Mercedes-Benz GLK
Date of manufacture
2012 – 2015 (SUV)
Platform
-
Manufacturing locations
Bremen, Germany
Beijing, People's Republic of China
Designer
-
Tags
Compact SUV
German cars
The Mercedes-Benz GLK has been produced since 2012 as an SUV, in two countries: Germany and China. The engine range includes six- and eight-cylinder engines with manual and automatic transmissions. The most powerful model is the GLK 350 4MATIC with 225 kW, which has a top speed of 238 km/h and the best acceleration from 0-100 km/h in 6.4 seconds. For the eco-oriented user, the Mercedes-Benz GLK 220 CDI has the lowest fuel consumption of 5.5 l/100 km and CO2 emissions of 143 g/km. The luggage compartment has a capacity of 450 l. The vehicle successfully passed the EURONCAP safety tests in 2010, receiving a rating of 5 out of 5.
Car body style
SUV
after upgrade (facelift)
Date of manufacture
2012 – 2015Internal designation
X204
Technical data
SUV
| GLK 200 | GLK 250 | GLK 250 4MATIC | GLK 350 4MATIC | GLK 200 CDI | GLK 200 CDI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 6/24 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1991 | 1991 | 1991 | 3498 | 2143 | 2143 |
| Maximum output / speed [kW/min-1] | 135/5500 | 155/5500 | 155/5500 | 225/6500 | 105/3200 | 105/3200 |
| Maximum torque [Nm/min-1] | 300/1200-4000 | 350/1200-4000 | 350/1200-4000 | 370/3500-5250 | 350/1200-2800 | 350/1200-2800 |
| Bore and stroke [mm x mm] | 83,0 x 92,0 | 83,0 x 92,0 | 83,0 x 92,0 | 92,6 x 86,0 | 83,0 x 99,0 | 83,0 x 99,0 |
| Compression ratio | 9,8:1 | 9,8:1 | 9,8:1 | 12,0:1 | 16,2:1 | 16,2:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | 4x4 | Rear | Rear |
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 6 gear manual | 7 gear automatic |
| Drive specifications | - |
|
|
| - |
|
| Top speed [km/h] | 210 | 215 | 215 | 238 | 195 | 190 |
| Acceleration 0–100 km/h [s] | 8.8 | 7.8 | 7.9 | 6.5 | 10.3 | 10.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.1-9.2 | 8.5-8.6 | 9.0 | 10.3-10.8 | 6.5 | 6.4-6.5 |
| Out of town [l] | 6.1-6.2 | 6.2-6.3 | 6.5-6.6 | 6.8-7.3 | 4.9-5.1 | 5.1-5.2 |
| Combined [l] | 7.2-7.3 | 7.0-7.1 | 7.4-7.5 | 8.1-8.6 | 5.5-5.6 | 5.6-5.7 |
| CO2 emissions [g/km] | 168-170 | 164-165 | 173-174 | 189-199 | 143-147 | 145-147 |
| Emission standard | EU6 | EU6 | EU6 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1735 | 1765 | 1825 | 1845 | 1825 | 1845 |
| Overall weight [kg] | 2310 | 2340 | 2400 | 2420 | 2400 | 2420 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2300 | 750/2400 | 750/2400 | 750/2000 | 750/2400 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 450 | 450 | 450 | 450 | 450 | 450 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1550 | -/1550 | -/1550 | -/1550 | -/1550 | -/1550 |
| Boot length [mm] | 890 | 890 | 890 | 890 | 890 | 890 |
| Boot length with rear seats folded [mm] | 1674 | 1674 | 1674 | 1674 | 1674 | 1674 |
| Boot width between wheels/max [mm] | -/950 | -/950 | -/950 | -/950 | -/950 | -/950 |
| Boot height to headliner/ceiling [mm] | -/840 | -/840 | -/840 | -/840 | -/840 | -/840 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 66 | 66 | 66 | 66 | 59 | 59 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.36 | 0.36 | 0.36 | 0.36 | 0.34 | 0.34 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 |
| Tyre dimensions rear | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 |
| Wheel size front | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 |
| Wheel size rear | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.65/- | 11.65/- | 11.65/- | 11.65/- | 11.65/- | 11.65/- |
| Overall length [mm] | 4536 | 4536 | 4536 | 4536 | 4536 | 4536 |
| Overall width without/including mirrors [mm] | 1840/- | 1840/- | 1840/- | 1840/- | 1840/- | 1840/- |
| Overall height [mm] | 1669 | 1669 | 1669 | 1669 | 1669 | 1669 |
| Wheelbase [mm] | 2755 | 2755 | 2755 | 2755 | 2755 | 2755 |
| Front wheel track [mm] | 1574 | 1574 | 1574 | 1574 | 1574 | 1574 |
| Rear wheel track [mm] | 1597 | 1597 | 1597 | 1597 | 1597 | 1597 |
| Forward overhang [mm] | 824 | 824 | 824 | 824 | 824 | 824 |
| Rear overhang [mm] | 957 | 957 | 957 | 957 | 957 | 957 |
| Clearance [mm] | 147 | 147 | 147 | 147 | 145 | 145 |
| Wading depth [mm] | 300 | 300 | 300 | 300 | 300 | 300 |
| Approach angle front [°] | 23.6 | 23.6 | 23.6 | 23.6 | 23.6 | 23.6 |
| Approach angle rear [°] | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 |
| Transition angle [°] | 15.1 | 15.1 | 15.1 | 14.9 | 15.1 | 15.1 |
