BMW 5
Date of manufacture
2007 – 2010 (Sedan)
2007 – 2010 (Estate)
Platform
-
Manufacturing locations
Dingolfing, Germany
Designer
Davide Arcangeli
Tags
E-segment
German cars
The BMW 5 is available as a sedan and estate. The car has been produced since 2007. The country of manufacture of the car is Germany. The power unit range includes petrol and diesel engines. The most powerful model is the M5 with 373 kW. The highest speed of 250 km/h is achieved by the M5 version. The lowest combined consumption of 5.1 l/100 km is achieved by the 520d version. CO2 emissions are 136 g/km. The sedan body has a trunk volume of 520 l. The estate body has a trunk volume of 500 l.
Car body style
Sedan
after upgrade (facelift)
Date of manufacture
2007 – 2010Internal designation
E60 Estate
after upgrade (facelift)
Date of manufacture
2007 – 2010Internal designation
E61 Technical data
Sedan
| 520i | 520i | 523i | 523i | 525i | 525i | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 1995 | 1995 | 2497 | 2497 | 2996 | 2996 |
| Maximum output / speed [kW/min-1] | 125/6700 | 125/6700 | 140/6100 | 140/6100 | 160/6100 | 160/6100 |
| Maximum torque [Nm/min-1] | 210/4250 | 210/4250 | 240/3500 | 240/3500 | 270/2400 | 270/2400 |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 82,0 x 78,8 | 82,0 x 78,8 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications | - |
| - |
| - |
|
| Top speed [km/h] | 224 | 224 | 237 | 236 | 248 | 246 |
| Acceleration 0–100 km/h [s] | 8.7 | 9.6 | 8.2 | 8.7 | 7.1 | 7.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.2 | 9.4 | 10.1 | 10.3 | 10.3 | 10.4 |
| Out of town [l] | 5.4 | 5.4 | 5.7 | 5.9 | 5.7 | 5.8 |
| Combined [l] | 6.7 | 6.9 | 7.3 | 7.5 | 7.4 | 7.5 |
| CO2 emissions [g/km] | 162 | 164 | 174 | 178 | 176 | 178 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1535 | 1565 | 1575 | 1600 | 1585 | 1605 |
| Overall weight [kg] | 2000 | 2030 | 2060 | 2085 | 2070 | 2090 |
| Maximum trailer weight unbraked/braked [kg] | 750/1600 | 750/1800 | 750/1600 | 750/1800 | 750/1800 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 520 | 520 | 520 | 520 | 520 | 520 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.27 | 0.26 | 0.27 | 0.26 | 0.27 | 0.26 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95W | 225/55 R16 95W |
| Tyre dimensions rear | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95W | 225/55 R16 95W |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | 310 x 24 | 310 x 24 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 |
| Overall length [mm] | 4841 | 4841 | 4841 | 4841 | 4841 | 4841 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1468 | 1468 | 1468 | 1468 | 1468 | 1468 |
| Wheelbase [mm] | 2888 | 2888 | 2888 | 2888 | 2888 | 2888 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1101 | 1101 | 1101 | 1101 | 1101 | 1101 |
| Clearance [mm] | 142 | 142 | 142 | 142 | 142 | 142 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 967 | 967 | 967 | 967 | 967 | 967 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 525i xDrive | 525i xDrive | 530i | 530i | 530i xDrive | 530i xDrive | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2996 | 2996 | 2996 | 2996 | 2996 | 2996 |
| Maximum output / speed [kW/min-1] | 160/6100 | 160/6100 | 200/6700 | 200/6700 | 200/6700 | 200/6700 |
| Maximum torque [Nm/min-1] | 270/2400 | 270/2400 | 320/2750 | 320/2750 | 320/2750 | 320/2750 |
| Bore and stroke [mm x mm] | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications |
|
| - |
|
|
|
| Top speed [km/h] | 240 | 234 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 7.9 | 8.2 | 6.3 | 6.5 | 6.6 | 6.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 11.3 | 11.2 | 10.9 | 10.8 | 11.5 | 11.6 |
| Out of town [l] | 6.2 | 6.3 | 5.8 | 5.6 | 6.2 | 6.0 |
