	X7 xDrive40i	X7 xDrive50i	X7 M50i	X7 xDrive40i	X7 xDrive30d	X7 M50d
Date of sale	from to 2019	from to 2019	from 8/2019 to	from 2020 to	from to 8/2020	from to 2019
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Petrol supercharged + Electric	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6 /24	8/32	8 /32	6/24	6 /24	6 /24
Engine displacement [cm³]	2998	4395	4395	2998	2993	2993
Maximum output / speed [kW/min-1]	250/5500-6500	340/5250-6000	390/5500-6000	245/5500-6250 8 el.	195/4000	294/4400
Maximum torque [Nm/min-1]	450/1500-5200	650/1500-4750	750/1800-4600	450/1600-4800	620/2000-2500	760/2000-3000
Bore and stroke [mm x mm]	82.0 x 94.6	89.0 x 88.3	89.0 x 88.3	82.0 x 94.6	84.0 x 90.0	84.0 x 90.0
Compression ratio	11.0:1	10.5:1	10.5:1	11.0:1	16.5:1	16.0:1
Oil volume [l]	6.5	10.5	10.5	-	6.5	6.5
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection High Precision Injection turbo-supercharged Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable valve lift Valvetronic Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection High Precision Injection turbo-supercharged Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable valve lift Valvetronic Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection High Precision Injection supercharging by twin turbochargers Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable valve lift Valvetronic Gasoline Particulate Filter start&stop system brake energy recuperation	Mild Hybrid direct injection High Precision Injection turbo-supercharged Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable valve lift Valvetronic Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection Common Rail supercharging by a pair of differently sized turbochargers with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation	direct injection Common Rail supercharging by four turbochargers (two small and two large) particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic

Top speed [km/h]	245	250	250	243	227	250
Acceleration 0–100 km/h [s]	6.1	5.4	4.7	6.3	7.0	5.4
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	-	-	15.0-14.9	10.5-10.0	-	-
Out of town [l]	-	-	8.8-8.5	7.5-7.3	-	-
Combined [l]	9.0-8.7	11.4	11.1-10.9	8.6-8.3	6.8-6.5	7.4-7.0
CO2 emissions [g/km]	205-198	261	252-248	197-190	178-171	193-185

Emission standard	EU6d-TEMP	EU6d-TEMP	EU6d-TEMP - EU6d	Euro 6d	EU6d-TEMP	EU6d-TEMP
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	-	-	-	48	-	-
Battery type and capacity	-	-	-	Lithium-Ionen-Akkumulator, 11 A⋅h	-	-
Range with fully charged battery [km]	-	-	-	-	-	-
Charging time	-	-	-	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	2395	2535	2555	2435	2445	2535
Overall weight [kg]	3155	3255	3285	3195	3220	3290
Maximum trailer weight unbraked/braked [kg]	750/2200	750/2700	750/2700	750/3500	750/2200	750/2600
Maximum front/rear axle load [kg]	1340/1910	1445/ 1920	1455/1925	-	1365/ 1950	1415/ 1945
Maximum vertical load on the tow bar [kg]	140	140	140	140	140	140
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	326	326	326	326	326	326
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2120	-/2120	-/2120	-/2120	-/2120	-/2120
Boot volume, third row of seats [l]	-	-	-	-	-	-
Boot volume, third row seats folded [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	7 [6 subject to a surcharge]	7 [6 subject to a surcharge]	7 [6 subject to a surcharge]	7 [6 subject to a surcharge]	7 [6 subject to a surcharge]	7 [6 subject to a surcharge]
Fuel tank volume [l]	83	83	83	83	80	80
AdBlue tank volume [l]	-	-	-	-	22	22
Air resistance [Cd]	0.33	0.34	0.34	-	0.33	0.34
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	five-link	five-link	five-link	five-link	five-link	five-link
Tyre dimensions front	275/50 R20 113W XL	275/50 R20 113W XL	285/45 R21 113Y XL	275/50 R20 113W XL	275/50 R20 113W XL	285/45 R211 13YXL
Tyre dimensions rear	275/50 R20 113W XL	275/50 R20 113W XL	285/45 R21 113Y XL	275/50 R20 113W XL	275/50 R20 113W XL	285/45 R211 13YXL
Wheel size front	8.5J x 20	8.5J x 20	9.5J x 21	8.5J x 20	8.5J x 20	9.5J x 21
Wheel size rear	8.5J x 20	8.5J x 20	9.5J x 21	8.5J x 20	8.5J x 20	9.5J x 21
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Electro-mechanical power steering Servotronic	Electro-mechanical power steering Servotronic	Electro-mechanical power steering Servotronic	Electro-mechanical power steering Servotronic	Electro-mechanical power steering Servotronic	Electro-mechanical power steering Servotronic
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	13.0/-	13.0/-	13.0/-	13.0/-	13.0/-	13.0/-

