Cupra Formentor
Date of manufacture
2020 – to this day (Medium SUV)
Platform
Volkswagen Group MQB Evo
Manufacturing locations
Martorell, Spain
Designer
Alejandro Mesonero-Romanos
Tags
Compact SUV
Spanish cars
Sport SUV
The Cupra Formentor is a mid-size SUV that has been manufactured in Spain since 2020. It is built on the Volkswagen Group MQB Evo platform and offers petrol, diesel and hybrid engine options. The most powerful variant, the 2.0 TSI 310 VZ 4WD, has a top speed of 250 km/h, while the most efficient 1.4 e-HYBRID 204 has fuel consumption of 1.2 l/100 km and CO2 emissions of 30 g/km. The boot capacity is 345 l. The model has passed the EURONCAP 2021 safety tests with a rating of 5 out of 5.
Car body style
Medium SUV
Date of manufacture
2020 – to this dayInternal designation
KM6Engine size
Technical data
Medium SUV
| 1.5 TSI 150 | 1.5 TSI 150 | 2.0 TSI 190 4Drive | 2.0 TSI 245 | 2.0 TSI 310 VZ 4WD | 1.4 e-HYBRID 204 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1498 | 1498 | 1498 | 1984 | 1984 | 1395 |
| Maximum output / speed [kW/min-1] | 110/5000-6000 | 110/5000-6000 | 140/4200-6000 | 180/5250-6500 | 228/5450-6500 | 110/5000-6000 85 el. 150 total |
| Maximum torque [Nm/min-1] | 250/1500-3500 | 250/1500-3500 | 320/1500-4100 | 370/1600-4300 | 400/2000-5450 | 250/1550-3500 350 total |
| Bore and stroke [mm x mm] | 74,5 x 85,9 | 74,5 x 85,9 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 74,5 x 80.0 |
| Compression ratio | 10,5:1 | 10,5:1 | 12.2:1 | 9.6:1 | 9.3:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | 4x4 | Front | 4x4 | Front |
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic | 6 gear automatic |
| Drive specifications | - |
|
|
|
|
|
| Top speed [km/h] | 204 | 203 | 220 | 238 | 250 | 205 |
| Acceleration 0–100 km/h [s] | 8.9 | 8.9 | 7.1 | 6.8 | 4.9 | 7.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.3 | 6.6 | 8.9 | 9.1 | 9.6 | - |
| Out of town [l] | 5.0 | 5.1 | 5.9 | 5.7 | 6.5 | - |
| Combined [l] | 5.5 | 5.6 | 7.0 | 6.9 | 7.7 | 1.5-1.4 [13.0-12.8 kWh] |
| CO2 emissions [g/km] | 125 | 128 | 159 | 159 | 175 | 34-33 |
| Low speed [l] | 7.9 | 8.9 | 9.9 | 10.7 | 12.3 | - |
| Medium speed [l] | 6.0 | 6.6 | 7.6 | 7.4 | 8.4 | - |
| High speed [l] | 5.5 | 5.8 | 6.5 | 6.6 | 7.3 | - |
| Extra high speed [l] | 6.8 | 6.9 | 7.6 | 7.6 | 8.2 | - |
| Combined speed [l] | 6.6-6.3 | 7.0-6.6 | 7.9-7.5 | 7.8-7.6 | 8.7-8.4 | 1.3-1.2 [15.5-14.8 kWh] |
| CO2 emissions [g/km] | 150-142 | 158-150 | 179-170 | 176-173 | 196-191 | 37-30 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | - | - | - | - | - | Lithium-Ionen-Akkumulator, 12.8 kWh |
| Range with fully charged battery [km] | - | - | - | - | - | 59-53 [WLTP] |
| Charging time | - | - | - | - | - |
|
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1463 | 1437 | 1596 | 1556 | 1644 | 1681 |
| Overall weight [kg] | 1980 | 1960 | 2110 | 2060 | 2140 | 2120 |
| Maximum trailer weight unbraked/braked [kg] | 730/1500 | 710/1500 | 750/1700 | 750/1600 | 750/1800 | 750/1500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | 80 | 80 | 80 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 450 | 450 | 450 | 450 | 420 | 345 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1505 | -/1505 | -/1505 | -/1505 | -/1475 | -/1415 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | - | - | - | - | - | - |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 245/45 R18 96W | 245/45 R18 96W | 245/45 R18 96W | 245/40 R19 94W | 245/40 R19 94W | 225/40 R18 92Y |
| Tyre dimensions rear | 245/45 R18 96W | 245/45 R18 96W | 245/45 R18 96W | 245/40 R19 94W | 245/40 R19 94W | 225/40 R18 92Y |
| Wheel size front | 8J x 18 ET40 | 8J x 18 ET40 | 8J x 18 ET40 | 8J x 19 ET40 | 8J x 19 ET40 | 7,5J x 18 ET46 |
| Wheel size rear | 8J x 18 ET40 | 8J x 18 ET40 | 8J x 18 ET40 | 8J x 19 ET40 | 8J x 19 ET40 | 7,5J x 18 ET46 |
| Brake dimensions front | 312 x 25 | 312 x 25 | 312 x 25 | 340 x 30 or 370 x 32 | 340 x 30 or 370 x 32 | 312 x 25 |
| Brake dimensions rear | 272 x 10 | 272 x 10 | 272 x 10 | 310 x 22 | 310 x 22 | 272 x 10 |
| Steering | Electric variable power steering R-EPS | Electric variable power steering R-EPS | Electric variable power steering R-EPS | Electric variable power steering R-EPS | Electric variable power steering R-EPS | Electric variable power steering R-EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.7/11.4 | 10.7/11.4 | 10.7/11.4 | 10.7/11.4 | 10.7/11.4 | 10.7/11.4 |
| Overall length [mm] | 4450 | 4450 | 4450 | 4450 | 4450 | 4450 |
