Opel Karl

Date of manufacture

2014 – 2019 (Five-door hatchback)

Platform

Manufacturing locations

Changwon, South Korea

Designer

Mark Adams

Quentin Huber

Car body style

Five-door hatchback

Date of manufacture

2014 – 2019

Internal designation

Engine size

1.0 ECOTEC KARL ROCKS

1.0 KARL ROCKS

1.0 LPG KARL ROCKS

Euro NCAP

Technical data

Five-door hatchback

	1.0	1.0 ECOTEC	1.0	1.0 LPG	1.0 KARL ROCKS	1.0 ECOTEC KARL ROCKS
Date of sale	-	-	from to 2018	from to 2018	from 2016 to	from 2016 to
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	3/12	3/12	3/12	3/12	3/12	3/12
Engine displacement [cm³]	999	999	999	999	999	999
Maximum output / speed [kW/min-1]	54-55/6500	54-55/6500	55/6500	55/6500 [54/6500 LPG]	54-55/6500	54-55/6500
Maximum torque [Nm/min-1]	95/4500	95/4500	95/4500	95/4500 [92/4500 LPG]	95/4500	95/4500
Bore and stroke [mm x mm]	84.0 x 77.4	84.0 x 77.4	84.0 x 77.4	84.0 x 77.4	84.0 x 77.4	84.0 x 77.4
Compression ratio	10,5:1	10,5:1	10,5:1	10,5:1	10,5:1	10,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	start&stop system	-	combustion of petrol or LPG	-	start&stop system

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear robotic manual	5 gear manual	5 gear manual	5 gear manual
Drive specifications	-	-	robotic gearbox Easytronic	-	-	-

Top speed [km/h]	170	170	170	170	168	168
Acceleration 0–100 km/h [s]	13.9	13.9	14.9	14.9	14.0	14.0
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	22.9	22.9	-	23.9	23.9	23.9

City [l]	6.2-5.4	5.8-5.1	5.6-5.5	5.7-5.6 [7.1-7.0 LPG]	6.2-5.6	5.9-5.2
Out of town [l]	4.5-3.7	4.3-3.6	3.8-3.6	3.9-3.7 [4.9-4.6 LPG]	4.5-4.2	4.6-4.0
Combined [l]	5.1-4.3	4.8-4.1	4.5-4.3	4.6-4.4 [5.7-5.5 LPG]	5.2-4.7	5.1-4.4
CO2 emissions [g/km]	117-99	110-94	103-99	106-102 [93-89 LPG]	118-106	116-101

Low speed [l]	-	-	-	-	-	-
Medium speed [l]	-	-	-	-	-	-
High speed [l]	-	-	-	-	-	-
Extra high speed [l]	-	-	-	-	-	-
Combined speed [l]	6.2-6.0	6.1-5.9	-	-	6.2-6.1	6.2-6.1
CO2 emissions [g/km]	141-135	137-134	-	-	141-136	139-137

Emission standard	Euro 6 - Euro 6d-TEMP	Euro 6 - Euro 6d-TEMP	Euro 6	Euro 6	Euro 6 - Euro 6d-TEMP	Euro 6 - Euro 6d-TEMP
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	939	939	939	1025	939	939
Overall weight [kg]	1353	1353	1353	1410	1353	1353
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	740/710	740/710	740/710	740/710	740/710	740/710
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	206	206	206	151	206	206
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1013	-/1013	-/1013	-/958	-/1013	-/1013
Boot length [mm]	484	484	484	484	484	484
Boot length with rear seats folded [mm]	1107	1107	1107	1107	1107	1107
Boot width between wheels/max [mm]	950/960	950/960	950/960	950/960	950/960	950/960
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	716	716	716	716	716	716
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	608	608	608	608	608	608
Boot opening width min/max [mm]	955	955	955	955	955	955

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	32	32	32	32 [24.8 LPG]	32	32
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.331	0.331	0.331	0.331	0.331	0.331
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar
Tyre dimensions front	165/65 R14	165/65 R14	165/65 R14	165/65 R14	185/55 R15	185/55 R15
Tyre dimensions rear	165/65 R14	165/65 R14	165/65 R14	165/65 R14	185/55 R15	185/55 R15
Wheel size front	5.0J x 14	5.0J x 14	5.0J x 14	5.0J x 14	6.0J x 15	6.0J x 15
Wheel size rear	5.0J x 14	5.0J x 14	5.0J x 14	5.0J x 14	6.0J x 15	6.0J x 15
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	9.4/9.8	9.4/9.8	9.4/9.8	9.4/9.8	10.3/10.6	10.3/10.6

Overall length [mm]	3675	3675	3675	3675	3676	3676
Overall width without/including mirrors [mm]	1595/1876	1595/1876	1595/1876	1595/1876	1595/1876	1595/1876
Overall height [mm]	1485	1485	1485	1485	1535	1535
Wheelbase [mm]	2385	2385	2385	2385	2385	2385
Front wheel track [mm]	1410	1410	1410	1410	1396	1396
Rear wheel track [mm]	1418	1418	1418	1418	1404	1404
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.0 KARL ROCKS	1.0 LPG KARL ROCKS
Date of sale	from 2016 to 2018	from 2016 to 2018
Engine type	Petrol	Petrol
Number of cylinders/valves	3/12	3/12
Engine displacement [cm³]	999	999
Maximum output / speed [kW/min-1]	55/6500	55/6500 [54/6500 LPG]
Maximum torque [Nm/min-1]	95/4500	95/4500 [92/4500 LPG]
Bore and stroke [mm x mm]	84.0 x 77.4	84.0 x 77.4
Compression ratio	10,5:1	10,5:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	-	combustion of petrol or LPG

Drive axle	Front	Front
Gearbox	5 gear robotic manual	5 gear manual
Drive specifications	robotic gearbox Easytronic	-

Top speed [km/h]	168	168
Acceleration 0–100 km/h [s]	15.0	15.0
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	24.9

City [l]	5.6	5.8 [7.1 LPG]
Out of town [l]	4.1	4.1 [5.2 LPG]
Combined [l]	4.6	4.7 [5.9 LPG]
CO2 emissions [g/km]	105	108 [95 LPG]

Emission standard	Euro 6	Euro 6
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	939	1025
Overall weight [kg]	1353	1410
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	740/710	740/710
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	206	151
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1013	-/958
Boot length [mm]	484	484
Boot length with rear seats folded [mm]	1107	1107
Boot width between wheels/max [mm]	950/960	950/960
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	716	716
Height of the open boot door [mm]	-	-
Boot opening height [mm]	608	608
Boot opening width min/max [mm]	955	955

Number of doors	5	5
Number of seats	5	5
Fuel tank volume [l]	32	32 [24.8 LPG]
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.331	0.331
Front suspension	MacPherson	MacPherson
Rear suspension	rigid with trailing arms and torsion bar	rigid with trailing arms and torsion bar
Tyre dimensions front	185/55 R15	185/55 R15
Tyre dimensions rear	185/55 R15	185/55 R15
Wheel size front	6.0J x 15	6.0J x 15
Wheel size rear	6.0J x 15	6.0J x 15
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.3/10.6	10.3/10.6

Overall length [mm]	3676	3676
Overall width without/including mirrors [mm]	1595/1876	1595/1876
Overall height [mm]	1535	1535
Wheelbase [mm]	2385	2385
Front wheel track [mm]	1396	1396
Rear wheel track [mm]	1404	1404
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	-	-
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
