Jeep Grand Cherokee

Date of manufacture

2013 – 2016 (Large SUV)

Platform

Manufacturing locations

Detroit, Michigan, USA

Toluca, Mexico

Designer

Mark Allen

Car body style

Large SUV

after upgrade (facelift)

Date of manufacture

2013 – 2016

Internal designation

WK2

Engine size

Petrol

Diesel

Euro NCAP

Test year 2011

pre-facelift version (2011)

Technical data

Large SUV

	3.6 V6 VVT	5.7 V8 MDS HEMI	6.4 V8 SRT HEMI	3.0 V6
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	6/24	8/16	8/16	6/24
Engine displacement [cm³]	3604	5654	6417	2987
Maximum output / speed [kW/min-1]	210/6350	259/5200	344/6250	184/4000
Maximum torque [Nm/min-1]	347/4300	520/4200	624/4100	570/2000
Bore and stroke [mm x mm]	96.0 x 83.0	99.5 x 90.9	103.9 x 94.6	83.0 x 92.0
Compression ratio	10.2:1	10.5:1	10.9:1	15.5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing E85 fuel combustion start&stop system	variable valve timing technology MDS (shuts down four cylinders if necessary)	turbocharger with variable blade geometry technology MDS (shuts down four cylinders if necessary)	direct injection Multijet II with Common Rail turbocharger with variable blade geometry particulate filter start&stop system

Drive axle	4x4	4x4	4x4	4x4
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	automatically controlled all-wheel drive eight-speed automatic gearbox	automatically controlled all-wheel drive eight-speed automatic gearbox	permanent all-wheel drive eight-speed automatic gearbox	automatically controlled all-wheel drive eight-speed automatic gearbox

Top speed [km/h]	206	225	257	202
Acceleration 0–100 km/h [s]	8.3	7.3	5.0	8.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	14.3 [18.9 E85]	19.6	20.7	9.3
Out of town [l]	8.2 [10.8 E85]	9.2	10.1	6.5
Combined [l]	10.4 [13.8 E85]	13.0	14.0	7.5
CO2 emissions [g/km]	244	304	327	198

Emission standard	EU6	EU6	EU6	EU5+
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	2266-2354	2382-2499	2418-2458	2403-2522
Overall weight [kg]	2915	2949	2949	2915
Maximum trailer weight unbraked/braked [kg]	750/2812	750/3500	750/2949	750/3500
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	725	725	725	725
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1554	-/1554	-/1554	-/1554
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	93.5	93.5	93.5	93.5
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar	five-link, stabiliser bar
Tyre dimensions front	265/60 R18	265/60 R18	295/45 ZR20	265/60 R18
Tyre dimensions rear	265/60 R18	265/60 R18	295/45 ZR20	265/60 R18
Wheel size front	8J x 18	8J x 18	10J x 20	8J x 18
Wheel size rear	8J x 18	8J x 18	10J x 20	8J x 18
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	11.6/-	11.6/-	11.6/-	11.6/-

Overall length [mm]	4828	4828	4846	4828
Overall width without/including mirrors [mm]	1943/2154	1943/2154	1954/-	1943/2154
Overall height [mm]	1792	1792	1749	1802
Wheelbase [mm]	2915	2915	2914	2915
Front wheel track [mm]	1628	1628	1669	1628
Rear wheel track [mm]	1634	1634	1661	1634
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	213	216	210	215
Wading depth [mm]	-	-	-	-
Approach angle front [°]	26.3-35.8	26.3-35.8	18.4	26.3-35.8
Approach angle rear [°]	26.5-29.5	26.5-29.5	21.9	26.5-29.5
Transition angle [°]	18.8-23.5	18.8-23.5	17.8	18.8-23.5
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	966	966	966	966
Headroom rear [mm]	961	961	961	961
Front elbow/shoulder width [mm]	1491/-	1491/-	1491/-	1491/-
Rear elbow/shoulder width [mm]	1474/-	1474/-	1474/-	1474/-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Jeep Grand Cherokee WK2 facelift 2013 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
