Basic information Technical Specifications Gallery

Honda Civic

Date of manufacture

2015 – 2017 (Five-door hatchback)

2015 – 2017 (Estate)

Platform

Manufacturing locations

Swindon, United Kingdom

Designer

Noriyuki Ishii

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2015 – 2017

Internal designation

Engine size

Petrol

Diesel

Estate (Tourer)

after upgrade (facelift)

Date of manufacture

2015 – 2017

Internal designation

Engine size

Petrol

1.8 I-VTEC

Diesel

1.6 I-DTEC

Euro NCAP

Test year 2012

pre-facelift version (2012)

Technical data

Five-door hatchback

	1.4 I-VTEC	1.8 I-VTEC	1.8 I-VTEC	2.0 VTEC TURBO	1.6 I-DTEC
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1339	1798	1798	1996	1597
Maximum output / speed [kW/min-1]	73/6000	104/6500	104/6500	228/6500	88/4000
Maximum torque [Nm/min-1]	127/4800	174/4300	174/4300	400/2500-4500	300/2000
Bore and stroke [mm x mm]	73,0 x 80,0	81,0 x 87,3	81,0 x 87,3	86,0 x 85,9	76,0 x 88,0
Compression ratio	10,5:1	10,6:1	10,6:1	9,8:1	16,0:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	variable timing of intake valves i‐VTEC start&stop system	variable timing of intake valves i‐VTEC start&stop system	variable timing of intake valves i‐VTEC start&stop system	variable timing of intake valves i‐VTEC s Dual‐VTC turbo-supercharged start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter start&stop system

Drive axle	Front	Front	Front	Front	Front
Gearbox	6 gear manual	6 gear manual	5 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	-	automatic gearbox	-	-

Top speed [km/h]	187	215	210	270	207
Acceleration 0–100 km/h [s]	13.0-14.0	8.7-9.7	10.4-11.4	5.7	10.2-10.8
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	6.6-6.7	7.3-7.6	8.7	9.4	3.9-4.1
Out of town [l]	4.7-4.8	4.9-5.2	4.8-5.0	6.1	3.3-3.6
Combined [l]	5.4-5.5	5.8-6.1	6.3-6.4	7.3	3.6-3.7
CO2 emissions [g/km]	128-131	136-145	148-150	170	94-98

Emission standard	EU6	EU6	EU6	EU6	EU5
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1255-1346	1278-1412	1313-1443	1453-1468	1378-1497
Overall weight [kg]	1680	1750	1790	1700	1870
Maximum trailer weight unbraked/braked [kg]	500/1200	500/1400	500/1000	-	500/1400
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-	75/-

Boot volume [l]	477	477	477	475-498	477
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1378	-/1378	-/1378	-/1427	-/1378
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	4	5
Number of seats	5	5	5	5	5
Fuel tank volume [l]	50	50	50	50	50
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	195/65 R15 87T	195/65 R15 87T	195/65 R15 87T	235/35 R19 91Y	205/55 R16 91V
Tyre dimensions rear	195/65 R15 87T	195/65 R15 87T	195/65 R15 87T	235/35 R19 91Y	205/55 R16 91V
Wheel size front	6.0J x 15 ET45	6.0J x 15 ET45	6.0J x 15 ET45	8.5J x 19 ET60	6.5J x 16 ET45
Wheel size rear	6.0J x 15 ET45	6.0J x 15 ET45	6.0J x 15 ET45	8.5J x 19 ET60	6.5J x 16 ET45
Brake dimensions front	280	280	280	350	293
Brake dimensions rear	276	276	276	296	276
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	10.50/11.28	10.50/11.28	10.50/11.28	-/12.59	10.50/11.28

Overall length [mm]	4370	4370	4370	4390	4370
Overall width without/including mirrors [mm]	1770/-	1770/-	1770/-	1878/-	1770/-
Overall height [mm]	1440	1440	1440	1466	1440
Wheelbase [mm]	2595	2595	2595	2595	2595
Front wheel track [mm]	1540	1540	1540	1605	1540
Rear wheel track [mm]	1540	1540	1540	1528	1540
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	140	140	140	118	140
Wading depth [mm]	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Estate (Tourer)

