BMW 2
Date of manufacture
11/2013 – to this day (Coupé)
2014 – to this day (Convertible)
Platform
-
Manufacturing locations
Leipzig, Germany
Designer
-
Tags
C-segment
German cars
The BMW 2 in coupe and convertible body styles has been manufactured in Germany since 2013. It offers a wide range of engine options, from petrol to diesel. The most powerful model is the M2 F87 Competition with a maximum power output of 302 kW and a top speed of 250 km/h. The most economical vehicle is the 220d with a combined fuel consumption of 4.1 l/100 km and CO2 emissions of 108 g/km. The convertible offers a luggage compartment of 280-335 l, while the coupe version has a capacity of 390 l.
Car body style
Coupé
Date of manufacture
11/2013 – to this dayInternal designation
F22Technical data
Coupé
| 218i | 218i | 218i | 218i | 220i | 220i | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 8/2019 to | - | from 8/2019 to | - | from 7/2016 to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1499 | 1499 | 1499 | 1499 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 100/4500 -6000 | 100/4400 | 100/4500 -6000 | 100/4400 | 135/5000-6250 | 135/5000 |
| Maximum torque [Nm/min-1] | 220/1250 | 220/1250-4300 | 220/1250 | 220/1250-4300 | 270/1250-4500 | 290/1350-4250 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 84,0 x 90,1 | 82.0 x 94.6 |
| Compression ratio | 11.0:1 | 11.0:1 | 11.0:1 | 11.0:1 | 11,0:1 | 11.0 :1 |
| Oil volume [l] | 4.25 | 4.25 | 4.25 | 4.25 | 5,0 | 5.25 |
| Coolant volume [l] | 7.7 | - | 8.7 | - | 6,9 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications | - | - |
|
| - | - |
| Top speed [km/h] | 210 | 210 | 210 | 210 | 235 | 235 |
| Acceleration 0–100 km/h [s] | 8.8 | 8.8 | 8.9 | 8.9 | 7.0 | 7.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 11.2 | - | - | - | - | 8.6 |
| City [l] | 6.3-6.9 | 7.4-7.4 | 6.2-6.8 | 7.2-7.0 | 8.3-8.7 | 7.6-8.1 |
| Out of town [l] | 4.4-4.8 | 5.4-5.2 | 4.4-4.8 | 5.1-5.0 | 4.8-5.0 | 4.7-5.0 |
| Combined [l] | 5.1-5.6 | 6.2-6.0 | 5.1-5.5 | 5.9-5.7 | 6.1-6.3 | 5.7-6.1 |
| CO2 emissions [g/km] | 119-130 | 140-137 | 118-129 | 133-130 | 142-148 | 131-140 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1415 | 1420 | 1435 | 1440 | 1425 | 1455 |
| Overall weight [kg] | 1850 | 1850 | 1870 | 1870 | 1860 | 1890 |
| Maximum trailer weight unbraked/braked [kg] | 680/1300 | 680/1300 | 680/1300 | 680/1300 | 680/1200 | 680/1500 |
| Maximum front/rear axle load [kg] | 875/1040 | 875/1040 | 875/1040 | 900/1040 | 880/1040 | 895/ 1065 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75 /- | 75 /- | 75 /- | 75 /- | 75/- | 75/- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R1691V |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R1691V |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774/- | 1774/- | 1774/- | 1774/- | 1774/- | 1774 /- |
| Overall height [mm] | 1418 | 1418 | 1418 | 1418 | 1418 | 1418 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 220i | 220i | 220i | 228i | 228i | 230i | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 7/2016 to 9/2018 | from 8/2019 to | - | - | from 7/2016 to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1997 | 1998 | 1998 | 1997 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 135/5000-6250 | 135/5000 | 135/5000 | 180/5000 -6500 | 180/5000 -6500 | 185/5200 |
| Maximum torque [Nm/min-1] | 270/1250-4500 | 290/1350-4250 | 270/1350-4600 | 350/1250 -4800 | 350/1250 -4800 | 350/1450-4800 |
| Bore and stroke [mm x mm] | 84,0 x 90,1 | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.1 | 84.0 x 90.1 | 82.0 x 94.6 |
| Compression ratio | 11,0:1 | 11.0 :1 | 11.0:1 | 11.0 :1 | 11.0 :1 | 10.2:1 |
| Oil volume [l] | 5,0 | 5.25 | 5.25 | 1385/1460 | 1385/1460 | 5.25 |
| Coolant volume [l] | 7,6 | - | - | 5.0 | 5.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 6 gear manual |
| Drive specifications |
|
|
| - |
| - |
| Top speed [km/h] | 230 | 230 | 230 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 7.0 | 7.2 | 7.2 | 5.8 | 5.73 | 5.8 |
| Acceleration 0–80 km/h [s] | - | - | - | 6.5 | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | 6.5 |
| City [l] | 7.7-8.0 | 7.0-7.4 | 7.3-7.2 | 8.7 | 8.5 | 8.1-8.5 |
| Out of town [l] | 4.6-4.8 | 4.7-5.0 | 5.1-4.9 | 5.4 | 5.1 | 5.1-5.2 |
| Combined [l] | 6.1-6.3 | 5.5-5.9 | 5.9-5.8 | 6.6 | 6.3 | 6.2-6.4 |
| CO2 emissions [g/km] | 134-139 | 126-135 | 135-132 | 154 | 148 | 142-147 |
| Emission standard | EU6 | EU6 | EU6d-TEMP | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1440 | 1475 | 1480 | 1480 | 1480 | 1475 |
| Overall weight [kg] | 1875 | 1910 | 1910 | 1895 | 1915 | 1910 |
| Maximum trailer weight unbraked/braked [kg] | 680/1200 | 680/1500 | 680/1500 | 700/1200 | 700/1200 | 715/1500 |
