Hyundai Santa Fe

Date of manufacture

6/2012 – 2016 (SUV)

Platform

Manufacturing locations

Ulsan, South Korea

Montgomery, Alabama, USA

Designer

Car body style

SUV

Date of manufacture

6/2012 – 2016

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

SUV

	2.4 GDI CVVT	2.0 CRDi VGT	2.2 CRDi VGT	2.2 CRDi VGT	2.2 CRDi VGT 7 seats	2.2 CRDi VGT
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2359	1995	2199	2199	2199	2199
Maximum output / speed [kW/min-1]	141/6300	110/4000	145/3800	145/3800	145/3800	145/3800
Maximum torque [Nm/min-1]	242/4250	383/1800-2500	431/1800-2500	431/1800-2500	431/1800-2500	431/1800-2500
Bore and stroke [mm x mm]	88,0 x 97,0	84,0 x 90,0	85,4 x 96,0	85,4 x 96,0	85,4 x 96,0	85,4 x 96,0
Compression ratio	11,3:1	16,5:1	16,0:1	16,0:1	16,0:1	16,0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection GDI variable timing of intake valves CVVT	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	Front	Front	Front	4x4	4x4	4x4
Gearbox	6 gear manual	6 gear manual	6 gear manual	6 gear manual	6 gear manual	6 gear automatic
Drive specifications	-	-	-	all-wheel drive 4WD	all-wheel drive 4WD	all-wheel drive 4WD automatic gearbox

Top speed [km/h]	190	187	190	190	190	190
Acceleration 0–100 km/h [s]	10.0	11.0	9.4	9.8	9.8	10.1
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	11.8	8.1	7.1	7.3	7.3	8.8
Out of town [l]	6.9	4.9	4.7	4.7	4.7	5.4
Combined [l]	8.7	6.1	5.6	5.7	5.7	6.7
CO2 emissions [g/km]	202	159	147	149	149	175

Emission standard	EU5	EU5-EU6	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1666-1827	1777-1938	1777-1938	1843-2004	1877-2038	1882-2043
Overall weight [kg]	2510	2510	2510	2510	2600	2510
Maximum trailer weight unbraked/braked [kg]	750/2500	750/2500	750/2500	750/2500	750/2500	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	585	585	585	585	585	585
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1570	-/1570	-/1570	-/1570	-/1570	-/1570
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	7	5
Fuel tank volume [l]	64	64	64	64	64	64
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.34	0.34	0.34	0.34	0.34	0.34
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	235/65 R17	235/65 R17	235/65 R17	235/65 R18	235/65 R18	235/65 R18
Tyre dimensions rear	235/65 R17	235/65 R17	235/65 R17	235/65 R18	235/65 R18	235/65 R18
Wheel size front	7.0J x 17	7.0J x 17	7.0J x 17	7.5J x 18	7.5J x 18	7.5J x 18
Wheel size rear	7.0J x 17	7.0J x 17	7.0J x 17	7.5J x 18	7.5J x 18	7.5J x 18
Brake dimensions front	320	320	320	320	320	320
Brake dimensions rear	302	302	302	302	302	302
Steering	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.9/-	10.9/-	10.9/-	10.9/-	10.9/-	10.9/-

Overall length [mm]	4690	4690	4690	4690	4690	4690
Overall width without/including mirrors [mm]	1880/-	1880/-	1880/-	1880/-	1880/-	1880/-
Overall height [mm]	1675	1675	1675	1675	1675	1675
Wheelbase [mm]	2700	2700	2700	2700	2700	2700
Front wheel track [mm]	1633	1633	1633	1628	1628	1628
Rear wheel track [mm]	1644	1644	1644	1639	1639	1639
Forward overhang [mm]	935	935	935	935	935	935
Rear overhang [mm]	1055	1055	1055	1055	1055	1055
Clearance [mm]	185	185	185	185	185	185
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	16.9	16.9	16.9	16.9	16.9	16.9
Approach angle rear [°]	21.5	21.5	21.5	21.5	21.5	21.5
Transition angle [°]	17.1	17.1	17.1	17.1	17.1	17.1
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1006	1006	1006	1006	1006	1006
Headroom rear [mm]	992	992	992	992	992	992
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.2 CRDi VGT 7 seats	2.2 CRDi VGT Grand
Date of sale	-	-
Engine type	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	2199	2199
Maximum output / speed [kW/min-1]	145/3800	145/3800
Maximum torque [Nm/min-1]	431/1800-2500	431/1800-2500
Bore and stroke [mm x mm]	85,4 x 96,0	85,4 x 96,0
Compression ratio	16,0:1	16,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4
Gearbox	6 gear automatic	6 gear automatic
Drive specifications	all-wheel drive 4WD automatic gearbox	all-wheel drive 4WD automatic gearbox

Top speed [km/h]	190	200
Acceleration 0–100 km/h [s]	10.1	10.3
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	8.8	9.9
Out of town [l]	5.4	6.2
Combined [l]	6.7	7.6
CO2 emissions [g/km]	175	199

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1915-2076	1991-2131
Overall weight [kg]	2600	2630
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2000
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	100/-	100/-

Boot volume [l]	585	634
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1570	-/1842
Boot volume, third row of seats [l]	-	-
Boot volume, third row seats folded [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	5	5
Number of seats	7	6-7
Fuel tank volume [l]	64	71
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.34	0.34
Front suspension	MacPherson, torsion stabiliser	MacPherson, torsion stabiliser
Rear suspension	multilink	multilink
Tyre dimensions front	235/65 R18	235/65 R18
Tyre dimensions rear	235/65 R18	235/65 R18
Wheel size front	7.5J x 18	7.5J x 18
Wheel size rear	7.5J x 18	7.5J x 18
Brake dimensions front	320	320
Brake dimensions rear	302	302
Steering	Rack & pinion with electric power steering m FLEX STEER	Rack & pinion with electric power steering m FLEX STEER
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.9/-	10.9/-

Overall length [mm]	4690	4915
Overall width without/including mirrors [mm]	1880/-	1885/-
Overall height [mm]	1675	1685
Wheelbase [mm]	2700	2800
Front wheel track [mm]	1628	1628
Rear wheel track [mm]	1639	1639
Forward overhang [mm]	935	965
Rear overhang [mm]	1055	1150
Clearance [mm]	185	180
Wading depth [mm]	-	-
Approach angle front [°]	16.9	16.7
Approach angle rear [°]	21.5	20.2
Transition angle [°]	17.1	15.8
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	1006	1006
Headroom rear [mm]	992	1008
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-
Third row of seats, headroom [mm]	-	908
Third row elbow/shoulder width [mm]	-	-

Gallery

Hyundai Santa Fe DM 2012 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