| Combined [l] | 8.1 | 8.1 | 7.7 | 7.5 | 8.2 | 8.1 |
| CO2 emissions [g/km] | 193 | 193 | 182 | 178 | 194 | 193 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1700 | 1720 | 1605 | 1615 | 1710 | 1730 |
| Overall weight [kg] | 2185 | 2205 | 2090 | 2100 | 2195 | 2215 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 520 | 520 | 520 | 520 | 520 | 520 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.28 | 0.27 | 0.26 | 0.29 | 0.28 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 94W | 225/50 R 17 94W |
| Tyre dimensions rear | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 94W | 225/50 R 17 94W |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Brake dimensions front | 324 x 30 | 324 x 30 | 348 x 30 | 348 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 320 x 20 | 345 x 24 | 345 x 24 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.9 | 11.9 | 11.4 | 11.4 | 11.9 | 11.9 |
| Overall length [mm] | 4841 | 4841 | 4841 | 4841 | 4841 | 4841 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1482 | 1482 | 1468 | 1468 | 1482 | 1482 |
| Wheelbase [mm] | 2888 | 2888 | 2888 | 2888 | 2888 | 2888 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1101 | 1101 | 1101 | 1101 | 1101 | 1101 |
| Clearance [mm] | 142 | 142 | 142 | 142 | 142 | 142 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 967 | 967 | 967 | 967 | 967 | 967 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 540i | 540i | 550i | 550i | M5 | 520d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Diesel supercharged |
| Number of cylinders/valves | 8/32 | 8/32 | 8/32 | 8/32 | 10/40 | 4/16 |
| Engine displacement [cm³] | 4000 | 4000 | 4799 | 4799 | 4999 | 1995 |
| Maximum output / speed [kW/min-1] | 225/6300 | 225/6300 | 270/6300 | 270/6300 | 373/7750 | 130/4000 |
| Maximum torque [Nm/min-1] | 390/3500 | 390/3500 | 490/3400 | 490/3400 | 520/6100 | 350/2000 |
| Bore and stroke [mm x mm] | 87,0 x 84,1 | 87,0 x 84,1 | 93,0 x 88,3 | 93,0 x 88,3 | 75,2 x 92,0 | 84,0 x 90,0 |
| Compression ratio | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 12,0:1 | 17,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 7 gear automatic | 6 gear manual |
| Drive specifications | - |
| - |
|
| - |
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 231 |
| Acceleration 0–100 km/h [s] | 6.1 | 6.2 | 5.2 | 5.3 | 4.7 | 8.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 15.8 | 14.4 | 16.6 | 15.5 | 22.7 | 6.5 |
| Out of town [l] | 7.4 | 6.9 | 7.6 | 7.2 | 10.2 | 4.3 |
| Combined [l] | 10.5 | 9.7 | 10.9 | 10.3 | 14.8 | 5.1 |
| CO2 emissions [g/km] | 250 | 232 | 260 | 246 | 357 | 136 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1725 | 1735 | 1735 | 1735 | 1855 | 1585 |
| Overall weight [kg] | 2210 | 2220 | 2220 | 2220 | 2300 | 2050 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/1900 | 750/1800 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 520 | 520 | 520 | 520 | 500 | 520 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.28 | 0.27 | 0.28 | 0.27 | 0.31 | 0.28 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 255/40 R 19 | 225/55 R16 95W |
| Tyre dimensions rear | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 285/35 R 19 | 225/55 R16 95W |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 8J x 17 | 8J x 17 | 8.5J x 19 | 7J x 16 |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 8J x 17 | 8J x 17 | 9.5J x 19 | 7J x 16 |
| Brake dimensions front | 348 x 30 | 348 x 30 | 348 x 30 | 348 x 30 | 374 x 36 | 324 x 30 |
| Brake dimensions rear | 345 x 24 | 345 x 24 | 345 x 24 | 345 x 24 | 370 x 24 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.4 | 11.4 | 11.4 | 12.4 | 11.4 |
