Opel Corsa
Date of manufacture
10/2019 – to this day (Five-door hatchback)
Platform
PSA CMP (EMP1)
Manufacturing locations
Zaragoza, Spain
Designer
Martin Schaufler
Tags
B-segment
German cars
The Opel Corsa is manufactured as a five-door hatchback. The car has been produced since 2019. The country where the model is manufactured is Spain. The car is built on the PSA CMP (EMP1) platform. The powertrain offering includes petrol, diesel and electric powertrains. The highest power is achieved by the Corsa-e (100 kW). The highest speed of the 1.2 Turbo model is 208 km/h. The lowest combined consumption is 4 l/100 km for the 1.5 CDTI version. CO2 emissions are 104 g/km. The trunk volume is 309 l. The car was tested in the safety area in 2019 and achieved an overall rating of 4 out of 5 according to EURONCAP.
Car body style
Technical data
Five-door hatchback
| 1.2 | 1.2 Turbo | 1.2 Turbo | 1.2 Turbo | Corsa-e | 1.5 CDTI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | from 2020 to | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Electric | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | - | 4/16 |
| Engine displacement [cm³] | 1199 | 1199 | 1199 | 1199 | - | 1499 |
| Maximum output / speed [kW/min-1] | 55/5750 | 74/5500 | 74/5500 | 96/5500 | 100 | 75/3500 |
| Maximum torque [Nm/min-1] | 118/2750 | 205/1750 | 205/1750 | 230/1750 | 260 | 250/1750 |
| Bore and stroke [mm x mm] | 75.0 x 90.5 | 75.0 x 90.5 | 75.0 x 90.5 | 75.0 x 90.5 | - | 75.0 x 84,8 |
| Compression ratio | 11.0:1 | 10.5:1 | 10.5:1 | 10.5:1 | - | 16.5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic | 1 gear automatic | 5 gear manual |
| Drive specifications | - | - |
|
|
| - |
| Top speed [km/h] | 174 | 194 | 192 | 208 | 150 | 188 |
| Acceleration 0–100 km/h [s] | 13,2 | 9,9 | 10,8 | 8,7 | 8.1 | 10,2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | 15,2 |
| City [l] | 4,9-4,8 | 5,5-5,3 | 5,3-5,1 | 5,5-5,4 | - | 3,9-3,8 |
| Out of town [l] | 3,8-3,7 | 3,9-3,7 | 4,0-3,9 | 4,2-4,0 | - | 3,1-3,0 |
| Combined [l] | 4,2-4,1 | 4,5-4,3 | 4,5-4,3 | 4,7-4,5 | - | 3,4-3,3 |
| CO2 emissions [g/km] | 96-93 | 101-98 | 102-99 | 107-103 | - | 90-87 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 5,6-5,2 | 5,6-5,2 | 5,7-5,3 | 5,7-5,4 | 17.5-16.5 kWh | 4,3-4,0 |
| CO2 emissions [g/km] | 127-117 | 127-116 | 129-121 | 130-122 | - | 114-104 |
| Emission standard | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | - | Euro 6d-TEMP - Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | - | - | - | - | Lithium-Ionen-Akkumulator, 50 kWh | - |
| Range with fully charged battery [km] | - | - | - | - | 337 | - |
| Charging time | - | - | - | - |
| - |
| Number of modules/cells | - | - | - | - | 18/216 | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1055 | 1165 | 1165 | 1233 | 1530 | 1165 |
| Overall weight [kg] | 1550 | 1620 | 1645 | 1650 | 1920 | 1660 |
| Maximum trailer weight unbraked/braked [kg] | 500/500 | 580/1200 | 580/1200 | 615/1200 | - | 580/1200 |
| Maximum front/rear axle load [kg] | 782/870 | 890/870 | 890/870 | 890/870 | - | 890/870 |
| Maximum vertical load on the tow bar [kg] | 55 | 55 | 55 | 55 | - | 55 |
| Maximum load on roof/carrier [kg] | 70/- | 70/- | 70/- | 70/- | - | 70/- |
| Boot volume [l] | 309 | 309 | 309 | 309 | 267 | 309 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1081 | -/1081 | -/1081 | -/1081 | -/1042 | -/1081 |
| Boot length [mm] | 674 | 674 | 674 | 674 | 674 | 674 |
| Boot length with rear seats folded [mm] | 1553 | 1553 | 1553 | 1553 | 1553 | 1553 |
| Boot width between wheels/max [mm] | 969/- | 969/- | 969/- | 969/- | 969/- | 969/- |
| Boot height to headliner/ceiling [mm] | 536/- | 536/- | 536/- | 536/- | 536/- | 536/- |
| Loading edge height [mm] | 682 | 682 | 682 | 682 | 682 | 682 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 40 | 44 | 44 | 44 | - | 41 |
| AdBlue tank volume [l] | - | - | - | - | - | 15 |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 185/65 R15 | 185/65 R15 | 185/65 R15 | 205/45 R17 | 185/65 R15 | 185/65 R15 |
| Tyre dimensions rear | 185/65 R15 | 185/65 R15 | 185/65 R15 | 205/45 R17 | 185/65 R15 | 185/65 R15 |
| Wheel size front | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 7.0J x 17 | 6.0J x 15 | 6.0J x 15 |
| Wheel size rear | 6.0J x 15 | 6.0J x 15 | 6.0J x 15 | 7.0J x 17 | 6.0J x 15 | 6.0J x 15 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/10,74 | -/10,74 | -/10,74 | -/10,74 | -/10,74 | -/10,74 |
| Overall length [mm] | 4060 | 4060 | 4060 | 4060 | 4060 | 4060 |
| Overall width without/including mirrors [mm] | 1765/1960 | 1765/1960 | 1765/1960 | 1765/1960 | 1765/1960 | 1765/1960 |
| Overall height [mm] | 1433 | 1433 | 1433 | 1433 | 1433 | 1433 |
| Wheelbase [mm] | 2538 | 2538 | 2538 | 2538 | 2538 | 2538 |
| Front wheel track [mm] | 1489 | 1489 | 1489 | 1489 | 1489 | 1489 |
| Rear wheel track [mm] | 1488 | 1488 | 1488 | 1488 | 1488 | 1488 |
| Forward overhang [mm] | 831 | 831 | 831 | 831 | 831 | 831 |
| Rear overhang [mm] | 691 | 691 | 691 | 691 | 691 | 691 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Rating | - | - | - |    | - | - |
| Clean Air Index | - | - | - | 3.7/10 | - | - |
| Energy Efficiency Index | - | - | - | 5.9/10 | - | - |
| GHG index | - | - | - | 4.6/10 | - | - |
