Nissan Juke
Date of manufacture
6/2014 – 2019 (SUV)
Platform
Nissan B
Manufacturing locations
Sunderland, United Kingdom
Yokosuka, Japan
Designer
-
Tags
Small SUV
Japanese cars
The Nissan Juke has been manufactured in the UK and Japan since 2014 as an SUV. It is built on the Nissan B platform and offers petrol and diesel engines with a maximum power of 160 kW for the 1.6 DIG-T NISMO RS model. The same model reaches a top speed of 220 km/h and accelerates from 0-100 km/h in 7 seconds. The most economical variant is the 1.2 DIG-T engine with a combined consumption of 5.6 l/100 km and CO2 emissions of 129 g/km. The trunk has a capacity of 354 l. The model has successfully passed EURONCAP safety tests and has been rated 5 out of 5.
Car body style
SUV
after upgrade (facelift)
Date of manufacture
6/2014 – 2019Internal designation
F15Engine size
Technical data
SUV
| 1.6 | 1.6 | 1.6 | 1.2 DIG-T | 1.6 | 1.6 DIG-T | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from 2018 to | from 2018 to | from to 2018 | from to 2018 | from to 2018 |
| Engine type | Petrol | Petrol | Petrol | Ignition supercharged | Petrol | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1598 | 1197 | 1598 | 1618 |
| Maximum output / speed [kW/min-1] | 69/5400 | 83/5600 | 83/5600 | 85/4500 | 86/6000 | 140/5600 |
| Maximum torque [Nm/min-1] | 140/3200-4400 | 144/4000 | 144/4000 | 190/2000 | 158/4000 | 240/2000-5200 |
| Bore and stroke [mm x mm] | 78,0 x 83,6 | 78,0 x 83,6 | 78,0 x 83,6 | 72,2 x 73,1 | 78,0 x 83,6 | 79,7 x 81,1 |
| Compression ratio | 10,7:1 | 10,7:1 | 10,7:1 | 10,0:1 | 10,7:1 | 9,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 5 gear manual | 1 gear automatic | 6 gear manual | 1 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 168 | 178 | 170 | 178 | 170 | 215 |
| Acceleration 0–100 km/h [s] | 12.0 | 12.5 | 12.3 | 10.8 | 11.5 | 7.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.6 | 8.7 | 7.8 | 6.9-7.1 | 7.5-8.3 | 7.6 |
| Out of town [l] | 5.0 | 6.5-6.1 | 6.1-5.7 | 4.9 | 4.9-5.2 | 5.1 |
| Combined [l] | 6.0 | 7.3-7.0 | 6.8-6.5 | 5.6-5.7 | 6.0-6.3 | 6.0 |
| CO2 emissions [g/km] | 138 | 166-161 | 154-149 | 129 | 128-145 | 139 |
| Low speed [l] | - | 10.1-9.6 | 11.2-10.6 | - | - | - |
| Medium speed [l] | - | 7.7-7.3 | 7.6-7.0 | - | - | - |
| High speed [l] | - | 7.3-6.9 | 7.0-6.5 | - | - | - |
| Extra high speed [l] | - | 9.4-9.1 | 9.1-8.7 | - | - | - |
| Combined speed [l] | - | 8.5-8.2 | 8.4-7.9 | - | - | - |
| CO2 emissions [g/km] | - | 192-185 | 190-180 | - | - | - |
| Emission standard | EU5-EU6 | Euro 6d-TEMP | Euro 6d-TEMP | EU5-EU6 | EU5-EU6 | EU5-EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1163-1189 | 1173-1248 | 1203-1277 | 1236-1307 | 1205-1278 | 1300-1359 |
| Overall weight [kg] | 1605 | 1655 | 1690 | 1710 | 1680 | 1760 |
| Maximum trailer weight unbraked/braked [kg] | 604/1250 | 604/1250 | 625/1250 | 639/1250 | 625/1250 | 671/1200 |
