Kia Venga
Date of manufacture
2015 – 2019 (MPV)
Platform
Hyundai-Kia PB
Manufacturing locations
Žilina, Slovakia
Designer
Peter Schreyer
Tags
Small MPV
Korean cars
The Kia Venga has been available as an MPV since 2015 and is manufactured in a Slovakian factory. It is built on the Hyundai-Kia PB platform and offers a wide range of petrol and diesel engines, with the most powerful of them reaching 91.5 kW. The fastest Kia Venga model can reach speeds of up to 185 km/h, while the most fuel-efficient 1.4 CRDi ISG consumes only 4.2 l/100 km with emissions of 110 g/km. In the middle of the car you will find a trunk with a volume of 444 l. Tested in the safety area in 2010, the Kia Venga scored 5 out of 5 according to EURONCAP.
Car body style
MPV
after upgrade (facelift)
Date of manufacture
2015 – 2019Internal designation
YN Engine size
Technical data
MPV
| 1.4 CVVT | 1.4 CVVT ISG | 1.6 CVVT | 1.6 CVVT ISG | 1.6 CVVT | 1.6 CVVT | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from to 2018 | - | - | from to 2015 | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1396 | 1396 | 1591 | 1591 | 1591 | 1591 |
| Maximum output / speed [kW/min-1] | 66,2/6000 | 66,2/6000 | 91,5/6300 | 91,5/6300 | 91,5/6300 | 91,5/6300 |
| Maximum torque [Nm/min-1] | 137/4000 | 137/4000 | 156/4200 | 156/4200 | 156/4200 | 156/4200 |
| Bore and stroke [mm x mm] | 77,0 x 74,99 | 77,0 x 74,99 | 77,0 x 85,44 | 77,0 x 85,44 | 77,0 x 85,44 | 77,0 x 85,44 |
| Compression ratio | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear manual | 6 gear manual | 6 gear manual | 4 gear automatic | 6 gear automatic |
| Drive specifications | - | - | - | - |
|
|
| Top speed [km/h] | 168 | 168 | 185 | 183-185 | 178 | 180 |
| Acceleration 0–100 km/h [s] | 12.8 | 12.8 | 10.8 | 10.8-11.0 | 12.2 | 11.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.2 | 6.6 | 7.4 | 7.9-7.1 | 8.3 | 9.0-8.6 |
| Out of town [l] | 5.3 | 5.1 | 5.7 | 5.7-5.2 | 5.5 | 5.7-5.2 |
| Combined [l] | 6.0 | 5.6 | 6.4 | 6.5-5.9 | 6.5 | 6.9-6.5 |
| CO2 emissions [g/km] | 140 | 130 | 148 | 149-139 | 154 | 159-150 |
| Emission standard | EU5-EU6 | EU5-EU6 | EU5-EU6 | EU5-EU6 - Euro 6d-TEMP | EU5 | EU6 - Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1253-1343 | 1253-1343 | 1255-1355 | 1255-1355 | 1269-1369 | 1297-1410 |
| Overall weight [kg] | 1710 | 1710 | 1710 | 1710 | 1730 | 1780 |
| Maximum trailer weight unbraked/braked [kg] | 550/1300 | 550/1300 | 550/1300 | 550/1300 | 550/1100 | 550/1100 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 70/- | 70/- | 70/- | 70/- | 70/- | 70/- |
| Boot volume [l] | 444 | 444 | 444 | 444 | 444 | 444 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1486 | -/1486 | -/1486 | -/1486 | -/1486 | -/1486 |
| Boot length [mm] | 713-850 | 713-850 | 713-850 | 713-850 | 713-850 | 713-850 |
| Boot length with rear seats folded [mm] | 1482-1700 | 1482-1700 | 1482-1700 | 1482-1700 | 1482-1700 | 1482-1700 |
| Boot width between wheels/max [mm] | 1160/1320 | 1160/1320 | 1160/1320 | 1160/1320 | 1160/1320 | 1160/1320 |
| Boot height to headliner/ceiling [mm] | 762/924 | 762/924 | 762/924 | 762/924 | 762/924 | 762/924 |
| Loading edge height [mm] | 715 | 715 | 715 | 715 | 715 | 715 |
| Height of the open boot door [mm] | 1920 | 1920 | 1920 | 1920 | 1920 | 1920 |
| Boot opening height [mm] | 762 | 762 | 762 | 762 | 762 | 762 |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser |
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar |
| Tyre dimensions front | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 |
| Tyre dimensions rear | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 | 195/65 R15 |
| Wheel size front | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 |
| Wheel size rear | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 |
| Brake dimensions front | 280 x 26 | 280 x 26 | 280 x 26 | 280 x 26 | 280 x 26 | 280 x 26 |
| Brake dimensions rear | 258 x 10 | 258 x 10 | 258 x 10 | 258 x 10 | 258 x 10 | 258 x 10 |
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.42/- | 10.42/- | 10.42/- | 10.42/- | 10.42/- | 10.42/- |
