Opel Cascada
Date of manufacture
3/2013 – 2019 (Convertible)
Platform
Delta II platform
Manufacturing locations
Gliwice, Poland
Designer
Andrew Dyson
Elizabeth Wetzel
Tags
C-segment
German cars
The Opel Cascada is a convertible that has been manufactured since 2013 and is produced in Warsaw. It is built on the Delta II platform and the engine range includes petrol and diesel variants. The most powerful model is the 1.6 Turbo with 147 kW, which has a top speed of 235 km/h and a 0-100 km/h acceleration of 8.9 seconds. The most economical 2.0 CDTI has a fuel consumption of 4.9 l/100 km and emissions of 129 g/km. The interior of the car offers a capacity of 280-380 litres.
Technical data
Convertible
| 1.4 Turbo | 1.6 Turbo | 1.6 Turbo | 1.4 Turbo | 1.6 Turbo | 1.6 Turbo | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from 2018 to | from 2018 to | from to 2018 | - | from to 2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1362 | 1598 | 1598 | 1362 | 1598 | 1598 |
| Maximum output / speed [kW/min-1] | 88/4200-6000 | 100/4000-6000 | 100/4000-6000 | 103/4900-6000 | 125/4750-6000 | 125/4750-6000 |
| Maximum torque [Nm/min-1] | 200/1850-4200 | 240/1650-3500 | 240/1650-3500 | 200/1850-4900 | 260-280/1650-4500 | 260/1650-4500 |
| Bore and stroke [mm x mm] | 72,5 x 82,5 | 79,0 x 81,5 | 79,0 x 81,5 | 72,5 x 82,5 | 79,0 x 81,5 | 79,0 x 81,5 |
| Compression ratio | 9,5:1 | 10,5:1 | 10,5:1 | 9,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic |
| Drive specifications | - | - |
| - | - |
|
| Top speed [km/h] | 195 | 205 | 200 | 207 | 222 | 217-219 |
| Acceleration 0–100 km/h [s] | 11.9 | 11.4 | 11.9 | 10.9 | 9.6-9.9 | 9.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | 11.7 | - | - | 9.5 | - |
| City [l] | 8.4 | 9.0 | 10.0 | 7.9 | 9.3-8.0 | 9.3-9.5 |
| Out of town [l] | 5.5 | 6.1 | 6.2 | 5.5 | 5.9-5.3 | 5.9-6.1 |
| Combined [l] | 6.5 | 7.2 | 7.6 | 6.4 | 7.2-6.3 | 7.2-7.3 |
| CO2 emissions [g/km] | 153 | 164 | 174 | 149 | 164-148 | 168-172 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | 7.8-7.5 | 8.5-8.1 | - | 7.8-7.6 | - |
| CO2 emissions [g/km] | - | 177-170 | 194-183 | - | 178-172 | - |
| Emission standard | EU5-EU6 | Euro 6d-TEMP | Euro 6d-TEMP | EU5 | EU5-EU6-Euro 6d-TEMP | EU5-EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1626 | 1658 | 1658 | 1626 | 1658 | 1658 |
| Overall weight [kg] | 2105 | 2150 | 2170 | 2110 | 2140-2150 | 2140 |
| Maximum trailer weight unbraked/braked [kg] | 750/1250 | 750/1300 | 750/1300 | 750/1250 | 750/1300 | 750/1300 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 280-380 | 280-380 | 280-380 | 280-380 | 280-380 | 280-380 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/750 | -/750 | -/750 | -/750 | -/750 | -/750 |
| Boot length [mm] | 1121 | 1121 | 1121 | 1121 | 1121 | 1121 |
| Boot length with rear seats folded [mm] | 1818 | 1818 | 1818 | 1818 | 1818 | 1818 |
| Boot width between wheels/max [mm] | -/626 | -/626 | -/626 | -/626 | -/626 | -/626 |
| Boot height to headliner/ceiling [mm] | -/532 | -/532 | -/532 | -/532 | -/532 | -/532 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 56 | 56 | 56 | 56 | 56 | 56 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge |
| Rear suspension | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar |
| Tyre dimensions front | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 |
| Tyre dimensions rear | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 |
| Wheel size rear | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 |
| Overall length [mm] | 4760 | 4760 | 4760 | 4760 | 4760 | 4760 |
| Overall width without/including mirrors [mm] | 1839/2020 | 1839/2020 | 1839/2020 | 1839/2020 | 1839/2020 | 1839/2020 |
| Overall height [mm] | 1443 | 1443 | 1443 | 1443 | 1443 | 1443 |
| Wheelbase [mm] | 2695 | 2695 | 2695 | 2695 | 2695 | 2695 |
| Front wheel track [mm] | 1587 | 1587 | 1587 | 1587 | 1587 | 1587 |
| Rear wheel track [mm] | 1587 | 1587 | 1587 | 1587 | 1587 | 1587 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.6 Turbo | 2.0 CDTI | 2.0 CDTI | 2.0 CDTI | 2.0 CDTI BiTurbo | ||