| Overall length [mm] | 4841 | 4841 | 4841 | 4841 | 4855 | 4841 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1468 | 1468 | 1468 | 1468 | 1469 | 1468 |
| Wheelbase [mm] | 2888 | 2888 | 2888 | 2888 | 2889 | 2888 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1580 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1566 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | - | 852 |
| Rear overhang [mm] | 1101 | 1101 | 1101 | 1101 | - | 1101 |
| Clearance [mm] | 142 | 142 | 142 | 142 | - | 142 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 967 | 967 | 967 | 967 | 967 | 967 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 520d | 525d | 525d | 525d xDrive | 525d xDrive | 530d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 1995 | 2993 | 2993 | 2993 | 2993 | 2993 |
| Maximum output / speed [kW/min-1] | 130/4000 | 145/4000 | 145/4000 | 145/4000 | 145/4000 | 173/4000 |
| Maximum torque [Nm/min-1] | 350/2000 | 400/1300 | 400/1300 | 400/1300 | 400/1300 | 500/1750 |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | 4x4 | 4x4 | Rear |
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications |
| - |
|
|
| - |
| Top speed [km/h] | 229 | 237 | 235 | 232 | 230 | 250 |
| Acceleration 0–100 km/h [s] | 8.4 | 7.6 | 7.7 | 7.8 | 7.9 | 6.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.5 | 8.2 | 8.5 | 8.8 | 9.1 | 8.6 |
| Out of town [l] | 4.6 | 5.0 | 5.3 | 5.4 | 5.6 | 5.1 |
| Combined [l] | 5.6 | 6.2 | 6.5 | 6.7 | 6.9 | 6.4 |
| CO2 emissions [g/km] | 149 | 165 | 172 | 179 | 183 | 170 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1595 | 1655 | 1670 | 1745 | 1755 | 1655 |
| Overall weight [kg] | 2060 | 2230 | 2240 | 2240 | 2245 | 2140 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 520 | 520 | 520 | 520 | 520 | 520 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.27 | 0.27 | 0.26 | 0.29 | 0.28 | 0.28 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/55 R16 95W | 225/55 R16 95W | 225/55 R16 95W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W |
| Tyre dimensions rear | 225/55 R16 95W | 225/55 R16 95W | 225/55 R16 95W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W |
| Wheel size front | 7J x16 | 7J x 16 | 7J x 16 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Wheel size rear | 7J x16 | 7J x 16 | 7J x 16 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Brake dimensions front | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 324 x 30 | 320 x 20 | 320 x20 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.4 | 11.4 | 11.9 | 11.9 | 11.4 |
| Overall length [mm] | 4841 | 4841 | 4841 | 4841 | 4841 | 4841 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1468 | 1468 | 1468 | 1482 | 1482 | 1468 |
| Wheelbase [mm] | 2888 | 2888 | 2888 | 2888 | 2888 | 2888 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1101 | 1101 | 1101 | 1101 | 1101 | 1101 |
| Clearance [mm] | 142 | 142 | 142 | 142 | 142 | 142 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 967 | 967 | 967 | 967 | 967 | 967 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 530d | 530d xDrive | 530d xDrive | 535d | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | ||
| Engine displacement [cm³] | 2993 | 2993 | 2993 | 2993 | ||
| Maximum output / speed [kW/min-1] | 173/4000 | 173/4000 | 173/4000 | 210/4400 | ||
| Maximum torque [Nm/min-1] | 500/1750 | 500/1750 | 500/1750 | 580/1750 | ||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | ||
| Compression ratio | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Rear | 4x4 | 4x4 | Rear | ||
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 248 | 242 | 240 | 250 | ||
| Acceleration 0–100 km/h [s] | 6.8 | 6.6 | 6.8 | 6.4 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 9.1 | 9.2 | 9.6 | 9.0 | ||
| Out of town [l] | 5.2 | 5.5 | 5.5 | 5.4 | ||
| Combined [l] | 6.6 | 6.9 | 7.0 | 6.7 | ||