| Overall width without/including mirrors [mm] | 1839/1992 | 1839/1992 | 1839/1992 | 1839/1992 | 1839/1992 | 1839/1992 |
| Overall height [mm] | 1528 | 1528 | 1528 | 1528 | 1528 | 1528 |
| Wheelbase [mm] | 2680 | 2680 | 2680 | 2680 | 2680 | 2680 |
| Front wheel track [mm] | 1585 | 1585 | 1585 | 1585 | 1585 | 1585 |
| Rear wheel track [mm] | 1559 | 1559 | 1559 | 1559 | 1559 | 1559 |
| Forward overhang [mm] | 893 | 893 | 893 | 893 | 893 | 893 |
| Rear overhang [mm] | 877 | 877 | 877 | 877 | 877 | 877 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1075 | 1075 | 1075 | 1075 | 1075 | 1075 |
| Headroom rear [mm] | 986 | 986 | 986 | 986 | 986 | 986 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.4 e-HYBRID 245 VZ | 2.0 TDI 150 | 2.0 TDI 150 4Drive | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Petrol supercharged + Electric | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1395 | 1968 | 1968 | |||
| Maximum output / speed [kW/min-1] | 110/5000-6000 85 el. 180 total | 110/3250-4200 | 110/3000-4200 | |||
| Maximum torque [Nm/min-1] | 250/1550-3500 400 total | 340/1600-3000 | 360/1600-2750 | |||
| Bore and stroke [mm x mm] | 74,5 x 80.0 | 81,0 x 95,5 | 81,0 x 95,5 | |||
| Compression ratio | 10,0:1 | 16,0:1 | 16,0:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | 4x4 | |||
| Gearbox | 6 gear automatic | 6 gear manual | 7 gear automatic | |||
| Drive specifications |
| - |
| |||
| Top speed [km/h] | 210 | 205 | 203 | |||
| Acceleration 0–100 km/h [s] | 7.0 | 9.3 | 8.6 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | - | 5.3 | 5.9 | |||
| Out of town [l] | - | 3.8 | 4.7 | |||
| Combined [l] | 1.9 [14.1 kWh] | 4.4 | 5.2 | |||
| CO2 emissions [g/km] | 43 | 115 | 136 | |||
| Low speed [l] | - | 6.1 | 7.8 | |||
| Medium speed [l] | - | 4.5 | 5.7 | |||
| High speed [l] | - | 4.1 | 5.0 | |||
| Extra high speed [l] | - | 5.2 | 6.0 | |||
| Combined speed [l] | 1.5 [15.5-14.8 kWh] | 5.0-4.7 | 6.1-5.8 | |||
| CO2 emissions [g/km] | 34-32 | 131-124 | 159-152 | |||
| Emission standard | Euro 6d | Euro 6d | Euro 6d | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| System voltage [V] | - | - | - | |||
| Battery type and capacity | Lithium-Ionen-Akkumulator, 12.8 kWh | - | - | |||
| Range with fully charged battery [km] | 52-55 [WLTP] | - | - | |||
| Charging time |
| - | - | |||
| Number of modules/cells | - | - | - | |||
| Battery weight [kg] | - | - | - | |||
| Charger | - | - | - | |||
| Standby weight [kg] | 1704 | 1513 | 1623 | |||
| Overall weight [kg] | 2120 | 2030 | 2140 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1600 | 750/2000 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | 80 | 80 | 80 | |||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | |||
| Boot volume [l] | 345 | 450 | 450 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1415 | -/1505 | -/1505 | |||
| Boot length [mm] | - | - | - | |||
| Boot length with rear seats folded [mm] | - | - | - | |||
| Boot width between wheels/max [mm] | - | - | - | |||
| Boot height to headliner/ceiling [mm] | - | - | - | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | - | - | - | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | multilink | multilink | multilink | |||
| Tyre dimensions front | 245/40 R19 94W | 245/45 R18 96W | 245/45 R18 96W | |||
| Tyre dimensions rear | 245/40 R19 94W | 245/45 R18 96W | 245/45 R18 96W | |||
| Wheel size front | 8J x19 ET40 | 8J x 18 ET40 | 8J x 18 ET40 | |||
| Wheel size rear | 8Jx19 ET40 | 8J x 18 ET40 | 8J x 18 ET40 | |||
| Brake dimensions front | 340 x 30 | 312 x 25 | 312 x 25 | |||
| Brake dimensions rear | 310 x 22 | 272 x 10 | 272 x 10 | |||
| Steering | Electric variable power steering R-EPS | Electric variable power steering R-EPS | Electric variable power steering R-EPS | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 10.7/11.4 | 10.7/11.4 | 10.7/11.4 | |||
| Overall length [mm] | 4450 | 4450 | 4450 | |||
| Overall width without/including mirrors [mm] | 1839/1992 | 1839/1992 | 1839/1992 | |||
| Overall height [mm] | 1528 | 1528 | 1528 | |||
| Wheelbase [mm] | 2680 | 2680 | 2680 | |||
| Front wheel track [mm] | 1585 | 1585 | 1585 | |||
| Rear wheel track [mm] | 1559 | 1559 | 1559 | |||
| Forward overhang [mm] | 893 | 893 | 893 | |||
| Rear overhang [mm] | 877 | 877 | 877 | |||
| Clearance [mm] | - | - | - | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 1075 | 1075 | 1075 | |||
| Headroom rear [mm] | 986 | 986 | 986 | |||
| Front elbow/shoulder width [mm] | - | - | - | |||
| Rear elbow/shoulder width [mm] | - | - | - | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - |
