Mini One & Cooper Clubman
Date of manufacture
2010 – 6/2014 (Estate)
Platform
-
Manufacturing locations
Oxford, United Kingdom
Designer
-
Tags
A-segment
Mini One & Cooper Clubman is a estate car with a production plant in the United Kingdom. It offers a wide range of engines, from petrol to diesel. The highest power (155 kW) is found in the John Cooper Works model, which reaches a speed of 238 km/h and the best acceleration 0-100 km/h in 6.8 seconds. The most economical variant is Cooper D with a consumption of 3.9 l/100 km and CO2 emissions of 103 g/km. The car trunk has a capacity of 260 liters.
Technical data
Estate
| One | One | Cooper | Cooper | Cooper S | Cooper S | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1598 | 1598 | 1598 |
| Maximum output / speed [kW/min-1] | 72/6000 | 72/6000 | 90/6000 | 90/6000 | 135/5500 | 135/5500 |
| Maximum torque [Nm/min-1] | 153/3000 | 153/3000 | 160/4250 | 160/4250 | 240/1600-5000 | 240/1600-5000 |
| Bore and stroke [mm x mm] | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 | 77,0 x 85,8 |
| Compression ratio | 11,0:1 | 11,0:1 | 11,0:1 | 11,0:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | 4.2 | 4.2 | 4.2 | 4.2 | 4.2 | 4.2 |
| Coolant volume [l] | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications | - |
| - |
| - |
|
| Top speed [km/h] | 185 | 179 | 201 | 195 | 227 | 222 |
| Acceleration 0–100 km/h [s] | 11.1 | 12.8 | 9.8 | 10.9 | 7.5 | 7.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 16.4 (5th gear) | - | 12.7 (5th gear) | - | 7.6 (5th gear) | - |
| City [l] | 7.3 | 8.8 | 7.0 | 8.8 | 7.4 | 8.9 |
| Out of town [l] | 4.5 | 5.2 | 4.7 | 5.2 | 5.0 | 5.0 |
| Combined [l] | 5.5 | 6.5 | 5.5 | 6.5 | 5.9 | 6.4 |
| CO2 emissions [g/km] | 129 | 152 | 129 | 152 | 137 | 150 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1215 | 1245 | 1220 | 1250 | 1280 | 1305 |
| Overall weight [kg] | 1640 | 1670 | 1645 | 1675 | 1690 | 1715 |
| Maximum trailer weight unbraked/braked [kg] | - | - | 500/750 | 500/750 | - | - |
| Maximum front/rear axle load [kg] | 835 / 840 | 870 / 845 | 840 / 840 | 870 / 850 | 875 / 850 | 900 / 850 |
| Maximum vertical load on the tow bar [kg] | - | 50 | 50 | 50 | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 260 | 260 | 260 | 260 | 260 | 260 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/930 | -/930 | -/930 | -/930 | -/930 | -/930 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 |
| Fuel tank volume [l] | 40 | 40 | 40 | 40 | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.32 | 0.32 | 0.32 | 0.32 | 0.34 | 0.34 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 195/55 R16 87V | 195/55 R16 87V |
| Tyre dimensions rear | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 195/55 R16 87V | 195/55 R16 87V |
| Wheel size front | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 |
| Wheel size rear | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 |
| Brake dimensions front | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 | 294 x 22 | 294 x 22 |
| Brake dimensions rear | 259 x 10 | 259 x 10 | 259 x 10 | 259 x 10 | 259 x 10 | 259 x 10 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- |
| Overall length [mm] | 3961 | 3961 | 3961 | 3961 | 3961 | 3961 |
| Overall width without/including mirrors [mm] | 1683/- | 1683/- | 1683/- | 1683/- | 1683/- | 1683/- |
| Overall height [mm] | 1426 | 1426 | 1426 | 1426 | 1432 | 1432 |
| Wheelbase [mm] | 2547 | 2547 | 2547 | 2547 | 2547 | 2547 |
| Front wheel track [mm] | 1459 | 1459 | 1459 | 1459 | 1453 | 1453 |
| Rear wheel track [mm] | 1467 | 1467 | 1467 | 1467 | 1461 | 1461 |
| Forward overhang [mm] | 691 | 691 | 691 | 691 | 691 | 691 |
| Rear overhang [mm] | 723 | 723 | 723 | 723 | 723 | 723 |
