattro | 2.0 TDI 140kW quattro | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 2018 to | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1984 | 1984 | 1598 | 1598 | 1968 | 1968 |
| Maximum output / speed [kW/min-1] | 140/4200-6000 | 221/5300-6500 | 85/3250-4000 | 85/3250-4000 | 110/3500-4000 | 140/3500-4000 |
| Maximum torque [Nm/min-1] | 320/1500-4100 | 400/2000-2500 | 250/1750-3200 | 250/1750-3200 | 340/1750-3000 | 400/1900-3300 |
| Bore and stroke [mm x mm] | 82,5 x 92,8 | 82,5 x 92,8 | 79,5 x 80,5 | 79,5 x 80,5 | 81,0 x 95,5 | 81,0 x 95,5 |
| Compression ratio | 11,7:1 | 9,3:1 | 16,2:1 | 16,2:1 | 16,2:1 | 16,2:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Front | Front | 4x4 | 4x4 |
| Gearbox | 7 gear automatic | 7 gear automatic | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications |
|
| - |
|
|
|
| Top speed [km/h] | 228 | 250 | 197 | 197 | 211 | 218 |
| Acceleration 0–100 km/h [s] | 6,5 | 4,8 | 10,3 | 10,5 | 8,1 | 7,3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8,5-8,4 | 8,8-8,6 | 5,0-4,9 | 4,6-4,4 | 5,8-5,6 | 5,9-5,7 |
| Out of town [l] | 5,5-5-3 | 6,2-6,0 | 4,4-4,1 | 4,3-4,0 | 4,6-4,3 | 4,6-4,4 |
| Combined [l] | 6,6-6,4 | 7,2-7,0 | 4,6-4,4 | 4,3-4,1 | 5,0-4,8 | 5,1-4,9 |
| CO2 emissions [g/km] | 150-146 | 163-159 | 120-114 | 114-109 | 131-125 | 134-128 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 8,4-7,9 | - | - | - | - | - |
| CO2 emissions [g/km] | 189-178 | - | - | - | - | - |
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6 | Euro 6 | Euro 6 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1505 | 1585 | 1385 | 1395 | 1550 | 1555 |
| Overall weight [kg] | 2045 | 2065 | 1870 | 1880 | 2035 | 2040 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1400 | 690/1500 | 690/1500 | 750/1800 | 750/1800 |
| Maximum front/rear axle load [kg] | 1100/1020 | 1105/1055 | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 60/- | 60/- | 60/- | 60/- | 60/- | 60/- |
| Boot volume [l] | 355 | 355 | 405 | 405 | 355 | 355 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1000 | -/1000 | -/1050 | -/1050 | -/1000 | -/1000 |
| Boot length [mm] | 779 | 779 | 779 | 779 | 779 | 779 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 740 | 727 | 740 | 740 | 740 | 740 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | -/940 | -/940 | -/940 | -/940 | -/940 | -/940 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 55 | 55 | 50 | 50 | 55 | 55 |
| AdBlue tank volume [l] | - | - | - | - | 13 | 13 |
| Air resistance [Cd] | 0.32 | 0.34 | - | - | 0,31 | 0,31 |
| Front suspension | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser |
| Rear suspension | four-link | four-link | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar |
| Tyre dimensions front | 205/60 R16 92V | 235/45 R 18 94 Y | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Tyre dimensions rear | 205/60 R16 92V | 235/45 R 18 94 Y | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V |
| Wheel size front | 6.0J x 16 | 8.0J x 18 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Wheel size rear | 6.0J x 16 | 8.0J x 18 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- |
| Overall length [mm] | 4191 | 4210 | 4191 | 4191 | 4191 | 4191 |
| Overall width without/including mirrors [mm] | 1794/2009 | 1802/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 |
| Overall height [mm] | 1508 | 1495 | 1508 | 1508 | 1508 | 1508 |
| Wheelbase [mm] | 2595 | 2594 | 2601 | 2601 | 2595 | 2595 |
| Front wheel track [mm] | 1547 | 1547 | 1547 | 1547 | 1547 | 1547 |
| Rear wheel track [mm] | 1548 | 1551 | 1541 | 1541 | 1548 | 1548 |
| Forward overhang [mm] | 828 | 836 | 828 | 828 | 828 | 828 |
| Rear overhang [mm] | 768 | 780 | 762 | 762 | 768 | 768 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | 1029 |
| Headroom rear [mm] | 966 | 966 | 966 | 966 | 966 | 966 |
| Front elbow/shoulder width [mm] | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 |
| Rear elbow/shoulder width [mm] | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 30 TDI 85kW | 30 TDI 85kW | 35 TDI 110kW | 35 TDI 110kW | 35 TDI 110kW quattro | ||
