Honda Civic Sedan

Date of manufacture

2006 – 2011 (Sedan)

Platform

Manufacturing locations

Suzuka, Japan

Designer

Motoaki Minowa

Car body style

Sedan

Date of manufacture

2006 – 2011

Internal designation

FA, FD

Engine size

Petrol

1.8 i-VTEC

Petrol + Electric

1.3 Hybrid

Euro NCAP

Technical data

Sedan

	1.8 i-VTEC	1.8 i-VTEC	1.3 Hybrid
Date of sale	-	-	-
Engine type	Petrol	Petrol	Petrol + Electric
Number of cylinders/valves	4/8	4/8	4/8
Engine displacement [cm³]	1799	1799	1339
Maximum output / speed [kW/min-1]	103/6300	103/6300	70/6000 15/2000 el.
Maximum torque [Nm/min-1]	174/4300	174/4300	123/4600 103/0-1160 el.
Bore and stroke [mm x mm]	81,0 x 87,3	81,0 x 87,3	73,0 x 80,0
Compression ratio	10,5:1	10,5:1	10,8:1
Oil volume [l]	-	-	-
Coolant volume [l]	-	-	-
Technical specifications	variable timing of intake valves i‐VTEC	variable timing of intake valves i‐VTEC	Mild Hybrid IMA variable timing of intake valves i‐VTEC start&stop system

Drive axle	Front	Front	Front
Gearbox	6 gear manual	5 gear automatic	1 gear automatic
Drive specifications	-	automatic gearbox	automatic gearbox with one variable ratio CVT s jedním proměnným převodem

Top speed [km/h]	200	200	185
Acceleration 0–100 km/h [s]	9.0	10.4	12.1
Acceleration 0–80 km/h [s]	-	-	-
Acceleration 80–120 km/h [s]	-	-	-

City [l]	8.7	9.5	5.2
Out of town [l]	5.5	5.1	4.3
Combined [l]	6.6	6.7	4.6
CO2 emissions [g/km]	156	159	109

Emission standard	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-
Energy class	-	-	-
Stationary vehicle noise [dB]	-	-	-
Driving noise [dB]	-	-	-

Standby weight [kg]	1269	1299	1368
Overall weight [kg]	1675	1705	1720
Maximum trailer weight unbraked/braked [kg]	500/1200	500/1000	-
Maximum front/rear axle load [kg]	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-
Maximum load on roof/carrier [kg]	55/-	55/-	55/-

Boot volume [l]	375	375	350
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-
Boot length [mm]	-	-	-
Boot length with rear seats folded [mm]	-	-	-
Boot width between wheels/max [mm]	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-
Loading edge height [mm]	-	-	-
Height of the open boot door [mm]	-	-	-
Boot opening height [mm]	-	-	-
Boot opening width min/max [mm]	-	-	-

Number of doors	4	4	4
Number of seats	5	5	5
Fuel tank volume [l]	50	50	50
AdBlue tank volume [l]	-	-	-
Air resistance [Cd]	-	-	-
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	double wishbone with stabiliser	double wishbone with stabiliser	double wishbone with stabiliser
Tyre dimensions front	195/65 R15 91H	205/55 R16 91V	195/65 R15 91H
Tyre dimensions rear	195/65 R15 91H	205/55 R16 91V	195/65 R15 91H
Wheel size front	6J x 15	6.5J x 16	6J x 15
Wheel size rear	6J x 15	6.5J x 16	6J x 15
Brake dimensions front	282	282	282
Brake dimensions rear	260	260	260
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-
Turning diameter track/circumference [m]	10.8/11.6	10.8/11.6	10.8/11.6

Overall length [mm]	4545	4545	4545
Overall width without/including mirrors [mm]	1750/-	1750/-	1750/-
Overall height [mm]	1435	1435	1430
Wheelbase [mm]	2700	2700	2700
Front wheel track [mm]	1505	1505	1505
Rear wheel track [mm]	1545	1545	1545
Forward overhang [mm]	-	-	-
Rear overhang [mm]	-	-	-
Clearance [mm]	154	154	145
Wading depth [mm]	-	-	-
Approach angle front [°]	-	-	-
Approach angle rear [°]	-	-	-
Transition angle [°]	-	-	-
Climbing rate [°]	-	-	-
Maximum side tilt [°]	-	-	-

Headroom front [mm]	-	-	-
Headroom rear [mm]	-	-	-
Front elbow/shoulder width [mm]	-	-	-
Rear elbow/shoulder width [mm]	-	-	-
Legroom front knees/total [mm]	-	-	-
Legroom rear knees/total [mm]	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
