	xDrive35i	xDrive50i	X6 M	xDrive30d	xDrive40d	X6 M50d
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/32	8/32	6/24	6/24	6/24
Engine displacement [cm³]	2979	4395	4395	2993	2993	2993
Maximum output / speed [kW/min-1]	225/5800	300/5500-6400	408/6000	180/4000	225/4400	280/4000-4400
Maximum torque [Nm/min-1]	400/1200-5000	600/1750-4500	680/1500-5650	540/1750-3000	600/1500-2500	740/2000-3000
Bore and stroke [mm x mm]	84,0 x 89,6	89,0 x 88,3	89,0 x 88,3	84,0 x 90,0	84,0 x 90,0	84,0 x 90,0
Compression ratio	10,2:1	10,0:1	9,3:1	16,5:1	16,5:1	16,5:1
Oil volume [l]	6.5	8.5	8.5	6.7	6.7	-
Coolant volume [l]	10.9	17.2	17.0	10.4	10.4	-
Technical specifications	direct injection High Precision Injection turbo-supercharged Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable lift of intake valves Valvetronic brake energy recuperation	direct injection High Precision Injection supercharging by twin turbochargers variable timing of intake and exhaust valves Double‐VANOS brake energy recuperation	direct injection High Precision Injection supercharging by twin turbochargers Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter brake energy recuperation	direct injection Common Rail supercharging by twin turbochargers particulate filter brake energy recuperation	direct injection Common Rail supercharging by three turbochargers with variable blade geometry (two high-pressure and one low-pressure) particulate filter brake energy recuperation

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	8 gear automatic	8 gear automatic	6 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic

Top speed [km/h]	240	250	250	222	236	250
Acceleration 0–100 km/h [s]	6.7	5.4	4.7	7.5	6.5	5.3
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	13.2	17.5	19.3	8.7	8.8	9.0
Out of town [l]	8.3	9.6	10.8	6.7	6.8	7.0
Combined [l]	10.1	12.5	13.9	7.4	7.5	7.7
CO2 emissions [g/km]	236	292	325	195	198	204

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	2145	2265	2380	2150	2185	2225
Overall weight [kg]	2670	2790	2905	2675	2710	2800
Maximum trailer weight unbraked/braked [kg]	750/2700-3500	750/2700-3500	750/3000	750/2700-3500	750/2700-3500	750/2700-3500
Maximum front/rear axle load [kg]	1275/1475	1375/1490	1400/1520	1285/1475	1310/1475	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	570	570	570	570	570	570
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1450	-/1450	-/1450	-/1450	-/1450	-/1450
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	4-5	4-5	4-5	4-5	4-5	4-5
Fuel tank volume [l]	85	85	85	85	85	85
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.34	0.36	0.38	0.33	0.34	0.37
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	255/50 R19 107V	255/50 R19 107V	275/40 R20 106Y	255/50 R19 107V	255/50 R19 107V	275/40 R20 106Y
Tyre dimensions rear	255/50 R19 107V	255/50 R19 107V	315/35 R20 110Y	255/50 R19 107V	255/50 R19 107V	315/35 R20 110Y
Wheel size front	9J x 19	9J x 19	10J x 20	9J x 19	9J x 19	10J x 20
Wheel size rear	9J x 19	9J x 19	11J x 20	9J x 19	9J x 19	11J x 20
Brake dimensions front	348 x 30	385 x 36	395 x 36	332 x 30	348 x 30	385 x 36
Brake dimensions rear	320 x 20	345 x 24	385 x 24	320 x 20	320 x 20	345 x 24
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-/12.8	-/12.8	-/12.8	12.8	12.8	12.8

Overall length [mm]	4877	4877	4876	4877	4877	4877
Overall width without/including mirrors [mm]	1983/2195	1983/2195	1983/2195	1983/2195	1983/2195	1983/2195
Overall height [mm]	1669	1669	1684	1669	1669	1669
Wheelbase [mm]	2933	2933	2933	2933	2933	2933
Front wheel track [mm]	1644	1644	1660	1644	1644	1644
Rear wheel track [mm]	1706	1706	1672	1706	1706	1706
Forward overhang [mm]	858	858	856	858	858	858
Rear overhang [mm]	1086	1086	1087	1086	1086	1086
Clearance [mm]	212	212	205	212	212	212
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	25.1	25.1	22	25.1	25.1	25.1
Approach angle rear [°]	25.5	25.5	21.5	25.5	25.5	25.5
Transition angle [°]	19.1	19.1	18.6	19.1	19.1	19.1
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	973	973	973	973	973	973
Headroom rear [mm]	946	946	946	946	946	946
Front elbow/shoulder width [mm]	1551/-	1551/-	1521/-	1551/-	1551/-	1551/-
Rear elbow/shoulder width [mm]	1513/-	1513/-	1448/-	1513/-	1513/-	1513/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