| CO2 emissions [g/km] | 176 | 183 | 186 | 178 | ||
| Emission standard | EU4 | EU4 | EU4 | EU4 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1675 | 1760 | 1780 | 1735 | ||
| Overall weight [kg] | 2160 | 2245 | 2265 | 2220 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2000 | 750/2000 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | ||
| Boot volume [l] | 520 | 520 | 520 | 520 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 4 | 4 | 4 | 4 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.27 | 0.29 | 0.29 | 0.27 | ||
| Front suspension | - | - | - | - | ||
| Rear suspension | - | - | - | - | ||
| Tyre dimensions front | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 W | ||
| Tyre dimensions rear | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 W | ||
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5 J x 17 | ||
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5 J x 17 | ||
| Brake dimensions front | 324 x 30 | 324 x 30 | 324 x 30 | 348 x 36 | ||
| Brake dimensions rear | 320 x 20 | 320 x 20 | 320 x 20 | 345 x 24 | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 11.4 | 11.9 | 11.9 | 11.4 | ||
| Overall length [mm] | 4841 | 4841 | 4841 | 4841 | ||
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | ||
| Overall height [mm] | 1468 | 1482 | 1482 | 1468 | ||
| Wheelbase [mm] | 2888 | 2888 | 2888 | 2888 | ||
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | ||
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | ||
| Forward overhang [mm] | 852 | 852 | 852 | 852 | ||
| Rear overhang [mm] | 1101 | 1101 | 1101 | 1101 | ||
| Clearance [mm] | 142 | 142 | 142 | 142 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 993 | 993 | 993 | 993 | ||
| Headroom rear [mm] | 967 | 967 | 967 | 967 | ||
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | ||
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
Estate
| 520i | 520i | 523i | 523i | 525i | 525i | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 1995 | 1995 | 2497 | 2497 | 2996 | 2996 |
| Maximum output / speed [kW/min-1] | 125/6700 | 125/6700 | 140/6100 | 140/6100 | 160/6100 | 160/6100 |
| Maximum torque [Nm/min-1] | 210/4250 | 210/4250 | 240/3500 | 240/3500 | 270/2400 | 270/2400 |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 82,0 x 78,8 | 82,0 x 78,8 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications | - |
| - |
| - |
|
| Top speed [km/h] | 220 | 220 | 230 | 229 | 243 | 241 |
| Acceleration 0–100 km/h [s] | 9.0 | 10.0 | 8.5 | 9.1 | 7.4 | 7.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.4 | 9.5 | 10.6 | 10.6 | 10.8 | 10.7 |
| Out of town [l] | 5.6 | 5.5 | 6.0 | 6.0 | 5.9 | 6.0 |
| Combined [l] | 6.9 | 7.0 | 7.7 | 7.7 | 7.7 | 7.7 |
| CO2 emissions [g/km] | 166 | 167 | 183 | 184 | 183 | 184 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1635 | 1665 | 1665 | 1695 | 1680 | 1705 |
| Overall weight [kg] | 2160 | 2190 | 2190 | 2220 | 2205 | 2230 |
| Maximum trailer weight unbraked/braked [kg] | 750/1600 | 750/1800 | 750/1600 | 750/1800 | 750/1800 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 500 | 500 | 500 | 500 | 500 | 500 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.28 | 0.29 | 0.28 | 0.29 | 0.28 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95W | 225/55 R16 95W |
| Tyre dimensions rear | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95V | 225/55 R16 95W | 225/55 R16 95W |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | 310 x 24 | 310 x 24 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 |
| Overall length [mm] | 4843 | 4843 | 4843 | 4843 | 4843 | 4843 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1491 | 1491 | 1491 | 1491 | 1491 | 1491 |
