Mini One & Cooper Cabrio
Date of manufacture
11/2015 – 2018 (Convertible)
Platform
-
Manufacturing locations
Born, Netherlands
Designer
-
Tags
A-segment
Mini One and Cooper Cabrio are convertible models from the Mini brand, which have been manufactured since 2015. The models are made in the Netherlands and offer a wide range of engines, the most powerful of which is the John Cooper Works with a maximum power of 170 kW. The fastest model is also the John Cooper Works with a maximum speed of 242 km/h and the best acceleration 0-100 km/h in 6.5 seconds. The most economical engine is the Cooper SD with a combined fuel consumption of 4.3 l/100 km and CO2 emissions of 113 g/km. The luggage compartment has a capacity of 160-215 liters.
Car body style
Convertible
Date of manufacture
11/2015 – 2018Internal designation
F57Engine size
Technical data
Convertible
| One | Cooper | Cooper | Cooper S | Cooper S | John Cooper Works | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1198 | 1499 | 1499 | 1998 | 1998 | 1998 |
| Maximum output / speed [kW/min-1] | 75/4250-6000 | 100/4400 | 100/4400 | 141/5000-6000 | 141/5000-6000 | 170/5200-6000 |
| Maximum torque [Nm/min-1] | 180/1400-4000 | 220/1250 | 220/1250 | 280/1250-4600 | 280/1250-4600 | 320/1250-4800 |
| Bore and stroke [mm x mm] | 78,0 x 86,0 | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 | 82,0 x 94,6 |
| Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 | 10,2:1 |
| Oil volume [l] | 4.25 | 4.25 | 4.25 | 5.25 | 5.25 | 5.25 |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 190 | 208 | 206 | 230 | 228 | 242 |
| Acceleration 0–100 km/h [s] | 10.6 | 8.8 | 8.7 | 7.2 | 7.1 | 6.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 13.2 (5th gear) | 10.3 (5th gear) | - | 6.7 (5th gear) | - | 6.1 (5th gear) |
| City [l] | 5.9-6.0 | 5.9-6.0 | 6.2-6.3 | 7.8-7.9 | 7.1-7.2 | 8.6 |
| Out of town [l] | 4.4-4.6 | 4.3-4.5 | 4.5-4.7 | 4.9-5.1 | 4.8-5.0 | 5.4 |
| Combined [l] | 5.0-5.2 | 4.9-5.1 | 5.1-5.3 | 6.0-6.1 | 4.6-5.8 | 6.5 |
| CO2 emissions [g/km] | 116-120 | 114-118 | 119-123 | 139-142 | 131-134 | 152 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1280 | 1280 | 1305 | 1350 | 1370 | 1385 |
| Overall weight [kg] | 1670 | 1670 | 1695 | 1745 | 1765 | 1770 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | 900/805 | 910/800 | 940/800 | 955/810 | 975/810 | 960/820 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 160-215 | 160-215 | 160-215 | 160-215 | 160-215 | 160-215 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 40 | 40 | 40 | 44 | 44 | 44 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.34 | 0.36 | 0.36 | 0.36 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 176/65 R15 84H | 176/65 R15 84H | 176/65 R15 84H | 195/55 R16 87W | 195/55 R16 87W | 205/45 R17 88Y XL |
| Tyre dimensions rear | 176/65 R15 84H | 176/65 R15 84H | 176/65 R15 84H | 195/55 R16 87W | 195/55 R16 87W | 205/45 R17 88Y XL |
| Wheel size front | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 | 7.0J x 17 |
| Wheel size rear | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 | 7.0J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- |
| Overall length [mm] | 3821 | 3821 | 3821 | 3850 | 3850 | 3874 |
| Overall width without/including mirrors [mm] | 1727/- | 1727/- | 1727/- | 1727/- | 1727/- | 1727/- |
| Overall height [mm] | 1415 | 1415 | 1415 | 1415 | 1415 | 1415 |
