	420i	430i	M4 G82	M4 G82 Competition	M440i xDrive	420d
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Petrol supercharged + Electric	Diesel supercharged + Electric
Number of cylinders/valves	4/16	4/16	6/24	6/24	6/24	4/16
Engine displacement [cm³]	1998	1998	2993	2993	2998	1995
Maximum output / speed [kW/min-1]	135/5000-6500	190/5000-6500	353/6250	375/6250	275/5500-6500 8 el.	140/4000 8 el.
Maximum torque [Nm/min-1]	300/1350-4000	400/1550-4400	550/2650-6130	650/2750-5500	500/1900-5000	400/1750-2500
Bore and stroke [mm x mm]	82.0 x 94.6	82.0 x 94.6	84.0 x 90.0	84.0 x 90.0	82.0 x 94.6	84.0 x 90.0
Compression ratio	11.0:1	10.2:1	9.3:1	9.3:1	10.2:1	16.5:1
Oil volume [l]	5.25	5.25	7.0	7.0	6.5	5.5
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection supercharging by twin turbochargers variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection supercharging by twin turbochargers variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	Mild Hybrid direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	Mild Hybrid direct injection Common Rail supercharging by a pair of differently sized turbochargers with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	Rear	Rear	4x4	4x4	4x4	Rear
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	eight-speed automatic gearbox Steptronic	eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	eight-speed automatic gearbox Steptronic

Top speed [km/h]	240	250	250 [290 subject to a surcharge]	250 [290 subject to a surcharge]	250	240
Acceleration 0–100 km/h [s]	7.5	5.8	4.2	3.9	4.5	7.1
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	5.6	3.4	-	-

City [l]	7.2-6.6	7.7-7.3	16,0	14.6	9.0-8.6	4.9-4.5
Out of town [l]	5.0-4.6	5.3-4.8	7.8	7.6	6.0-5.7	3.9-3.6
Combined [l]	5.8-5.3	6.1-5.7	10.8	10.2	7.1-6.8	4.2-3.9
CO2 emissions [g/km]	132-122	141-131	248	234	161-155	112-103

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	-	-	-	-	48	48
Battery type and capacity	-	-	-	-	Lithium-Ionen-Akkumulator, 11 A⋅h	Lithium-Ionen-Akkumulator, 11 A⋅h
Range with fully charged battery [km]	-	-	-	-	-	-
Charging time	-	-	-	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1600	1620	1775	1800	1815	1680
Overall weight [kg]	2015	2030	2155	2155	2245	2095
Maximum trailer weight unbraked/braked [kg]	750/1600	750/1600	-	-	750/1800	750/1600
Maximum front/rear axle load [kg]	970/1120	980/1120	1075/1135	1075/1135	1110/1190	1020/1160
Maximum vertical load on the tow bar [kg]	75	75	-	-	75	75
Maximum load on roof/carrier [kg]	75/-	75/-	75 /-	75 /-	75/-	75/-

Boot volume [l]	440	440	440	440	440	440
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	2	2	2	2	2	2
Number of seats	4	4	4	4	4	4
Fuel tank volume [l]	59	59	59	59	59	59
AdBlue tank volume [l]	-	-	-	-	-	18,9
Air resistance [Cd]	0.25	0.25	0.34	0.34	0.29	0.25
Front suspension	MacPherson, lower cross arms	MacPherson, lower cross arms	MacPherson, two separate lower arms	MacPherson, two separate lower arms	MacPherson, lower cross arms	MacPherson, lower cross arms
Rear suspension	five-link	five-link	five-link	five-link	five-link	five-link
Tyre dimensions front	225/50 R17 98Y XL	225/50 R17 98Y XL	275/40 ZR18 103Y XL	275/40 ZR18 103Y XL	225/45 R18 95Y XL	225/50 R17 98Y XL
Tyre dimensions rear	225/50 R17 98Y XL	225/50 R17 98Y XL	285/35 ZR19 103Y XL	285/35 ZR19 103Y XL	255/40 R18 99Y XL	225/50 R17 98Y XL
Wheel size front	7.5J x17	7.5J x 17	9.5J x 18	9.5J x 18	7.5J x 18	7.5J x 17
Wheel size rear	7.5J x17	7.5J x 17	10.5J x 19	10.5J x 19	7.5J x 18	7.5J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.4/-	11.4/-	12.2/-	12.2/-	12.0/-	11.4/-