| Wheelbase [mm] | 2886 | 2886 | 2886 | 2886 | 2886 | 2886 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1105 | 1105 | 1105 | 1105 | 1105 | 1105 |
| Clearance [mm] | 143 | 143 | 143 | 143 | 143 | 143 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 992 | 992 | 992 | 992 | 992 | 992 |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | 994 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 525i xDrive | 525i xDrive | 530i | 530i | 530i xDrive | 530i xDrive | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2996 | 2996 | 2996 | 2996 | 2996 | 2996 |
| Maximum output / speed [kW/min-1] | 160/6100 | 160/6100 | 200/6700 | 200/6700 | 200/6700 | 200/6700 |
| Maximum torque [Nm/min-1] | 270/2400 | 270/2400 | 320/2750 | 320/2750 | 320/2750 | 320/2750 |
| Bore and stroke [mm x mm] | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 |
| Compression ratio | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 | 12,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications |
|
| - |
|
|
|
| Top speed [km/h] | 233 | 230 | 250 | 250 | 246 | 244 |
| Acceleration 0–100 km/h [s] | 8.2 | 8.5 | 6.5 | 6.8 | 6.9 | 7.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 11.8 | 11.7 | 11.1 | 11.0 | 12.0 | 12.1 |
| Out of town [l] | 6.4 | 6.5 | 6.0 | 5.8 | 6.4 | 6.3 |
| Combined [l] | 8.4 | 8.4 | 7.9 | 7.7 | 8.5 | 8.4 |
| CO2 emissions [g/km] | 201 | 201 | 187 | 184 | 203 | 201 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1795 | 1815 | 1695 | 1705 | 1800 | 1810 |
| Overall weight [kg] | 2320 | 2340 | 2220 | 2230 | 2325 | 2335 |
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 500 | 500 | 500 | 500 | 500 | 500 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.29 | 0.28 | 0.31 | 0.31 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/50 R17 94Y | 225/50 R17 94Y | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 94Y | 225/50 R 17 94Y |
| Tyre dimensions rear | 225/50 R17 94Y | 225/50 R17 94Y | 225/50 R17 94W | 225/50 R17 94W | 225/50 R 17 94Y | 225/50 R 17 94Y |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Brake dimensions front | 324 x 30 | 324 x 30 | 348 x 30 | 348 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 320 x 20 | 345 x 24 | 345 x 24 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.9 | 11.9 | 11.4 | 11.4 | 11.9 | 11.9 |
| Overall length [mm] | 4843 | 4843 | 4843 | 4843 | 4843 | 4843 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1491 | 1491 | 1491 | 1491 | 1491 | 1491 |
| Wheelbase [mm] | 2886 | 2886 | 2886 | 2886 | 2886 | 2886 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1105 | 1105 | 1105 | 1105 | 1105 | 1105 |
| Clearance [mm] | 143 | 143 | 143 | 143 | 143 | 143 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 992 | 992 | 992 | 992 | 992 | 992 |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | 994 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 550i | 550i | M5 | 520d | 520d | 525d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 8/32 | 8/32 | 10/40 | 4/16 | 4/16 | 6/24 |
| Engine displacement [cm³] | 4799 | 4799 | 4999 | 1995 | 1995 | 2993 |
| Maximum output / speed [kW/min-1] | 270/6300 | 270/6300 | 373/7750 | 130/4000 | 130/4000 | 145/4000 |
| Maximum torque [Nm/min-1] | 490/3400 | 490/3400 | 520/6100 | 350/2000 | 350/2000 | 400/1300 |
| Bore and stroke [mm x mm] | 93,0 x 88,3 | 93,0 x 88,3 | 75,2 x 92,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 10,5:1 | 10,5:1 | 12,0:1 | 17,0:1 | 17,0:1 | 17,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear automatic | 7 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications | - |
|
| - |
| - |
| Top speed [km/h] | 250 | 250 | 250 | 224 | 224 | 232 |
| Acceleration 0–100 km/h [s] | 5.3 | 5.4 | 4.8 | 8.5 | 8.6 | 7.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 17.0 | 16.1 | 21.7 | 6.7 | 7.7 | 8.4 |
