BMW X3
Date of manufacture
9/2010 – 2014 (SUV)
Platform
-
Manufacturing locations
Greer, South Carolina, USA
Kaliningrad, Russia
Designer
Erik Goplen
Tags
Compact SUV
German cars
The only body variant of the BMW X3 is an SUV. The car has been produced since 2010. The countries of production of the car include the USA and Russia. The list of power units includes gasoline and diesel engines. The highest power is achieved by the xDrive35d (230 kW). The highest speed is achieved by the xDrive35i model - 245 km/h. The lowest combined fuel consumption is 5.1 l/100 km for the sDrive18d version. CO2 emissions are 135 g/km. The luggage compartment volume offers 550 l. During EURONCAP safety tests, the car received a rating of 5 out of 5. Tested according to the methodology of 2011.
Car body style
Technical data
SUV
| xDrive20i | xDrive20i | xDrive28i | xDrive28i | xDrive35i | sDrive18d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol | Ignition supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 6/24 | 6/24 | 4/16 |
| Engine displacement [cm³] | 1997 | 1997 | 1997 | 2996 | 2979 | 1995 |
| Maximum output / speed [kW/min-1] | 135/5000 | 135/5000 | 180/5000 | 190/6600 | 225/5800 | 105/4000 |
| Maximum torque [Nm/min-1] | 270/1250-4500 | 270/1250-4500 | 350/1250-4800 | 310/2600-3000 | 400/1200-5000 | 360/1750-2500 |
| Bore and stroke [mm x mm] | 84,0 x 90,1 | 84,0 x 90,1 | 84,0 x 90,1 | 85,0 x 88,0 | 84,0 x 89,6 | 84,0 x 90,0 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,0:1 | 10,7:1 | 10,2:1 | 16,5:1 |
| Oil volume [l] | 5.75 | 5.75 | 5.75 | 6.5 | 6.5 | - |
| Coolant volume [l] | 7.5 | 7.5 | 8.4 | - | 9.6 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual |
| Drive specifications |
|
|
|
|
| - |
| Top speed [km/h] | 210 | 210 | 230 | 230 | 245 | 195 |
| Acceleration 0–100 km/h [s] | 8.3 | 8.6 | 6.7 | 6.9 | 5.7 | 9.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 9.5 | - | - | - | - | - |
| City [l] | 9.9 | 9.1 | 9.1 | 12.3 | 11.2 | 5.8 |
| Out of town [l] | 6.7 | 6.7 | 6.7 | 7.1 | 7.4 | 4.7 |
| Combined [l] | 7.9 | 7.5 | 7.5 | 9.0 | 8.8 | 5.1 |
| CO2 emissions [g/km] | 184 | 175 | 175 | 210 | 204 | 135 |
| Emission standard | EU5/EU6 | EU5/EU6 | EU5/EU6 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1785 | 1795 | 1795 | 1820 | 1880 | 1735 |
| Overall weight [kg] | 2300 | 2310 | 2310 | 2305 | 2365 | 2250 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2400 | 750/2400 | 750/2400 | 750/2400 | 750/2000 |
| Maximum front/rear axle load [kg] | 1070 / 1310 | 1070 / 1310 | 1080 / 1290 | 1080 / 1305 | 1130 / 1315 | - |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 550 | 550 | 550 | 550 | 550 | 550 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1600 | -/1600 | -/1600 | -/1600 | -/1600 | -/1600 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 67 | 67 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.34 | 0.35 | 0.33 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | 225/60 R17 99V |
| Tyre dimensions rear | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | 225/60 R17 99V |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 8J x 18 | 7.5J x 17 |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 8J x 18 | 7.5J x 17 |
| Brake dimensions front | 328 x 28 | 328 x 28 | 328 x 28 | 328 x 28 | 356 x 30 | 328 x 28 |
| Brake dimensions rear | 330 x 20 | 330 x 20 | 330 x 20 | 330 x 20 | 330 x 20 | 330 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/11.9 | -/11.9 | -/11.9 | -/11.9 | -/11.9 | -/11.9 |
| Overall length [mm] | 4648 | 4648 | 4648 | 4648 | 4648 | 4648 |
| Overall width without/including mirrors [mm] | 1881/2098 | 1881/2098 | 1881/2098 | 1881/2098 | 1881/2098 | 1881/2098 |
| Overall height [mm] | 1661 | 1661 | 1661 | 1661 | 1661 | 1661 |
| Wheelbase [mm] | 2810 | 2810 | 2810 | 2810 | 2810 | 2810 |
| Front wheel track [mm] | 1616 | 1616 | 1616 | 1616 | 1594 | 1616 |
| Rear wheel track [mm] | 1632 | 1632 | 1632 | 1632 | 1610 | 1632 |
| Forward overhang [mm] | 861 | 861 | 861 | 861 | 861 | 861 |
| Rear overhang [mm] | 977 | 977 | 977 | 977 | 977 | 977 |
| Clearance [mm] | 212 | 212 | 212 | 212 | 212 | 212 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 25.7 | 25.7 | 25.7 | 25.7 | 25.7 | 25.7 |
| Approach angle rear [°] | 22.6 | 22.6 | 22.6 | 22.6 | 22.6 | 22.6 |