| Climbing rate [°] | 70 | 70 | 70 | 70 | 70 | 70 |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1010 | 1010 | 1010 | 1010 | 1010 | 1010 |
| Headroom rear [mm] | 1012 | 1012 | 1012 | 1012 | 1012 | 1012 |
| Front elbow/shoulder width [mm] | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 |
| Rear elbow/shoulder width [mm] | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| GLK 220 CDI | GLK 220 CDI | GLK 220 CDI 4MATIC | GLK 220 BlueTEC 4MATIC | GLK 250 BlueTEC 4MATIC | GLK 350 CDI 4MATIC | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 6/24 |
| Engine displacement [cm³] | 2143 | 2143 | 2143 | 2143 | 2143 | 2987 |
| Maximum output / speed [kW/min-1] | 125/3200-4800 | 125/3200-4800 | 125/3200-4800 | 125/3200-4800 | 150/4200 | 195/3800 |
| Maximum torque [Nm/min-1] | 400/1400-2800 | 400/1400-2800 | 400/1400-2800 | 400/1400-2800 | 500/1600-1800 | 620/1600-2400 |
| Bore and stroke [mm x mm] | 83,0 x 99,0 | 83,0 x 99,0 | 83,0 x 99,0 | 83,0 x 99,0 | 83,0 x 99,0 | 83,0 x 92,0 |
| Compression ratio | 16,2:1 | 16,2:1 | 16,2:1 | 16,2:1 | 16,2:1 | 15,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications | - |
|
|
|
|
|
| Top speed [km/h] | 205 | 205 | 205 | 205 | 210 | 232 |
| Acceleration 0–100 km/h [s] | 8.5 | 8.7 | 8.8 | 8.8 | 8.0 | 6.4 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.5 | 6.4-6.5 | 7.1-7.2 | 7.0-7.1 | 7.0-7.1 | 8.2-8.3 |
| Out of town [l] | 4.9-5.0 | 5.1-5.2 | 5.5-5.6 | 5.5-5.6 | 5.5-5.6 | 6.1-6.2 |
| Combined [l] | 5.5 | 5.6-5.7 | 6.1-6.2 | 6.1-6.2 | 6.1-6.2 | 6.9-7.0 |
| CO2 emissions [g/km] | 143-145 | 145-147 | 159-161 | 159-162 | 159-162 | 179-181 |
| Emission standard | EU5 | EU5 | EU5 | EU6 | EU6 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1825 | 1845 | 1880 | 1925 | 1925 | 1925 |
| Overall weight [kg] | 2400 | 2420 | 2455 | 2500 | 2500 | 2500 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2400 | 750/2400 | 750/2400 | 750/2400 | 750/2500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 450 | 450 | 450 | 400 | 400 | 450 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1550 | -/1550 | -/1550 | -/1500 | -/1500 | -/1550 |
| Boot length [mm] | 890 | 890 | 890 | 890 | 890 | 890 |
| Boot length with rear seats folded [mm] | 1674 | 1674 | 1674 | 1674 | 1674 | 1674 |
| Boot width between wheels/max [mm] | -/950 | -/950 | -/950 | -/950 | -/950 | -/950 |
| Boot height to headliner/ceiling [mm] | -/840 | -/840 | -/840 | -/840 | -/840 | -/840 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 59 | 59 | 59 | 59 | 59 | 66 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.34 | 0.34 | 0.35 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 235/60 R17 102 V | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 102 V |
| Tyre dimensions rear | 235/60 R17 102 V | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 | 235/60 R17 102 V |
| Wheel size front | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 |
| Wheel size rear | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 | 7.5J x 17 ET47.5 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.65/- | 11.65/- | 11.65/- | 11.65/- | 11.65/- | 11.65/- |
| Overall length [mm] | 4536 | 4536 | 4536 | 4536 | 4536 | 4536 |
| Overall width without/including mirrors [mm] | 1840/- | 1840/- | 1840/- | 1840/- | 1840/- | 1840/- |
| Overall height [mm] | 1669 | 1669 | 1669 | 1669 | 1669 | 1669 |
| Wheelbase [mm] | 2755 | 2755 | 2755 | 2755 | 2755 | 2755 |
| Front wheel track [mm] | 1574 | 1574 | 1574 | 1574 | 1574 | 1574 |
| Rear wheel track [mm] | 1597 | 1597 | 1597 | 1597 | 1597 | 1597 |
| Forward overhang [mm] | 824 | 824 | 824 | 824 | 824 | 824 |
| Rear overhang [mm] | 957 | 957 | 957 | 957 | 957 | 957 |
| Clearance [mm] | 145 | 145 | 144 | 144 | 145 | 144 |
| Wading depth [mm] | 300 | 300 | 300 | 300 | 300 | 300 |
| Approach angle front [°] | 23.6 | 23.6 | 23.6 | 23.6 | 23.6 | 23.6 |
| Approach angle rear [°] | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 |
| Transition angle [°] | 15.1 | 15.1 | 15.1 | 15.1 | 15.1 | 15.1 |
| Climbing rate [°] | 70 | 70 | 70 | 70 | 70 | 70 |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1010 | 1010 | 1010 | 1010 | 1010 | 1010 |
| Headroom rear [mm] | 1012 | 1012 | 1012 | 1012 | 1012 | 1012 |
| Front elbow/shoulder width [mm] | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 | 1401/1442 |
| Rear elbow/shoulder width [mm] | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 | 1408/1440 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Gallery