| Maximum front/rear axle load [kg] | 880/1040 | 895/ 1065 | 905/1065 | 900/ 1065 | 900/ 1065 | 905/ 1085 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75 /- | 75 /- | 75 /- | 75/- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | 0.30 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/50 R17 89W | 205/50 R17 89Y |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/50 R17 89W | 205/50 R17 89Y |
| Wheel size front | 7 J x 16 | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Wheel size rear | 7 J x 16 | 7J x 16 | 7J x 16 | 7J x 17l | 7J x 17 | 7J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774/- | 1774 /- | 1774/- | 1774 /- | 1774 /- | 1774 /- |
| Overall height [mm] | 1418 | 1418 | 1418 | 1418 | 1418 | 1418 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 230i | 230i | M 235i | M 235i | M235i xDrive | M240i | |
|---|---|---|---|---|---|---|
| Date of sale | from 7/2016 to 9/2018 | from 8/2019 to | - | - | - | from 7/2016 to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 6/24 | 6 /24 |
| Engine displacement [cm³] | 1998 | 1998 | 2979 | 2979 | 2979 | 2998 |
| Maximum output / speed [kW/min-1] | 185/5200 | 185/5200 | 240/5800-6000 | 240/5800-6000 | 240/5800 -6000 | 250/5500 |
| Maximum torque [Nm/min-1] | 350/1450-4800 | 350/1450-4800 | 450/1300-4500 | 450/1300-4500 | 450/1300 -4500 | 500/1520-4500 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 84,0 x 89,6 | 84,0 x 89,6 | 84,0 x 89,6 | 82.0 x 94.6 |
| Compression ratio | 10.2:1 | 10.2:1 | 10,2:1 | 10,2:1 | 10.2 :1 | 11.0:1 |
| Oil volume [l] | 5.25 | 5.25 | 6,5 | 6,5 | 6.5 | 6.5 |
| Coolant volume [l] | - | - | 6,7 | 7,2 | 7.2 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | 4x4 | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual |
| Drive specifications |
|
| - |
|
| - |
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 5.6 | 5.6 | 5.0 | 4.8 | 4.63 | 4.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.2-7.4 | 7.3-7.3 | 10.9 | 10.3 | 10.8 | 10.6 |
| Out of town [l] | 4.9-5.0 | 5.2-5.1 | 6.4 | 5.9 | 6.1 | 6.2 |
| Combined [l] | 5.7-5.9 | 6.0-5.9 | 8.1 | 7.6 | 7.8 | 7.8 |
| CO2 emissions [g/km] | 130-134 | 138-135 | 189 | 176 | 182 | 179 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1500 | 1505 | 1530 | 1545 | 1600 | 1545 |
| Overall weight [kg] | 1935 | 1935 | 1965 | 1980 | 2035 | 1980 |
| Maximum trailer weight unbraked/braked [kg] | 715/1500 | 715/1500 | - | - | - | - |
| Maximum front/rear axle load [kg] | 905/ 1085 | 915/1085 | 970/1080 | 970/1080 | 1020/ 1080 | 975/ 1100 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75/- | 75/- | 75 /- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.30 | 0.30 | 0.33 | 0.33 | 0.33 | 0.33 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/50 R17 89Y | 205/50 R17 89Y | 225/40 ZR18 Y | 225/40 ZR18 Y | 225/40 R18 88Y | 225/40 R18 88Y |
| Tyre dimensions rear | 205/50 R17 89Y | 205/50 R17 89Y | 245/35 ZR 18 Y | 245/35 ZR 18 Y | 245/35 R 18 92Y XL | 245/35 R18 92Y XL |
| Wheel size front | 7J x 17 | 7J x 17 | 7.5 J x 18 | 7.5 J x 18 | 7.5J x 18 | 7.5J x 18 |
| Wheel size rear | 7J x 17 | 7J x 17 | 8 J x 18 | 8 J x 18 | 8J x 18 | 8J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4454 | 4454 | 4454 | 4454 |
| Overall width without/including mirrors [mm] | 1774 /- | 1774/- | 1774/- | 1774/- | 1774 /- | 1774/- |
| Overall height [mm] | 1418 | 1418 | 1408 | 1408 | 1408 | 1408 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1516 | 1516 | 1516 | 1516 |
| Rear wheel track [mm] | 1556 | 1556 | 1534 | 1534 | 1534 | 1534 |
| Forward overhang [mm] | 780 | 780 | 802 | 802 | 802 | 802 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 130 | 130 | 130 | 130 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| M240i | M240i | M240i xDrive | M240i xDrive | M2 F87 | M2 F87 | |
|---|---|---|---|---|---|---|
| Date of sale | from 7/2016 to 9/2018 | from 8/2019 to | from 7/2016 to 9/2018 | from 8/2019 to | from 2016 to 2020 | from 2016 to 2020 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6 /24 | 6/24 | 6 /24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2998 | 2998 | 2998 | 2998 | 2979 | 2979 |
| Maximum output / speed [kW/min-1] | 250/5500 | 250/5500 | 250/5500 | 250/5500 | 272/6500 | 272/6500 |
| Maximum torque [Nm/min-1] | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 | 500/1400-5560 | 500/1400-5560 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 84,0 x 89,6 | 84,0 x 89,6 |
| Compression ratio | 11.0:1 | 11.0:1 | 11.0:1 | 11.0:1 | 10,2:1 | 10,2:1 |
| Oil volume [l] | 6.5 | 6.5 | 6.5 | 6.5 | 6.5 | 6.5 |
| Coolant volume [l] | - | - | - | - | 10,3 | 10,3 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | 4x4 | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual | 7 gear automatic |
| Drive specifications |
|
|
|
| - |
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 [270 subject to a surcharge] | 250 [270 subject to a surcharge] |