| Clearance [mm] | 138 | 138 | 138 | 138 | 135 | 135 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 990 | 990 | 990 | 990 | 990 | 990 |
| Headroom rear [mm] | 958 | 958 | 958 | 958 | 958 | 958 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| John Cooper Works | One D | Cooper D | Cooper D | Cooper SD | Cooper SD | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1598 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 155/6000 | 66/4000 | 82/4000 | 82/4000 | 105/4000 | 105/4000 |
| Maximum torque [Nm/min-1] | 260/1850-5600 | 215/1750-2500 | 270/1750-2250 | 270/1750-2250 | 305/1750-2700 | 305/1750-2700 |
| Bore and stroke [mm x mm] | 77,0 x 85,8 | 78,0 x 83,6 | 78,0 x 83,6 | 78,0 x 83,6 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 10,0:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 |
| Oil volume [l] | - | 5.2 | 5.2 | 5.2 | 5.2 | 5.2 |
| Coolant volume [l] | - | 5.4 | 5.4 | 5.4 | 5.4 | 5.4 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear automatic |
| Drive specifications | - | - | - |
| - |
|
| Top speed [km/h] | 238 | 182 | 197 | 192 | 215 | 205 |
| Acceleration 0–100 km/h [s] | 6.8 | 11.8 | 10.2 | 10.6 | 8.6 | 8.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | 12.6 (5th gear) | 9.7 (5th gear) | - | 8.4 (5th gear) | - |
| City [l] | 9.5 | 4.4 | 4.4 | 6.9 | 5.2 | 7.0 |
| Out of town [l] | 5.8 | 3.6 | 3.6 | 4.2 | 3.9 | 4.3 |
| Combined [l] | 7.2 | 3.9 | 3.9 | 5.2 | 4.4 | 5.3 |
| CO2 emissions [g/km] | 167 | 103 | 103 | 138 | 115 | 141 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1280 | 1280 | 1260 | 1290 | 1310 | 1330 |
| Overall weight [kg] | 1690 | 1685 | 1685 | 1715 | 1735 | 1755 |
| Maximum trailer weight unbraked/braked [kg] | - | - | 500/750 | 500/750 | 500/750 | 500/750 |
| Maximum front/rear axle load [kg] | - | 890 / 825 | 890 / 825 | 915 / 830 | 915 / 850 | 935 / 850 |
| Maximum vertical load on the tow bar [kg] | - | - | 50 | 50 | 50 | 50 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 260 | 260 | 260 | 260 | 260 | 260 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/930 | -/930 | -/930 | -/930 | -/930 | -/930 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 |
| Fuel tank volume [l] | 50 | 40 | 40 | 40 | 40 | 40 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.32 | 0.32 | 0.32 | 0.34 | 0.34 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 205/45 R17 84W | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 195/55 R16 87V | 195/55 R16 87V |
| Tyre dimensions rear | 205/45 R17 84W | 175/65 R15 84H | 175/65 R15 84H | 175/65 R15 84H | 195/55 R16 87V | 195/55 R16 87V |
| Wheel size front | 7.0J x 17 | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 |
| Wheel size rear | 7.0J x 17 | 5.5J x 15 | 5.5J x 15 | 5.5J x 15 | 6.5J x 16 | 6.5J x 16 |
| Brake dimensions front | 316 x 22 | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 | 280 x 22 |
| Brake dimensions rear | 280 x 10 | 259 x 10 | 259 x 10 | 259 x 10 | 259 x 10 | 259 x 10 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- | 11.0/- |
| Overall length [mm] | 3961 | 3961 | 3961 | 3961 | 3961 | 3961 |
| Overall width without/including mirrors [mm] | 1683/- | 1683/- | 1683/- | 1683/- | 1683/- | 1683/- |
| Overall height [mm] | 1432 | 1426 | 1426 | 1426 | 1426 | 1426 |
| Wheelbase [mm] | 2547 | 2547 | 2547 | 2547 | 2547 | 2547 |
| Front wheel track [mm] | 1453 | 1459 | 1459 | 1459 | 1453 | 1453 |
| Rear wheel track [mm] | 1461 | 1467 | 1467 | 1467 | 1461 | 1461 |
| Forward overhang [mm] | - | 691 | 691 | 691 | 691 | 691 |
| Rear overhang [mm] | - | 723 | 723 | 723 | 723 | 723 |
| Clearance [mm] | 135 | 138 | 138 | 138 | 138 | 138 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 990 | 990 | 990 | 990 | 990 | 990 |
| Headroom rear [mm] | 958 | 958 | 958 | 958 | 958 | 958 |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Gallery
