Fiat Qubo

Qubo 225 2016

Date of manufacture

2016 – 2020 (Small MPV)

Platform

GM Fiat Small platform

Manufacturing locations

Bursa, Turkey

Designer

-

Tags

Small MPV
Italian cars
The small MPV Fiat Qubo is the only body version of the car produced since 2016 in Turkey on the GM Fiat Small platform. The engine range includes petrol and diesel engines, the most powerful of which is the 1.3 Multijet with 70 kW. The best dynamics is provided by the same model, which reaches a maximum speed of 167 km/h and accelerates from 0-100 km/h in 11.9 seconds. The most economical variant 1.3 Multijet has a combined consumption of 4.8 l/100 km and CO2 emissions of 126 g/km. The luggage compartment with a size of 330 l then allows you to store valuable loads and other things necessary for travelling.

Car body style

Small MPV

after upgrade (facelift)
Date of manufacture
2016 – 2020
Internal designation
225

Technical data

Small MPV

1.4 8v 1.4 Natural Power 1.3 Multijet 1.3 Multijet
Date of sale----
Engine typePetrolPetrolDiesel superchargedDiesel supercharged
Number of cylinders/valves4/84/84/164/16
Engine displacement [cm³]1368136812481248
Maximum output / speed [kW/min-1]
57/6000
57/6000 [51/6000 CNG]
59/3750
70/3750
Maximum torque [Nm/min-1]
115/300
115/3250 [104/3250 CNG]
200/1500
200/1500
Drive axleFrontFrontFrontFront
Gearbox5 gear manual5 gear manual5 gear manual5 gear manual
Top speed [km/h]155155 [149 CNG]161167-170
Acceleration 0–100 km/h [s]14.715.9 [17.7 CNG]13.911.9-12.2
City [l]9.5-8.99.7-8.9 [6.3-5.6 kg]6.5-4.85.9-4.9
Out of town [l]6.4-5.86.6-5.5 [4.2-3.5 kg]4.4-3.64.1-3.6
Combined [l]7.5-6.97.8-6.8 [5.1-4.3 kg]5.2-4.04.8-4.1
CO2 emissions [g/km]172-161157 [119 CNG]161-106126-107
Emission standardEU6 - EURO 6D-TempEU6 - EURO 6D-TempEU6 - EURO 6D-TempEU6 - EURO 6D-Temp
Standby weight [kg]1180-12551290-13651200-13051200-1305
Overall weight [kg]169017501710-17401710-1740
Maximum trailer weight unbraked/braked [kg]400/600-400/1000400/1000
Boot volume [l]330250330330
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/2500-/2400-/2500-/2500
Number of doors5555
Number of seats5555
Fuel tank volume [l]4545 [13.2 kg]4545
AdBlue tank volume [l]----
Overall length [mm]3957395739573957
Overall width without/including mirrors [mm]1716/-1716/-1716/-1716/-
Overall height [mm]1735173517351735
Wheelbase [mm]2513251325132513
Headroom front [mm]----
Headroom rear [mm]----
Front elbow/shoulder width [mm]----
Rear elbow/shoulder width [mm]----

Gallery

Fiat Qubo 225 facelift 2016 interiorFiat Qubo 225 facelift 2016 front seatsFiat Qubo 225 facelift 2016 rear folding seats
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
