Peugeot 5008
Date of manufacture
2013 – 2016 (MPV)
Platform
PSA PF2
Manufacturing locations
Sochaux, France
Designer
-
Tags
Mid-size MPV
French cars
The Peugeot 5008 is available in the MPV body style. The car has been produced since 2013. It is manufactured in France. The car is built on the PSA PF2 platform. The list of power units includes petrol and diesel engines. The most powerful car is the 1.6 THP with a power of 121 kW. The fastest model is the 1.2 PureTech with a top speed of 201 km/h. The most fuel-efficient model is the 1.6 e-HDI with a combined fuel consumption of 4.3 l/100 km and CO2 emissions of 113 g/km. The luggage compartment volume is 579-678 l. In terms of safety, the car received a 5 out of 5 rating from EURONCAP in 2009.
Car body style
MPV
after upgrade (facelift)
Date of manufacture
2013 – 2016Internal designation
T8Engine size
Technical data
MPV
| 1.6 VTi | 1.2 PureTech | 1.6 THP | 1.6 HDI | 1.6 e-HDI | 1.6 BlueHDI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 3/12 | 4/16 | 4/8 | 4/8 | 4/8 |
| Engine displacement [cm³] | 1598 | 1199 | 1598 | 1560 | 1560 | 1560 |
| Maximum output / speed [kW/min-1] | 88/6000 | 96/5500 | 121/6000 | 84/3600 | 84/3600 | 88/3500 |
| Maximum torque [Nm/min-1] | 160/4250 | 230/1750 | 240/1400 | 270/1750 | 270/1750 | 300/1750 |
| Bore and stroke [mm x mm] | 77,0 x 85,8 | 75,0 x 90,5 | 77,0 x 85,8 | 75,0 x 88,3 | 75,0 x 88,3 | 75,0 x 88,3 |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear robotic manual | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 187 | 201 | 195 | 185 | 183 | 183 |
| Acceleration 0–100 km/h [s] | 12.2 [12.3 seven seats] | 10.8 [10.9 seven seats] | 9.6 [9.8 seven seats] | 12.3 [12.9 seven seats] | 13.2 [13.3 seven seats] | 12.0 [12.2 seven seats] |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.5 | 6.6 | 7.6 | 5.9 | 4.4-4.9 | 4.9-5.0 |
| Out of town [l] | 5.6 | 4.8 | 5.1 | 4.3 | 4.1-5.1 | 4.0-4.1 |
| Combined [l] | 7.0 | 5.4 | 6.1 | 4.9 | 4.3-4.7 | 4.3-4.4 |
| CO2 emissions [g/km] | 162 | 125 | 140 | 128 | 113-123 | 113-115 |
| Emission standard | EU5 | EU6 | EU6 | EU5 | EU5 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1599 [1625 seven seats] | 1495 [1505 seven seats] | 1575 [- seven seats] | 1660 [1699 seven seats] | 1688 [1699 seven seats] | 1565 [- seven seats] |
| Overall weight [kg] | 2000 [2190 seven seats] | 2040 [2200 seven seats] | 2060 [2225 seven seats] | 2070 [2250 seven seats] | 2070 [2250 seven seats] | 2080 [2250 seven seats] |
| Maximum trailer weight unbraked/braked [kg] | 740/1500 [750/1400 seven seats] | 745/1400 [750/1400 seven seats] | 750/1650 [750/1600 seven seats] | 750/1300 [750/1100 seven seats] | 750/1300 [700/1100 seven seats] | 750/1300 [750/1100 seven seats] |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 579-678 | 579-678 | 579-678 | 579-678 | 579-678 | 579-678 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1754 | -/1754 | -/1754 | -/1754 | -/1754 | -/1754 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1165 | 1165 | 1165 | 1165 | 1165 | 1165 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | -/1170 | -/1170 | -/1170 | -/1170 | -/1170 | -/1170 |
| Boot height to headliner/ceiling [mm] | -/950 | -/950 | -/950 | -/950 | -/950 | -/950 |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | 60 | 60 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 |
| Front suspension | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H |
| Tyre dimensions rear | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.3/- | 12.3/- | 12.3/- | 12.3/- | 12.3/- | 12.3/- |
| Overall length [mm] | 4529 | 4529 | 4529 | 4529 | 4529 | 4529 |
| Overall width without/including mirrors [mm] | 1837/- | 1837/- | 1837/- | 1837/- | 1837/- | 1837/- |
| Overall height [mm] | 1639 | 1639 | 1639 | 1639 | 1639 | 1639 |
| Wheelbase [mm] | 2727 | 2727 | 2727 | 2727 | 2727 | 2727 |
| Front wheel track [mm] | 1532 | 1532 | 1532 | 1532 | 1532 | 1532 |
| Rear wheel track [mm] | 1561 | 1561 | 1561 | 1561 | 1561 | 1561 |
| Forward overhang [mm] | 935 | 935 | 935 | 935 | 935 | 935 |
| Rear overhang [mm] | 867 | 867 | 867 | 867 | 867 | 867 |
| Clearance [mm] | 133 | 133 | 133 | 133 | 133 | 133 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 919 | 919 | 919 | 919 | 919 | 919 |
