Dacia Lodgy
Date of manufacture
3/2012 – 2016 (MPV)
Platform
Dacia M0 platform
Manufacturing locations
Tangier, Morocco
Designer
-
Tags
Mid-size MPV
The Dacia Lodgy MPV is the only body style of the car produced since 2012. The car is built on the Dacia M0 platform and its engine range includes petrol and diesel engines. The highest performance is achieved by the 1.2 TCe 115 (85 kW) with a maximum speed of 179 km/h and the lowest combined consumption of 4 l/100 km is achieved by the 1.5 dCi 90 with CO2 emissions of 103 g/km. The car's trunk has a capacity of 827 l. In 2012, the car was tested for safety according to EURONCAP, where it received a total rating of 3 out of 5 points. Morocco is the country of production of this car.
Car body style
MPV
Date of manufacture
3/2012 – 2016Internal designation
Engine size
Technical data
MPV
| 1.6 | 1.6 LPG | 1.6 SCe 102 | 1.6 SCe 102 | 1.2 Tce | 1.2 TCe 115 | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2015 | from to 2015 | from 2015 to | from 2015 to | from to 2015 | from 2015 to |
| Engine type | Petrol | Petrol | Petrol | Petrol | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/8 | 4/8 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1598 | 1198 | 1197 |
| Maximum output / speed [kW/min-1] | 60,5/5000 | 60,5/5000 [59/5000 LPG] | 75/5500 | 75/5500 | 85/4500 | 85/4500 |
| Maximum torque [Nm/min-1] | 134/2800 | 134/2800 [131/2800 LPG] | 156/4000 | 156/4000 | 190/2000 | 190/1750 |
| Bore and stroke [mm x mm] | 79,5 x 80,5 | 79,5 x 80,5 | 79,5 x 80,5 | 79,5 x 80,5 | 72,2 x 73,2 | 72,2 x 73,2 |
| Compression ratio | 9,5:1 | 9,5:1 | 9.5:1 | 9.5:1 | - | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications | - |
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear manual | 5 gear manual | 5 gear manual | 5 gear manual | 5 gear manual |
| Drive specifications | - | - | - | - | - | - |
| Top speed [km/h] | 160 | 160 [158 LPG] | 172 | 170 | 179 | 179 |
| Acceleration 0–100 km/h [s] | 14.5 | 14.5 [15.1 LPG] | 11,6 | 11,6 | 11.1 | 10,6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.3 | 8.7 [11.2 LPG] | 7,8 | 7,8 [10,1 LPG] | 7.3 | 6,6-6,8 |
| Out of town [l] | 5.6 | 5.7 [7.3 LPG] | 5,2 | 5,2 [6,5 LPG] | 4.8 | 4,8-5,0 |
| Combined [l] | 7.0 | 6.7 [8.6 LPG] | 6,1 | 6,1 [7,8 LPG] | 5.7 | 5,5-5,6 |
| CO2 emissions [g/km] | 161 | 155 [139 LPG] | 139 | 139 [125 LPG] | 131 | 124-128 |
| Emission standard | EU5 | EU5 | Euro 6 | Euro 6 | EU5 | Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1165 | 1271 | 1211 [1261 seven seats] | 1280 | 1267 | 1256 [1280 seven seats] |
| Overall weight [kg] | 1800 | 1831 | 1765 [1845 seven seats] | 1850 | 1818 | 1810 [1875 seven seats] |
| Maximum trailer weight unbraked/braked [kg] | 580/1400 | 635/1400 | 605/1400 [630/1400 seven seats] | 640/1400 | 630/1400 | 625/1400 [640/1400 seven seats] |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 827 | 827 | 827 | 827 | 827 | 827 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2617 [- | -/2617 [- | -/2617 [- | -/2617 [- | -/2617 [- | -/2617 [- |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1180 | 1180 | 1180 | 1180 | 1180 | 1180 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1174 [-/- | 1174 [-/- | 1174 [-/- | 1174 [-/- | 1174 [-/- | 1174 [-/- |
| Boot height to headliner/ceiling [mm] | 583/- | 583/- | 583/- | 583/- | 583/- | 583/- |
