Nissan Micra

Date of manufacture

1/2017 – to this day (Five-door hatchback)

Platform

Nissan V

Manufacturing locations

Flins-sur-Seine, France

Designer

Car body style

Five-door hatchback

Date of manufacture

1/2017 – to this day

Internal designation

K14

Engine size

Petrol

Diesel

Euro NCAP

Technical data

Five-door hatchback

	1.0	0.9 IG-T	0.9 IG-T	1.0 IG-T	1.0 IG-T 100	IG-T 100
Date of sale	from to 2019	from to 2018	from to 2018	from 2020 to	from 2020 to	from 2018 to 2020
Engine type	Petrol	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	998	898	898	999	999	999
Maximum output / speed [kW/min-1]	52/6300	66/5500	66/5500	68/5000	68/5000	74/5000
Maximum torque [Nm/min-1]	95/3500	140/2250	140/2250	160/2000	160/2000	160/2750
Bore and stroke [mm x mm]	71,0 x 84,0	72,2 x 73,1	72,2 x 73,1	81.3 x 72.2	81.3 x 72.2	81.3 x 72.2
Compression ratio	10.5:1	9.5:1	9.5:1	9.5:1	9.5:1	9.5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	turbo-supercharged	turbo-supercharged start&stop system	turbo-supercharged start&stop system	turbo-supercharged start&stop system	turbo-supercharged start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	1 gear automatic	5 gear manual
Drive specifications	-	-	-	-	automatic gearbox Xtronic with one variable ratio	-

Top speed [km/h]	158	175	175	178	171	184
Acceleration 0–100 km/h [s]	16.4	12.1	12.1	11.8	13.0	10.9
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	5.9	6.7-6.5	5.8-5.6	5.8-5.5	5.5	5.6
Out of town [l]	3.8	4.2-3.7	3.9-3.7	4.1-3.9	4.6-4.3	4.0-3.9
Combined [l]	4.6	5.1-4.8	4.6-4.4	4.7-4.5	5.0-4.7	4.6-4.5
CO2 emissions [g/km]	103	115-107	104-99	108-103	113-108	105-104

Low speed [l]	7.4	8.5	-	-	-	7.9-7.5
Medium speed [l]	5.7	5.9	-	-	-	5.5-5.2
High speed [l]	5.3	5.3	-	-	-	4.9-4.5
Extra high speed [l]	6.7	6.6	-	-	-	6.3-5.8
Combined speed [l]	6.1	6.3	-	-	-	5.9-5.5
CO2 emissions [g/km]	139	144	-	-	-	133-126

Emission standard	Euro 6	Euro 6	Euro 6	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP - Euro 6d	Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1091-1138	1128-1252	1128-1252	1116-1158	1143-1185	1135-1180
Overall weight [kg]	1490	1530	1530	1530	1545	1550
Maximum trailer weight unbraked/braked [kg]	510/900	525/1200	525/1200	555/1200	555/1200	555/1200
Maximum front/rear axle load [kg]	760/765	820/765	820/765	820/810	825/810	820/810
Maximum vertical load on the tow bar [kg]	75	75	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	300	300	300	300	300	300
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1004	-/1004	-/1004	-/1004	-/1004	-/1004
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	41	41	41	41	41	41
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15
Wheel size front	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15
Wheel size rear	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15	6.0J x 15
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.3/-	10.3/-	10.3/-	10.3/-	10.3/-	10.3/-

Overall length [mm]	3999	3999	3999	3999	3999	3999
Overall width without/including mirrors [mm]	1734/1935	1734/1935	1734/1935	1734/1935	1734/1935	1734/1935
Overall height [mm]	1455	1455	1455	1455	1455	1455
Wheelbase [mm]	2525	2525	2525	2525	2525	2525
Front wheel track [mm]	1510	1510	1510	1510	1510	1510
Rear wheel track [mm]	1520	1520	1520	1520	1520	1520
Forward overhang [mm]	827	827	827	827	827	827
Rear overhang [mm]	647	647	647	647	647	647
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	IG-T 100	DIG-T 117	1.5 dCi	1.5 dCi
Date of sale	from 2018 to 2020	from 2018 to 2020	from to 2018	from to 2018
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	3/12	3/12	4/8	4/8
Engine displacement [cm³]	999	999	1461	1461
Maximum output / speed [kW/min-1]	74/5000	86/5250	66/4000	66/4000
Maximum torque [Nm/min-1]	160/2750	180/1750-4000	220/2000	220/2000
Bore and stroke [mm x mm]	81.3 x 72.2	81.3 x 72.2	76,0 x 80,5	76,0 x 80,5
Compression ratio	9.5:1	10.5:1	15,5:1	15,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	turbo-supercharged start&stop system	direct injection turbo-supercharged variable timing of intake and exhaust valves Gasoline Particulate Filter start&stop system	direct injection Common Rail turbo-supercharged cartridge catalytic converter NOx-Filter particulate filter	direct injection Common Rail turbo-supercharged particulate filter cartridge catalytic converter NOx-Filter start&stop system

Drive axle	Front	Front	Front	Front
Gearbox	1 gear automatic	6 gear manual	6 gear manual	6 gear manual
Drive specifications	automatic gearbox Xtronic with one variable ratio	-	-	-

Top speed [km/h]	177	195	179	179
Acceleration 0–100 km/h [s]	13.0	9.9	11.9	11.9
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	5.7	6.1	4.3-4.1	3.8-3.5
Out of town [l]	4.5-4.4	4.2	3.6-3.5	3.4-3.1
Combined [l]	5.1-4.9	5.0	3.8-3.7	3.5-3.2
CO2 emissions [g/km]	115-111	114	101-97	92-85

Low speed [l]	8.5-8.3	7.5	6.3	-
Medium speed [l]	6.1-5.9	5.6	5.2	-
High speed [l]	5.6-5.2	5.0	4.6	-
Extra high speed [l]	7.4-6.7	6.3	5.9	-
Combined speed [l]	6.7-6.3	5.9	5.4	-
CO2 emissions [g/km]	149-142	133	142	-

Emission standard	Euro 6d-TEMP	Euro 6d-TEMP	Euro 6	Euro 6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1155-1195	1170-1195	1215-1317	1215-1317
Overall weight [kg]	1550	1550	1590	1590
Maximum trailer weight unbraked/braked [kg]	555/1200	555/1200	555/1170	555/1170
Maximum front/rear axle load [kg]	825/810	835/765	855/765	855/765
Maximum vertical load on the tow bar [kg]	75	75	75	75
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	300	300	300	300
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1004	-/1004	-/1004	-/1004
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	41	41	41	41
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/65 R15	205/45 R17	185/65 R15	185/65 R15
Tyre dimensions rear	185/65 R15	205/45 R17	185/65 R15	185/65 R15
Wheel size front	6.0J x 15	6.5J x 17	6.0J x 15	6.0J x 15
Wheel size rear	6.0J x 15	6.5J x 17	6.0J x 15	6.0J x 15
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering	Rack & pinion with electric power steering
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.3/-	10.3/-	10.3/-	10.3/-

Overall length [mm]	3999	3999	3999	3999
Overall width without/including mirrors [mm]	1734/1935	1734/1935	1734/1935	1734/1935
Overall height [mm]	1455	1439	1455	1455
Wheelbase [mm]	2525	2525	2525	2525
Front wheel track [mm]	1510	1510	1510	1510
Rear wheel track [mm]	1520	1520	1520	1520
Forward overhang [mm]	827	827	827	827
Rear overhang [mm]	647	647	647	647
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Nissan Micra K14 2019 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