| Headroom rear [mm] | 897 | 897 | 897 | 897 | 897 | 897 |
| Front elbow/shoulder width [mm] | 1476/1450 | 1476/1450 | 1476/1450 | 1476/1450 | 1476/1450 | 1476/1450 |
| Rear elbow/shoulder width [mm] | 1520/1442 | 1520/1442 | 1520/1442 | 1520/1442 | 1520/1442 | 1520/1442 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | 799 | 799 | 799 | 799 | 799 | 799 |
| Third row elbow/shoulder width [mm] | 1170/1341 | 1170/1341 | 1170/1341 | 1170/1341 | 1170/1341 | 1170/1341 |
| 1.6 BlueHDI | 2.0 HDI | 2.0 BlueHDI | 2.0 HDI | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/8 | 4/16 | 4/16 | 4/16 | ||
| Engine displacement [cm³] | 1560 | 1997 | 1997 | 1997 | ||
| Maximum output / speed [kW/min-1] | 88/3500 | 110/3750 | 110/4000 | 120/3750 | ||
| Maximum torque [Nm/min-1] | 300/1750 | 340/2000 | 370/2000 | 340/2000 | ||
| Bore and stroke [mm x mm] | 75,0 x 88,3 | 85,0 x 88,0 | 85,0 x 88,0 | 85,0 x 88,0 | ||
| Compression ratio | - | - | - | - | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic | ||
| Drive specifications |
| - | - |
| ||
| Top speed [km/h] | 187 | 195 | 195 | 190 | ||
| Acceleration 0–100 km/h [s] | 13.1 [13.2 seven seats] | 9.9 [10.0 seven seats] | 9.8 [9.9 seven seats] | 10.4 [10.5 seven seats] | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 4.7 | 6.8 | 5.3 | 7.9 | ||
| Out of town [l] | 4.1 | 4.6 | 3.8-3.9 | 5.6 | ||
| Combined [l] | 4.4 | 5.4 | 4.4-4.5 | 6.4 | ||
| CO2 emissions [g/km] | 114 | 140 | 115-117 | 167 | ||
| Emission standard | EU6 | EU5 | EU6 | EU5 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1585 [- seven seats] | 1721 [1750 seven seats] | 1605 [- seven seats] | 1782 [1821 seven seats] | ||
| Overall weight [kg] | 2070 [- seven seats] | 2125 [2310 seven seats] | 2140 [2310 seven seats] | 2125 [2330 seven seats] | ||
| Maximum trailer weight unbraked/braked [kg] | 750/1200 [750/1050 seven seats] | 750/1550 [750/1500 seven seats] | 750/1550 | 750/1600 [750/1500 seven seats] | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | - | - | - | - | ||
| Boot volume [l] | 579-678 | 579-678 | 579-678 | 579-678 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1754 | -/1754 | -/1754 | -/1754 | ||
| Boot volume, third row of seats [l] | - | - | - | - | ||
| Boot volume, third row seats folded [l] | - | - | - | - | ||
| Boot length [mm] | 1165 | 1165 | 1165 | 1165 | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | -/1170 | -/1170 | -/1170 | -/1170 | ||
| Boot height to headliner/ceiling [mm] | -/950 | -/950 | -/950 | -/950 | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | ||
| Fuel tank volume [l] | 60 | 60 | 60 | 60 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | ||
| Front suspension | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | MacPherson, torsion stabiliser | ||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | ||
| Tyre dimensions front | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | ||
| Tyre dimensions rear | 215/55 R16H | 215/55 R16H | 215/55 R16H | 215/55 R16H | ||
| Wheel size front | - | - | - | - | ||
| Wheel size rear | - | - | - | - | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 12.3/- | 12.3/- | 12.3/- | 12.3/- | ||
| Overall length [mm] | 4529 | 4529 | 4529 | 4529 | ||
| Overall width without/including mirrors [mm] | 1837/- | 1837/- | 1837/- | 1837/- | ||
| Overall height [mm] | 1639 | 1639 | 1639 | 1639 | ||
| Wheelbase [mm] | 2727 | 2727 | 2727 | 2727 | ||
| Front wheel track [mm] | 1532 | 1532 | 1532 | 1532 | ||
| Rear wheel track [mm] | 1561 | 1561 | 1561 | 1561 | ||
| Forward overhang [mm] | 935 | 935 | 935 | 935 | ||
| Rear overhang [mm] | 867 | 867 | 867 | 867 | ||
| Clearance [mm] | 133 | 133 | 133 | 133 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 919 | 919 | 919 | 919 | ||
| Headroom rear [mm] | 897 | 897 | 897 | 897 | ||
| Front elbow/shoulder width [mm] | 1476/1450 | 1476/1450 | 1476/1450 | 1476/1450 | ||
| Rear elbow/shoulder width [mm] | 1520/1442 | 1520/1442 | 1520/1442 | 1520/1442 | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - | ||
| Third row of seats, headroom [mm] | 799 | 799 | 799 | 799 | ||
| Third row elbow/shoulder width [mm] | 1170/1341 | 1170/1341 | 1170/1341 | 1170/1341 |
