Lancia Ypsilon

Date of manufacture

2011 – 2015 (Five-door hatchback)

Platform

Fiat Mini platform

Manufacturing locations

Tychy, Poland

Designer

Alberto Dilillo

Car body style

Five-door hatchback

Date of manufacture

2011 – 2015

Internal designation

846

Engine size

Petrol

1.2 8v

0.9T TwinAir

Diesel

1.3 Multijet

Technical data

Five-door hatchback

	1.2 8v	0.9T TwinAir	0.9T TwinAir	1.3 Multijet
Date of sale	-	-	-	-
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Diesel supercharged
Number of cylinders/valves	4/8	2/8	2/8	4/16
Engine displacement [cm³]	1242	875	875	1248
Maximum output / speed [kW/min-1]	51/5500	62,5/5500	62,5/5500	70/4000
Maximum torque [Nm/min-1]	102/3000	145/1900	145/1900	200/1500
Bore and stroke [mm x mm]	70,8 x 78,9	80,5 x 86,0	80,5 x 86,0	69,6 x 82,0
Compression ratio	11,1:1	10,0:1	10,0:1	16,8:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing start&stop system	turbo-supercharged electro-hydraulic control of intake valves lift MultiAir start&stop system	turbo-supercharged electro-hydraulic control of intake valves lift MultiAir start&stop system	direct injection Multijet with Common Rail turbocharger with variable blade geometry particulate filter start&stop system

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear robotic manual	5 gear manual
Drive specifications	-	-	robotic gearbox DFN	-

Top speed [km/h]	163	176	176	183
Acceleration 0–100 km/h [s]	14.5	11.9	12.2	11.4
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	6.4	5.0	4.9	4.7
Out of town [l]	4.1	3.8	3.7	3.2
Combined [l]	4.9	4.2	4.1	3.8
CO2 emissions [g/km]	115	99	97	99

Emission standard	EU5-EU6	EU5-EU6	EU5-EU6	EU5-EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	965	975	980	1050
Overall weight [kg]	-	-	-	-
Maximum trailer weight unbraked/braked [kg]	400/750	400/750	400/750	400/1000
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	245	245	245	245
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	4	4	4	4
Number of seats	4-5	4-5	4-5	4-5
Fuel tank volume [l]	40	40	40	40
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/55 R15 82H	185/55 R15 82H	185/55 R15 82H	185/55 R15 82H
Tyre dimensions rear	185/55 R15 82H	185/55 R15 82H	185/55 R15 82H	185/55 R15 82H
Wheel size front	6J x 15	6J x 15	6J x 15	6J x 15
Wheel size rear	6J x 15	6J x 15	6J x 15	6J x 15
Brake dimensions front	257 x 12	257 x 22	257 x 22	257 x 22
Brake dimensions rear	-	-	-	-
Steering	-	-	-	-
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	9.4/-	9.4/-	9.4/-	9.4/-

Overall length [mm]	3842	3842	3842	3842
Overall width without/including mirrors [mm]	1666/-	1666/-	1666/-	1666/-
Overall height [mm]	1518	1518	1518	1518
Wheelbase [mm]	2390	2390	2390	2390
Front wheel track [mm]	1414	1414	1414	1414
Rear wheel track [mm]	1408	1408	1408	1408
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-