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | from 2018 to | from 2018 to | from 2018 to | from 2018 to | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | |
| Engine displacement [cm³] | 1598 | 1598 | 1968 | 1968 | 1968 | |
| Maximum output / speed [kW/min-1] | 85/3250-4000 | 85/3250-4000 | 110/3500-4000 | 110/3500-4000 | 110/3500-4000 | |
| Maximum torque [Nm/min-1] | 250/1750-3200 | 250/1750-3200 | 340/1750-3000 | 340/1750-3000 | 340/1750-3000 | |
| Bore and stroke [mm x mm] | 79,5 x 80,5 | 79,5 x 80,5 | 81,0 x 95,5 | 81,0 x 95,5 | 81,0 x 95,5 | |
| Compression ratio | 16,2:1 | 16,2:1 | 16,2:1 | 16,2:1 | 16,2:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Front | Front | Front | Front | 4x4 | |
| Gearbox | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | 7 gear automatic | |
| Drive specifications | - |
| - |
|
| |
| Top speed [km/h] | 197 | 197 | 211 | 211 | 211 | |
| Acceleration 0–100 km/h [s] | 10,3 | 10,5 | 8,5 | 8,5 | 8,1 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 5,6-5,4 | 5,3-4,9 | 5,8-5,4 | 5,5-5,1 | 6,2-6,0 | |
| Out of town [l] | 4,5-4,2 | 4,5-4,2 | 4,3-3,9 | 4,3-3,9 | 4,8-4,6 | |
| Combined [l] | 4,9-4,6 | 4,8-4,5 | 4,7-4,5 | 4,7-4,4 | 5,3-5,1 | |
| CO2 emissions [g/km] | 128-121 | 126-117 | 124-118 | 123-115 | 140-133 | |
| Low speed [l] | - | - | - | - | - | |
| Medium speed [l] | - | - | - | - | - | |
| High speed [l] | - | - | - | - | - | |
| Extra high speed [l] | - | - | - | - | - | |
| Combined speed [l] | 6,2-5,6 | 6,4-5,8 | - | - | 6,3-5,8 | |
| CO2 emissions [g/km] | 162-148 | 167-153 | - | - | 165-153 | |
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1420 | 1435 | 1440 | 1465 | 1550 | |
| Overall weight [kg] | 1930 | 1945 | 1955 | 1980 | 2070 | |
| Maximum trailer weight unbraked/braked [kg] | 710/1500 | 710/1500 | 720/1600 | 730/1600 | 750/1800 | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | |
| Maximum load on roof/carrier [kg] | 60/- | 60/- | 60/- | 60/- | 60/- | |
| Boot volume [l] | 405 | 405 | 405 | 405 | 355 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1050 | -/1050 | -/1050 | -/1050 | -/1000 | |
| Boot length [mm] | 779 | 779 | 779 | 779 | 779 | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | 740 | 740 | 740 | 740 | 740 | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | -/940 | -/940 | -/940 | -/940 | -/940 | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | 55 | |
| AdBlue tank volume [l] | 13 | 13 | 13 | 13 | 13 | |
| Air resistance [Cd] | 0,31 | 0,31 | 0,31 | 0,31 | 0,31 | |
| Front suspension | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | MacPherson, lower cross arms, torsion stabiliser | |
| Rear suspension | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | twist beam axle with torsion bar | |
| Tyre dimensions front | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | |
| Tyre dimensions rear | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | 205/60 R16 92V | |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | 6.0J x 16 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11,1/- | 11,1/- | 11,1/- | 11,1/- | 11,1/- | |
| Overall length [mm] | 4191 | 4191 | 4191 | 4191 | 4191 | |
| Overall width without/including mirrors [mm] | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | 1794/2009 | |
| Overall height [mm] | 1508 | 1508 | 1508 | 1508 | 1508 | |
| Wheelbase [mm] | 2601 | 2601 | 2601 | 2601 | 2595 | |
| Front wheel track [mm] | 1547 | 1547 | 1547 | 1547 | 1547 | |
| Rear wheel track [mm] | 1541 | 1541 | 1548 | 1548 | 1548 | |
| Forward overhang [mm] | 828 | 828 | 828 | 828 | 828 | |
| Rear overhang [mm] | 762 | 762 | 762 | 762 | 768 | |
| Clearance [mm] | - | - | - | - | - | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | - | - | - | - | - | |
| Approach angle rear [°] | - | - | - | - | - | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | |
| Headroom rear [mm] | 966 | 966 | 966 | 966 | 966 | |
| Front elbow/shoulder width [mm] | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | 1444/1390 | |
| Rear elbow/shoulder width [mm] | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | 1416/1347 | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