| Acceleration 0–100 km/h [s] | - | 4.6 | 4.4 | 4.4 | 4,5 | 4,3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | 4,4 | 4,4 |
| City [l] | 9.4 | 9.4-9.3 | 9.8 | 10.1-9.9 | 11,6 | 10,5 |
| Out of town [l] | 5.8 | 6.2-6.2 | 6.0 | 6.7-6.6 | 6,7 | 6,4 |
| Combined [l] | 7.1 | 7.4-7.3 | 7.4 | 8.0-7.8 | 8,5 | 7,9 |
| CO2 emissions [g/km] | 163 | 169-167 | 169 | 181-178 | 199 | 185 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1560 | 1565 | 1615 | 1615 | 1570 | 1595 |
| Overall weight [kg] | 1995 | 1995 | 2050 | 2050 | 2010 | 2010 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | 975/ 1100 | 975/1100 | 1025/ 1110 | 1025/1110 | 970/1080 | 970/1080 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75 /- | 75 /- | 75 /- | 75 /- | 75 /- | 75 /- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.33 | 0,33 | 0.34 | 0,34 | 0,35 | 0,35 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40 R18 88Y | 225/40 ZR18 88Y | 225/40 R18 88Y | 225/40 ZR18 88Y | 245/35 ZR19 93 Y | 245/35 ZR19 93 Y |
| Tyre dimensions rear | 245/35 R18 92Y XL | 245/35 ZR 18 92Y XL | 245/35 R18 92Y XL | 245/35 ZR 18 92Y XL | 265/35 ZR19 98 Y | 265/35 ZR19 98 Y |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 9.0J x 19 | 9.0J x 19 |
| Wheel size rear | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 10.0J x 19 | 10.0J x 19 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 11.3/- | 11.7/- | 11.7/- |
| Overall length [mm] | 4454 | 4454 | 4454 | 4454 | 4468 | 4468 |
| Overall width without/including mirrors [mm] | 1774/- | 1774/- | 1774/- | 1774/- | 1854/- | 1854/- |
| Overall height [mm] | 1408 | 1408 | 1408 | 1408 | 1410 | 1410 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2693 | 2693 |
| Front wheel track [mm] | 1516 | 1516 | 1516 | 1516 | 1579 | 1579 |
| Rear wheel track [mm] | 1534 | 1534 | 1534 | 1534 | 1601 | 1601 |
| Forward overhang [mm] | 802 | 802 | 802 | 802 | 807 | 807 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 968 | 968 |
| Clearance [mm] | 130 | 130 | 130 | 130 | 123 | 123 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| M2 F87 Competition | M2 F87 Competition | 218d | 218d | 218d | 218d | |
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to 2020 | from 2018 to 2020 | - | from 8/2019 to | - | from 8/2019 to |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2979 | 2979 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 302/5250-7000 | 302/5250-7000 | 105/4000 | 110/4000 | 105/4000 | 110/4000 |
| Maximum torque [Nm/min-1] | 550/2350-5200 | 550/2350-5200 | 320/1750-2500 | 320/1500-3000 | 320/1750-2500 | 320/1500-3000 |
| Bore and stroke [mm x mm] | 84,0 x 89,6 | 84,0 x 89,6 | 84,0 x 90,0 | 90.0 x 84.0 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 10,2:1 | 10,2:1 | 16,5:1 | 16.5:1 | 16,5:1 | 16.5:1 |
| Oil volume [l] | 6.5 | 6.5 | 5,2 | 5.0 | 5,2 | 5.0 |
| Coolant volume [l] | 10,0 | 10,0 | 7,0 | - | 7,0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 7 gear automatic | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - |
| - | - |
|
|
| Top speed [km/h] | 250 [270 subject to a surcharge] | 250 [270 subject to a surcharge] | 213 | 213 | 213 | 213 |
| Acceleration 0–100 km/h [s] | 4,4 | 4,2 | 8.9 | 8.5 | 8.6 | 8.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 4,0 | 4,1 | - | - | - | - |
| City [l] | - | - | 5.3-5.5 | 5.3-5.1 | 5.1-5.4 | 5.3-5.2 |
| Out of town [l] | - | - | 3.8-3.9 | 4.1-4.0 | 3.7-3.9 | 4.2-4.1 |
| Combined [l] | 10,0-9,8 | 9,2-9,0 | 4.3-4.5 | 4.6-4.4 | 4.2-4.4 | 4.5-4.4 |
| CO2 emissions [g/km] | 227-224 | 209-206 | 114-119 | 120-116 | 111-117 | 119-116 |
| Emission standard | EU6 | EU6 | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1625 | 1650 | 1430 | 1495 | 1450 | 1515 |
| Overall weight [kg] | 2010 | 2010 | 1865 | 1930 | 1885 | 1950 |
| Maximum trailer weight unbraked/braked [kg] | - | - | 690/1200-1500 | 715/1500 | 690/1200-1500 | 715/1500 |
| Maximum front/rear axle load [kg] | 970/1080 | 970/1080 | 890/1045 | 920/1100 | 890/1045 | 920/1100 |
| Maximum vertical load on the tow bar [kg] | - | - | - | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75 /- | 75 /- | 75/- | 75 /- | 75/- | 75 /- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0,36 | 0,36 | 0.28 | 0.29 | 0.28 | 0.29 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 245/35 ZR19 93 Y | 245/35 ZR19 93 Y | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Tyre dimensions rear | 265/35 ZR19 98 Y | 265/35 ZR19 98 Y | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Wheel size front | 9.0J x 19 | 9.0J x 19 | 7 J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 |
