	GLS 450 4MATIC	GLS 580 4MATIC	GLS 63 AMG 4MATIC+	Maybach GLS 600 4MATIC	GLS 350d 4MATIC	GLS 400d 4MATIC
Date of sale	from 2020 to	-	from 2020 to	from 2020 to	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/32	8/32	8/32	6/24	6/24
Engine displacement [cm³]	2999	3982	3982	3982	2925	2925
Maximum output / speed [kW/min-1]	270/5500-6100 16 el.	360/5500 16 el.	450/5750-6500 16 el.	410/6000-6500 16 el.	210/3400-4600	243/3600-4000
Maximum torque [Nm/min-1]	500/1600-4500 250 el.	700/2000-4000 250 el.	850/2500-4500 250 el.	730/2500-5000 250 el.	600/1200-3200	700/1200-3200
Bore and stroke [mm x mm]	83.0 x 92.4	83,0 x 92,0	83,0 x 92,0	83,0 x 92,0	82.0 x 92.3	82.0 x 92.3
Compression ratio	10.5:1	10.5:1	8.6:1	10.5:1	15.5:1	15.5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	Mild Hybrid direct injection turbo-supercharged Twin-Scroll electrically driven compressor eZV Gasoline Particulate Filter starter-generator EQ Boost start&stop system	Mild Hybrid direct injection BlueDIRECT supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves CAMTRONIC Gasoline Particulate Filter starter-generator EQ Boost start&stop system	Mild Hybrid direct injection BlueDIRECT supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves CAMTRONIC Gasoline Particulate Filter starter-generator EQ Boost start&stop system	Mild Hybrid direct injection BlueDIRECT supercharging by twin turbochargers Twin-Scroll variable timing of intake and exhaust valves CAMTRONIC Gasoline Particulate Filter starter-generator EQ Boost start&stop system	direct injection Common Rail supercharging by twin turbochargers with variable blade geometry variable intake valve timing and lift CAMTRONIC particulate filter SCR catalytic converter with AdBlue additive injection start&stop system	direct injection Common Rail supercharging by twin turbochargers with variable blade geometry variable intake valve timing and lift CAMTRONIC particulate filter SCR catalytic converter with AdBlue additive injection start&stop system

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic	9 gear automatic
Drive specifications	automatically controlled all-wheel drive 4MATIC nine-speed automatic gearbox 9G-TRONIC	automatically controlled all-wheel drive 4MATIC nine-speed automatic gearbox 9G-TRONIC	automatically controlled all-wheel drive 4MATIC+ nine-speed automatic gearbox AMG SPEEDSHIFT MCT	automatically controlled all-wheel drive 4MATIC nine-speed automatic gearbox 9G-TRONIC	automatically controlled all-wheel drive 4MATIC nine-speed automatic gearbox 9G-TRONIC	automatically controlled all-wheel drive 4MATIC nine-speed automatic gearbox 9G-TRONIC

Top speed [km/h]	246	250	250 [280 subject to a surcharge]	250	227	238
Acceleration 0–100 km/h [s]	6.2	5.3	4.2	4.9	7.0	6.3
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	12.2-11.5	15.3-14.4	15.3	16.0	9.9-8.6	9.9-8.6
Out of town [l]	7.9-7.4	9.0-8.4	10.0	9.7	6.8-6.1	6.8-6.1
Combined [l]	9.4-9.0	11.2-10.7	11.9	12.0	7.9-7.1	7.9-7.1
CO2 emissions [g/km]	215-206	257-245	273	275	209-187	209-187

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	48	48	48	48	-	-
Battery type and capacity	-	-	-	-	-	-
Range with fully charged battery [km]	-	-	-	-	-	-
Charging time	-	-	-	-	-	-
Number of modules/cells	-	-	-	-	-	-
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	2460	2545	2630	2785	2500	2505
Overall weight [kg]	3230	3250	3395	3250	3250	3250
Maximum trailer weight unbraked/braked [kg]	750/3500	750/3500	750/3300	750/3500	750/3500	750/3500
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	140	140	140	140	140	140
Maximum load on roof/carrier [kg]	100/-	100/-	75/-	100/-	100/-	100/-

Boot volume [l]	355	355	355	520	355	355
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2400	-/2400	-/2400	-	-/2400	-/2400
Boot volume, third row of seats [l]	-	-	-	-	-	-
Boot volume, third row seats folded [l]	-	-	-	-	-	-
Boot length [mm]	1377 [570 seven seats]	1377 [570 seven seats]	1377 [570 seven seats]	961	1377 [570 seven seats]	1377 [570 seven seats]
Boot length with rear seats folded [mm]	2217	2217	2217	2217	2217	2217
Boot width between wheels/max [mm]	1050/-	1050/-	1050/-	1050/-	1050/-	1050/-
Boot height to headliner/ceiling [mm]	-/882	-/882	-/882	490/-	-/882	-/882
Loading edge height [mm]	824	824	837	839	824	824
Height of the open boot door [mm]	2169	2169	2313	2184	2169	2169
Boot opening height [mm]	838	838	838	838	838	838
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	7	7	7	4-5	7	7
Fuel tank volume [l]	90	90	90	90	90	90
AdBlue tank volume [l]	-	-	-	-	31.6	31.6
Air resistance [Cd]	0.33	0.34	-	0.37	0.33	0.33
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	275/55 R19 W	275/50 R20 W	275/50 R21 113Y XL	285/45 R22	275/55 R19 W	275/55 R19 W
Tyre dimensions rear	275/55 R19 W	275/50 R20 W	315/45 R21 116Y	325/40 R22	275/55 R19 W	275/55 R19 W
Wheel size front	8.5J x 19 H2	8.5J x 20 H2	9,0J x 21 H2 ET45	9.5J x 22 H2	8.5J x 19 H2	8.5J x 19 H2
Wheel size rear	8.5J x 19 H2	8.5J x 20 H2	11,5J x 21 H2 ET45	11.5J x 22 H2	8.5J x 19 H2	8.5J x 19 H2
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	12.52/-	12.52/-	13.1/-	-	12.52/-	12.52/-

Overall length [mm]	5207	5207	5243	5205	5207	5207
Overall width without/including mirrors [mm]	1956/2157	1956/2157	2030/2157	2030/2157	1956/2157	1956/2157
Overall height [mm]	1823	1823	1836	1838	1823	1823
Wheelbase [mm]	3135	3135	3135	3135	3135	3135
Front wheel track [mm]	1669	1669	1705	1699	1669	1669
Rear wheel track [mm]	1692	1692	1723	1723	1692	1692
Forward overhang [mm]	936	936	966	938	936	936
Rear overhang [mm]	1136	1136	1142	1132	1136	1136
Clearance [mm]	199	199	204	160	199	199
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	21.0	21.0	18.9	24.0	21.0	21.0
Approach angle rear [°]	20.0	20.0	18.2	21.0	20.0	20.0
Transition angle [°]	15.0	15.0	16.3	14.0	15.0	15.0
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1051	1051	1051	1080	1051	1051
Headroom rear [mm]	1022	1022	1022	1020	1022	1022
Front elbow/shoulder width [mm]	1506/1545	1506/1545	1506/1545	1506/1545	1506/1545	1506/1545
Rear elbow/shoulder width [mm]	1485/1523	1485/1523	1485/1523	1424/1491	1485/1523	1485/1523
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-
Third row of seats, headroom [mm]	988	988	988	-	988	988
Third row elbow/shoulder width [mm]	1278/1291	1278/1291	1278/1291	-	1278/1291	1278/1291
