Maserati Levante
Date of manufacture
2016 – 2020 (Large SUV)
Platform
-
Manufacturing locations
Turin, Italy
Designer
Centro Stile FCA
Tags
Large SUV
Italian cars
Sport SUV
Car body style
Large SUV
Date of manufacture
2016 – 2020Internal designation
M161Engine size
Technical data
Large SUV
| Levante | Levante S | Levante GTS | Levante Trofeo | Levante Diesel | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | from 2018 to | from 2018 to | - | |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | |
| Number of cylinders/valves | 6/24 | 6/24 | 8/32 | 8/32 | 6/24 | |
| Engine displacement [cm³] | 2979 | 2979 | 3799 | 3799 | 2987 | |
| Maximum output / speed [kW/min-1] | 257/5750 | 316/5750 | 405/6250 | 434/6250 | 202/4000 | |
| Maximum torque [Nm/min-1] | 500/4500-5000 | 580/4500-5000 | 730/2500-5000 | 730/2500-5000 | 600/2000-2600 | |
| Bore and stroke [mm x mm] | 86.5 x 84.5 | 86.5 x 84.5 | 86.5 x 80.8 | 86.5 x 80.8 | 83.0 x 92.0 | |
| Compression ratio | 9.7:1 | 9.7:1 | 9.44:1 | 9.44:1 | 16.5:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | |
| Drive specifications |
|
|
|
|
| |
| Top speed [km/h] | 251 | 264 | 292 | 304 | 230 | |
| Acceleration 0–100 km/h [s] | 6.0 | 5.2 | 4.2 | 3.9 | 6.9 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 14.8-14.2 | 15.0-14.4 | 18.8 | 18.8 | 10.0-8.2 | |
| Out of town [l] | 9.5-8.3 | 9.4-8.5 | 10.5 | 10.5 | 7.3-6.6 | |
| Combined [l] | 12.0-10.7 | 12.2-10.9 | 13.5 | 13.5 | 8.3-7.2 | |
| CO2 emissions [g/km] | 278-249 | 282-253 | 313 | 313 | 220-189 | |
| Emission standard | Euro 6 - Euro 6d | Euro 6 - Euro 6d | Euro 6 - Euro 6d | Euro 6 - Euro 6d | Euro 6 - Euro 6d | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 2109 | 2109 | 2170 | 2170 | 2205 | |
| Overall weight [kg] | - | - | - | - | - | |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | |
| Boot volume [l] | 580 | 580 | 580 | 580 | 580 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1625 | -/1625 | -/1625 | -/1625 | -/1625 | |
| Boot length [mm] | - | - | - | - | - | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | - | - | - | - | - | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 80 | 80 | 80 | 80 | 80 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | - | - | - | - | - | |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | |
| Tyre dimensions front | 265/50 R19 | 265/50 R19 | 265/45 R20 | 265/45 R20 | 265/50 R19 | |
| Tyre dimensions rear | 265/50 R19 | 295/45 ZR19 | 295/40 R20 | 295/40 R20 | 265/50 R19 | |
| Wheel size front | - | - | - | - | - | |
| Wheel size rear | - | - | - | - | - | |
| Brake dimensions front | 345 x 32 | 380 x 34 | 380 x 34 | 380 x 34 | 345 x 32 | |
| Brake dimensions rear | 330 x 22 | 330 x 22 | 330 x 22 | 330 x 22 | 330 x 22 | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.7/- | 11.7/- | 11.7/- | 11.7/- | 11.7/- | |
| Overall length [mm] | 5005 | 5005 | 5020 | 5020 | 5005 | |
| Overall width without/including mirrors [mm] | 1981/2158 | 1981/2158 | 1981/2158 | 1981/2158 | 1981/2158 | |
| Overall height [mm] | 1679 | 1679 | 1698 | 1698 | 1679 | |
| Wheelbase [mm] | 3004 | 3004 | 3004 | 3004 | 3004 | |
| Front wheel track [mm] | 1624 | 1624 | 1637 | 1637 | 1624 | |
| Rear wheel track [mm] | 1676 | 1676 | 1699 | 1699 | 1676 | |
| Forward overhang [mm] | 967 | 967 | 975 | 975 | 967 | |
| Rear overhang [mm] | 1034 | 1034 | 1041 | 1041 | 1034 | |
| Clearance [mm] | - | - | - | - | - | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | - | - | - | - | - | |
| Approach angle rear [°] | - | - | - | - | - | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | - | - | - | - | - | |
| Headroom rear [mm] | - | - | - | - | - | |
| Front elbow/shoulder width [mm] | - | - | - | - | - | |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