| Wheel size rear | 10.0J x 19 | 10.0J x 19 | 7 J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.7/- | 11.7/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4461 | 4461 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1854/- | 1854/- | 1774/- | 1774/- | 1774/- | 1774/- |
| Overall height [mm] | 1410 | 1410 | 1418 | 1418 | 1418 | 1418 |
| Wheelbase [mm] | 2693 | 2693 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1579 | 1579 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1601 | 1601 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 807 | 807 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 968 | 968 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 123 | 123 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 220d | 220d | 220d | 220d | 220d xDrive | 225d | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 8/2019 to | - | from 8/2019 to | from 8/2019 to | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 135/4000 | 140/4000 | 135/4000 | 140/4000 | 140/4000 | 160/4400 |
| Maximum torque [Nm/min-1] | 380/1750-2750 | 400/1750-2500 | 380/1750-2750 | 400/1750-2500 | 400/1750-2500 | 450/1750-2500 |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 16,5:1 | 16.5:1 | 16,5:1 | 16.5:1 | 16.5:1 | 16,5:1 |
| Oil volume [l] | 5,2 | 5.0 | 5,2 | 5.0 | 5.0 | 5,0-5,2 |
| Coolant volume [l] | 7,0 | - | 7,0 | - | - | 7,0 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | 4x4 | Rear |
| Gearbox | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications | - | - |
|
|
|
|
| Top speed [km/h] | 230 | 230 | 230 | 230 | 225 | 242 |
| Acceleration 0–100 km/h [s] | 7.2 | 7.2 | 7.1 | 7.1 | 7.0 | 6.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 5.6-5.9 | 5.4-5.2 | 4.9-5.2 | 5.3-5.2 | 6.0-5.8 | 5.6 |
| Out of town [l] | 3.9-4.1 | 4.2-4.1 | 3.8-4.0 | 4.2-4.1 | 4.7-4.6 | 4.2 |
| Combined [l] | 4.5-4.8 | 4.6-4.5 | 4.2-4.4 | 4.6-4.5 | 5.1-5.0 | 4.7 |
| CO2 emissions [g/km] | 119-125 | 122-119 | 111-117 | 121-120 | 132-132 | 124 |
| Emission standard | EU6 | EU6c | EU6 | EU6d-TEMP | EU6d-TEMP | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1450 | 1505 | 1465 | 1530 | 1605 | 1495 |
| Overall weight [kg] | 1885 | 1945 | 1900 | 1965 | 2040 | 1930 |
| Maximum trailer weight unbraked/braked [kg] | 710/1200-1500 | 725/1500 | 710/1200-1500 | 725/1500 | 750/1500 | 710/1200-1500 |
| Maximum front/rear axle load [kg] | 900/1050 | 925/ 1110 | 900/1050 | 925/ 1110 | 965/1120 | 920/1080 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75 /- | 75 /- | 75/- |
| Boot volume [l] | 390 | 390 | 390 | 390 | 390 | 390 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.28 | 0.28 | 0.28 | 0.28 | 0.29 | 0.29 |
| Front suspension | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms | MacPherson, lower cross arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W |
| Wheel size front | 7 J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 | 7J x 16 | 7 J x 17 |
| Wheel size rear | 7 J x 16 | 7J x 16 | 7 J x 16 | 7J x 16 | 7J x 16 | 7 J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 11.3/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774/- | 1774/- | 1774/- | 1774/- | 1774/- | 1774/- |
| Overall height [mm] | 1418 | 1418 | 1418 | 1418 | 1418 | 1418 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1522 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 927 | 927 | 927 | 927 | 927 | 927 |
| Front elbow/shoulder width [mm] | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- | 1436/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 225d | ||||||
|---|---|---|---|---|---|---|
| Date of sale | from 8/2019 to | |||||
| Engine type | Diesel supercharged | |||||
| Number of cylinders/valves | 4/16 | |||||
| Engine displacement [cm³] | 1995 | |||||
| Maximum output / speed [kW/min-1] | 165/4400 | |||||
| Maximum torque [Nm/min-1] | 450/1500-3000 | |||||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | |||||
| Compression ratio | 16.5:1 | |||||
| Oil volume [l] | 5.0 | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Rear | |||||
| Gearbox | 8 gear automatic | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 243 | |||||
| Acceleration 0–100 km/h [s] | 6.3 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | 5.5-5.4 | |||||
| Out of town [l] | 4.2-4.1 | |||||
| Combined [l] | 4.7-4.6 | |||||
| CO2 emissions [g/km] | 124-121 | |||||
| Emission standard | EU6c | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| Standby weight [kg] | 1550 | |||||
| Overall weight [kg] | 1985 | |||||
| Maximum trailer weight unbraked/braked [kg] | 740/1500 | |||||
| Maximum front/rear axle load [kg] | 930/ 1110 | |||||
| Maximum vertical load on the tow bar [kg] | 75 | |||||
| Maximum load on roof/carrier [kg] | 75 /- | |||||
| Boot volume [l] | 390 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | |||||
| Boot length [mm] | - | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | - | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 2 | |||||
