Hyundai Nexo
Date of manufacture
2018 – to this day (Medium SUV)
Platform
-
Manufacturing locations
Ulsan, South Korea
Designer
Yong Jun Heo
Tags
Compact SUV
Korean cars
Hydrogen powered
The Hyundai Nexo is a mid-size SUV produced since 2018 in South Korea. It offers only electric motors with a maximum power of 120 kW, making it the fastest version. The top speed is 179 km/h and the best 0-100 km/h acceleration takes 9.2 seconds. Fuel consumption is 0.95 kg/100 km and emissions are 0 g/km. The trunk volume is 461 l. In terms of safety, the EURONCAP model in 2018 achieved a rating of 5 out of 5.
Car body style
Technical data
Medium SUV
| Nexo | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Electric | |||||
| Number of cylinders/valves | - | |||||
| Engine displacement [cm³] | - | |||||
| Maximum output / speed [kW/min-1] | 120 | |||||
| Maximum torque [Nm/min-1] | 395 | |||||
| Bore and stroke [mm x mm] | - | |||||
| Compression ratio | - | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Front | |||||
| Gearbox | 1 gear automatic | |||||
| Drive specifications |
| |||||
| Top speed [km/h] | 179 | |||||
| Acceleration 0–100 km/h [s] | 9.2 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | 7.4 | |||||
| City [l] | 0.89 kg | |||||
| Out of town [l] | 0.77 kg | |||||
| Combined [l] | 0.84 kg | |||||
| CO2 emissions [g/km] | 0 | |||||
| Low speed [l] | - | |||||
| Medium speed [l] | - | |||||
| High speed [l] | - | |||||
| Extra high speed [l] | - | |||||
| Combined speed [l] | 0.95 kg | |||||
| CO2 emissions [g/km] | 0 | |||||
| Emission standard | - | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | - | |||||
| System voltage [V] | - | |||||
| Battery type and capacity | Lithium polymer, 1.56 kWh | |||||
| Range with fully charged battery [km] | 666 | |||||
| Charging time | - | |||||
| Number of modules/cells | - | |||||
| Battery weight [kg] | - | |||||
| Charger | - | |||||
| Standby weight [kg] | 1889-1948 | |||||
| Overall weight [kg] | 2340 | |||||
| Maximum trailer weight unbraked/braked [kg] | - | |||||
| Maximum front/rear axle load [kg] | - | |||||
| Maximum vertical load on the tow bar [kg] | - | |||||
| Maximum load on roof/carrier [kg] | - | |||||
| Boot volume [l] | 461 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1466 | |||||
| Boot length [mm] | - | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | - | |||||
| Boot height to headliner/ceiling [mm] | - | |||||
| Loading edge height [mm] | - | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | - | |||||
| Number of doors | 5 | |||||
| Number of seats | 5 | |||||
| Fuel tank volume [l] | 156.6 (3x 52.5) [6.3 kg] | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | 0.329 | |||||
| Front suspension | MacPherson | |||||
| Rear suspension | multilink | |||||
| Tyre dimensions front | 225/60 R17 | |||||
| Tyre dimensions rear | 225/60 R17 | |||||
| Wheel size front | 7.0J x 17 | |||||
| Wheel size rear | 7.0J x 17 | |||||
| Brake dimensions front | - | |||||
| Brake dimensions rear | - | |||||
| Steering | - | |||||
| Number of steering wheel turns | - | |||||
| Turning diameter track/circumference [m] | 11.2/- | |||||
| Overall length [mm] | 4670 | |||||
| Overall width without/including mirrors [mm] | 1860/- | |||||
| Overall height [mm] | 1630 | |||||
| Wheelbase [mm] | 2790 | |||||
| Front wheel track [mm] | 1618 | |||||
| Rear wheel track [mm] | 1629 | |||||
| Forward overhang [mm] | 960 | |||||
| Rear overhang [mm] | 920 | |||||
| Clearance [mm] | 162 | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | - | |||||
| Headroom rear [mm] | - | |||||
| Front elbow/shoulder width [mm] | - | |||||
| Rear elbow/shoulder width [mm] | - | |||||
| Legroom front knees/total [mm] | - | |||||
| Legroom rear knees/total [mm] | - | |||||
| Rating |   | |||||
| Clean Air Index | 10.0/10 | |||||
| Energy Efficiency Index | 7.3/10 | |||||
| GHG index | 10.0/10 |
