Land Rover Range Rover Sport
Date of manufacture
2014 – 2017 (Large SUV)
Platform
JLR D7u
Manufacturing locations
Solihull, United Kingdom
Designer
Gerry McGovern
Tags
Large SUV
British cars
The Land Rover Range Rover Sport is a large SUV that has been manufactured in the UK since 2014. It is built on the JLR D7u platform and offers a wide range of engine options - petrol, diesel and hybrid. The most powerful engine is the 5.0 V8 Supercharged 550 SVR with 405 kW, which guarantees a top speed of 260 km/h. The most economical model 2.0 SD4 240 has a combined fuel consumption of 6.2 l/100 km and CO2 emissions of 164 g/km. The luggage compartment size is 784 l.
Car body style
Large SUV
Date of manufacture
2014 – 2017Internal designation
L494Engine size
Technical data
Large SUV
| 3.0 V6 Supercharged 340 | 5.0 V8 Supercharged 510 | 5.0 V8 Supercharged 550 SVR | 2.0 SD4 240 | 3.0 TDV6 258 | 3.0 SDV6 292 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | from 2015 to | from 2016 to | - | from to 2015 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 8/32 | 8/32 | 4/16 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2995 | 5000 | 5000 | 1999 | 2993 | 2993 |
| Maximum output / speed [kW/min-1] | 250/6500 | 375/6000-6500 | 405/6000-6500 | 177/4000 | 190/4000 | 215/4000 |
| Maximum torque [Nm/min-1] | 450/3500-5000 | 625/2500-5500 | 680/3500-4000 | 500/1500 | 600/2000 | 600/2000 |
| Bore and stroke [mm x mm] | 84.5 x 89.0 | 92.5 x 93.0 | 92.5 x 93.0 | 83.0 x 92.35 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 10.5:1 | 9.5:1 | 9.5:1 | 15.5:1 | 16.1:1 | 16.1:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 210 | 225 [250 subject to a surcharge] | 260 | 207 | 210 | 210 [222 subject to a surcharge] |
| Acceleration 0–100 km/h [s] | 7.2 | 5.3 | 4.7 | 8.3 | 7.6 | 7.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | - | 18.3 | 18.3 | 7.9-7.5 | 8.3 | 8.7 |
| Out of town [l] | - | 9.7 | 9.8 | 5.7-5.5 | 6.7 | 6.8 |
| Combined [l] | - | 12.8 | 12.8 | 6.5-6.2 | 7.3 | 7.5 |
| CO2 emissions [g/km] | 229 | 298 | 298 | 172-164 | 194 | 199 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | - | 2335 | 2330 | 2115 | 2115 | 2115 |
| Overall weight [kg] | - | 3050 | 3000 | 2950 | 3000 | 3000 |
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 |
| Maximum front/rear axle load [kg] | 1500/1775 | 1500/1775 | 1500/1775 | 1500/1775 | 1500/1775 | 1500/1775 |
| Maximum vertical load on the tow bar [kg] | 150 | 150 | 150 | 150 | 150 | 150 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 784 | 784 | 784 | 784 | 784 | 784 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1761 | -/1761 | -/1761 | -/1761 | -/1761 | -/1761 |
| Boot length [mm] | 1043-1143 | 1043-1143 | 1043-1143 | 1043-1143 | 1043-1143 | 1043-1143 |
| Boot length with rear seats folded [mm] | 1871 | 1871 | 1871 | 1871 | 1871 | 1871 |
| Boot width between wheels/max [mm] | 1120/1285 | 1120/1285 | 1120/1285 | 1120/1285 | 1120/1285 | 1120/1285 |
| Boot height to headliner/ceiling [mm] | -/767 | -/767 | -/767 | -/767 | -/767 | -/767 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5/7 | 5/7 | 5/7 | 5/7 | 5/7 | 5/7 |
| Fuel tank volume [l] | 105 | 105 | 105 | 74 | 77 | 77 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.37 | 0.37 | 0.37 | 0.34 | 0.34 | 0.34 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | - | - | - | - | - | - |
| Tyre dimensions rear | - | - | - | - | - | - |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | 350 | 380 | 380 | 350 | 350 | 380 |
| Brake dimensions rear | 350 | 365 | 365 | 350 | 350 | 365 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | 2.78 | 2.78 | 2.78 | 2.78 | 2.78 | 2.78 |
| Turning diameter track/circumference [m] | 12.1/12.6 | 12.1/12.6 | 12.1/12.6 | 12.1/12.6 | 12.1/12.6 | 12.1/12.6 |
| Overall length [mm] | 4850 | 4850 | 4850 | 4850 | 4850 | 4850 |
| Overall width without/including mirrors [mm] | 1983/2220 | 1983/2220 | 1983/2220 | 1983/2220 | 1983/2220 | 1983/2220 |
| Overall height [mm] | 1780 | 1780 | 1780 | 1780 | 1780 | 1780 |
| Wheelbase [mm] | 2923 | 2923 | 2923 | 2923 | 2923 | 2923 |
| Front wheel track [mm] | 1690 | 1690 | 1690 | 1690 | 1690 | 1690 |
| Rear wheel track [mm] | 1685 | 1685 | 1685 | 1685 | 1685 | 1685 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 213 or 278 | 213 or 278 | 213 or 278 | 213 or 278 | 213 or 278 | 213 or 278 |
| Wading depth [mm] | 850 | 850 | 850 | 850 | 850 | 850 |
| Approach angle front [°] | 24.3 or 33.0 | 24.3 or 33.0 | 24.3 or 33.0 | 24.3 or 33.0 | 24.3 or 33.0 | 24.3 or 33.0 |
| Approach angle rear [°] | 24.9 or 31.0 | 24.9 or 31.0 | 24.9 or 31.0 | 24.9 or 31.0 | 24.9 or 31.0 | 24.9 or 31.0 |