Overall length [mm]	5151	5151	5151	5151	5151	5151
Overall width without/including mirrors [mm]	2000/2218	2000/2218	2000/2218	2000/2218	2000/2218	2000/2218
Overall height [mm]	1805	1805	1805	1805	1805	1805
Wheelbase [mm]	3105	3105	3105	3105	3105	3105
Front wheel track [mm]	1684	1684	1682	1684	1684	1682
Rear wheel track [mm]	1705	1705	1703	1705	1705	1703
Forward overhang [mm]	874	874	874	874	874	874
Rear overhang [mm]	1172	1172	1172	1172	1172	1172
Clearance [mm]	221	221	221	221	221	221
Wading depth [mm]	500	500	500	500	500	500
Approach angle front [°]	25.0	25.0	25.0	25.0	25.0	25.0
Approach angle rear [°]	22.2	22.2	22.2	22.2	22.2	22.2
Transition angle [°]	19.8	19.8	19.8	19.8	19.8	19.8
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1064	1064	1064	1064	1064	1064
Headroom rear [mm]	1013	1013	1013	1013	1013	1013
Front elbow/shoulder width [mm]	1560/-	1560/-	1560/-	1560/-	1560/-	1560/-
Rear elbow/shoulder width [mm]	1527/-	1527/-	1527/-	1527/-	1527/-	1527/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-
Third row of seats, headroom [mm]	1013	1013	1013	1013	1013	1013
Third row elbow/shoulder width [mm]	1218/-	1218/-	1218/-	1218/-	1218/-	1218/-

	X7 xDrive40d
Date of sale	from 2/2020 to
Engine type	Diesel supercharged + Electric
Number of cylinders/valves	6/24
Engine displacement [cm³]	2993
Maximum output / speed [kW/min-1]	250/4400 8 el.
Maximum torque [Nm/min-1]	700/1750-2250
Bore and stroke [mm x mm]	84.0 x 90.0
Compression ratio	16.5:1
Oil volume [l]	7.0
Coolant volume [l]	-
Technical specifications	Mild Hybrid direct injection Common Rail supercharging by a pair of differently sized turbochargers with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	4x4
Gearbox	8 gear automatic
Drive specifications	automatically controlled all-wheel drive xDrive eight-speed automatic gearbox Steptronic

Top speed [km/h]	245
Acceleration 0–100 km/h [s]	6.1
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	7.8-7.5
Out of town [l]	5.9-5.7
Combined [l]	6.6-6.4
CO2 emissions [g/km]	173-167

Emission standard	Euro 6d
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	48
Battery type and capacity	Lithium-Ionen-Akkumulator, 11 A⋅h
Range with fully charged battery [km]	-
Charging time	-
Number of modules/cells	-
Battery weight [kg]	-
Charger	-

Standby weight [kg]	2545
Overall weight [kg]	3295
Maximum trailer weight unbraked/braked [kg]	750/3500
Maximum front/rear axle load [kg]	1415/ 1960
Maximum vertical load on the tow bar [kg]	140
Maximum load on roof/carrier [kg]	100/-

Boot volume [l]	326
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2120
Boot volume, third row of seats [l]	-
Boot volume, third row seats folded [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	7 [6 subject to a surcharge]
Fuel tank volume [l]	80
AdBlue tank volume [l]	22
Air resistance [Cd]	0,33
Front suspension	double wishbone
Rear suspension	five-link
Tyre dimensions front	275/50 R20 113W XL
Tyre dimensions rear	275/50 R20 113W XL
Wheel size front	8.5J x 20
Wheel size rear	8.5J x 20
Brake dimensions front	-
Brake dimensions rear	-
Steering	Electro-mechanical power steering Servotronic
Number of steering wheel turns	-
Turning diameter track/circumference [m]	13.0/-

Overall length [mm]	5151
Overall width without/including mirrors [mm]	2000/2218
Overall height [mm]	1805
Wheelbase [mm]	3105
Front wheel track [mm]	1684
Rear wheel track [mm]	1705
Forward overhang [mm]	874
Rear overhang [mm]	1172
Clearance [mm]	221
Wading depth [mm]	500
Approach angle front [°]	25.0
Approach angle rear [°]	22.2
Transition angle [°]	19.8
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	1064
Headroom rear [mm]	1013
Front elbow/shoulder width [mm]	1560/-
Rear elbow/shoulder width [mm]	1527/-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-
Third row of seats, headroom [mm]	1013
Third row elbow/shoulder width [mm]	1218/-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
