Kia Stinger

Date of manufacture

2017 – 2020 (Coupé)

Platform

Manufacturing locations

Gwangmyeong, South Korea

Kaliningrad, Russia

Designer

Peter Schreyer

Gregory Guillaume

Car body style

Coupé (Gran Turismo)

Date of manufacture

2017 – 2020

Internal designation

Engine size

Petrol

2.0 T-GDI

3.3 V6 T-GDI

Diesel

2.2 CRDi

Euro NCAP

Technical data

Coupé (Gran Turismo)

	2.0 T-GDI	3.3 V6 T-GDI	2.2 CRDi	2.2 CRDi
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	6/24	4/16	4/16
Engine displacement [cm³]	1998	3342	2199	2199
Maximum output / speed [kW/min-1]	188/6200	272/6000	147/3800	147/3800
Maximum torque [Nm/min-1]	353/1400-4000	510/1300-4500	440/1750-2750	450/1750-2750
Bore and stroke [mm x mm]	86,0 x 86,0	92,0 x 83,8	85,4 x 96,0	85,4 x 96,0
Compression ratio	10,0:1	10,0:1	16,0:1	16,0:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection GDI turbo-supercharged variable timing of intake and exhaust valves D‐CVVT Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	direct injection GDI supercharging by twin turbochargers (twin) variable timing of intake and exhaust valves D‐CVVT Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	direct injection Common Rail turbocharger with variable blade geometry particulate filter Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG	direct injection Common Rail turbocharger with variable blade geometry particulate filter Particle filter for diesel engines (only models that comply with Euro 6d-TEMP) start&stop system ISG

Drive axle	Rear	4x4	Rear	4x4
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	automatic gearbox	all-wheel drive AWD automatic gearbox	automatic gearbox	all-wheel drive AWD automatic gearbox

Top speed [km/h]	233	270	230	230
Acceleration 0–100 km/h [s]	6.0-6.3	4.9-5.5	7.6	8.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	4.4	3.3	5.9	5.9

City [l]	10.7-10.5	14.3-14.2	7.3-6.6	7.9
Out of town [l]	6.6-6.4	8.5-8.3	5.0-4.9	5.6
Combined [l]	8.1-7.9	10.6-10.5	5.8-5.6	6.4
CO2 emissions [g/km]	186-181	244-240	154-147	169

Emission standard	EU6 - Euro 6d-TEMP	EU6 - Euro 6d-TEMP	EU6 - Euro 6d-TEMP	EU6 - Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	69	69	67	67

Standby weight [kg]	1717-1846	1909-1980	1778-1913	1849-1975
Overall weight [kg]	2185	2325	2260	2325
Maximum trailer weight unbraked/braked [kg]	750/1500	750/1500	750/1500	750/1500
Maximum front/rear axle load [kg]	1115/1220	1130/1220	1190/1260	1190/1260
Maximum vertical load on the tow bar [kg]	75	75	75	75
Maximum load on roof/carrier [kg]	90/-	90/-	90/-	90/-

Boot volume [l]	406	406	406	406
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1114	-/1114	-/1114	-/1114
Boot length [mm]	710	710	710	710
Boot length with rear seats folded [mm]	1055	1055	1055	1055
Boot width between wheels/max [mm]	964/1304	964/1304	964/1304	964/1304
Boot height to headliner/ceiling [mm]	-/605	-/605	-/605	-/605
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	60	60	60	60
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	0.3	0.3	0.3	0.3
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	225/45 R18 95Y	225/40 R19 93Y	225/45 R18 95Y	225/45 R18 95Y
Tyre dimensions rear	225/45 R18 95Y	255/35 R19 96Y	225/45 R18 95Y	225/45 R18 95Y
Wheel size front	8.0Jx18 ET34	8.0Jx19 ET34	8.0Jx18 ET34	8.0Jx18 ET34
Wheel size rear	8.0Jx18 ET34	8.5Jx19 ET46,5	8.0Jx18 ET34	8.0Jx18 ET34
Brake dimensions front	345	350	320	320
Brake dimensions rear	330	340	315	315
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	2.4	2.1	2.4	2.3
Turning diameter track/circumference [m]	11.2/-	11.7/-	11.2/-	11.7/-

Overall length [mm]	4830	4830	4830	4830
Overall width without/including mirrors [mm]	1870/-	1870/-	1870/-	1870/-
Overall height [mm]	1400	1400	1400	1400
Wheelbase [mm]	2905	2905	2905	2905
Front wheel track [mm]	1596	1596	1596	1596
Rear wheel track [mm]	1647	1619	1647	1647
Forward overhang [mm]	830	830	830	830
Rear overhang [mm]	1095	1095	1095	1095
Clearance [mm]	130	130	130	130
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	974	974	974	974
Headroom rear [mm]	939	939	939	939
Front elbow/shoulder width [mm]	-/1433	-/1433	-/1433	-/1433
Rear elbow/shoulder width [mm]	-/1391	-/1391	-/1391	-/1391
Legroom front knees/total [mm]	-/1083	-/1083	-/1083	-/1083
Legroom rear knees/total [mm]	-/925	-/925	-/925	-/925

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