| Transition angle [°] | 19.4 or 27.2 | 19.4 or 27.2 | 19.4 or 27.2 | 19.4 or 27.2 | 19.4 or 27.2 | 19.4 or 27.2 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1002 | 1002 | 1002 | 1002 | 1002 | 1002 |
| Headroom rear [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | -/1073 | -/1073 | -/1073 | -/1073 | -/1073 | -/1073 |
| Legroom rear knees/total [mm] | -/939 | -/939 | -/939 | -/939 | -/939 | -/939 |
| 3.0 SDV6 306 | 4.4 SDV8 339 | 3.0 SDV6 Hybrid 354 | ||||
|---|---|---|---|---|---|---|
| Date of sale | from 2015 to | - | from 2015 to | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged + Electric | |||
| Number of cylinders/valves | 6/24 | 8/32 | 6/24 | |||
| Engine displacement [cm³] | 2993 | 4367 | 2993 | |||
| Maximum output / speed [kW/min-1] | 225/4000 | 250/3500 | 225 combustion 35 el. 250/4000 total | |||
| Maximum torque [Nm/min-1] | 700/1500-1750 | 740/1750-2250 | 700/1500-1750 | |||
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 98.5 | 84.0 x 90.0 | |||
| Compression ratio | 16.1:1 | 16.1:1 | 16.1:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | 4x4 | 4x4 | 4x4 | |||
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | |||
| Drive specifications |
|
|
| |||
| Top speed [km/h] | 210 [225 subject to a surcharge] | 210 [225 subject to a surcharge] | 210 [225 subject to a surcharge] | |||
| Acceleration 0–100 km/h [s] | 7.2 | 6.9 | 6.7 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 7.9 | 11.5-10.8 | 6.8-6.7 | |||
| Out of town [l] | 6.4 | 7.6 | 6.3-5.9 | |||
| Combined [l] | 7.0 | 8.7-8.4 | 6.4-6.2 | |||
| CO2 emissions [g/km] | 185 | 229-219 | 169-164 | |||
| Emission standard | EU5 | EU5 | EU5 | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| System voltage [V] | - | - | - | |||
| Battery type and capacity | - | - | Lithium-Ionen-Akkumulator, - kWh | |||
| Range with fully charged battery [km] | - | - | - | |||
| Charging time | - | - | - | |||
| Number of modules/cells | - | - | - | |||
| Battery weight [kg] | - | - | - | |||
| Charger | - | - | - | |||
| Standby weight [kg] | 2185 | 2398 | 2372 | |||
| Overall weight [kg] | 3050 | 3200 | 3150 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | 750/3000 | |||
| Maximum front/rear axle load [kg] | 1500/1775 | 1550/1775 | 1500/1775 | |||
| Maximum vertical load on the tow bar [kg] | 150 | 150 | 120 | |||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | |||
| Boot volume [l] | 784 | 784 | 784 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1761 | -/1761 | -/1761 | |||
| Boot length [mm] | 1043-1143 | 1043-1143 | 1043-1143 | |||
| Boot length with rear seats folded [mm] | 1871 | 1871 | 1871 | |||
| Boot width between wheels/max [mm] | 1120/1285 | 1120/1285 | 1120/1285 | |||
| Boot height to headliner/ceiling [mm] | -/767 | -/767 | -/767 | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5/7 | 5/7 | 5/7 | |||
| Fuel tank volume [l] | 89 | 105 | 77 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | 0.34 | 0.36 | 0.37 | |||
| Front suspension | double wishbone | double wishbone | double wishbone | |||
| Rear suspension | multilink | multilink | multilink | |||
| Tyre dimensions front | - | - | - | |||
| Tyre dimensions rear | - | - | - | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | 380 | 380 | 380 | |||
| Brake dimensions rear | 365 | 365 | 365 | |||
| Steering | - | - | - | |||
| Number of steering wheel turns | 2.78 | 2.78 | 2.78 | |||
| Turning diameter track/circumference [m] | 12.1/12.6 | 12.1/12.6 | 12.1/12.6 | |||
| Overall length [mm] | 4850 | 4850 | 4850 | |||
| Overall width without/including mirrors [mm] | 1983/2220 | 1983/2220 | 1983/2220 | |||
| Overall height [mm] | 1780 | 1780 | 1780 | |||
| Wheelbase [mm] | 2923 | 2923 | 2923 | |||
| Front wheel track [mm] | 1690 | 1690 | 1690 | |||
| Rear wheel track [mm] | 1685 | 1685 | 1685 | |||
| Forward overhang [mm] | - | - | - | |||
| Rear overhang [mm] | - | - | - | |||
| Clearance [mm] | 213 or 278 | 213 or 278 | 213 or 278 | |||
| Wading depth [mm] | 850 | 850 | 850 | |||
| Approach angle front [°] | 24.3 or 33.0 | 24.3 or 33.0 | 24.3 or 33.0 | |||
| Approach angle rear [°] | 24.9 or 31.0 | 24.9 or 31.0 | 24.9 or 31.0 | |||
| Transition angle [°] | 19.4 or 27.2 | 19.4 or 27.2 | 18.9 or 25.9 | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 1002 | 1002 | 1002 | |||
| Headroom rear [mm] | 993 | 993 | 993 | |||
| Front elbow/shoulder width [mm] | - | - | - | |||
| Rear elbow/shoulder width [mm] | - | - | - | |||
| Legroom front knees/total [mm] | -/1073 | -/1073 | -/1073 | |||
| Legroom rear knees/total [mm] | -/939 | -/939 | -/939 |