| Overall length [mm] | 4075 | 4075 | 4075 | 4075 | 4075 | 4075 |
| Overall width without/including mirrors [mm] | 1765/- | 1765/- | 1765/- | 1765/- | 1765/- | 1765/- |
| Overall height [mm] | 1600 | 1600 | 1600 | 1600 | 1600 | 1600 |
| Wheelbase [mm] | 2615 | 2615 | 2615 | 2615 | 2615 | 2615 |
| Front wheel track [mm] | 1553 | 1553 | 1553 | 1553 | 1553 | 1553 |
| Rear wheel track [mm] | 1557 | 1557 | 1557 | 1557 | 1557 | 1557 |
| Forward overhang [mm] | 792 | 792 | 792 | 792 | 792 | 792 |
| Rear overhang [mm] | 668 | 668 | 668 | 668 | 668 | 668 |
| Clearance [mm] | 156 | 156 | 156 | 156 | 156 | 156 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 |
| Headroom rear [mm] | 980 | 980 | 980 | 980 | 980 | 980 |
| Front elbow/shoulder width [mm] | -/1388 | -/1388 | -/1388 | -/1388 | -/1388 | -/1388 |
| Rear elbow/shoulder width [mm] | -/1367 | -/1367 | -/1367 | -/1367 | -/1367 | -/1367 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.4 CRDi | 1.4 CRDi ISG | |||||
|---|---|---|---|---|---|---|
| Date of sale | from to 2016 | from to 2016 | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1396 | 1396 | ||||
| Maximum output / speed [kW/min-1] | 66/4000 | 66/4000 | ||||
| Maximum torque [Nm/min-1] | 220/1750-2750 | 220/1750-2750 | ||||
| Bore and stroke [mm x mm] | 75,0 x 79,0 | 75,0 x 79,0 | ||||
| Compression ratio | 17,0:1 | 17,0:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | Front | Front | ||||
| Gearbox | 6 gear manual | 6 gear manual | ||||
| Drive specifications | - | - | ||||
| Top speed [km/h] | 167 | 167 | ||||
| Acceleration 0–100 km/h [s] | 14.2 | 14.2 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 5.2 | 4.9 | ||||
| Out of town [l] | 3.9 | 3.8 | ||||
| Combined [l] | 4.4 | 4.2 | ||||
| CO2 emissions [g/km] | 115 | 110 | ||||
| Emission standard | EU5-EU6 | EU5-EU6 | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1345-1445 | 1345-1445 | ||||
| Overall weight [kg] | 1800 | 1800 | ||||
| Maximum trailer weight unbraked/braked [kg] | 550/1300 | 550/1300 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | ||||
| Maximum load on roof/carrier [kg] | 70/- | 70/- | ||||
| Boot volume [l] | 444 | 444 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1486 | -/1486 | ||||
| Boot length [mm] | 713-850 | 713-850 | ||||
| Boot length with rear seats folded [mm] | 1482-1700 | 1482-1700 | ||||
| Boot width between wheels/max [mm] | 1160/1320 | 1160/1320 | ||||
| Boot height to headliner/ceiling [mm] | 762/924 | 762/924 | ||||
| Loading edge height [mm] | 715 | 715 | ||||
| Height of the open boot door [mm] | 1920 | 1920 | ||||
| Boot opening height [mm] | 762 | 762 | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 50 | 50 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.31 | 0.31 | ||||
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | ||||
| Rear suspension | rigid with trailing arms and torsion bar | rigid with trailing arms and torsion bar | ||||
| Tyre dimensions front | 195/65 R15 | 195/65 R15 | ||||
| Tyre dimensions rear | 195/65 R15 | 195/65 R15 | ||||
| Wheel size front | 6.0J x 15 | 6.0J x 15 | ||||
| Wheel size rear | 6.0J x 15 | 6.0J x 15 | ||||
| Brake dimensions front | 280 x 26 | 280 x 26 | ||||
| Brake dimensions rear | 258 x 10 | 258 x 10 | ||||
| Steering | Rack & pinion with electric power steering m | Rack & pinion with electric power steering m | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 10.42/- | 10.42/- | ||||
| Overall length [mm] | 4075 | 4075 | ||||
| Overall width without/including mirrors [mm] | 1765/- | 1765/- | ||||
| Overall height [mm] | 1600 | 1600 | ||||
| Wheelbase [mm] | 2615 | 2615 | ||||
| Front wheel track [mm] | 1553 | 1553 | ||||
| Rear wheel track [mm] | 1557 | 1557 | ||||
| Forward overhang [mm] | 792 | 792 | ||||
| Rear overhang [mm] | 668 | 668 | ||||
| Clearance [mm] | 156 | 156 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1020 | 1020 | ||||
| Headroom rear [mm] | 980 | 980 | ||||
| Front elbow/shoulder width [mm] | -/1388 | -/1388 | ||||
| Rear elbow/shoulder width [mm] | -/1367 | -/1367 | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