| Maximum front/rear axle load [kg] | - | 850/860 | 880/880 | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 354 | 354 | 354 | 354 | 354 | 354 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1189 | -/1189 | -/1189 | -/1189 | -/1189 | -/1189 |
| Boot length [mm] | 733 | 733 | 733 | 733 | 733 | 733 |
| Boot length with rear seats folded [mm] | 1470 | 1470 | 1470 | 1470 | 1470 | 1470 |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | -/907 | -/907 | -/907 | -/907 | -/907 | -/907 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 46 | 46 | 46 | 46 | 46 | 46 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.35 | 0.35 | 0.35 | 0.35 | 0.35 | 0.35 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar |
| Tyre dimensions front | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | 215/55 R17 | 215/55 R17 |
| Tyre dimensions rear | 205/60 R16 | 205/60 R16 | 205/60 R16 | 205/60 R16 | 215/55 R17 | 215/55 R17 |
| Wheel size front | 6.5JJ x 16 | 6.5J x 16 | 6.5J x 16 | 6.5JJ x 16 | 7.0JJ x 17 | 7.0JJ x 17 |
| Wheel size rear | 6.5JJ x 16 | 6.5J x 16 | 6.5J x 16 | 6.5JJ x 16 | 7.0JJ x 17 | 7.0JJ x 17 |
| Brake dimensions front | 280 x 24 | - | - | 280 x 24 | 280 x 24 | 296 x 26 |
| Brake dimensions rear | - | - | - | 292 x 9 | 292 x 9 | 292 x 9 |
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.7/- | 10.7/- | 10.7/- | 10.7/- | 10.7/- | 10.7/- |
| Overall length [mm] | 4135 | 4135 | 4135 | 4135 | 4135 | 4135 |
| Overall width without/including mirrors [mm] | 1765/- | 1765/- | 1765/- | 1765/- | 1765/- | 1765/- |
| Overall height [mm] | 1565 | 1565 | 1565 | 1565 | 1565 | 1565 |
| Wheelbase [mm] | 2530 | 2530 | 2530 | 2530 | 2530 | 2530 |
| Front wheel track [mm] | 1540 | 1525 | 1525 | 1539 | 1525 | 1525 |
| Rear wheel track [mm] | 1525 | 1523 | 1523 | 1537 | 1523 | 1523 |
| Forward overhang [mm] | 855 | 855 | 855 | 855 | 855 | 855 |
| Rear overhang [mm] | 750 | 750 | 750 | 750 | 750 | 750 |
| Clearance [mm] | 180 | 180 | 180 | 180 | 180 | 180 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 23 | 23 | 23 | 23 | 23 | 23 |
| Approach angle rear [°] | 27.5 | 27.5 | 27.5 | 27.5 | 27.5 | 27.5 |
| Transition angle [°] | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.6 DIG-T | 1.6 DIG-T NISMO RS | 1.6 DIG-T NISMO RS | 1.5 dCi | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | - | - | from to 2018 | ||
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/8 | ||
| Engine displacement [cm³] | 1618 | 1618 | 1618 | 1461 | ||
| Maximum output / speed [kW/min-1] | 140/5600 | 160/6000 | 157/6000 | 81/4000 | ||
| Maximum torque [Nm/min-1] | 240/2000-5200 | 280/3600-4800 | 250/2400-6000 | 260/2500 | ||
| Bore and stroke [mm x mm] | 79,7 x 81,1 | 79,7 x 81,1 | 79,7 x 81,1 | 76,0 x 80,5 | ||
| Compression ratio | 9,5:1 | 9,5:1 | 9,5:1 | 15,5:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | Front | 4x4 | Front | ||
| Gearbox | 7 gear automatic | 6 gear manual | 8 gear automatic | 6 gear manual | ||
| Drive specifications |
| - |
| - | ||
| Top speed [km/h] | 200 | 220 | 200 | 185 | ||
