Nissan Tiida

Date of manufacture

2004 – 2012 (Five-door hatchback)

2004 – 2012 (Sedan)

Platform

Nissan B

Manufacturing locations

Kanda, Japan

Cuernavaca, Mexico

Guangzhou, People's Republic of China

Samut Prakan, Thailand

Designer

Car body style

Five-door hatchback

Date of manufacture

2004 – 2012

Internal designation

C11

Engine size

Petrol

1.6

1.8

Diesel

1.5 dCi

Sedan

Date of manufacture

2004 – 2012

Internal designation

C11

Engine size

Petrol

1.6

1.8

Diesel

1.5 dCi

Technical data

Five-door hatchback

	1.6	1.6	1.8	1.5 dCi
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1596	1596	1797	1461
Maximum output / speed [kW/min-1]	81/6000	81/6000	93/5200	78/4000
Maximum torque [Nm/min-1]	153/4400	153/4400	173/4800	240/2000
Bore and stroke [mm x mm]	78,0 x 83,6	78,0 x 83,6	84,0 x 81,1	76,0 x 80,5
Compression ratio	-	-	-	15,2:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing CVTC	variable valve timing CVTC	variable valve timing CVTC	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	4 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	automatic gearbox	-	-

Top speed [km/h]	186	170	195	186
Acceleration 0–100 km/h [s]	11.1	12.6	10.4	11.3
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.9	10.0	10.1	6.1
Out of town [l]	5.7	5.9	6.5	4.7
Combined [l]	6.9	7.4	7.8	5.2
CO2 emissions [g/km]	165	178	188	139

Emission standard	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1203	1224	1232	1314
Overall weight [kg]	1715	1715	1735	1785
Maximum trailer weight unbraked/braked [kg]	602/1200	612/1000	616/1300	657/1100
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-

Boot volume [l]	300-425	300-425	300-425	300-425
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	52	52	52	52
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	195/65 R15	195/65 R15	195/65 R15	195/65 R15
Tyre dimensions rear	195/65 R15	195/65 R15	195/65 R15	195/65 R15
Wheel size front	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15
Wheel size rear	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4303	4303	4303	4303
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1533	1533	1533	1532
Wheelbase [mm]	2603	2603	2603	2603
Front wheel track [mm]	1480	1480	1480	1480
Rear wheel track [mm]	1485	1485	1485	1485
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Sedan

	1.6	1.6	1.8	1.5 dCi
Date of sale	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1596	1596	1797	1461
Maximum output / speed [kW/min-1]	81/6000	81/6000	93/5200	78/4000
Maximum torque [Nm/min-1]	153/4400	153/4400	173/4800	240/2000
Bore and stroke [mm x mm]	78,0 x 83,6	78,0 x 83,6	84,0 x 81,1	76,0 x 80,5
Compression ratio	-	-	-	15,2:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	variable valve timing CVTC	variable valve timing CVTC	variable valve timing CVTC	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front	Front
Gearbox	5 gear manual	4 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	automatic gearbox	-	-

Top speed [km/h]	186	170	195	186
Acceleration 0–100 km/h [s]	11.1	12.6	10.4	11.3
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	8.9	10.0	10.1	6.1
Out of town [l]	5.7	5.9	6.5	4.7
Combined [l]	6.9	7.4	7.8	5.2
CO2 emissions [g/km]	165	178	188	139

Emission standard	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1193	1214	1223	1295
Overall weight [kg]	1715	1715	1735	1785
Maximum trailer weight unbraked/braked [kg]	597/1200	607/1000	612/1300	648/1100
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-

Boot volume [l]	500	500	500	500
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	4	4	4	4
Number of seats	5	5	5	5
Fuel tank volume [l]	52	52	52	52
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	195/65 R15	195/65 R15	195/65 R15	195/65 R15
Tyre dimensions rear	195/65 R15	195/65 R15	195/65 R15	195/65 R15
Wheel size front	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15
Wheel size rear	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15	5.5JJ x 15
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení	Rack & pinion with electric power steering řízení
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4479	4479	4479	4479
Overall width without/including mirrors [mm]	1695/-	1695/-	1695/-	1695/-
Overall height [mm]	1525	1525	1525	1524
Wheelbase [mm]	2603	2603	2603	2603
Front wheel track [mm]	1480	1480	1480	1480
Rear wheel track [mm]	1485	1485	1485	1485
Forward overhang [mm]	-	-	-	-
Rear overhang [mm]	-	-	-	-
Clearance [mm]	-	-	-	-
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
