Maserati GranCabrio

Date of manufacture

2010 – 2017 (Convertible)

Platform

Maserati M139

Manufacturing locations

Modena, Italy

Designer

Jason Castriota

Car body style

Convertible

Date of manufacture

2010 – 2017

Internal designation

M139

Engine size

GranCabrio

GranCabrio Sport

Technical data

Convertible

	GranCabrio	GranCabrio Sport
Date of sale	-	from 2011 to
Engine type	Petrol	Petrol
Number of cylinders/valves	8/32	8/32
Engine displacement [cm³]	4691	4691
Maximum output / speed [kW/min-1]	323/7000	331/7000
Maximum torque [Nm/min-1]	490/4750	510/4750
Bore and stroke [mm x mm]	94.0 x 84.5	94.0 x 84.5
Compression ratio	11.25:1	11.25:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable valve timing	variable valve timing

Drive axle	Rear	Rear
Gearbox	6 gear automatic	6 gear automatic
Drive specifications	six-speed automatic gearbox	six-speed automatic gearbox

Top speed [km/h]	283	285
Acceleration 0–100 km/h [s]	5.2	5.0
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	22.5	22.5
Out of town [l]	9.8	9.8
Combined [l]	14.5	14.5
CO2 emissions [g/km]	337	337

Emission standard	Euro 5 - Euro 6	Euro 5 - Euro 6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1980	1980
Overall weight [kg]	2280	2280
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	173	173
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	4	4
Fuel tank volume [l]	75	75
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	245/35 ZR20	245/35 ZR20
Tyre dimensions rear	285/35 ZR20	285/35 ZR20
Wheel size front	8.5J x 20	8.5J x 20
Wheel size rear	10.5J x 20	10.5J x 20
Brake dimensions front	360 x 32	360 x 32
Brake dimensions rear	330 x 28	330 x 28
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.7/-	10.7/-

Overall length [mm]	4881	4881
Overall width without/including mirrors [mm]	1915/2056	1915/2056
Overall height [mm]	1380	1380
Wheelbase [mm]	2942	2942
Front wheel track [mm]	1586	1586
Rear wheel track [mm]	1590	1590
Forward overhang [mm]	873	873
Rear overhang [mm]	1066	1066
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Maserati GranCabrio M139 2012 front seats

Maserati GranCabrio M139 2013 front seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