|---|---|---|---|---|---|---|
| Date of sale | from to 2018 | from to 2015 | from to 2015 | from to 2018 | from to 2015 | |
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | |
| Engine displacement [cm³] | 1598 | 1956 | 1956 | 1956 | 1956 | |
| Maximum output / speed [kW/min-1] | 147/5500 | 121/4000 | 121/4000 | 125/4000 | 143/4000 | |
| Maximum torque [Nm/min-1] | 280/1650-3500 | 350/1750-2500 | 350/1750-2500 | 400/1750-2500 | 400/1750-2500 | |
| Bore and stroke [mm x mm] | 79,0 x 81,5 | 83,0 x 90,4 | 83,0 x 90,4 | 83,0 x 90,4 | 83,0 x 90,4 | |
| Compression ratio | 9,5:1 | 16,5:1 | 16,5:1 | 16,0:1 | 16,5:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Front | Front | Front | Front | Front | |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual | |
| Drive specifications | - | - |
| - | - | |
| Top speed [km/h] | 235 | 218 | 212 | 218 | 230 | |
| Acceleration 0–100 km/h [s] | 8.9 | 10.3 | 10.4 | 10.3 | 9.4 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 8.4 | 6.3 | 8.2 | 6.0 | 6.3 | |
| Out of town [l] | 5.8 | 4.6 | 5.0 | 4.2 | 4.6 | |
| Combined [l] | 6.8 | 5.2 | 6.2 | 4.9 | 5.2 | |
| CO2 emissions [g/km] | 158 | 138 | 163 | 129 | 138 | |
| Emission standard | EU5-EU6 | EU5 | EU5 | EU6 | EU5 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1658 | 1741 | 1741 | 1741 | 1741 | |
| Overall weight [kg] | 2140 | 2200 | 2200 | 2200 | 2215 | |
| Maximum trailer weight unbraked/braked [kg] | 750/1300 | 750/1250 | 750/1300 | 750/1250 | 750/1300 | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | |
| Boot volume [l] | 280-380 | 280-380 | 280-380 | 280-380 | 280-380 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/750 | -/750 | -/750 | -/750 | -/750 | |
| Boot length [mm] | 1121 | 1121 | 1121 | 1121 | 1121 | |
| Boot length with rear seats folded [mm] | 1818 | 1818 | 1818 | 1818 | 1818 | |
| Boot width between wheels/max [mm] | -/626 | -/626 | -/626 | -/626 | -/626 | |
| Boot height to headliner/ceiling [mm] | -/532 | -/532 | -/532 | -/532 | -/532 | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 2 | 2 | 2 | 2 | 2 | |
| Number of seats | 4 | 4 | 4 | 4 | 4 | |
| Fuel tank volume [l] | 56 | 56 | 56 | 56 | 56 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | - | - | - | - | - | |
| Front suspension | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | MacPherson with separate HiPerStrut weighbridge | |
| Rear suspension | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | twist beam axle with trailing arms, Watts linkage, torsion bar | |
| Tyre dimensions front | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | |
| Tyre dimensions rear | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | 235/50 R18 | |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | |
| Wheel size rear | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | 7.5J x 18 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | Rack & pinion with electric power steering | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | 11.8/12.2 | |
| Overall length [mm] | 4760 | 4760 | 4760 | 4760 | 4760 | |
| Overall width without/including mirrors [mm] | 1839/2020 | 1839/2020 | 1839/2020 | 1839/2020 | 1839/2020 | |
| Overall height [mm] | 1443 | 1443 | 1443 | 1443 | 1443 | |
| Wheelbase [mm] | 2695 | 2695 | 2695 | 2695 | 2695 | |
| Front wheel track [mm] | 1587 | 1587 | 1587 | 1587 | 1587 | |
| Rear wheel track [mm] | 1587 | 1587 | 1587 | 1587 | 1587 | |
| Forward overhang [mm] | - | - | - | - | - | |
| Rear overhang [mm] | - | - | - | - | - | |
| Clearance [mm] | - | - | - | - | - | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | - | - | - | - | - | |
| Approach angle rear [°] | - | - | - | - | - | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | - | - | - | - | - | |
| Headroom rear [mm] | - | - | - | - | - | |
| Front elbow/shoulder width [mm] | - | - | - | - | - | |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
