Kia Picanto
Date of manufacture
2017 – 2020 (Five-door hatchback)
Platform
-
Manufacturing locations
Seosan, South Korea
Designer
Peter Schreyer
Tags
A-segment
Korean cars
The Kia Picanto is a five-door hatchback produced since 2017 in South Korea. The engine range is limited to petrol units, with the most powerful model being the 1.0 T-GDI with 73.6 kW and the fastest model 0-100 km/h in 10.1 seconds. The most economical variant 1.0 CVVT has a consumption of 4.2 l/100 km and emissions of 97 g/km. The trunk has a capacity of 255 l and has passed the EURONCAP safety tests with a rating of 4 out of 5.
Car body style
Technical data
Five-door hatchback
| 1.0 CVVT | 1.0 CVVT | 1.0 CVVT | 1.25 CVVT | 1.25 CVVT | 1.25 CVVT | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 998 | 998 | 998 | 1248 | 1248 | 1248 |
| Maximum output / speed [kW/min-1] | 49,3/5500 | 49,3/5500 | 49,3/5500 | 61,8/6000 | 61,8/6000 | 61,8/6000 |
| Maximum torque [Nm/min-1] | 97/3500 | 97/3500 | 97/3500 | 122/4000 | 122/4000 | 122/4000 |
| Bore and stroke [mm x mm] | 71,0 x 84,0 | 71,0 x 84,0 | 71,0 x 84,0 | 71,0 x 78,8 | 71,0 x 78,8 | 71,0 x 78,8 |
| Compression ratio | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear manual | 4 gear automatic | 5 gear manual | 5 gear manual | 4 gear automatic |
| Drive specifications | - | - |
| - | - |
|
| Top speed [km/h] | 161 | 161 | 148 | 173 | 173 | 161 |
| Acceleration 0–100 km/h [s] | 14.5 | 14.5 | 14.5 | 12.0 | 12.0 | 13.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.0-5.6 | 5.3 | 6.1-5.9 | 5.9 | 6.4-5.8 | 7.0-6.5 |
| Out of town [l] | 4.5-3.7 | 3.6 | 5.2-5.2 | 3.8 | 4.6-3.7 | 5.5-4.5 |
| Combined [l] | 5.0-4.4 | 4.2 | 5.5-5.5 | 4.6 | 5.3-4.5 | 6.0-5.4 |
| CO2 emissions [g/km] | 115-101 | 97 | 127-125 | 106 | 121-104 | 138-124 |
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | 70 | 70 | 70 | 71 | 71 | 71 |
| Standby weight [kg] | 935-1028 | 935-1028 | 935-1028 | 939-1051 | 939-1051 | 959-1058 |
| Overall weight [kg] | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | 740/720 | 740/720 | 740/720 | 740/720 | 740/720 | 740/720 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 60/- | 60/- | 60/- | 60/- | 60/- | 60/- |
| Boot volume [l] | 255 | 255 | 255 | 255 | 255 | 255 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1010 | -/1010 | -/1010 | -/1010 | -/1010 | -/1010 |
| Boot length [mm] | 550 | 550 | 550 | 550 | 550 | 550 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 992/- | 992/- | 992/- | 992/- | 992/- | 992/- |
| Boot height to headliner/ceiling [mm] | -/605 | -/605 | -/605 | -/605 | -/605 | -/605 |
| Loading edge height [mm] | 720 | 720 | 720 | 720 | 720 | 720 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | -/960 | -/960 | -/960 | -/960 | -/960 | -/960 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 35 | 35 | 35 | 35 | 35 | 35 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, coil springs, gas shock absorbers | MacPherson, coil springs, gas shock absorbers | MacPherson, coil springs, gas shock absorbers | MacPherson, coil springs, gas shock absorbers | MacPherson, coil springs, gas shock absorbers | MacPherson, coil springs, gas shock absorbers |
| Rear suspension | twist beam axle with trailing arms, gas shock absorbers and torsion bar | twist beam axle with trailing arms, gas shock absorbers and torsion bar | twist beam axle with trailing arms, gas shock absorbers and torsion bar | twist beam axle with trailing arms, gas shock absorbers and torsion bar | twist beam axle with trailing arms, gas shock absorbers and torsion bar | twist beam axle with trailing arms, gas shock absorbers and torsion bar |
| Tyre dimensions front | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 |
| Tyre dimensions rear | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 | 175 / 65 R14 |
| Wheel size front | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 |
| Wheel size rear | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 | 5.5J x 14 ET45 |
| Brake dimensions front | 256 | 256 | 256 | 256 | 256 | 256 |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 |
| Turning diameter track/circumference [m] | 9.4/- | 9.4/- | 9.4/- | 9.4/- | 9.4/- | 9.4/- |
| Overall length [mm] | 3595 | 3595 | 3595 | 3595 | 3595 | 3595 |
| Overall width without/including mirrors [mm] | 1595/1880 | 1595/1880 | 1595/1880 | 1595/1880 | 1595/1880 | 1595/1880 |
| Overall height [mm] | 1485 | 1485 | 1485 | 1485 | 1485 | 1485 |