| Transition angle [°] | 19.4 | 19.4 | 19.4 | 19.4 | 19.4 | 19.4 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1033 | 1033 | 1033 | 1033 | 1033 | 1033 |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | 994 |
| Front elbow/shoulder width [mm] | 1483/- | 1483/- | 1483/- | 1483/- | 1483/- | 1483/- |
| Rear elbow/shoulder width [mm] | 1458/- | 1458/- | 1458/- | 1458/- | 1458/- | 1458/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| sDrive18d | xDrive20d | xDrive20d | xDrive30d | xDrive35d | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 6/24 | 6/24 | |
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 2993 | 2993 | |
| Maximum output / speed [kW/min-1] | 105/4000 | 135/4000 | 135/4000 | 190/4000 | 230/4400 | |
| Maximum torque [Nm/min-1] | 360/1750-2500 | 380/1750-2750 | 380/1750-2750 | 560/1500-3000 | 630/1500-2500 | |
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | |
| Compression ratio | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | |
| Oil volume [l] | - | 5.2 | 5.2 | 7.2 | 7.2 | |
| Coolant volume [l] | - | - | - | 10.0 | 12.0 | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Rear | 4x4 | 4x4 | 4x4 | 4x4 | |
| Gearbox | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic | 8 gear automatic | |
| Drive specifications |
|
|
|
|
| |
| Top speed [km/h] | 190 | 210 | 210 | 230 | 244 | |
| Acceleration 0–100 km/h [s] | 10.3 | 8.5 | 8.5 | 6.2 | 5.8 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | 9.0 | - | - | - | |
| City [l] | 5.8 | 6.7 | 6.1 | 6.8 | 6.7 | |
| Out of town [l] | 5.2 | 5.0 | 5.3 | 5.6 | 5.8 | |
| Combined [l] | 5.4 | 5.6 | 5.6 | 6.0 | 6.1 | |
| CO2 emissions [g/km] | 142 | 149 | 147 | 159 | 162 | |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1755 | 1790 | 1800 | 1875 | 1925 | |
| Overall weight [kg] | 2270 | 2290 | 2300 | 2390 | 2440 | |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2400 | 750/2400 | 750/2400 | |
| Maximum front/rear axle load [kg] | - | 1080 / 1305 | 1080 / 1305 | 1140 / 1320 | 1160 / 1320 | |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | |
| Boot volume [l] | 550 | 550 | 550 | 550 | 550 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1600 | -/1600 | -/1600 | -/1600 | -/1600 | |
| Boot length [mm] | - | - | - | - | - | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | - | - | - | - | - | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 67 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | 0.33 | 0.33 | 0.33 | 0.34 | 0.35 | |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | |
| Tyre dimensions front | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | |
| Tyre dimensions rear | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 8J x 18 | |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 7.5J x 17 | 8J x 18 | |
| Brake dimensions front | 328 x 28 | 328 x 28 | 328 x 28 | 328 x 28 | 328 x 28 | |
| Brake dimensions rear | 330 x 20 | 330 x 20 | 330 x 20 | 330 x 20 | 330 x 20 | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | -/11.9 | -/11.9 | -/11.9 | -/11.9 | -/11.9 | |
| Overall length [mm] | 4648 | 4648 | 4648 | 4648 | 4648 | |
| Overall width without/including mirrors [mm] | 1881/2098 | 1881/2098 | 1881/2098 | 1881/2098 | 1881/2098 | |
| Overall height [mm] | 1661 | 1661 | 1661 | 1661 | 1661 | |
| Wheelbase [mm] | 2810 | 2810 | 2810 | 2810 | 2810 | |
| Front wheel track [mm] | 1616 | 1616 | 1616 | 1616 | 1616 | |
| Rear wheel track [mm] | 1632 | 1632 | 1632 | 1632 | 1632 | |
| Forward overhang [mm] | 861 | 861 | 861 | 861 | 861 | |
| Rear overhang [mm] | 977 | 977 | 977 | 977 | 977 | |
| Clearance [mm] | 212 | 212 | 212 | 212 | 212 | |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | |
| Approach angle front [°] | 25.7 | 25.7 | 25.7 | 25.7 | 25.7 | |
| Approach angle rear [°] | 22.6 | 22.6 | 22.6 | 22.6 | 22.6 | |
| Transition angle [°] | 19.4 | 19.4 | 19.4 | 19.4 | 19.4 | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 1033 | 1033 | 1033 | 1033 | 1033 | |
| Headroom rear [mm] | 994 | 994 | 994 | 994 | 994 | |
| Front elbow/shoulder width [mm] | 1483/- | 1483/- | 1483/- | 1483/- | 1483/- | |
| Rear elbow/shoulder width [mm] | 1458/- | 1458/- | 1458/- | 1458/- | 1458/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
