Nissan NP300 Navara
Date of manufacture
10/2015 – to this day (SUV)
Platform
Nissan F-Alpha
Manufacturing locations
Samut Prakan, Thailand
Barcelona, Spain
Cuernavaca, Mexico
Designer
Mamoru Aoki
Tags
Pick-up
Japanese cars
The Nissan NP300 Navara is available in SUV body style and has been manufactured since 2015. The car can be built on the Nissan F-Alpha platform, with origins from Thailand, Spain or Mexico. It only offers gasoline engines, the most powerful of which is the 2.3 dCi 190 Double Cab with 140 kW of power and a maximum speed of 184 km/h. The 2.3 dCi 160 King Cab has the lowest combined fuel consumption of 6.1 l/100 km and CO2 emissions of 159 g/km. In 2015, this model was tested for safety and achieved an overall rating of 4 out of 5 according to EURONCAP.
Car body style
SUV
Date of manufacture
10/2015 – to this dayInternal designation
D23
Technical data
SUV
| 2.3 dCi 160 King Cab | 2.3 dCi 160 King Cab | 2.3 dCi 160 King Cab | 2.3 dCi 160 Double Cab | 2.3 dCi 160 Double Cab | 2.3 dCi 190 Double Cab | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2019 | from to 2019 | from 2019 to | from to 2019 | from 2019 to | from to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2298 | 2298 | 2299 | 2298 | 2299 | 2298 |
| Maximum output / speed [kW/min-1] | 120/3750 | 120/3750 | 120/3750 | 120/3750 | 120/3750 | 140/3750 |
| Maximum torque [Nm/min-1] | 403/1500-2500 | 403/1500-2500 | 425/1500-2500 | 403/1500-2500 | 425/1500-2500 | 450/1500-2500 |
| Bore and stroke [mm x mm] | 85,0 x 101,3 | 85,0 x 101,3 | 85,0 x 101,3 | 85,0 x 101,3 | 85,0 x 101,3 | 85,0 x 101,3 |
| Compression ratio | 15,4:1 | 15,4:1 | 15.0:1 | 15,4:1 | 15.0:1 | 15,4:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual |
| Drive specifications | - |
|
|
|
|
|
| Top speed [km/h] | 172 | 172 | 172 | 172 | 172 | 184 |
| Acceleration 0–100 km/h [s] | - | 12.0 | 12.0 | 12.0 | 12.0 | 10.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.8 | 7.0-6.8 | 8.4 | 7.0-6.8 | 8.4 | 7.4-6.8 |
| Out of town [l] | 5.8 | 6.1 | 6.1 | 6.1 | 6.1 | 6.1-5.9 |
| Combined [l] | 6.1 | 6.4-6.3 | 7.0 | 6.4-6.3 | 7.0 | 6.4-6.3 |
| CO2 emissions [g/km] | 159 | 169-167 | 184 | 169-167 | 184 | 169-167 |
| Emission standard | EU5 - Euro 6 | EU5 - Euro 6 | Euro 6d-TEMP | EU5 - Euro 6 | Euro 6d-TEMP | EU5 - Euro 6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1839-2135 | 1924 | 2110-2235 | 2044-2342 | 2145-2333 | 2065-2381 |
| Overall weight [kg] | 3035 | 3035 | 3200 | 3035 | 3250 | 3035 |
| Maximum trailer weight unbraked/braked [kg] | 750/3035 | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 |
| Maximum front/rear axle load [kg] | - | - | 1490/1980 | - | 1490/1980 | - |
| Maximum vertical load on the tow bar [kg] | 120 | 140 | 140 | 140 | 140 | 140 |
| Maximum load on roof/carrier [kg] | - | - | - | -/56 | -/100 | -/56 |
| Boot volume [l] | - | - | - | - | - | - |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | 1795 | 1795 | 1800 | 1580 | 1585 | 1580 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1130/1560 | 1130/1560 | 1130/1560 | 1130/1560 | 1130/1560 | 1130/1560 |
