Kia XCeed
Date of manufacture
8/2019 – to this day (Crossover)
Platform
Hyundai-Kia K2
Manufacturing locations
Žilina, Slovakia
Designer
Peter Schreyer
Tags
C-segment
Korean cars
The Kia XCeed is a crossover vehicle that was launched in 2019. The car is manufactured in a Slovakian factory and is built on the Hyundai-Kia K2 platform. It offers petrol, diesel and hybrid engines with a maximum power of 150 kW (1.6 T-GDI). The maximum speed of the 1.6 T-GDI model is 220 km/h, while the lowest fuel consumption (1.2 l/100 km) is for the Plug-in Hybrid version. CO2 emissions are 29 g/km. The size of the luggage compartment is 291 liters.
Car body style
Crossover
Date of manufacture
8/2019 – to this dayInternal designation
CDEngine size
Technical data
Crossover
| 1.0 T-GDI | 1.4 T-GDI | 1.4 T-GDI | 1.6 T-GDI | 1.6 T-GDI | 1.6 Plug-in Hybrid | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol + Electric |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 998 | 1353 | 1353 | 1591 | 1591 | 1580 |
| Maximum output / speed [kW/min-1] | 88/6000 | 103/6000 | 103/6000 | 150/5500 | 150/5500 | 77,2/5700 44,5/1798-2500 el. 104/5700 total |
| Maximum torque [Nm/min-1] | 172/1500-4000 | 242/1500-3200 | 242/1500-3200 | 265/1500-4500 | 265/1500-4500 | 147/4000 170/0-1798 el. 265/1000-2400 total |
| Bore and stroke [mm x mm] | 71,0 x 84,0 | 71,6 x 84,0 | 71,6 x 84,0 | 77,0 x 85,4 | 77,0 x 85,4 | 72,0 x 97,0 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,0:1 | 9,5:1 | 9,5:1 | 13,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 186 | 200 | 200 | 220 | 220 | 160-193 [120 el.] |
| Acceleration 0–100 km/h [s] | 11,3 | 9,4 | 9,5 | 7,7 | 7,5 | 11,0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,8-6,5 | 7,6-7,2 | 6,9-6,5 | 8,6 | 7,6-7,5 | - |
| Out of town [l] | 5,0-4,8 | 5,4-5,3 | 5,3-5,2 | 5,9-5,6 | 5,8-5,5 | - |
| Combined [l] | 5,7-5,4 | 6,2-6,0 | 5,9-5,7 | 6,9-6,7 | 6,5-6,2 | 1,3-1,2 [11-110,4 kWh] |
| CO2 emissions [g/km] | 130-124 | 142-137 | 135-130 | 158-153 | 148-143 | 31-29 |
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP - Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | 68 | 68 | 67 | 69 | 68 | - |
| Driving noise [dB] | 74,1 / 3750 rev/min | 76,6 / 3750 rev/min | 77,6 / 3750 rev/min | 80,1 / 3750 rev/min | 80,8 / 3750 rev/min | - |
| System voltage [V] | - | - | - | - | - | 360 |
| Battery type and capacity | - | - | - | - | - | Lithium polymer, 8.9 kWh |
| Range with fully charged battery [km] | - | - | - | - | - | 58 |
| Charging time | - | - | - | - | - |
|
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | 117 |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1332-1458 | 1345-1481 | 1375-1511 | 1390-1499 | 1417-1527 | 1519-1596 |
| Overall weight [kg] | 1820 | 1840 | 1860 | 1860 | 1880 | 2030 |
| Maximum trailer weight unbraked/braked [kg] | 600/1200 | 600/1410 | 600/1410 | 600/1410 | 600/1410 | 600/1300 |
| Maximum front/rear axle load [kg] | 1050/950 | 1050/950 | 1050/950 | 1050/950 | 1050/950 | - |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | 80/- | 80/- |
| Boot volume [l] | 426 | 426 | 426 | 426 | 426 | 291 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1378 | -/1378 | -/1378 | -/1378 | -/1378 | -/1243 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | 50 | 37 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser |
| Rear suspension | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers |
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 235/45 R18 94V | 235/45 R18 94V | 205/60 R16 |
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 235/45 R18 94V | 235/45 R18 94V | 205/60 R16 |
| Wheel size front | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 7,5J x 18 ET45 | 7,5J x 18 ET45 | 6,5Jx16 ET40 |
| Wheel size rear | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 7,5J x 18 ET45 | 7,5J x 18 ET45 | 6,5Jx16 ET40 |
| Brake dimensions front | 305 x 25 | 305 x 25 | 305 x 25 | 320 x 28 | 320 x 28 | 305 x 25 |
| Brake dimensions rear | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 | 284 x 10 |
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering |
| Number of steering wheel turns | 2,44 | 2,44 | 2,44 | 2,44 | 2,44 | 2,38 |
| Turning diameter track/circumference [m] | 10,6/- | 10,6/- | 10,6/- | 10,6/- | 10,6/- | 10,6/- |
| Overall length [mm] | 4395 | 4395 | 4395 | 4395 | 4395 | 4395 |
| Overall width without/including mirrors [mm] | 1826/- | 1826/- | 1826/- | 1826/- | 1826/- | 1826/- |
| Overall height [mm] | 1483 | 1483 | 1483 | 1495 | 1495 | 1483 |
| Wheelbase [mm] | 2650 | 2650 | 2650 | 2650 | 2650 | 2650 |
| Front wheel track [mm] | 1585 | 1585 | 1585 | 1575 | 1575 | 1585 |
| Rear wheel track [mm] | 1583 | 1583 | 1583 | 1573 | 1573 | 1583 |