| Out of town [l] | 7.8 | 7.5 | 10.5 | 4.5 | 4.7 | 5.2 |
| Combined [l] | 11.2 | 10.7 | 14.6 | 5.3 | 5.8 | 6.4 |
| CO2 emissions [g/km] | 267 | 254 | 348 | 140 | 154 | 171 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1835 | 1835 | 1955 | 1675 | 1695 | 1735 |
| Overall weight [kg] | 2320 | 2320 | 2415 | 2200 | 2220 | 2260 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/1800 | 750/1800 | 750/1800 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 500 | 500 | 500 | 500 | 500 | 500 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.29 | 0.32 | 0.3 | 0.29 | 0.29 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/50 R17 94Y | 225/50 R17 94Y | 255/40 ZR19 | 225/55 R16 95W | 225/55 R16 95W | 225/55 R16 95Y |
| Tyre dimensions rear | 225/50 R17 94Y | 225/50 R17 94Y | 285/35 ZR19 | 225/55 R16 95W | 225/55 R16 95W | 225/55 R16 95Y |
| Wheel size front | 8J x 17 | 8J x 17 | 8.5J x 19 | 7J x 16 | 7J x16 | 7J x 16 |
| Wheel size rear | 8J x 17 | 8J x 17 | 9.5J x 19 | 7J x 16 | 7J x16 | 7J x 16 |
| Brake dimensions front | 348 x 30 | 348 x 30 | 374 x 36 | 324 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 345 x 24 | 345 x 24 | 370 x 24 | 320 x 20 | 320 x 20 | 320 x 30 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.4 | 12.4 | 11.4 | 11.4 | 11.4 |
| Overall length [mm] | 4843 | 4843 | 4855 | 4843 | 4843 | 4843 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1491 | 1491 | 1512 | 1491 | 1491 | 1491 |
| Wheelbase [mm] | 2886 | 2886 | 2880 | 2886 | 2886 | 2886 |
| Front wheel track [mm] | 1558 | 1558 | 1590 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1588 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | - | 852 | 852 | 852 |
| Rear overhang [mm] | 1105 | 1105 | - | 1105 | 1105 | 1105 |
| Clearance [mm] | 143 | 143 | - | 143 | 143 | 143 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 992 | 992 | 992 | 992 | 992 | 992 |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | 994 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 525d | 525d xDrive | 525d xDrive | 530d | 530d | 530d xDrive | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2993 | 2993 | 2993 | 2993 | 2993 | 2993 |
| Maximum output / speed [kW/min-1] | 145/4000 | 145/4000 | 145/4000 | 173/4000 | 173/4000 | 173/4000 |
| Maximum torque [Nm/min-1] | 400/1300 | 400/1300 | 400/1300 | 500/1750 | 500/1750 | 500/1750 |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 | 17,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | 4x4 | 4x4 | Rear | Rear | 4x4 |
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications |
|
|
| - |
|
|
| Top speed [km/h] | 232 | 228 | 228 | 245 | 243 | 235 |
| Acceleration 0–100 km/h [s] | 7.9 | 8.1 | 8.3 | 6.9 | 7.0 | 6.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8.6 | 9.1 | 9.2 | 8.8 | 9.3 | 9.6 |
| Out of town [l] | 5.4 | 5.6 | 5.7 | 5.3 | 5.3 | 5.8 |
| Combined [l] | 6.6 | 6.9 | 7.0 | 6.6 | 6.8 | 7.2 |
| CO2 emissions [g/km] | 176 | 184 | 187 | 176 | 180 | 192 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1765 | 1845 | 1855 | 1735 | 1775 | 1845 |
| Overall weight [kg] | 2290 | 2350 | 2360 | 2260 | 2300 | 2350 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 500 | 500 | 500 | 500 | 500 | 500 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 | -/1650 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 70 | 70 | 70 | 70 | 70 | 70 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.31 | 0.31 | 0.29 | 0.29 | 0.31 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 225/55 R16 95Y | 225/50 R17 94Y | 225/50 R17 94Y | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94Y |
| Tyre dimensions rear | 225/55 R16 95Y | 225/50 R17 94Y | 225/50 R17 94Y | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94Y |