| Wheelbase [mm] | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Front wheel track [mm] | 1420 | 1420 | 1420 | 1420 | 1420 | 1420 |
| Rear wheel track [mm] | 1423 | 1423 | 1423 | 1423 | 1423 | 1423 |
| Forward overhang [mm] | 675 | 675 | 675 | 675 | 675 | 675 |
| Rear overhang [mm] | 520 | 520 | 520 | 520 | 520 | 520 |
| Clearance [mm] | 141 | 141 | 141 | 141 | 141 | 141 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1005 | 1005 | 1005 | 1005 | 1005 | 1005 |
| Headroom rear [mm] | 960 | 960 | 960 | 960 | 960 | 960 |
| Front elbow/shoulder width [mm] | 1245/1300 | 1245/1300 | 1245/1300 | 1245/1300 | 1245/1300 | 1245/1300 |
| Rear elbow/shoulder width [mm] | 1230/1280 | 1230/1280 | 1230/1280 | 1230/1280 | 1230/1280 | 1230/1280 |
| Legroom front knees/total [mm] | -/1085 | -/1085 | -/1085 | -/1085 | -/1085 | -/1085 |
| Legroom rear knees/total [mm] | -/820 | -/820 | -/820 | -/820 | -/820 | -/820 |
| 1.0 T-GDI | ||||||
|---|---|---|---|---|---|---|
| Date of sale | - | |||||
| Engine type | Ignition supercharged | |||||
| Number of cylinders/valves | 3/12 | |||||
| Engine displacement [cm³] | 998 | |||||
| Maximum output / speed [kW/min-1] | 73.6/4500 | |||||
| Maximum torque [Nm/min-1] | 172/1500-4000 | |||||
| Bore and stroke [mm x mm] | 71,0 x 84,0 | |||||
| Compression ratio | 10,0:1 | |||||
| Oil volume [l] | - | |||||
| Coolant volume [l] | - | |||||
| Technical specifications |
| |||||
| Drive axle | Front | |||||
| Gearbox | 5 gear manual | |||||
| Drive specifications | - | |||||
| Top speed [km/h] | 180 | |||||
| Acceleration 0–100 km/h [s] | 10.1 | |||||
| Acceleration 0–80 km/h [s] | - | |||||
| Acceleration 80–120 km/h [s] | - | |||||
| City [l] | 6.4-5.6 | |||||
| Out of town [l] | 4.4-4.0 | |||||
| Combined [l] | 5.2-4.6 | |||||
| CO2 emissions [g/km] | 118-105 | |||||
| Emission standard | EU6 - Euro 6d-TEMP | |||||
| Standard for fuel consumption measurement | - | |||||
| Energy class | - | |||||
| Stationary vehicle noise [dB] | - | |||||
| Driving noise [dB] | 69 | |||||
| Standby weight [kg] | 1020-1101 | |||||
| Overall weight [kg] | 1405 | |||||
| Maximum trailer weight unbraked/braked [kg] | - | |||||
| Maximum front/rear axle load [kg] | 745/720 | |||||
| Maximum vertical load on the tow bar [kg] | - | |||||
| Maximum load on roof/carrier [kg] | 60/- | |||||
| Boot volume [l] | 255 | |||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1010 | |||||
| Boot length [mm] | 550 | |||||
| Boot length with rear seats folded [mm] | - | |||||
| Boot width between wheels/max [mm] | 992/- | |||||
| Boot height to headliner/ceiling [mm] | -/605 | |||||
| Loading edge height [mm] | 720 | |||||
| Height of the open boot door [mm] | - | |||||
| Boot opening height [mm] | - | |||||
| Boot opening width min/max [mm] | -/960 | |||||
| Number of doors | 5 | |||||
| Number of seats | 5 | |||||
| Fuel tank volume [l] | 35 | |||||
| AdBlue tank volume [l] | - | |||||
| Air resistance [Cd] | - | |||||
| Front suspension | MacPherson, coil springs, gas shock absorbers | |||||
| Rear suspension | twist beam axle with trailing arms, gas shock absorbers and torsion bar | |||||
| Tyre dimensions front | 195/45 R16 84V | |||||
| Tyre dimensions rear | 195/45 R16 84V | |||||
| Wheel size front | 6,5Jx16 ET 51 | |||||
| Wheel size rear | 6,5Jx16 ET 51 | |||||
| Brake dimensions front | 256 | |||||
| Brake dimensions rear | 244 | |||||
| Steering | Rack & pinion with electric power steering m | |||||
| Number of steering wheel turns | 2.8 | |||||
| Turning diameter track/circumference [m] | 9.4/- | |||||
| Overall length [mm] | 3595 | |||||
| Overall width without/including mirrors [mm] | 1595/1880 | |||||
| Overall height [mm] | 1485 | |||||
| Wheelbase [mm] | 2400 | |||||
| Front wheel track [mm] | 1420 | |||||
| Rear wheel track [mm] | 1423 | |||||
| Forward overhang [mm] | 675 | |||||
| Rear overhang [mm] | 520 | |||||
| Clearance [mm] | 141 | |||||
| Wading depth [mm] | - | |||||
| Approach angle front [°] | - | |||||
| Approach angle rear [°] | - | |||||
| Transition angle [°] | - | |||||
| Climbing rate [°] | - | |||||
| Maximum side tilt [°] | - | |||||
| Headroom front [mm] | 1005 | |||||
| Headroom rear [mm] | 960 | |||||
| Front elbow/shoulder width [mm] | 1245/1300 | |||||
| Rear elbow/shoulder width [mm] | 1230/1280 | |||||
| Legroom front knees/total [mm] | -/1085 | |||||
| Legroom rear knees/total [mm] | -/820 |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