Overall length [mm]	4768	4768	4794	4794	4770	4768
Overall width without/including mirrors [mm]	1852/2081	1852/2081	1887/2081	1887/2081	1852/2081	1852/2081
Overall height [mm]	1383	1383	1393	1393	1393	1383
Wheelbase [mm]	2851	2851	2857	2857	2851	2851
Front wheel track [mm]	1575	1575	1617	1617	1575	1575
Rear wheel track [mm]	1611	1611	1605	1605	1611	1611
Forward overhang [mm]	858	858	860	860	858	858
Rear overhang [mm]	1059	1059	1077	1077	1059	1059
Clearance [mm]	127	127	120	120	129	127
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1023	1023	1023	1023	1023	1023
Headroom rear [mm]	909	909	909	909	909	909
Front elbow/shoulder width [mm]	1465/-	1465/-	1465/-	1465/-	1465/-	1465/-
Rear elbow/shoulder width [mm]	1375/-	1375/-	1375/-	1375/-	1375/-	1375/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	420d xDrive
Date of sale	-
Engine type	Diesel supercharged + Electric
Number of cylinders/valves	4/16
Engine displacement [cm³]	1995
Maximum output / speed [kW/min-1]	140/4000 8 el.
Maximum torque [Nm/min-1]	400/1750-2500
Bore and stroke [mm x mm]	84.0 x 90.0
Compression ratio	16.5:1
Oil volume [l]	5.5
Coolant volume [l]	-
Technical specifications	Mild Hybrid direct injection Common Rail supercharging by a pair of differently sized turbochargers with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	4x4
Gearbox	8 gear automatic
Drive specifications	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic

Top speed [km/h]	238
Acceleration 0–100 km/h [s]	7.4
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	5.2-4.8
Out of town [l]	4.2-4.0
Combined [l]	4.6-4.3
CO2 emissions [g/km]	121-112

Emission standard	Euro 6d
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	48
Battery type and capacity	Lithium-Ionen-Akkumulator, 11 A⋅h
Range with fully charged battery [km]	-
Charging time	-
Number of modules/cells	-
Battery weight [kg]	-
Charger	-

Standby weight [kg]	1745
Overall weight [kg]	2165
Maximum trailer weight unbraked/braked [kg]	750/1800
Maximum front/rear axle load [kg]	1070/1170
Maximum vertical load on the tow bar [kg]	75
Maximum load on roof/carrier [kg]	75/-

Boot volume [l]	440
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	2
Number of seats	4
Fuel tank volume [l]	59
AdBlue tank volume [l]	18,9
Air resistance [Cd]	0.25
Front suspension	MacPherson, lower cross arms
Rear suspension	five-link
Tyre dimensions front	225/50 R17 98Y XL
Tyre dimensions rear	225/50 R17 98Y XL
Wheel size front	7.5Jx 17
Wheel size rear	7.5Jx 17
Brake dimensions front	-
Brake dimensions rear	-
Steering	Electric power steering Servotronic
Number of steering wheel turns	-
Turning diameter track/circumference [m]	12.0/-

Overall length [mm]	4768
Overall width without/including mirrors [mm]	1852/2081
Overall height [mm]	1390
Wheelbase [mm]	2851
Front wheel track [mm]	1575
Rear wheel track [mm]	1611
Forward overhang [mm]	858
Rear overhang [mm]	1059
Clearance [mm]	126
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	1023
Headroom rear [mm]	909
Front elbow/shoulder width [mm]	1465/-
Rear elbow/shoulder width [mm]	1375/-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Convertible