| Number of seats | 4 | |||||
| Fuel tank volume [l] | 52 | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | 0.29 | |||||
| Front suspension | MacPherson, lower cross arms | |||||
| Rear suspension | five-link | |||||
| Tyre dimensions front | 205/55 R17 89Y | |||||
| Tyre dimensions rear | 205/55 R17 89Y | |||||
| Wheel size front | 7J x 17 | |||||
| Wheel size rear | 7J x 17 | |||||
| Brake dimensions front | - | |||||
| Brake dimensions rear | - | |||||
| Steering | Electric power steering EPS | |||||
| Number of steering wheel turns | - | |||||
| Turning diameter track/circumference [m] | 10.9/- | |||||
| Overall length [mm] | 4432 | |||||
| Overall width without/including mirrors [mm] | 1774/- | |||||
| Overall height [mm] | 1418 | |||||
| Wheelbase [mm] | 2690 | |||||
| Front wheel track [mm] | 1521 | |||||
| Rear wheel track [mm] | 1556 | |||||
| Forward overhang [mm] | 780 | |||||
| Rear overhang [mm] | 962 | |||||
| Clearance [mm] | 140 | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | 1018 | |||||
| Headroom rear [mm] | 927 | |||||
| Front elbow/shoulder width [mm] | 1436/- | |||||
| Rear elbow/shoulder width [mm] | 1403/- | |||||
| Legroom front knees/total [mm] | - | |||||
| Legroom rear knees/total [mm] | - |
Convertible
| 218i | 218i | 218i | 218i | 220i | 220i | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to | from to 9/2018 | from 9/2018 to | from to 9/2018 | from 9/2018 to |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1499 | 1499 | 1499 | 1499 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 100/4500-6000 | 100/4400 | 100/4500-6000 | 100/4400 | 135/5000-6250 | 135/5000 |
| Maximum torque [Nm/min-1] | 220/1250 | 220/1250-4300 | 220/1250 | 220/1250-4300 | 270/1250 -4500 | 270/1350-4600 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.1 | 82.0 x 94.6 |
| Compression ratio | 11.0:1 | 11.0:1 | 11.0:1 | 11.0:1 | 11.0 :1 | 11.0:1 |
| Oil volume [l] | 4.25 | 4.25 | 4.25 | 4.25 | 5.0 | 5.25 |
| Coolant volume [l] | 7,7 | - | 7,8 | - | 6.9 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications | - | - |
|
| - | - |
| Top speed [km/h] | 207 | 207 | 205 | 205 | 231 | 226 |
| Acceleration 0–100 km/h [s] | 9.4 | 9.4 | 9.6 | 9.6 | 7.5 | 7.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 11.4 | - | - | - | 9.3 | - |
| City [l] | 7.5-6,9 | 8.1-7.8 | 7.1-6,5 | 7.6-7.4 | 8.9-9.4 | 7.2-7.1 |
| Out of town [l] | 5,1-4,7 | 5.6-5.5 | 5,0-4,6 | 5.5-5.4 | 5.1-5.4 | 5.7-5.5 |
| Combined [l] | 6,0-5,5 | 6.5-6.3 | 5,8-5,3 | 6.3-6.1 | 6.5-6.9 | 6.2-6.1 |
| CO2 emissions [g/km] | 139-129 | 148-144 | 134-124 | 143-139 | 152-161 | 142-139 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1590 | 1575 | 1590 | 1595 | 1585 | 1615 |
| Overall weight [kg] | 1965 | 1965 | 1985 | 1985 | 1980 | 2010 |
| Maximum trailer weight unbraked/braked [kg] | 750/1300 | 750/1300 | 750/1300 | 750/1300 | 750/1200 | 750/1500 |
| Maximum front/rear axle load [kg] | 865/1160 | 880/1040 | 865/1160 | 910/1040 | 885/1160 | 935/1145 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | -/- | -/- | -/- | -/- | -/- | -/- |
| Boot volume [l] | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.32 | 0.32 | 0.32 | 0.32 | 0.32 | 0.32 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91W | 205/55 R16 91W |
| Tyre dimensions rear | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91H | 205/55 R16 91W | 205/55 R16 91W |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electro-mechanical power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774 /- | 1774/- | 1774 /- | 1774/- | 1774 /- | 1774/- |
| Overall height [mm] | 1413 | 1413 | 1413 | 1413 | 1413 | 1413 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1028 | 1028 | 1028 | 1028 | 1028 | 1028 |
| Headroom rear [mm] | 940 | 940 | 940 | 940 | 940 | 940 |
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- |
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 220i | 220i | 220i | 228i | 228i | 230i | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 7/2016 to 9/2018 | from 7/2016 to 9/2018 | from to 9/2018 | from to 9/2018 | from 7/2016 to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4 /16 | 4 /16 | 4/16 | 4/16 | 4 /16 |
| Engine displacement [cm³] | 1997 | 1998 | 1998 | 1997 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 135/5000-6250 | 135/5000 | 135/5000 | 180/5000-6500 | 180/5000-6500 | 185/5200 |
| Maximum torque [Nm/min-1] | 270/1250 -4500 | 290/1350-4250 | 290/1350-4250 | 350/1250 -4800 | 350/1250 -4800 | 350/1450-4800 |
| Bore and stroke [mm x mm] | 84.0 x 90.1 | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.1 | 84.0 x 90.1 | 82.0 x 94.6 |
| Compression ratio | 11.0 :1 | 11.0 :1 | 11.0 :1 | 10.0 :1 | 10.0 :1 | 10.2:1 |
| Oil volume [l] | 5.0 | 5.25 | 5.25 | 5.0 | 5.0 | 5.25 |