| Loading edge height [mm] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] |
| Height of the open boot door [mm] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] |
| Boot opening height [mm] | 894 | 894 | 894 | 894 | 894 | 894 |
| Boot opening width min/max [mm] | 859/1067 | 859/1067 | 859/1067 | 859/1067 | 859/1067 | 859/1067 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5/7 | 5/7 | 5/7 | 5/7 | 5/7 | 5/7 |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 [33,6 LPG] | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms |
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar |
| Tyre dimensions front | 185/70 R14 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T |
| Tyre dimensions rear | 185/70 R14 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T |
| Wheel size front | 5.5Jx14 | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 |
| Wheel size rear | 5.5Jx14 | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 |
| Brake dimensions front | 280 | 280 | 280 | 280 | 280 | 280 |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 3,3 | 3,3 | 3,3 | 3,3 | 3,3 | 3,3 |
| Turning diameter track/circumference [m] | 11.1/11.6 | 11.1/11.6 | 11,1/11,6 | 11,1/11,6 | 11.1/11.6 | 11,1/11,6 |
| Overall length [mm] | 4498 | 4498 | 4498 | 4498 | 4498 | 4498 |
| Overall width without/including mirrors [mm] | 1751/- | 1751/- | 1751/2004 | 1751/2004 | 1751/- | 1751/2004 |
| Overall height [mm] | 1679 | 1679 | 1682 | 1682 | 1679 | 1682 |
| Wheelbase [mm] | 2810 | 2810 | 2810 | 2810 | 2810 | 2810 |
| Front wheel track [mm] | 1492 | 1492 | 1492 | 1492 | 1492 | 1492 |
| Rear wheel track [mm] | 1478 | 1478 | 1478 | 1478 | 1478 | 1478 |
| Forward overhang [mm] | 822 | 822 | 822 | 822 | 822 | 822 |
| Rear overhang [mm] | 866 | 866 | 866 | 866 | 866 | 866 |
| Clearance [mm] | 120 | 120 | 120 | 120 | 120 | 120 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1003 | 1003 | 1003 | 1003 | 1003 | 1003 |
| Headroom rear [mm] | 952 | 952 | 952 | 952 | 952 | 952 |
| Front elbow/shoulder width [mm] | 1408/1401 | 1408/1401 | 1408/1401 | 1408/1401 | 1408/1401 | 1408/1401 |
| Rear elbow/shoulder width [mm] | 1466/1424 | 1466/1424 | 1466/1424 | 1466/1424 | 1466/1424 | 1466/1424 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | 177/- | 177/- | 177/- | 177/- | 177/- | 177/- |
| Third row of seats, headroom [mm] | 867 | 867 | 867 | 867 | 867 | 867 |
| Third row elbow/shoulder width [mm] | 1357/1300 | 1357/1300 | 1357/1300 | 1357/1300 | 1357/1300 | 1357/1300 |
| 1.5 dCi | 1.5 dCi 90 | 1.5 dCi | 1.5 dCi 109 | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 2015 | from 2015 to | from to 2015 | from 2015 to | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/8 | 4/8 | 4/8 | 4/8 | ||
| Engine displacement [cm³] | 1461 | 1461 | 1461 | 1461 | ||
| Maximum output / speed [kW/min-1] | 66/3750 | 66/4000 | 79/4000 | 80/4000 | ||
| Maximum torque [Nm/min-1] | 200/1750 | 220/1750 | 240/1750 | 260/1750 | ||
| Bore and stroke [mm x mm] | 76,0 x 80,5 | 76,0 x 80,5 | 76,0 x 80,5 | 76,0 x 80,5 | ||
| Compression ratio | 15,5:1 | 15,5:1 | 15,5:1 | 15,5:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 5 gear manual | 5 gear manual | 6 gear manual | 6 gear manual | ||
| Drive specifications | - | - | - | - | ||
| Top speed [km/h] | 169 | 169 | 175 | 177 | ||
| Acceleration 0–100 km/h [s] | 12.4 | 12,3 | 11.6 | 11,2 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 4.9 | 4,3 | 5.3 | 4,4 | ||
