Basic information Technical Specifications Gallery

Opel Meriva

Date of manufacture

2006 – 2010 (MPV)

Platform

Gamma platform

Manufacturing locations

Zaragoza, Spain

Designer

Car body style

MPV

after upgrade (facelift)

Date of manufacture

2006 – 2010

Internal designation

Meriva A

Engine size

Petrol

Diesel

Euro NCAP

Pre-2009 Rating

pre-facelift version (2003)

Adults

Children

Pedestrians

Technical data

MPV

	1.4 16V	1.6 16V	1.6 16V	1.6 Turbo OPC	1.3 CDTI	1.7 CDTI
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1364	1598	1598	1598	1248	1686
Maximum output / speed [kW/min-1]	66/5600	77/6000	77/6000	132/5500	55/4000	74/4400
Maximum torque [Nm/min-1]	125/4000	150/3900	150/3900	230/2200-5500	170/1750-2500	240/2300
Bore and stroke [mm x mm]	73,4 x 80,6	79,0 x 81,5	79,0 x 81,5	79,0 x 81,5	69,6 x 82,0	79,0 x 86,0
Compression ratio	-	-	-	-	-	-
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	-	-	-	turbo-supercharged	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear robotic manual	6 gear manual	5 gear manual	5 gear manual
Drive specifications	-	-	robotic gearbox Easytronic	-	-	-

Top speed [km/h]	168	181	181	222	157	178
Acceleration 0–100 km/h [s]	14.4	13.3	14.3	8.2	17.8	13.4
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	8.1-8.3	8.8	8.9	10.4	6.2	6.6
Out of town [l]	5.1-5.3	5.5	5.4	6.3	4.3	4.4
Combined [l]	6.2-6.4	6.7	6.7	7.8	5.0	5.2
CO2 emissions [g/km]	148-154	159	159	187	135	140

Emission standard	EU4	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1330	1330	1330	1330	1330	1330
Overall weight [kg]	1785	1785	1785	1785	1785	1785
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	360	360	360	360	360	360
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1410	-/1410	-/1410	-/1410	-/1410	-/1410
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	-	-	-	-	-	-
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	185/60 R15	185/60 R15	185/60 R15	205/50 R17	185/60 R15	185/60 R15
Tyre dimensions rear	185/60 R15	185/60 R15	185/60 R15	205/50 R17	185/60 R15	185/60 R15
Wheel size front	6.0J x 15	6.0J x 15	6.0J x 15	7.0J x 17	6.0J x 15	6.0J x 15
Wheel size rear	6.0J x 15	6.0J x 15	6.0J x 15	7.0J x 17	6.0J x 15	6.0J x 15
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.5/10.9	10.5/10.9	10.5/10.9	10.5/10.9	10.5/10.9	10.5/10.9

Overall length [mm]	4052	4052	4052	4068	4052	4052
Overall width without/including mirrors [mm]	1694/1948	1694/1948	1694/1948	1694/1948	1694/1948	1694/1948
Overall height [mm]	1624	1624	1624	1624	1624	1624
Wheelbase [mm]	2630	2630	2630	2630	2630	2630
Front wheel track [mm]	1449	1449	1449	1449	1449	1449
Rear wheel track [mm]	1464	1464	1464	1464	1464	1464
Forward overhang [mm]	-	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-	-
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.7 CDTI
Date of sale	-
Engine type	Diesel supercharged
Number of cylinders/valves	4/16
Engine displacement [cm³]	1686
Maximum output / speed [kW/min-1]	92/4400
Maximum torque [Nm/min-1]	280/2300
Bore and stroke [mm x mm]	79,0 x 86,0
Compression ratio	-
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	direct injection Common Rail turbo-supercharged

Drive axle	Front
Gearbox	6 gear manual
Drive specifications	-

Top speed [km/h]	195
Acceleration 0–100 km/h [s]	10.9
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	-

City [l]	6.8
Out of town [l]	4.6
Combined [l]	5.4
CO2 emissions [g/km]	146

Emission standard	EU4
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

Standby weight [kg]	1330
Overall weight [kg]	1785
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	360
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1410
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	5
Number of seats	5
Fuel tank volume [l]	-
AdBlue tank volume [l]	-
Air resistance [Cd]	-
Front suspension	MacPherson
Rear suspension	twist beam axle with trailing arms
Tyre dimensions front	185/60 R15
Tyre dimensions rear	185/60 R15
Wheel size front	6.0J x 15
Wheel size rear	6.0J x 15
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	10.5/10.9

Overall length [mm]	4052
Overall width without/including mirrors [mm]	1694/1948
Overall height [mm]	1624
Wheelbase [mm]	2630
Front wheel track [mm]	1449
Rear wheel track [mm]	1464
Forward overhang [mm]	-
Rear overhang [mm]	-
Clearance [mm]	-
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	-
Headroom rear [mm]	-
Front elbow/shoulder width [mm]	-
Rear elbow/shoulder width [mm]	-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