| Coolant volume [l] | 7.6 | - | - | 7.0 | 7.6 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 6 gear manual | 8 gear automatic | 6 gear manual | 8 gear automatic | 6 gear manual |
| Drive specifications |
| - |
| - |
| - |
| Top speed [km/h] | 226 | 231 | 226 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 7.6 | 7.5 | 7.7 | 6.1 | 6.0 | 6.1 |
| Acceleration 0–80 km/h [s] | - | 9.5 | - | - | - | 7.2 |
| Acceleration 80–120 km/h [s] | - | - | - | 7.2 | - | - |
| City [l] | 8.3-8.7 | 8.0-8.6 | 7.2-7.7 | 9.1-9.3 | 8.8-9.0 | 8.5-8.9 |
| Out of town [l] | 5.0-5.2 | 4.9-5.3 | 4.9-5.2 | 5.5-5.6 | 5.3-5.4 | 5.3-5.5 |
| Combined [l] | 6.2-6.5 | 6.1-6.5 | 5.7-6.1 | 6.8-7.0 | 6.6-6.7 | 6.5-6.8 |
| CO2 emissions [g/km] | 144-152 | 139-149 | 131-140 | 159-163 | 154-157 | 149-155 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1605 | 1595 | 1595 | 1610 | 1630 | 1615 |
| Overall weight [kg] | 2000 | 1990 | 2010 | 1975 | 1995 | 1980 |
| Maximum trailer weight unbraked/braked [kg] | 750/1200 | 750/1500 | 750/1500 | 750/1200 | 750/1200 | 750/1500 |
| Maximum front/rear axle load [kg] | 885/1160 | 900/ 1145 | 900/ 1145 | 900/1130 | 900/1130 | 920/1130 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | -/- | -/- | -/- | -/- | -/- | -/- |
| Boot volume [l] | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.32 | 0.32 | 0.32 | 0.33 | 0.33 | 0.33 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/50 R17 89Y | 205/50 R17 89Y | 205/50 R17 89Y |
| Tyre dimensions rear | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/50 R17 89Y | 205/50 R17 89Y | 205/50 R17 89Y |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774 /- | 1774/- | 1774/- | 1774 /- | 1774 /- | 1774/- |
| Overall height [mm] | 1413 | 1413 | 1413 | 1413 | 1413 | 1413 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1028 | 1028 | 1028 | 1028 | 1028 | 1028 |
| Headroom rear [mm] | 940 | 940 | 940 | 940 | 940 | 940 |
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- |
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 230i | 230i | M235i | M235i | M235i xDrive | M240i | |
|---|---|---|---|---|---|---|
| Date of sale | from 9/2018 to | from 7/2016 to 9/2018 | from to 9/2018 | from to 9/2018 | from to 9/2018 | from 7/2016 to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4 /16 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 1998 | 1998 | 2979 | 2979 | 2979 | 2998 |
| Maximum output / speed [kW/min-1] | 185/5200 | 185/5200 | 240/5800-6000 | 240/5800-6000 | 240/5800-6000 | 250/5500 |
| Maximum torque [Nm/min-1] | 350/1450-4800 | 350/1450-4800 | 450/1300-4500 | 450/1300-4500 | 450/1300-4500 | 500/1520-4500 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 89.6 | 84.0 x 89.6 | 84.0 x 89.6 | 82.0 x 94.6 |
| Compression ratio | 10.2:1 | 10.2:1 | 10.2:1 | 10.2:1 | 10.2:1 | 11.0:1 |
| Oil volume [l] | 5.25 | 5.25 | 6.5 | 6.5 | 6.5 | 6.5 |
| Coolant volume [l] | - | - | 6.7 | 7.2 | 7.2 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | 4x4 | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual |
| Drive specifications | - |
| - |
|
| - |
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 5.9 | 5.9 | 5.2 | 5.0 | 5.0 | 4.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | 5.6 | - | - | 5.3 |
| City [l] | 7.6-7.5 | 7.6-7.8 | 11.5 | 10.7 | 10.7 | 11.2 |
| Out of town [l] | 5.8-5.6 | 5.1-5.3 | 6.8 | 6.2 | 6.2 | 6.6 |
| Combined [l] | 6.4-6.3 | 6.0-6.2 | 8.5 | 7.9 | 7.9 | 8.3 |
| CO2 emissions [g/km] | 147-144 | 137-142 | 199 | 184 | 184 | 189 |
| Emission standard | EU6d-TEMP | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1650 | 1615 | 1675 | 1675 | 1675 | 1690 |
| Overall weight [kg] | 2020 | 2010 | 2030 | 2050 | 2050 | 2045 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | - | - | - | - |
| Maximum front/rear axle load [kg] | 935/1130 | 920/1130 | 960/1145 | 960/1145 | 960/1145 | 975/ 1145 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | - | - | - | - |
| Maximum load on roof/carrier [kg] | -/- | -/- | -/- | -/- | -/- | -/- |
| Boot volume [l] | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.33 | 0.33 | 0.35 | 0.35 | 0.35 | 0.36 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/50 R17 89Y | 205/50 R17 89Y | 225/40 R18 88Y | 225/40 R18 88Y | 225/40 R18 88Y | 225/40 R18 88Y |
| Tyre dimensions rear | 205/50 R17 89Y | 205/50 R17 89Y | 245/35 R 18 92Y XL | 245/35 R 1892Y XL | 245/35 R 1892Y XL | 245/35 R 18 92Y XL |
| Wheel size front | 7J x 17 | 7J x 17 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 |
| Wheel size rear | 7J x 17 | 7J x 17 | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4454 | 4454 | 4454 | 4454 |
| Overall width without/including mirrors [mm] | 1774/- | 1774/- | 1774 /- | 1774 /- | 1774 /- | 1774/- |