	1.8 I-VTEC	1.8 I-VTEC	1.6 I-DTEC
Date of sale	-	-	-
Engine type	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16
Engine displacement [cm³]	1798	1798	1597
Maximum output / speed [kW/min-1]	104/6500	104/6500	88/4000
Maximum torque [Nm/min-1]	174/4300	174/4300	300/2000
Bore and stroke [mm x mm]	81,0 x 87,3	81,0 x 87,3	76,0 x 88,0
Compression ratio	10,6:1	10,6:1	16,0:1
Oil volume [l]	-	-	-
Coolant volume [l]	-	-	-
Technical specifications	variable timing of intake valves i‐VTEC start&stop system	variable timing of intake valves i‐VTEC start&stop system	direct injection Common Rail turbocharger with variable blade geometry particulate filter start&stop system

Drive axle	Front	Front	Front
Gearbox	6 gear manual	5 gear automatic	6 gear manual
Drive specifications	-	automatic gearbox	-

Top speed [km/h]	210	205	195
Acceleration 0–100 km/h [s]	9.2-9.5	11.1-11.4	10.1-10.5
Acceleration 0–80 km/h [s]	-	-	-
Acceleration 80–120 km/h [s]	-	-	-

City [l]	7.7-7.8	8.9	4.0-4.3
Out of town [l]	5.3-5.5	5.3	3.6-3.8
Combined [l]	6.2-6.4	6.6	3.8-3.9
CO2 emissions [g/km]	146-149	155	99-103

Emission standard	EU6	EU6	EU5
Standard for fuel consumption measurement	-	-	-
Energy class	-	-	-
Stationary vehicle noise [dB]	-	-	-
Driving noise [dB]	-	-	-

Standby weight [kg]	1359-1425	1388-1453	1412
Overall weight [kg]	1790	1830	1910
Maximum trailer weight unbraked/braked [kg]	500/1400	500/1000	500/1400
Maximum front/rear axle load [kg]	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-
Maximum load on roof/carrier [kg]	75/-	75/-	75/-

Boot volume [l]	624	624	624
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1668	-/1668	-/1668
Boot length [mm]	-	-	-
Boot length with rear seats folded [mm]	-	-	-
Boot width between wheels/max [mm]	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-
Loading edge height [mm]	-	-	-
Height of the open boot door [mm]	-	-	-
Boot opening height [mm]	-	-	-
Boot opening width min/max [mm]	-	-	-

Number of doors	5	5	5
Number of seats	5	5	5
Fuel tank volume [l]	50	50	50
AdBlue tank volume [l]	-	-	-
Air resistance [Cd]	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar	torsion bar
Tyre dimensions front	205/55 R16 88V	205/55 R16 88V	205/55 R16 88V
Tyre dimensions rear	205/55 R16 88V	205/55 R16 88V	205/55 R16 88V
Wheel size front	6.5J x 16 ET45	6.5J x 16 ET45	6.5J x 16 ET45
Wheel size rear	6.5J x 16 ET45	6.5J x 16 ET45	6.5J x 16 ET45
Brake dimensions front	293	293	293
Brake dimensions rear	276	276	276
Steering	-	-	-
Number of steering wheel turns	-	-	-
Turning diameter track/circumference [m]	10.50/11.28	10.50/11.28	10.50/11.28

Overall length [mm]	4590	4590	4590
Overall width without/including mirrors [mm]	1795/-	1795/-	1795/-
Overall height [mm]	1435	1435	1435
Wheelbase [mm]	2595	2595	2595
Front wheel track [mm]	1540	1540	1540
Rear wheel track [mm]	1540	1540	1540
Forward overhang [mm]	-	-	-
Rear overhang [mm]	-	-	-
Clearance [mm]	140	140	140
Wading depth [mm]	-	-	-
Approach angle front [°]	-	-	-
Approach angle rear [°]	-	-	-
Transition angle [°]	-	-	-
Climbing rate [°]	-	-	-
Maximum side tilt [°]	-	-	-

Headroom front [mm]	-	-	-
Headroom rear [mm]	-	-	-
Front elbow/shoulder width [mm]	-	-	-
Rear elbow/shoulder width [mm]	-	-	-
Legroom front knees/total [mm]	-	-	-
Legroom rear knees/total [mm]	-	-	-

Gallery

Honda Civic FK facelift 2015 typeR interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