| Boot height to headliner/ceiling [mm] | -/474 | -/474 | -/498 | -/474 | -/498 | -/474 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 2-4 | 2-4 | 2-4 | 5 | 5 | 5 |
| Fuel tank volume [l] | 73 | 73 | 73 | 73 | 73 | 73 |
| AdBlue tank volume [l] | 17 | 17 | 18.4 | 17 | 18.4 | 17 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | rigid with leaf springs | rigid with leaf springs | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 205 R16C | 205 R16C | 255/65 R17 | 255/70 R16 | 255/65 R17 | 255/60 R18 |
| Tyre dimensions rear | 205 R16C | 205 R16C | 255/65 R17 | 255/70 R16 | 255/65 R17 | 255/60 R18 |
| Wheel size front | 6.0J x 16 | 6.0J x 16 | 7.0J x 17 | 7.0J x 16 | 7.0J x 17 | 7.0J x 18 |
| Wheel size rear | 6.0J x 16 | 6.0J x 16 | 7.0J x 17 | 7.0J x 16 | 7.0J x 17 | 7.0J x 18 |
| Brake dimensions front | 296 | 296 | - | 296 | - | 296 |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Rack & pinion with power steering | Rack & pinion with power steering | Rack & pinion with power steering | Rack & pinion with power steering | Rack & pinion with power steering | Rack & pinion with power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.4/13.1 | 12.4/13.1 | 12.0/- | 12.4/13.1 | 12.0/- | 12.4/13.1 |
| Overall length [mm] | 5255 | 5255 | 5255 | 5330 | 5330 | 5330 |
| Overall width without/including mirrors [mm] | 1850/2075 | 1850/2075 | 1850/2075 | 1850/2075 | 1850/2075 | 1850/2085 |
| Overall height [mm] | 1780 | 1780 | 1822 | 1805 | 1824 | 1810 |
| Wheelbase [mm] | 3150 | 3150 | 3150 | 3150 | 3150 | 3150 |
| Front wheel track [mm] | 1570 | 1570 | 1570 | 1570 | 1570 | 1570 |
| Rear wheel track [mm] | 1570 | 1570 | 1570 | 1570 | 1570 | 1570 |
| Forward overhang [mm] | 870 | 870 | 880 | 870 | 880 | 870 |
| Rear overhang [mm] | 1235 | 1235 | 1225 | 1310 | 1300 | 1310 |
| Clearance [mm] | 196-233 | 196-233 | 219-223 | 196-233 | 219-223 | 196-233 |
| Wading depth [mm] | 600 | 600 | 600 | 600 | 600 | 600 |
| Approach angle front [°] | 29-32 | 29-32 | 30-31 | 29-32 | 30-31 | 29-32 |
| Approach angle rear [°] | 25-27 | 25-27 | 27-30 | 25-27 | 27-30 | 25-27 |
| Transition angle [°] | 22 | 22 | 23 | 22 | 23 | 22 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | 50.3 | 50.3 | 49 | 50.3 | 49 | 50.3 |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.3 dCi 190 Double Cab | 2.3 dCi 190 Double Cab | 2.3 dCi 190 Double Cab | ||||
|---|---|---|---|---|---|---|
| Date of sale | from to 2019 | from 2019 to | from 2019 to | |||
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 2298 | 2299 | 2299 | |||
| Maximum output / speed [kW/min-1] | 140/3750 | 140/3750 | 140/3750 | |||
| Maximum torque [Nm/min-1] | 450/1500-2500 | 450/1500-2500 | 450/1500-2500 | |||
| Bore and stroke [mm x mm] | 85,0 x 101,3 | 85,0 x 101,3 | 85,0 x 101,3 | |||
| Compression ratio | 15,4:1 | 15.0:1 | 15.0:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | 4x4 | 4x4 | 4x4 | |||
| Gearbox | 7 gear automatic | 6 gear manual | 7 gear automatic | |||
| Drive specifications |
|
|
| |||
| Top speed [km/h] | 180 | 184 | 180 | |||