| Overall height [mm] | 1413 | 1413 | 1403 | 1403 | 1403 | 1403 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1516 | 1516 | 1516 | 1516 |
| Rear wheel track [mm] | 1556 | 1556 | 1534 | 1534 | 1534 | 1534 |
| Forward overhang [mm] | 780 | 780 | 802 | 802 | 802 | 802 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 130 | 130 | 130 | 130 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1028 | 1028 | 1028 | 1028 | 1028 | 1028 |
| Headroom rear [mm] | 940 | 940 | 940 | 940 | 940 | 940 |
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- |
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| M240i | M240i | M240i xDrive | M240i xDrive | 218d | 218d | |
|---|---|---|---|---|---|---|
| Date of sale | from 7/2016 to 9/2018 | from 9/2018 to | from 7/2016 to 9/2018 | from 9/2018 to | from to 9/2018 | from 9/2018 to |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2998 | 2998 | 2998 | 2998 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 250/5500 | 250/5500 | 250/5500 | 250/5500 | 110/4000 | 110/4000 |
| Maximum torque [Nm/min-1] | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 | 320/1500-3000 | 320/1500-3000 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 11.0:1 | 11.0:1 | 11.0:1 | 11.0:1 | 16.5:1 | 16.5:1 |
| Oil volume [l] | 6.5 | 6.5 | 6.5 | 6.5 | 5.0 | 5.0 |
| Coolant volume [l] | - | - | - | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | 4x4 | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications |
|
|
|
| - | - |
| Top speed [km/h] | 250 | 250 | 250 | 250 | 208 | 208 |
| Acceleration 0–100 km/h [s] | 4.7 | 4.7 | 4.6 | 4.6 | 8,9 | 9.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.8 | 9.9-9.8 | 10.4 | 10.9-10.6 | 5,1-5,6 | 6.0-5.6 |
| Out of town [l] | 6.0 | 6.3-6.3 | 6.3 | 7.0-6.9 | 3,9-4,2 | 4.7-4.4 |
| Combined [l] | 7.4 | 7.6-7.6 | 7.8 | 8.4-8.3 | 4,3-4,7 | 5.2-4.8 |
| CO2 emissions [g/km] | 169 | 173-172 | 179 | 191-188 | 114-124 | 136-127 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6c |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1690 | 1710 | 1755 | 1760 | 1595 | 1640 |
| Overall weight [kg] | 2060 | 2060 | 2110 | 2110 | 1990 | 2015 |
| Maximum trailer weight unbraked/braked [kg] | - | 750/1500 | - | 750/1500 | 750/1500 | 750/1500 |
| Maximum front/rear axle load [kg] | 975/ 1145 | 975/ 1145 | 1020/ 1145 | 1025/ 1145 | 900/1155 | 910 /1160 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | 75 | 75 |
| Maximum load on roof/carrier [kg] | -/- | -/- | -/- | -/- | - | -/- |
| Boot volume [l] | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.36 | 0.36 | 0.37 | 0.37 | 0.31 | 0.31 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40R18 88Y | 225/40 ZR18 88Y | 225/40R18 88Y | 225/40 ZR18 88Y | 205/55 R16 91W | 205/55 R16 91V |
| Tyre dimensions rear | 245/35 R 18 92Y XL | 245/35 ZR 18 92Y XL | 245/35 R 18 92Y XL | 245/35 ZR 18 92Y XL | 205/55 R16 91W | 205/55 R16 91V |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7J x 16 | 7J x 16 |
| Wheel size rear | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 7J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering EPS | Electro-mechanical power steering EPS | Electro-mechanical power steering EPS | Electro-mechanical power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 11.3/- | 11.3/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4454 | 4454 | 4454 | 4454 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774/- | 1774/- | 1774/- | 1774/- | 1774 /- | 1774/- |
| Overall height [mm] | 1403 | 1403 | 1403 | 1403 | 1413 | 1413 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1516 | 1516 | 1516 | 1516 | 1521 | 1521 |
| Rear wheel track [mm] | 1534 | 1534 | 1534 | 1534 | 1556 | 1556 |
| Forward overhang [mm] | 802 | 802 | 790 | 802 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 130 | 130 | 130 | 130 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1028 | 1028 | 1028 | 1028 | 1028 | 1028 |
| Headroom rear [mm] | 940 | 940 | 940 | 940 | 940 | 940 |
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- |
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 218d | 218d | 220d | 220d | 220d | 220d | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to | from to 9/2018 | from 9/2018 to | from to 9/2018 | from 9/2018 to |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 110/4000 | 110/4000 | 140/4000 | 140/4000 | 140/4000 | 140/4000 |
| Maximum torque [Nm/min-1] | 320/1500-3000 | 320/1500-3000 | 400/1750-2500 | 400/1750-2500 | 400/1750 -2500 | 400/1750-2500 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 |
| Oil volume [l] | 5.0 | 5.0 | 5.0 | 5.0 | 5.0 | 5.0 |
| Coolant volume [l] | 7.0 | - | 7.0 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
| - | - |
|
|
| Top speed [km/h] | 208 | 205 | 225 | 225 | 225 | 225 |