| Wheel size front | 7J x 16 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Wheel size rear | 7J x 16 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 |
| Brake dimensions front | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 | 324 x 30 |
| Brake dimensions rear | 320 x 20 | 320 x20 | 320 x 20 | 320 x 20 | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.4 | 11.9 | 11.9 | 11.4 | 11.4 | 11.9 |
| Overall length [mm] | 4843 | 4843 | 4843 | 4843 | 4843 | 4843 |
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- | 1846/- |
| Overall height [mm] | 1491 | 1491 | 1491 | 1491 | 1491 | 1491 |
| Wheelbase [mm] | 2886 | 2886 | 2886 | 2886 | 2886 | 2886 |
| Front wheel track [mm] | 1558 | 1558 | 1558 | 1558 | 1558 | 1558 |
| Rear wheel track [mm] | 1581 | 1581 | 1581 | 1581 | 1581 | 1581 |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | 852 |
| Rear overhang [mm] | 1105 | 1105 | 1105 | 1105 | 1105 | 1105 |
| Clearance [mm] | 143 | 143 | 143 | 143 | 143 | 143 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 992 | 992 | 992 | 992 | 992 | 992 |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | 994 |
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- | 1484/- |
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- | 1496/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 530d xDrive | 535d | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 6/24 | 6/24 | ||||
| Engine displacement [cm³] | 2993 | 2993 | ||||
| Maximum output / speed [kW/min-1] | 173/4000 | 210/4400 | ||||
| Maximum torque [Nm/min-1] | 500/1750 | 580/1750 | ||||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | ||||
| Compression ratio | 17,0:1 | 17,0:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | Rear | ||||
| Gearbox | 6 gear automatic | 6 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 233 | 250 | ||||
| Acceleration 0–100 km/h [s] | 7.0 | 6.5 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 9.9 | 9.2 | ||||
| Out of town [l] | 5.6 | 5.6 | ||||
| Combined [l] | 7.2 | 6.9 | ||||
| CO2 emissions [g/km] | 192 | 182 | ||||
| Emission standard | EU4 | EU4 | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1855 | 1835 | ||||
| Overall weight [kg] | 2360 | 2320 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | - | - | ||||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | ||||
| Boot volume [l] | 500 | 500 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1650 | -/1650 | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 70 | 70 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.31 | 0.29 | ||||
| Front suspension | - | - | ||||
| Rear suspension | - | - | ||||
| Tyre dimensions front | 225/50 R17 94Y | 225/50 R 17 W | ||||
| Tyre dimensions rear | 225/50 R17 94Y | 225/50 R 17 W | ||||
| Wheel size front | 7.5J x 17 | 7.5 J x 17 | ||||
| Wheel size rear | 7.5J x 17 | 7.5 J x 17 | ||||
| Brake dimensions front | 324 x 30 | 348 x 36 | ||||
| Brake dimensions rear | 320 x 20 | 345 x 24 | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 11.9 | 11.4 | ||||
| Overall length [mm] | 4843 | 4843 | ||||
| Overall width without/including mirrors [mm] | 1846/- | 1846/- | ||||
| Overall height [mm] | 1491 | 1491 | ||||
| Wheelbase [mm] | 2886 | 2886 | ||||
| Front wheel track [mm] | 1558 | 1558 | ||||
| Rear wheel track [mm] | 1581 | 1581 | ||||
| Forward overhang [mm] | 852 | 852 | ||||
| Rear overhang [mm] | 1105 | 1105 | ||||
| Clearance [mm] | 143 | 143 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 992 | 992 | ||||
| Headroom rear [mm] | 994 | 994 | ||||
| Front elbow/shoulder width [mm] | 1484/- | 1484/- | ||||
| Rear elbow/shoulder width [mm] | 1496/- | 1496/- | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