| Acceleration 0–100 km/h [s] | 10.8 | 10.8 | 10.8 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 8.7 | 8.2 | 9.1 | |||
| Out of town [l] | 6.0-5.9 | 6.2 | 6.4 | |||
| Combined [l] | 7.0-6.9 | 7.0 | 7.4 | |||
| CO2 emissions [g/km] | 183 | 184 | 194 | |||
| Emission standard | EU5 - Euro 6 | Euro 6d-TEMP | Euro 6d-TEMP | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 2069-2414 | 2175-2338 | 2175-2338 | |||
| Overall weight [kg] | 3035 | 3250 | 3250 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | 750/3500 | |||
| Maximum front/rear axle load [kg] | - | 1490/1980 | 1490/1980 | |||
| Maximum vertical load on the tow bar [kg] | 140 | 140 | 140 | |||
| Maximum load on roof/carrier [kg] | -/56 | -/100 | -/100 | |||
| Boot volume [l] | - | - | - | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | |||
| Boot length [mm] | 1580 | 1585 | 1585 | |||
| Boot length with rear seats folded [mm] | - | - | - | |||
| Boot width between wheels/max [mm] | 1130/1560 | 1130/1560 | 1130/1560 | |||
| Boot height to headliner/ceiling [mm] | -/474 | -/498 | -/498 | |||
| Loading edge height [mm] | - | - | - | |||
| Height of the open boot door [mm] | - | - | - | |||
| Boot opening height [mm] | - | - | - | |||
| Boot opening width min/max [mm] | - | - | - | |||
| Number of doors | 4 | 4 | 4 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 73 | 73 | 73 | |||
| AdBlue tank volume [l] | 17 | 18.4 | 18.4 | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | double wishbone | double wishbone | double wishbone | |||
| Rear suspension | multilink | multilink | multilink | |||
| Tyre dimensions front | 255/60 R18 | 255/60 R18 | 255/60 R18 | |||
| Tyre dimensions rear | 255/60 R18 | 255/60 R18 | 255/60 R18 | |||
| Wheel size front | 7.0J x 18 | 7.0J x 18 | 7.0J x 18 | |||
| Wheel size rear | 7.0J x 18 | 7.0J x 18 | 7.0J x 18 | |||
| Brake dimensions front | 296 | - | - | |||
| Brake dimensions rear | - | - | - | |||
| Steering | Rack & pinion with power steering | Rack & pinion with power steering | Rack & pinion with power steering | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 12.4/13.1 | 12.0/- | 12.0/- | |||
| Overall length [mm] | 5330 | 5330 | 5330 | |||
| Overall width without/including mirrors [mm] | 1850/2085 | 1850/2085 | 1850/2085 | |||
| Overall height [mm] | 1810 | 1824 | 1824 | |||
| Wheelbase [mm] | 3150 | 3150 | 3150 | |||
| Front wheel track [mm] | 1570 | 1570 | 1570 | |||
| Rear wheel track [mm] | 1570 | 1570 | 1570 | |||
| Forward overhang [mm] | 870 | 880 | 880 | |||
| Rear overhang [mm] | 1310 | 1300 | 1300 | |||
| Clearance [mm] | 196-233 | 219-223 | 219-223 | |||
| Wading depth [mm] | 600 | 600 | 600 | |||
| Approach angle front [°] | 29-32 | 30-31 | 30-31 | |||
| Approach angle rear [°] | 25-27 | 27-30 | 27-30 | |||
| Transition angle [°] | 22 | 23 | 23 | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | 50.3 | 49 | 49 | |||
| Headroom front [mm] | - | - | - | |||
| Headroom rear [mm] | - | - | - | |||
| Front elbow/shoulder width [mm] | - | - | - | |||
| Rear elbow/shoulder width [mm] | - | - | - | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | - | - | - |
