BMW X3
Date of manufacture
2007 – 8/2010 (SUV)
Platform
-
Manufacturing locations
Graz, Austria
Kaliningrad, Russia
Designer
-
Tags
Compact SUV
German cars
The BMW X3 has been available in an SUV body style since 2007. Production of this model takes place in multiple countries such as Austria and Russia. It offers a wide range of engines, both diesel and petrol. The most powerful engine is the xDrive35d with a power output of 210 kW, allowing it to reach a top speed of 240 km/h. The most economical version, the xDrive18d, has a combined fuel consumption of 6.2 l/100 km and CO2 emissions of 165 g/km. The boot capacity is 480 l. In terms of safety, the BMW X3 boasts a rating of 4 out of 5 according to the EURONCAP test.
Car body style
Technical data
SUV
| xDrive20i | xDrive25i | xDrive25i | xDrive30i | xDrive30i | xDrive18d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 6/24 | 6/24 | 6/24 | 6/24 | 4/16 |
| Engine displacement [cm³] | 1995 | 2497 | 2497 | 2996 | 2996 | 1995 |
| Maximum output / speed [kW/min-1] | 110/6200 | 160/6500 | 160/6500 | 200/6650 | 200/6650 | 105/4000 |
| Maximum torque [Nm/min-1] | 200/3750 | 250/2750-4250 | 250/2750-4250 | 315/2750 | 315/2750 | 350/1750-2750 |
| Bore and stroke [mm x mm] | 90,0 x 84,0 | 78,8 x 82,0 | 78,8 x 82,0 | 88,0 x 85,0 | 88,0 x 85,0 | 90,0 x 84,0 |
| Compression ratio | 10,5:1 | 11,0:1 | 11,0:1 | 10,7:1 | 10,7:1 | 16,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 198 | 210 | 210 | 210 | 210 | 195 |
| Acceleration 0–100 km/h [s] | 11.5 | 8.5 | 8.9 | 7.2 | 7.5 | 10.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 12.6 | 12.8 | 13.1 | 13.4 | 13.3 | 7.9 |
| Out of town [l] | 6.9 | 7.3 | 7.6 | 7.3 | 7.6 | 5.2 |
| Combined [l] | 9.0 | 9.3 | 9.5 | 9.5 | 9.7 | 6.2 |
| CO2 emissions [g/km] | 215 | 224 | 228 | 229 | 233 | 165 |
| Emission standard | EU4 | EU4 | EU4 | EU4 | EU4 | EU4/EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1730 | 1805 | 1830 | 1815 | 1840 | 1815 |
| Overall weight [kg] | 2200 | 2260 | 2300 | 2260 | 2300 | 2265 |
| Maximum trailer weight unbraked/braked [kg] | 720/1600 | 720/1800 | 720/1800 | 720/2000 | 720/2000 | 720/1800 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | 80 | 80 | 80 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 480 | 480 | 480 | 480 | 480 | 480 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1560 | -/1560 | -/1560 | -/1560 | -/1560 | -/1560 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 67 | 67 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.35 | 0.34 | 0.34 | 0.34 | 0.34 | 0.34 |
| Front suspension | - | - | - | - | - | - |
| Rear suspension | - | - | - | - | - | - |
| Tyre dimensions front | 215/60 R17 96H | 235/55 R17 99H | 235/55 R17 99H | 235/55 R17 99H | 235/55 R17 99H | 215/60 R17 96H |
| Tyre dimensions rear | 215/60 R17 96H | 235/55 R17 99H | 235/55 R17 99H | 235/55 R17 99H | 235/55 R17 99H | 215/60 R17 96H |
| Wheel size front | 7J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 |
| Wheel size rear | 7J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 |
| Brake dimensions front | 325 x 25 | 325 x 25 | 325 x 25 | 325 x 25 | 325 x 25 | 325 x 25 |
| Brake dimensions rear | 320 x 22 | 320 x 22 | 320 x 22 | 320 x 22 | 320 x 22 | 320 x 22 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.7 | 11.7 | 11.7 | 11.7 | 11.7 | 11.7 |
| Overall length [mm] | 4569 | 4569 | 4569 | 4569 | 4569 | 4569 |
| Overall width without/including mirrors [mm] | 1853/- | 1853/- | 1853/- | 1853/- | 1853/- | 1853/- |
| Overall height [mm] | 1674 | 1674 | 1674 | 1674 | 1674 | 1674 |
| Wheelbase [mm] | 2795 | 2795 | 2795 | 2795 | 2795 | 2795 |
| Front wheel track [mm] | 1538 | 1524 | 1524 | 1524 | 1524 | 1538 |
| Rear wheel track [mm] | 1556 | 1542 | 1542 | 1542 | 1542 | 1556 |
| Forward overhang [mm] | 821 | 821 | 821 | 821 | 821 | 821 |
| Rear overhang [mm] | 953 | 953 | 953 | 953 | 953 | 953 |
| Clearance [mm] | 201 | 201 | 201 | 201 | 201 | 201 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 23.9 | 23.9 | 23.9 | 23.9 | 23.9 | 23.9 |
| Approach angle rear [°] | 21.8 | 21.8 | 21.8 | 21.8 | 21.8 | 21.8 |
