Hyundai i20
Date of manufacture
9/2020 – to this day (Five-door hatchback)
Platform
Hyundai-Kia K2
Manufacturing locations
İzmit, Turkey
Designer
Thomas Bürkle
Tags
B-segment
Korean cars
The Hyundai i20 is a modern five-door hatchback that was released in 2020. It is produced in the Turkish Hyundai-Kia K2 factory and offers a wide range of petrol engines. The highest power is provided by the 1.0 T-GDI Mild Hybrid with a maximum power of 60 kW, allowing it to reach a top speed of 190 km/h and the best acceleration from 0-100 km/h in 10.1 seconds. This model also has the lowest consumption of 5.4 l/100 km and emissions of 123 g/km. The trunk has a capacity of 262 liters.
Car body style
Five-door hatchback
Date of manufacture
9/2020 – to this dayInternal designation
BC3Technical data
Five-door hatchback
| 1.2i | 1.0 T-GDI | 1.0 T-GDI | 1.0 T-GDI Mild Hybrid | 1.0 T-GDI Mild Hybrid | 1.0 T-GDI Mild Hybrid | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 3/12 | 3/12 | 3/12 | 3/12 | 3/12 |
| Engine displacement [cm³] | 1197 | 998 | 998 | 998 | 998 | 998 |
| Maximum output / speed [kW/min-1] | 62/6000 | 73,6/4500 | 73,6/4500 | 74/4500-6000 | 74/4500-6000 | 88,3/6000 |
| Maximum torque [Nm/min-1] | 117,7/4200 | 171,6/1500-4000 | 171,6/1500-4000 | 172/1500-4000 | 172/1500-4000 | 200,1/2000-3500 |
| Bore and stroke [mm x mm] | 71.0 x 76.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 | 71.0 x 84.0 |
| Compression ratio | 11.0:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 173 | 188 | 185 | 188 | 185 | 190 |
| Acceleration 0–100 km/h [s] | 13,1 | 10,4 | 11,4 | 10,4 | 11.4 | 10,1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7,0-7,2 | 5,5-5,9 | 5,4-5,9 | 5.0 | 5,6 | 5,9-6,2 |
| Out of town [l] | 4,8-4,9 | 4,3-4,6 | 4,5-4,7 | 4,0 | 4,2 | 4,4-4,6 |
| Combined [l] | 5,6-5,8 | 4,8-5,1 | 4,8-5,2 | 4.4 | 4.7 | 5,0-5,2 |
| CO2 emissions [g/km] | 129-132 | 109-117 | 111-118 | 100 | 108 | 114-119 |
| Low speed [l] | 6,8-7,2 | 6,7-7,1 | 6,8-7,3 | - | - | 6,8-7,4 |
| Medium speed [l] | 5,3-5,8 | 5,2-5,7 | 5,2-5,9 | - | - | 5,2-5,8 |
| High speed [l] | 5,2-5,5 | 4,7-5,1 | 4,8-5,4 | - | - | 4,7-5,3 |
| Extra high speed [l] | 6,6-6,9 | 6,0-6,6 | 6,0-6,6 | - | - | 6,1-6,7 |
| Combined speed [l] | 5,9-6,3 | 5,5-6,0 | 5,6-6,2 | 5.4 | 5.6 | 5,6-6,1 |
| CO2 emissions [g/km] | 133-142 | 126-137 | 127-141 | 123 | 128 | 127-140 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | 48 | 48 | 48 |
| Battery type and capacity | - | - | - | Lithium polymer, 0.46 kWh | Lithium polymer, 0.46 kWh | Lithium polymer, 0.46 kWh |
| Range with fully charged battery [km] | - | - | - | - | - | - |
| Charging time | - | - | - | - | - | - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1013-1123 | 1065-1175 | 1090-1200 | 1090-1200 | 1115-1225 | 1090-1200 |
| Overall weight [kg] | 1550 | 1600 | 1630 | 1620 | 1650 | 1620 |
| Maximum trailer weight unbraked/braked [kg] | 450/910 | 450/1110 | 450/1110 | 450/1110 | 450/1110 | 450/1110 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 70/- | 70/- | 70/- | 70/- | 70/- | 70/- |
| Boot volume [l] | 352 | 352 | 352 | 262 | 262 | 262 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1165 | -/1165 | -/1165 | -/1075 | -/1075 | -/1075 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 40 | 40 | 40 | 40 | 40 | 40 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser | MacPherson, triangular arms, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar | twist beam axle with trailing arms and torsion bar |
| Tyre dimensions front | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 |
| Tyre dimensions rear | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 | 185/65 R15 |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 256 or 280 | 256 or 280 | 256 or 280 | 256 or 280 | 256 or 280 | 256 or 280 |
| Brake dimensions rear | 203 [262 x 10 subject to a surcharge] | 203 [262 x 10 subject to a surcharge] | 203 [262 x 10 subject to a surcharge] | 203 [262 x 10 subject to a surcharge] | 203 [262 x 10 subject to a surcharge] | 203 [262 x 10 subject to a surcharge] |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 |
| Turning diameter track/circumference [m] | 10.2/- | 10.2/- | 10.2/- | 10.2/- | 10.2/- | 10.2/- |
| Overall length [mm] | 4040 | 4040 | 4040 | 4040 | 4040 | 4040 |
