Mazda 5

5 CW 2010

Date of manufacture

2010 – 2014 (MPV)

Platform

Mazda CW

Manufacturing locations

Hiroshima, Japan

Designer

-

Tags

Mid-size MPV
Japanese cars
The Mazda 5 is an MPV that has been manufactured since 2010 and is from Japan. The vehicle is based on the Mazda CW platform and offers both petrol and diesel engines. The strongest engine is the 2.0 MZR with 110 kW of power, which reaches a top speed of 194 km/h and the fastest acceleration from 0-100 km/h in 11 seconds. The most economical engine, the 1.6 MZ-CD, has a fuel consumption of 5.2 l/100 km and emissions of 139 g/km. The car's trunk has a capacity of 538 l.

Car body style

MPV

Date of manufacture
2010 – 2014
Internal designation
CW
Engine size
PetrolDiesel

Technical data

MPV

1.8 MZR 2.0 MZR 1.6 MZ-CD
Date of sale---
Engine typePetrolPetrolDiesel supercharged
Number of cylinders/valves4/164/164/8
Engine displacement [cm³]179819981560
Maximum output / speed [kW/min-1]
85/5300
110/6200
85/4000
Maximum torque [Nm/min-1]
165/4000
191/4000
270/1750
Drive axleFrontFrontFront
Gearbox6 gear manual6 gear manual6 gear manual
Top speed [km/h]182194180
Acceleration 0–100 km/h [s]12.811.013.7
City [l]9.39.06.4
Out of town [l]6.05.74.6
Combined [l]7.26.95.2
CO2 emissions [g/km]168159139
Emission standardEU5EU5EU5
Standby weight [kg]147014851490
Overall weight [kg]208521252125
Maximum trailer weight unbraked/braked [kg]600/1200600/1200600/1200
Boot volume [l]538112538
Boot volume with rear seats folded to the edge of the seats/ceiling [l]-/1597-/1485-/1597
Boot volume, third row of seats [l]---
Number of doors555
Number of seats5-775-7
Fuel tank volume [l]707070
AdBlue tank volume [l]---
Overall length [mm]458545854585
Overall width without/including mirrors [mm]1750/-1750/-1750/-
Overall height [mm]161516151615
Wheelbase [mm]275027502750
Headroom front [mm]103410341034
Headroom rear [mm]100010001000
Front elbow/shoulder width [mm]-/1409-/1409-/1409
Rear elbow/shoulder width [mm]-/1410-/1410-/1410
Third row of seats, headroom [mm]942942942
Third row elbow/shoulder width [mm]-/1251-/1251-/1251

Gallery

Mazda 5 CW 2010 interiorMazda 5 CW 2011 interiorMazda 5 CW 2013 interiorMazda 5 CW 2010 rear seatsMazda 5 CW 2011 rear seatsMazda 5 CW 2010 rear folding seatsMazda 5 CW 2010 bootMazda 5 CW 2011 rear folding seats
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
