	5.0 V8	5.0 V8 LWB	5.0 V8 S/C	5.0 V8 S/C LWB	5.0 V8 S/C	5.0 V8 S/C LWB
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	8/32	8/32	8/32	8/32	8/32	8/32
Engine displacement [cm³]	5000	5000	5000	5000	5000	5000
Maximum output / speed [kW/min-1]	283/6500	283/6500	346/6000-6500	346/6000-6500	375/6000-6500	375/6000-6500
Maximum torque [Nm/min-1]	515/3500	515/3500	575/2500-5500	575/2500-5500	625/2500-5500	625/2500-5500
Bore and stroke [mm x mm]	92,5 x 93,0	92,5 x 93,0	92,5 x 93,0	92,5 x 93,0	92,5 x 93,0	92,5 x 93,0
Compression ratio	-	-	-	-	-	-
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	-	-	-	-	-

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	6 gear automatic	6 gear automatic	6 gear automatic	6 gear automatic	6 gear automatic	6 gear automatic
Drive specifications	-	-	-	-	-	-

Top speed [km/h]	250	250	250	250	250	250
Acceleration 0–100 km/h [s]	5.7	5.7	5.2	5.2	4.9	4.9
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	17.0	17.0	18.3	18.3	18.3	18.3
Out of town [l]	8.2	8.2	8.7	8.7	8.7	8.7
Combined [l]	11.3	11.3	12.1	12.1	12.1	12.1
CO2 emissions [g/km]	264	264	289	289	289	289

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1755	1773	1892	1915	1892	1915
Overall weight [kg]	2300	2335	2365	2390	2365	2390
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	520	520	520	520	520	520
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	82	82	82	82	82	82
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.29	-	0.29	-	0.29	-
Front suspension	-	-	-	-	-	-
Rear suspension	-	-	-	-	-	-
Tyre dimensions front	235/50 R18	235/50 R18	255/35 R20	255/35 R20	255/35 R20	255/35 R20
Tyre dimensions rear	235/50 R18	235/50 R18	255/35 R20	255/35 R20	255/35 R20	255/35 R20
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.9/-	12.3/-	11.9/-	12.3/-	11.9/-	12.3/-

Overall length [mm]	5127	5252	5127	5252	5127	5252
Overall width without/including mirrors [mm]	1899/-	1899/-	1899/-	1899/-	1899/-	1899/-
Overall height [mm]	1448	1448	1448	1448	1448	1448
Wheelbase [mm]	3032	3157	3032	3157	3032	3157
Front wheel track [mm]	1626	1626	1626	1626	1626	1626
Rear wheel track [mm]	1604	1604	1604	1604	1604	1604
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	116	116	116	116	116	116
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1004	1004	1004	1004	1004	1004
Headroom rear [mm]	946	960	946	960	946	960
Front elbow/shoulder width [mm]	1464/-	1464/-	1464/-	1464/-	1464/-	1464/-
Rear elbow/shoulder width [mm]	1437/-	1437/-	1437/-	1437/-	1437/-	1437/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	3.0 V6 Kompresor	3.0 V6 Kompresor LWB	3.0 V6 Kompresor	3.0 V6 Kompresor	3.0 V6 D	3.0 V6 D LWB
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	6/24	6/24	6/24	6/24	6/24
Engine displacement [cm³]	2995	2995	2995	2995	2993	2993
Maximum output / speed [kW/min-1]	250/6500	250/6500	250/6500	250/6500	202/4000	202/4000
Maximum torque [Nm/min-1]	450/3500-5000	450/3500-5000	450/3500-5000	450/3500-5000	600/2000	600/2000
Bore and stroke [mm x mm]	84,5 x 89,0	84,5 x 89,0	84,5 x 89,0	84,5 x 89,0	92,5 x 93,0	92,5 x 93,0
Compression ratio	10,5:1	10,5:1	10,5:1	10,5:1	-	-
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection supercharging with Roots mechanical two-rotor supercharger variable timing of intake and exhaust valves start&stop system	direct injection supercharging with Roots mechanical two-rotor supercharger variable timing of intake and exhaust valves start&stop system	direct injection supercharging with Roots mechanical two-rotor supercharger variable timing of intake and exhaust valves start&stop system	direct injection supercharging with Roots mechanical two-rotor supercharger variable timing of intake and exhaust valves start&stop system	-	-

Drive axle	Rear	Rear	4x4	4x4	Rear	Rear
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	6 gear automatic	6 gear automatic
Drive specifications	automatic gearbox Jaguar Sequential Shift	automatic gearbox Jaguar Sequential Shift	all-wheel drive automatic gearbox Jaguar Sequential Shift	all-wheel drive automatic gearbox Jaguar Sequential Shift	-	-

Top speed [km/h]	250	250	250	250	250	250
Acceleration 0–100 km/h [s]	5.9	5.9	6.4	6.4	6.4	6.4
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	13.5	13.5	14.4	14.4	9.6	9.6
Out of town [l]	7.4	7.4	7.8	7.8	5.6	5.6
Combined [l]	9.6	9.6	9.9	9.9	7.0	7.0
CO2 emissions [g/km]	224	224	234	234	184	184

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1748	1761	1870	1883	1796	1813
Overall weight [kg]	2350	2400	2430	2450	2365	2365
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	520	520	520	520	520	520
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4	4	4	4	4	4
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	82	82	82	82	82	82
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.29	-	0.29	0.29	0.29	-
Front suspension	-	-	-	-	-	-
Rear suspension	-	-	-	-	-	-
Tyre dimensions front	245/50 R18	245/50 R18	245/50 R18	245/50 R18	235/50 R18	235/50 R18
Tyre dimensions rear	275/45 R18	275/45 R18	275/45 R18	275/45 R18	235/50 R18	235/50 R18
Wheel size front	8.0 x 18	8.0 x 18	8.0 x 18	8.0 x 18	-	-
Wheel size rear	9.0 x 18	9.0 x 18	9.0 x 18	9.0 x 18	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.9/-	12.3/-	11.9/-	11.9/-	11.9/-	12.3/-

Overall length [mm]	5127	5252	5127	5127	5127	5252
Overall width without/including mirrors [mm]	1899/-	1899/-	1899/-	1899/-	1899/-	1899/-
Overall height [mm]	1448	1448	1448	1448	1448	1448
Wheelbase [mm]	3032	3157	3032	3032	3032	3157
Front wheel track [mm]	1626	1626	1626	1626	1626	1626
Rear wheel track [mm]	1604	1604	1604	1604	1604	1604
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	116	116	116	116	116	116
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1004	1004	1004	1004	1004	1004
Headroom rear [mm]	946	960	946	946	946	960
Front elbow/shoulder width [mm]	1464/-	1464/-	1464/-	1464/-	1464/-	1464/-
Rear elbow/shoulder width [mm]	1437/-	1437/-	1437/-	1437/-	1437/-	1437/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-
