Fiat Panda
Date of manufacture
2020 – to this day (Five-door hatchback)
2020 – to this day (Small SUV)
Platform
Fiat Mini platform
Manufacturing locations
Pomigliano d'Arco, Italy
Designer
Centro Stile Fiat
Tags
A-segment
Italian cars
The Fiat Panda is a modern and stylish car that has been manufactured since 2020. It is available as a five-door hatchback and small SUV, built on the Fiat Mini platform. It offers a wide range of engines, including petrol and hybrid power units. The highest speed is achieved by the 0.9 TwinAir Turbo Natural Power with a value of 170 km/h and the best acceleration 0-100 km/h in 12.7 seconds is achieved by the 0.9 TwinAir Turbo 4x4. The most economical variant is the 1.0 GSE Hybrid with a combined consumption of 4.1 l/100 km and CO2 emissions of 129 g/km. The luggage compartment offers a volume of 225 l for both body variants of the car, but unfortunately it did not maintain a full rating of 5 out of 5 points in the EURONCAP safety tests according to the 2018 methodology.
Car body style
Five-door hatchback
after upgrade (facelift)
Date of manufacture
2020 – to this dayInternal designation
319Engine size
Small SUV (Cross)
after upgrade (facelift)
Date of manufacture
2020 – to this dayInternal designation
319Engine size
Technical data
Five-door hatchback
| 0.9 TwinAir Turbo Natural Power | 0.9 TwinAir Turbo 4x4 | 1.0 GSE Hybrid | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Ignition supercharged | Ignition supercharged | Petrol + Electric | |||
| Number of cylinders/valves | 2/8 | 2/8 | 3/6 | |||
| Engine displacement [cm³] | 875 | 875 | 999 | |||
| Maximum output / speed [kW/min-1] | 59/5500 [52/5500 CNG] | 63/5500 | 51/6000 36 el. | |||
| Maximum torque [Nm/min-1] | 145/1900 [135/2500 CNG] | 145/1900 | 92/3500 50 el. | |||
| Bore and stroke [mm x mm] | 80,5 x 86,0 | 80,5 x 86,0 | 70,0 x 86.5 | |||
| Compression ratio | 10,0:1 | 10,0:1 | 12,0.1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | 4x4 | Front | |||
| Gearbox | 5 gear manual | 6 gear manual | 6 gear manual | |||
| Drive specifications | - |
| - | |||
| Top speed [km/h] | 170 [162 CNG] | 164 | 164 | |||
| Acceleration 0–100 km/h [s] | 12.7 [14.1 CNG] | 12.7 | 13.9 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | - | 6.3 | 5.5 | |||
| Out of town [l] | - | 5.4 | 3.2 | |||
| Combined [l] | 5.8 [5.7 kg] | 5.7 | 4.1 | |||
| CO2 emissions [g/km] | 133 [102 CNG] | 131 | 93 | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | 6.4 [5.0 kg] | 6.9 | - | |||
| CO2 emissions [g/km] | 148 [111 CNG] | 156 | 129-116 | |||
| Emission standard | Euro 6d | Euro 6d | Euro 6d | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| System voltage [V] | - | - | 12 | |||
| Battery type and capacity | - | - | Lithium-Ionen-Akkumulator, 11 A⋅h | |||
| Range with fully charged battery [km] | - | - | - | |||
| Charging time | - | - | - | |||
| Number of modules/cells | - | - | - | |||
| Battery weight [kg] | - | - | - | |||
| Charger | - | - | - | |||
| Standby weight [kg] | 1155 | 1165 | 1055 | |||
| Overall weight [kg] | 1550 [1530 four seats] | 1585 [1530 four seats] | 1440 [1420 four seats] | |||
| Maximum trailer weight unbraked/braked [kg] | - | 400/800 | - | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | - | - | 55/- | |||
| Boot volume [l] | 200 | 225 | 225 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/845 | -/870 | -/870 | |||
| Boot length [mm] | - | - | - | |||
| Boot length with rear seats folded [mm] | - | - | - | |||
| Boot width between wheels/max [mm] | - | - | - | |||
| Boot height to headliner/ceiling [mm] | - | - | - | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 4-5 | 4-5 | 4-5 | |||
| Fuel tank volume [l] | 35 [12 kg] | 35 | 38 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 175/65 R15 84T | 175/65 R14 82T | 175/65 R14 82T | |||
| Tyre dimensions rear | 175/65 R15 84T | 175/65 R14 82T | 175/65 R14 82T | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | 257 x 22 | 257 x 22 | 257 x 22 | |||
| Brake dimensions rear | 240 x 11 | 240 x 11 | - | |||
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 9.7/- | 9.7/- | 9.3/- | |||
| Overall length [mm] | 3686 | 3686 | 3653 | |||
| Overall width without/including mirrors [mm] | 1672/1882 | 1672/1882 | 1643/1882 | |||