| Out of town [l] | 3.8 | 3,8 | 4.0 | 3,8 | ||
| Combined [l] | 4.2 | 4,0 | 4.4 | 4,0 | ||
| CO2 emissions [g/km] | 109 | 103 | 116 | 105 | ||
| Emission standard | EU5 | Euro 6 | EU5 | Euro 6 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1280 | 1261 [1280 seven seats] | 1280 | 1280 [1280 seven seats] | ||
| Overall weight [kg] | 1870 | 1815 [1900 seven seats] | 1870 | 1860 [1920 seven seats] | ||
| Maximum trailer weight unbraked/braked [kg] | 640/1400 | 630/1400 [640/1400 seven seats] | 640/1400 | 640/1400 [640/1400 seven seats] | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | - | - | - | - | ||
| Boot volume [l] | 827 | 827 | 827 | 827 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2617 [- | -/2617 [- | -/2617 [- | -/2617 [- | ||
| Boot volume, third row of seats [l] | - | - | - | - | ||
| Boot volume, third row seats folded [l] | - | - | - | - | ||
| Boot length [mm] | 1180 | 1180 | 1180 | 1180 | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | 1174 [-/- | 1174 [-/- | 1174 [-/- | 1174 [-/- | ||
| Boot height to headliner/ceiling [mm] | 583/- | 583/- | 583/- | 583/- | ||
| Loading edge height [mm] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] | 610 [605 seven seats] | ||
| Height of the open boot door [mm] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | 2015 [2010 seven seats] | ||
| Boot opening height [mm] | 894 | 894 | 894 | 894 | ||
| Boot opening width min/max [mm] | 859/1067 | 859/1067 | 859/1067 | 859/1067 | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5/7 | 5/7 | 5/7 | 5/7 | ||
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms | MacPherson, lower triangular arms | ||
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | ||
| Tyre dimensions front | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | ||
| Tyre dimensions rear | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | 185/65R15 88T | ||
| Wheel size front | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 | ||
| Wheel size rear | 6Jx15 | 6Jx15 | 6Jx15 | 6Jx15 | ||
| Brake dimensions front | 280 | 280 | 280 | 280 | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | 3,3 | 3,3 | 3,3 | 3,3 | ||
| Turning diameter track/circumference [m] | 11.1/11.6 | 11,1/11,6 | 11.1/11.6 | 11,1/11,6 | ||
| Overall length [mm] | 4498 | 4498 | 4498 | 4498 | ||
| Overall width without/including mirrors [mm] | 1751/- | 1751/2004 | 1751/- | 1751/2004 | ||
| Overall height [mm] | 1679 | 1682 | 1679 | 1682 | ||
| Wheelbase [mm] | 2810 | 2810 | 2810 | 2810 | ||
| Front wheel track [mm] | 1492 | 1492 | 1492 | 1492 | ||
| Rear wheel track [mm] | 1478 | 1478 | 1478 | 1478 | ||
| Forward overhang [mm] | 822 | 822 | 822 | 822 | ||
| Rear overhang [mm] | 866 | 866 | 866 | 866 | ||
| Clearance [mm] | 120 | 120 | 120 | 120 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1003 | 1003 | 1003 | 1003 | ||
| Headroom rear [mm] | 952 | 952 | 952 | 952 | ||
| Front elbow/shoulder width [mm] | 1408/1401 | 1408/1401 | 1408/1401 | 1408/1401 | ||
| Rear elbow/shoulder width [mm] | 1466/1424 | 1466/1424 | 1466/1424 | 1466/1424 | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | 177/- | 177/- | 177/- | 177/- | ||
| Third row of seats, headroom [mm] | 867 | 867 | 867 | 867 | ||
| Third row elbow/shoulder width [mm] | 1357/1300 | 1357/1300 | 1357/1300 | 1357/1300 |