	420i	430i	M440i xDrive	420d
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Petrol supercharged + Electric	Diesel supercharged + Electric
Number of cylinders/valves	4/16	4/16	6/24	4/16
Engine displacement [cm³]	1998	1998	2998	1995
Maximum output / speed [kW/min-1]	135/5000-6500	190/5000-6500	275/5500-6500 8 el.	140/4000 8 el.
Maximum torque [Nm/min-1]	300/1350-4000	400/1550-4400	500/1900-5000	400/1750-2500
Bore and stroke [mm x mm]	82.0 x 94.6	82.0 x 94.6	82.0 x 94.6	84.0 x 90.0
Compression ratio	11.0:1	10.2:1	10.2:1	16.5:1
Oil volume [l]	5.25	5.25	7.2	5.5
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	Mild Hybrid direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS variable valve lift VALVETRONIC Gasoline Particulate Filter start&stop system brake energy recuperation	Mild Hybrid direct injection Common Rail supercharging by a pair of differently sized turbochargers with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	Rear	Rear	4x4	Rear
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	eight-speed automatic gearbox Steptronic	eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	eight-speed automatic gearbox Steptronic

Top speed [km/h]	236	250	250	236
Acceleration 0–100 km/h [s]	8.2	6.2	4.9	7.6
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	7.4-7.1	7.8-7.5	9.3-8.9	5.0-4.7
Out of town [l]	5.4-4.9	5.6-5.2	6.2-5.8	4.3-3.9
Combined [l]	6.1-5.7	6.4-6.0	7.4-6.9	4.5-4.2
CO2 emissions [g/km]	140-131	147-138	169-159	119-111

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

System voltage [V]	-	-	48	48
Battery type and capacity	-	-	Lithium-Ionen-Akkumulator, 11 A⋅h	Lithium-Ionen-Akkumulator, 11 A⋅h
Range with fully charged battery [km]	-	-	-	-
Charging time	-	-	-	-
Number of modules/cells	-	-	-	-
Battery weight [kg]	-	-	-	-
Charger	-	-	-	-

Standby weight [kg]	1765	1790	1965	1850
Overall weight [kg]	2185	2200	2390	2270
Maximum trailer weight unbraked/braked [kg]	750/1600	750/1600	750/1800	750/1600
Maximum front/rear axle load [kg]	990/1240	1000/1240	1120/1300	1025/1280
Maximum vertical load on the tow bar [kg]	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	385	385	385	385
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	2	2	2	2
Number of seats	4	4	4	4
Fuel tank volume [l]	59	59	59	59
AdBlue tank volume [l]	-	-	-	18,9
Air resistance [Cd]	0.28	0.28	0.28	0.27
Front suspension	MacPherson, lower cross arms	MacPherson, lower cross arms	MacPherson, lower cross arms	MacPherson, lower cross arms
Rear suspension	five-link	five-link	five-link	five-link
Tyre dimensions front	225/50 R17 98Y XL	225/50 R17 98Y XL	225/45 R18 95Y XL	225/50 R17 98Y XL
Tyre dimensions rear	225/50 R17 98Y XL	225/50 R17 98Y XL	255/40 R18 99Y XL	225/50 R17 98Y XL
Wheel size front	7.5J x 17	7.5J x 17	7.5J x 18	7.5J x 17
Wheel size rear	7.5J x 17	7.5J x 17	8.5J x 18	7.5J x 17
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic	Electric power steering Servotronic
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	11.4/-	11.4/-	12.0/-	11.4/-

Overall length [mm]	4768	4768	4770	4768
Overall width without/including mirrors [mm]	1852/2081	1852/2081	1852/2081	1852/2081
Overall height [mm]	1384	1384	1394	1384
Wheelbase [mm]	2851	2851	2851	2851
Front wheel track [mm]	1575	1575	1575	1575
Rear wheel track [mm]	1611	1611	1611	1611
Forward overhang [mm]	858	858	858	858
Rear overhang [mm]	1059	1059	1059	1059
Clearance [mm]	124	124	126	124
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	1030	1030	1030	1030
Headroom rear [mm]	918	918	918	918
Front elbow/shoulder width [mm]	1465/-	1465/-	1465/-	1465/-
Rear elbow/shoulder width [mm]	1173/-	1173/-	1173/-	1173/-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.

BMW 4

Date of manufacture

Platform

Manufacturing locations

Designer

Tags

Car body style

Coupé

Convertible

Liftback (Gran Coupe)

Technical data

Coupé

Convertible

Gallery