| Forward overhang [mm] | 905 | 905 | 905 | 905 | 905 | 905 |
| Rear overhang [mm] | 840 | 840 | 840 | 840 | 840 | 840 |
| Clearance [mm] | 174 | 174 | 174 | 184 | 184 | 174 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 987 | 987 | 987 | 987 | 987 | 987 |
| Headroom rear [mm] | 953 | 953 | 953 | 953 | 953 | 953 |
| Front elbow/shoulder width [mm] | -/1428 | -/1428 | -/1428 | -/1428 | -/1428 | -/1428 |
| Rear elbow/shoulder width [mm] | -/1406 | -/1406 | -/1406 | -/1406 | -/1406 | -/1406 |
| Legroom front knees/total [mm] | -/1073 | -/1073 | -/1073 | -/1073 | -/1073 | -/1073 |
| Legroom rear knees/total [mm] | -/883 | -/883 | -/883 | -/883 | -/883 | -/883 |
| 1.6 CRDi 115 48V | 1.6 CRDi 115 48V | 1.6 CRDi 136 48V | 1.6 CRDi 136 48V | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | ||
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1598 | ||
| Maximum output / speed [kW/min-1] | 85/4000 | 85/4000 | 100/4000 | 100/4000 | ||
| Maximum torque [Nm/min-1] | 280/1500-2750 | 300/1500-2500 | 280/1500-3000 | 320/2000-2250 | ||
| Bore and stroke [mm x mm] | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | ||
| Compression ratio | 15,9:1 | 15,9:1 | 15,9:1 | 15,9:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | ||
| Drive specifications | - |
| - |
| ||
| Top speed [km/h] | 190 | 190 | 196 | 198 | ||
| Acceleration 0–100 km/h [s] | 11,4 | 11,1 | 10,6 | 10,1 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 4,4-4,2 | 4,5 | 4,4-4,2 | 4,4-4,3 | ||
| Out of town [l] | 3,9-3,7 | 4,0 | 4,1-3,9 | 4,4-4,0 | ||
| Combined [l] | 4,1-3,9 | 4,2 | 4,2-4,0 | 4,4-4,2 | ||
| CO2 emissions [g/km] | 106-101 | 109 | 109-104 | 114-108 | ||
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | 69 | 70 | 70 | 68 | ||
| Driving noise [dB] | 74,3 / 3000 rev/min | - | 71,5 / 3000 rev/min | 72,9 / 3000 rev/min | ||
| System voltage [V] | 48 | 48 | 48 | 48 | ||
| Battery type and capacity | Lithium-Ionen-Akkumulator, 0,44 kWh | Lithium-Ionen-Akkumulator, 0,44 kWh | Lithium-Ionen-Akkumulator, 0,44 kWh | Lithium-Ionen-Akkumulator, 0,44 kWh | ||
| Range with fully charged battery [km] | - | - | - | - | ||
| Charging time | - | - | - | - | ||
| Number of modules/cells | - | - | - | - | ||
| Battery weight [kg] | - | - | - | - | ||
| Charger | - | - | - | - | ||
| Standby weight [kg] | 1445-1559 | 1472-1586 | 1445-1559 | 1472-1586 | ||
| Overall weight [kg] | 1920 | 1950 | 1920 | 1950 | ||
| Maximum trailer weight unbraked/braked [kg] | 650/1500 | 650/1500 | 650/1500 | 650/1500 | ||
| Maximum front/rear axle load [kg] | 1050/950 | 1050/950 | 1050/950 | 1050/950 | ||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | ||
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | ||
| Boot volume [l] | 426 | 426 | 426 | 426 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1378 | -/1378 | -/1378 | -/1378 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | ||
| AdBlue tank volume [l] | 12 | 12 | 12 | 12 | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | MacPherson, coil springs, gas shock absorbers, torsion stabiliser | ||
| Rear suspension | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | multilink, coil springs, stabiliser bar, gas shock absorbers | ||
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Wheel size front | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | ||
| Wheel size rear | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | 6,5J x 16 ET40 | ||
| Brake dimensions front | 305 x 25 | 305 x 25 | 305 x 25 | 305 x 25 | ||
| Brake dimensions rear | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 | ||
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | ||
| Number of steering wheel turns | 2,44 | 2,44 | 2,44 | 2,44 | ||
| Turning diameter track/circumference [m] | 10,6/- | 10,6/- | 10,6/- | 10,6/- | ||
| Overall length [mm] | 4395 | 4395 | 4395 | 4395 | ||
| Overall width without/including mirrors [mm] | 1826/- | 1826/- | 1826/- | 1826/- | ||
| Overall height [mm] | 1483 | 1483 | 1483 | 1483 | ||
| Wheelbase [mm] | 2650 | 2650 | 2650 | 2650 | ||
| Front wheel track [mm] | 1585 | 1585 | 1585 | 1585 | ||
| Rear wheel track [mm] | 1583 | 1583 | 1583 | 1583 | ||
| Forward overhang [mm] | 905 | 905 | 905 | 905 | ||
| Rear overhang [mm] | 840 | 840 | 840 | 840 | ||
| Clearance [mm] | 174 | 174 | 174 | 174 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 987 | 987 | 987 | 987 | ||
| Headroom rear [mm] | 953 | 953 | 953 | 953 | ||
| Front elbow/shoulder width [mm] | -/1428 | -/1428 | -/1428 | -/1428 | ||
| Rear elbow/shoulder width [mm] | -/1406 | -/1406 | -/1406 | -/1406 | ||
| Legroom front knees/total [mm] | -/1073 | -/1073 | -/1073 | -/1073 | ||
| Legroom rear knees/total [mm] | -/883 | -/883 | -/883 | -/883 |