| Overall height [mm] | 1605 | 1635 | 1551 | |||
| Wheelbase [mm] | 2300 | 2300 | 2300 | |||
| Front wheel track [mm] | 1414 | 1416 | 1409 | |||
| Rear wheel track [mm] | 1408 | 1412 | 1407 | |||
| Forward overhang [mm] | - | - | - | |||
| Rear overhang [mm] | - | - | - | |||
| Clearance [mm] | - | - | - | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | - | - | - | |||
| Headroom rear [mm] | - | - | - | |||
| Front elbow/shoulder width [mm] | - | - | - | |||
| Rear elbow/shoulder width [mm] | - | - | - | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - |
Small SUV (Cross)
| 0.9 TwinAir Turbo Natural Power | 0.9 TwinAir Turbo 4x4 | 1.0 GSE Hybrid | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | |||
| Engine type | Ignition supercharged | Ignition supercharged | Petrol + Electric | |||
| Number of cylinders/valves | 2/8 | 2/8 | 3/6 | |||
| Engine displacement [cm³] | 875 | 875 | 999 | |||
| Maximum output / speed [kW/min-1] | 59/5500 [52/5500 CNG] | 63/5500 | 51/6000 36 el. | |||
| Maximum torque [Nm/min-1] | 145/1900 [135/2500 CNG] | 145/1900 | 92/3500 50 el. | |||
| Bore and stroke [mm x mm] | 80,5 x 86,0 | 80,5 x 86,0 | 70,0 x 86.5 | |||
| Compression ratio | 10,0:1 | 10,0:1 | 12,0.1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | 4x4 | Front | |||
| Gearbox | 5 gear manual | 6 gear manual | 6 gear manual | |||
| Drive specifications | - |
| - | |||
| Top speed [km/h] | 170 [162 CNG] | 164 | 164 | |||
| Acceleration 0–100 km/h [s] | 12.7 [14.1 CNG] | 12.7 | 13.9 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | - | 6.3 | 5.5 | |||
| Out of town [l] | - | 5.4 | 3.2 | |||
| Combined [l] | 5.8 [5.7 kg] | 5.7 | 4.1 | |||
| CO2 emissions [g/km] | 133 [102 CNG] | 131 | 93 | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | 6.4 [5.0 kg] | 6.9 | - | |||
| CO2 emissions [g/km] | 148 [111 CNG] | 156 | 129-116 | |||
| Emission standard | Euro 6d | Euro 6d | Euro 6d | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| System voltage [V] | - | - | 12 | |||
| Battery type and capacity | - | - | Lithium-Ionen-Akkumulator, 11 A⋅h | |||
| Range with fully charged battery [km] | - | - | - | |||
| Charging time | - | - | - | |||
| Number of modules/cells | - | - | - | |||
| Battery weight [kg] | - | - | - | |||
| Charger | - | - | - | |||
| Standby weight [kg] | 1155 | 1165 | 1055 | |||
| Overall weight [kg] | 1550 [1530 four seats] | 1585 [1530 four seats] | 1440 [1420 four seats] | |||
| Maximum trailer weight unbraked/braked [kg] | - | 400/800 | - | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | - | - | 55/- | |||
| Boot volume [l] | 200 | 225 | 225 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/845 | -/870 | -/870 | |||
| Boot length [mm] | - | - | - | |||
| Boot length with rear seats folded [mm] | - | - | - | |||
| Boot width between wheels/max [mm] | - | - | - | |||
| Boot height to headliner/ceiling [mm] | - | - | - | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 4-5 | 4-5 | 4-5 | |||
| Fuel tank volume [l] | 35 [12 kg] | 35 | 38 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 175/65 R15 84T | 175/65 R15 84T | 175/65 R15 84T | |||
| Tyre dimensions rear | 175/65 R15 84T | 175/65 R15 84T | 175/65 R15 84T | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | 257 x 22 | 257 x 22 | 257 x 22 | |||
| Brake dimensions rear | 240 x 11 | 240 x 11 | - | |||
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 9.7/- | 9.7/- | 9.3/- | |||
| Overall length [mm] | 3705 | 3705 | 3705 | |||
| Overall width without/including mirrors [mm] | 1662/1882 | 1662/1882 | 1662/1882 | |||
| Overall height [mm] | 1657 | 1657 | 1657 | |||
| Wheelbase [mm] | 2300 | 2300 | 2300 | |||
| Front wheel track [mm] | 1403 | 1403 | 1403 | |||
| Rear wheel track [mm] | 1406 | 1406 | 1406 | |||
| Forward overhang [mm] | - | - | - | |||
| Rear overhang [mm] | - | - | - | |||
| Clearance [mm] | - | - | - | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | - | - | - | |||
| Headroom rear [mm] | - | - | - | |||
| Front elbow/shoulder width [mm] | - | - | - | |||
| Rear elbow/shoulder width [mm] | - | - | - | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - | |||
| Rating | - | - |    | |||
| Clean Air Index | - | - | 4.3/10 | |||
| Energy Efficiency Index | - | - | 5.7/10 | |||
| GHG index | - | - | 4.8/10 |