| Wheelbase [mm] | 2495 | 2495 | 2495 | 2495 | 2495 | 2495 |
| Front wheel track [mm] | 1501 | 1501 | 1501 | 1485 | 1485 | 1485 |
| Rear wheel track [mm] | 1501 | 1501 | 1501 | 1485 | 1485 | 1485 |
| Forward overhang [mm] | 749 | 749 | 749 | 757 | 757 | - |
| Rear overhang [mm] | 577 | 577 | 577 | 598 | 598 | - |
| Clearance [mm] | 115 | 115 | 115 | 115 | 115 | 115 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| John Cooper Works | Cooper D | Cooper D | Cooper SD | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 3/12 | 3/12 | 4/16 | ||
| Engine displacement [cm³] | 1998 | 1496 | 1496 | 1995 | ||
| Maximum output / speed [kW/min-1] | 170/5200-6000 | 85/4000 | 85/4000 | 125/4000 | ||
| Maximum torque [Nm/min-1] | 320/1250-4800 | 270/1750-2250 | 270/1750-2250 | 360/1500-2750 | ||
| Bore and stroke [mm x mm] | 82,0 x 94,6 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | ||
| Compression ratio | 10,2:1 | 16,5:1 | 16,5:1 | 16,5:1 | ||
| Oil volume [l] | 5.25 | 4.4 | 4.4 | 5.0 | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear automatic | ||
| Drive specifications |
| - |
|
| ||
| Top speed [km/h] | 240 | 208 | 208 | 218 | ||
| Acceleration 0–100 km/h [s] | 6.5 | 8.8 | 8.8 | 7.7 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | 9.9 (5th gear) | - | - | ||
| City [l] | 7.4 | 5.9-6.0 | 5.9-6.0 | 4.9-5.0 | ||
| Out of town [l] | 5.1 | 4.3-4.5 | 4.3-4.5 | 3.9-4.1 | ||
| Combined [l] | 5.9 | 4.9-5.1 | 4.9-5.1 | 4.3-4.4 | ||
| CO2 emissions [g/km] | 138 | 114-118 | 114-118 | 113-116 | ||
| Emission standard | EU6 | EU6 | EU6 | EU6 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1395 | 1280 | 1280 | 1380 | ||
| Overall weight [kg] | 1785 | 1670 | 1670 | 1770 | ||
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | ||
| Maximum front/rear axle load [kg] | 980/820 | 955/820 | 975/820 | 970/810 | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | - | - | - | - | ||
| Boot volume [l] | 160-215 | 160-215 | 160-215 | 160-215 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 2 | 2 | 2 | 2 | ||
| Number of seats | 4 | 4 | 4 | 4 | ||
| Fuel tank volume [l] | 44 | 44 | 44 | 44 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.36 | 0.34 | 0.34 | 0.36 | ||
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 205/45 R17 88Y XL | 176/65 R15 84H | 176/65 R15 84H | 195/55 R16 87W | ||
| Tyre dimensions rear | 205/45 R17 88Y XL | 176/65 R15 84H | 176/65 R15 84H | 195/55 R16 87W | ||
| Wheel size front | 7.0J x 17 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | ||
| Wheel size rear | 7.0J x 17 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | 10.8/- | 10.8/- | ||
| Overall length [mm] | 3874 | 3821 | 3821 | 3850 | ||
| Overall width without/including mirrors [mm] | 1727/- | 1727/- | 1727/- | 1727/- | ||
| Overall height [mm] | 1415 | 1415 | 1415 | 1415 | ||
| Wheelbase [mm] | 2495 | 2495 | 2495 | 2495 | ||
| Front wheel track [mm] | 1485 | 1501 | 1501 | 1485 | ||
| Rear wheel track [mm] | 1485 | 1501 | 1501 | 1485 | ||
| Forward overhang [mm] | - | 749 | 749 | 757 | ||
| Rear overhang [mm] | - | 577 | 577 | 598 | ||
| Clearance [mm] | 115 | 115 | 115 | 115 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | - | - | - | - | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | - | - | - | - | ||
| Rear elbow/shoulder width [mm] | - | - | - | - | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