| Acceleration 0–100 km/h [s] | 8,7 | 8.8 | 7.5 | 7.6 | 7.4 | 7.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | 7.7 | - | - | - |
| City [l] | 4,9-5,4 | 5.5-5.4 | 5.5-5.8 | 5.9-5.9 | 4.7-5.2 | 5.4-5.4 |
| Out of town [l] | 3,6-3,9 | 4.5-4.4 | 3.8-4.1 | 4.6-4.3 | 3.7-4.0 | 4.4-4.3 |
| Combined [l] | 4,1-4,5 | 4.8-4.7 | 4.4-4.7 | 5.1-4.9 | 4.1-4.4 | 4.8-4.7 |
| CO2 emissions [g/km] | 108-118 | 127-123 | 116-124 | 135-129 | 108-117 | 126-124 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1615 | 1670 | 1610 | 1660 | 1630 | 1690 |
| Overall weight [kg] | 2010 | 2035 | 2005 | 2035 | 2025 | 2055 |
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | 750/1500 | 750/1500 | 750/1500 | 750/1500 |
| Maximum front/rear axle load [kg] | 900/1155 | 910 /1160 | 905/1155 | 920/ 1160 | 905/1155 | 920/ 1160 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | - | -/- | - | -/- | - | -/- |
| Boot volume [l] | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 | 280-335 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91W | 205/55 R16 91V | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W |
| Tyre dimensions rear | 205/55 R16 91W | 205/55 R16 91V | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W | 205/55 R16 91W |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electro-mechanical power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS | Electric power steering EPS | Electro-mechanical power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4432 | 4432 | 4432 | 4432 | 4432 | 4432 |
| Overall width without/including mirrors [mm] | 1774 /- | 1774/- | 1774 /- | 1774/- | 1774 /- | 1774/- |
| Overall height [mm] | 1413 | 1413 | 1413 | 1413 | 1413 | 1413 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1521 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 780 | 780 | 780 | 780 | 780 | 780 |
| Rear overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1028 | 1028 | 1028 | 1028 | 1028 | 1028 |
| Headroom rear [mm] | 940 | 940 | 940 | 940 | 940 | 940 |
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- | 1383/- |
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- | 1104/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 225d | 225d | |||||
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1995 | 1995 | ||||
| Maximum output / speed [kW/min-1] | 165/4400 | 165/4400 | ||||
| Maximum torque [Nm/min-1] | 450/1500-3000 | 450/1500-3000 | ||||
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | ||||
| Compression ratio | 16.5:1 | 16.5:1 | ||||
| Oil volume [l] | 5.0 | 5.0 | ||||
| Coolant volume [l] | 7.0 | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | Rear | Rear | ||||
| Gearbox | 8 gear automatic | 8 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 235 | 231 | ||||
| Acceleration 0–100 km/h [s] | 6,4 | 6.5 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 5,4-5,7 | 5.7-5.6 | ||||
| Out of town [l] | 4,1-4,4 | 4.5-4.4 | ||||
| Combined [l] | 4,6-4,9 | 5.0-4.8 | ||||
| CO2 emissions [g/km] | 121-128 | 130-128 | ||||
| Emission standard | EU6 | EU6c | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1650 | 1710 | ||||
| Overall weight [kg] | 2015 | 2060 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | ||||
| Maximum front/rear axle load [kg] | 920/1145 | 925/ 1160 | ||||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | ||||
| Maximum load on roof/carrier [kg] | - | -/- | ||||
| Boot volume [l] | 280-335 | 280-335 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 2 | 2 | ||||
| Number of seats | 4 | 4 | ||||
| Fuel tank volume [l] | 52 | 52 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.31 | 0.32 | ||||
| Front suspension | MacPherson | MacPherson | ||||
| Rear suspension | five-link | five-link | ||||
| Tyre dimensions front | 205/55 R16 91W | 205/55 R17 89Y | ||||
| Tyre dimensions rear | 205/55 R16 91W | 205/55 R17 89Y | ||||
| Wheel size front | 7J x 16 | 7J x 17 | ||||
| Wheel size rear | 7J x 16 | 7J x 17 | ||||
| Brake dimensions front | - | - | ||||
| Brake dimensions rear | - | - | ||||
| Steering | Electric power steering EPS | Electro-mechanical power steering EPS | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | ||||
| Overall length [mm] | 4432 | 4432 | ||||
| Overall width without/including mirrors [mm] | 1774 /- | 1774/- | ||||
| Overall height [mm] | 1413 | 1413 | ||||
| Wheelbase [mm] | 2690 | 2690 | ||||
| Front wheel track [mm] | 1521 | 1521 | ||||
| Rear wheel track [mm] | 1556 | 1556 | ||||
| Forward overhang [mm] | 780 | 780 | ||||
| Rear overhang [mm] | 962 | 962 | ||||
| Clearance [mm] | 140 | 140 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1028 | 1028 | ||||
| Headroom rear [mm] | 940 | 940 | ||||
| Front elbow/shoulder width [mm] | 1383/- | 1383/- | ||||
| Rear elbow/shoulder width [mm] | 1104/- | 1104/- | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