| Acceleration 0–100 km/h [s] | 8.1 | 7.0 | 8.0 | 11.2 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 8.3 | 9.5 | 9.5 | 5.2-4.4 | ||
| Out of town [l] | 5.5 | 5.9 | 6.1 | 4.4-3.7 | ||
| Combined [l] | 6.5 | 7.2 | 7.3 | 4.7-4.0 | ||
| CO2 emissions [g/km] | 153 | 168 | 172 | 123-104 | ||
| Low speed [l] | - | - | - | 5.8 | ||
| Medium speed [l] | - | - | - | 5.1 | ||
| High speed [l] | - | - | - | 5.1 | ||
| Extra high speed [l] | - | - | - | 6.4 | ||
| Combined speed [l] | - | - | - | 5.7 | ||
| CO2 emissions [g/km] | - | - | - | 149 | ||
| Emission standard | EU5-EU6 | EU5-EU6 | EU5-EU6 | EU5-EU6c | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1431-1477 | 1315-1341 | 1446-1461 | 1305-1378 | ||
| Overall weight [kg] | 1880 | 1760 | 1880 | 1670-1770 | ||
| Maximum trailer weight unbraked/braked [kg] | 734/1150 | 671/1200 | 734/1150 | 673/1250 | ||
| Maximum front/rear axle load [kg] | - | 970/825 | 1020/905 | 985/830 | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | ||
| Boot volume [l] | 207 | 354 | 207 | 354 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/786 | -/1189 | -/786 | -/1189 | ||
| Boot length [mm] | 675 | 733 | 733 | 733 | ||
| Boot length with rear seats folded [mm] | 1409 | 1470 | 1470 | 1470 | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | -/681 | -/907 | -/907 | -/907 | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 50 | 46 | 50 | 46 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.35 | 0.35 | 0.35 | 0.35 | ||
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | ||
| Rear suspension | torsion bar | torsion bar | torsion bar | multilink | ||
| Tyre dimensions front | 215/55 R17 | 225/45 R18 | 225/45 R18 | 205/60 R16 | ||
| Tyre dimensions rear | 215/55 R17 | 225/45 R18 | 225/45 R18 | 205/60 R16 | ||
| Wheel size front | 7.0JJ x 17 | 7.0 x 18 | 7.0 x 18 | 6.5JJ x 16 | ||
| Wheel size rear | 7.0JJ x 17 | 7.0 x 18 | 7.0 x 18 | 6.5JJ x 16 | ||
| Brake dimensions front | 296 x 26 | - | - | 280 x 24 | ||
| Brake dimensions rear | 292 x 9 | - | - | 292 x 9 | ||
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 10.7/- | 10.7/- | 10.7/- | 10.7/- | ||
| Overall length [mm] | 4135 | 4165 | 4165 | 4135 | ||
| Overall width without/including mirrors [mm] | 1765/- | 1765/- | 1765/- | 1765/- | ||
| Overall height [mm] | 1565 | 1565 | 1565 | 1565 | ||
| Wheelbase [mm] | 2530 | 2530 | 2530 | 2530 | ||
| Front wheel track [mm] | 1525 | 1525 | 1525 | 1539 | ||
| Rear wheel track [mm] | 1505 | 1525 | 1505 | 1537 | ||
| Forward overhang [mm] | 855 | 855 | 855 | 855 | ||
| Rear overhang [mm] | 750 | 750 | 750 | 750 | ||
| Clearance [mm] | 170 | 180 | 170 | 180 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | 23.5 | 23 | 23 | 23 | ||
| Approach angle rear [°] | 26 | 27.5 | 27.5 | 27.5 | ||
| Transition angle [°] | 23 | 22.5 | 23 | 22.5 | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | - | - | - | - | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | - | - | - | - | ||
| Rear elbow/shoulder width [mm] | - | - | - | - | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