| Overall width without/including mirrors [mm] | 1775/- | 1775/- | 1775/- | 1775/- | 1775/- | 1775/- |
| Overall height [mm] | 1450 | 1450 | 1450 | 1450 | 1450 | 1450 |
| Wheelbase [mm] | 2580 | 2580 | 2580 | 2580 | 2580 | 2580 |
| Front wheel track [mm] | 1545 | 1545 | 1545 | 1545 | 1545 | 1545 |
| Rear wheel track [mm] | 1549 | 1549 | 1549 | 1549 | 1549 | 1549 |
| Forward overhang [mm] | 810 | 810 | 810 | 810 | 810 | 810 |
| Rear overhang [mm] | 650 | 650 | 650 | 650 | 650 | 650 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 985 | 985 | 985 | 985 | 985 | 985 |
| Headroom rear [mm] | 960 | 960 | 960 | 960 | 960 | 960 |
| Front elbow/shoulder width [mm] | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 | 1352/1395 |
| Rear elbow/shoulder width [mm] | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 | 1316/1390 |
| Legroom front knees/total [mm] | -/1072 | -/1072 | -/1072 | -/1072 | -/1072 | -/1072 |
| Legroom rear knees/total [mm] | -/882 | -/882 | -/882 | -/882 | -/882 | -/882 |
| 1.0 T-GDI Mild Hybrid | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Ignition supercharged | |||||
| Number of cylinders/valves | 3/12 | |||||
| Engine displacement [cm³] | 998 | |||||
| Maximum output / speed [kW/min-1] | 88,3/6000 | |||||
| Maximum torque [Nm/min-1] | 200,1/2000-3500 | |||||
| Bore and stroke [mm x mm] | 71.0 x 84.0 | |||||
| Compression ratio | 10,5:1 | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Front | |||||
| Gearbox | 7 gear automatic | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 190 | |||||
| Acceleration 0–100 km/h [s] | 10,3 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | 5,6-5,9 | |||||
| Out of town [l] | 4,6-4,9 | |||||
| Combined [l] | 5,0-5,3 | |||||
| CO2 emissions [g/km] | 114-121 | |||||
| Low speed [l] | 7,0-7,7 | |||||
| Medium speed [l] | 5,4-6,1 | |||||
| High speed [l] | 5,0-5,5 | |||||
| Extra high speed [l] | 6,4-7,0 | |||||
| Combined speed [l] | 5,8-6,4 | |||||
| CO2 emissions [g/km] | 133-146 | |||||
| Emission standard | Euro 6d | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| System voltage [V] | 48 | |||||
| Battery type and capacity | Lithium polymer, 0.46 kWh | |||||
| Range with fully charged battery [km] | - | |||||
| Charging time | - | |||||
| Number of modules/cells | - | |||||
| Battery weight [kg] | - | |||||
| Charger | - | |||||
| Standby weight [kg] | 1115-1225 | |||||
| Overall weight [kg] | 1650 | |||||
| Maximum trailer weight unbraked/braked [kg] | 450/1110 | |||||
| Maximum front/rear axle load [kg] | - | |||||
| Maximum vertical load on the tow bar [kg] | 75 | |||||
| Maximum load on roof/carrier [kg] | 70/- | |||||
| Boot volume [l] | 262 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1075 | |||||
| Boot length [mm] | - | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | - | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 5 | |||||
| Number of seats | 5 | |||||
| Fuel tank volume [l] | 40 | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | - | |||||
| Front suspension | MacPherson, triangular arms, torsion stabiliser | |||||
| Rear suspension | twist beam axle with trailing arms and torsion bar | |||||
| Tyre dimensions front | 185/65 R15 | |||||
| Tyre dimensions rear | 185/65 R15 | |||||
| Wheel size front | - | |||||
| Wheel size rear | - | |||||
| Brake dimensions front | 256 or 280 | |||||
| Brake dimensions rear | 203 [262 x 10 subject to a surcharge] | |||||
| Steering | - | |||||
| Number of steering wheel turns | 2.7 | |||||
| Turning diameter track/circumference [m] | 10.2/- | |||||
| Overall length [mm] | 4040 | |||||
| Overall width without/including mirrors [mm] | 1775/- | |||||
| Overall height [mm] | 1450 | |||||
| Wheelbase [mm] | 2580 | |||||
| Front wheel track [mm] | 1545 | |||||
| Rear wheel track [mm] | 1549 | |||||
| Forward overhang [mm] | 810 | |||||
| Rear overhang [mm] | 650 | |||||
| Clearance [mm] | 140 | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | 985 | |||||
| Headroom rear [mm] | 960 | |||||
| Front elbow/shoulder width [mm] | 1352/1395 | |||||
| Rear elbow/shoulder width [mm] | 1316/1390 | |||||
| Legroom front knees/total [mm] | -/1072 | |||||
| Legroom rear knees/total [mm] | -/882 |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