| Transition angle [°] | 17.2 | 17.2 | 17.2 | 17.2 | 17.2 | 17.2 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 997 | 997 | 997 | 997 | 997 | 997 |
| Headroom rear [mm] | 1002 | 1002 | 1002 | 1002 | 1002 | 1002 |
| Front elbow/shoulder width [mm] | 1433/- | 1433/- | 1433/- | 1433/- | 1433/- | 1433/- |
| Rear elbow/shoulder width [mm] | 1452/- | 1452/- | 1452/- | 1452/- | 1452/- | 1452/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| xDrive20d | xDrive20d | xDrive30d | xDrive30d | xDrive35d | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 6/24 | |
| Engine displacement [cm³] | 1995 | 1995 | 2993 | 2993 | 2993 | |
| Maximum output / speed [kW/min-1] | 130/4000 | 130/4000 | 160/4000 | 160/4000 | 210/4400 | |
| Maximum torque [Nm/min-1] | 350/1750-3000 | 350/1750-3000 | 500/1750-2750 | 500/1750-2750 | 580/1750-2250 | |
| Bore and stroke [mm x mm] | 90,0 x 84,0 | 90,0 x 84,0 | 90,0 x 84,0 | 90,0 x 84,0 | 90,0 x 84,0 | |
| Compression ratio | 16,5:1 | 16,5:1 | 17,0:1 | 17,0:1 | 17,0:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear automatic | |
| Drive specifications |
|
|
|
|
| |
| Top speed [km/h] | 206 | 205 | 210 | 210 | 240 | |
| Acceleration 0–100 km/h [s] | 8.9 | 9.2 | 7.4 | 7.7 | 6.4 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 8.2 | 8.3 | 9.7 | 9.9 | 9.7 | |
| Out of town [l] | 5.5 | 5.8 | 6.0 | 6.4 | 6.7 | |
| Combined [l] | 6.5 | 6.7 | 7.4 | 7.7 | 7.6 | |
| CO2 emissions [g/km] | 172 | 172 | 196 | 206 | 208 | |
| Emission standard | EU4/EU5 | EU4/EU5 | EU4 | EU4 | EU4 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1815 | 1825 | 1880 | 1885 | 1950 | |
| Overall weight [kg] | 2265 | 2265 | 2350 | 2355 | 2385 | |
| Maximum trailer weight unbraked/braked [kg] | 720/1800 | 720/2000 | 750/2000 | 750/2000 | 750/2000 | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | 80 | 80 | |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | |
| Boot volume [l] | 480 | 480 | 480 | 480 | 480 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1560 | -/1560 | -/1560 | -/1560 | -/1560 | |
| Boot length [mm] | - | - | - | - | - | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | - | - | - | - | - | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 67 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.34 | 0.35 | |
| Front suspension | - | - | - | - | - | |
| Rear suspension | - | - | - | - | - | |
| Tyre dimensions front | 215/60 R17 96H | 215/60 R17 96H | 235/55 R17 99H | 235/55 R17 99H | 235/50 R18 97V | |
| Tyre dimensions rear | 215/60 R17 96H | 215/60 R17 96H | 235/55 R17 99H | 235/55 R17 99H | 235/50 R18 97V | |
| Wheel size front | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 18 | |
| Wheel size rear | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 17 | 8J x 18 | |
| Brake dimensions front | 325 x 25 | 325 x 25 | 325 x 25 | 325 x 25 | 325 x 25 | |
| Brake dimensions rear | 320 x 22 | 320 x 22 | 320 x 22 | 320 x 22 | 320 x 22 | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.7 | 11.7 | 11.7 | 11.7 | 11.7 | |
| Overall length [mm] | 4569 | 4569 | 4569 | 4569 | 4569 | |
| Overall width without/including mirrors [mm] | 1853/- | 1853/- | 1853/- | 1853/- | 1853/- | |
| Overall height [mm] | 1674 | 1674 | 1674 | 1674 | 1674 | |
| Wheelbase [mm] | 2795 | 2795 | 2795 | 2795 | 2795 | |
| Front wheel track [mm] | 1538 | 1538 | 1524 | 1524 | 1524 | |
| Rear wheel track [mm] | 1556 | 1556 | 1542 | 1542 | 1542 | |
| Forward overhang [mm] | 821 | 821 | 821 | 821 | 821 | |
| Rear overhang [mm] | 953 | 953 | 953 | 953 | 953 | |
| Clearance [mm] | 201 | 201 | 201 | 201 | 201 | |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | |
| Approach angle front [°] | 23.9 | 23.9 | 23.9 | 23.9 | 23.9 | |
| Approach angle rear [°] | 21.8 | 21.8 | 21.8 | 21.8 | 21.8 | |
| Transition angle [°] | 17.2 | 17.2 | 17.2 | 17.2 | 17.2 | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 997 | 997 | 997 | 997 | 997 | |
| Headroom rear [mm] | 1002 | 1002 | 1002 | 1002 | 1002 | |
| Front elbow/shoulder width [mm] | 1433/- | 1433/- | 1433/- | 1433/- | 1433/- | |
| Rear elbow/shoulder width [mm] | 1452/- | 1452/- | 1452/- | 1452/- | 1452/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
