Basic information Technical Specifications Gallery

Peugeot Partner Tepee

Date of manufacture

5/2015 – 2018 (MPV)

Platform

PSA PF2

Manufacturing locations

Poissy, France

Vigo, Spain

Akçalar, Turkey

Designer

Car body style

MPV

after upgrade (facelift) (II.)

Date of manufacture

5/2015 – 2018

Internal designation

Engine size

Petrol

1.6 VTi

Diesel

1.6 BlueHDI

Euro NCAP

Test year 2014

pre-facelift version (2014)

Technical data

MPV

	1.6 VTi	1.6 VTi	1.6 BlueHDI	1.6 BlueHDI	1.6 BlueHDI	1.6 BlueHDI
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/8	4/8	4/8	4/8
Engine displacement [cm³]	1598	1598	1560	1560	1560	1560
Maximum output / speed [kW/min-1]	72/6000	88/6000	55/3500	73/3750	73/3750	88/3500
Maximum torque [Nm/min-1]	152/3500	160/4250	230/1750	254/1750	254/1750	300/1750
Bore and stroke [mm x mm]	77,0 x 85,8	77,0 x 85,8	75,0 x 88,3	75,0 x 88,3	75,0 x 88,3	75,0 x 88,3
Compression ratio	-	-	-	-	-	-
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing variable lift of intake valves	variable valve timing variable lift of intake valves	direct injection Common Rail turbo-supercharged particulate filter SCR catalytic converter with AdBlue additive injection particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection particulate filter start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front	Front	Front
Gearbox	5 gear manual	5 gear manual	5 gear manual	5 gear manual	6 gear robotic manual	6 gear manual
Drive specifications	-	-	-	-	robotic gearbox ETG6	-

Top speed [km/h]	170	177	156	166 [166 seven seats]	171	174 [174 seven seats]
Acceleration 0–100 km/h [s]	12.8	12.0	15.1	12.4 [13.4 seven seats]	14.3	11.4 [12.3 seven seats]
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	8.2	8.3	5.1	5.1	4.3	4.9
Out of town [l]	5.3	5.4	3.9	3.9	4.1	4.2
Combined [l]	6.4	6.5	4.3	4.3	4.2	4.4
CO2 emissions [g/km]	148	151	113	113	109	115

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1395	1395	1449	1449 [1496 seven seats]	1474	1473 [1504 seven seats]
Overall weight [kg]	2000	2000	2060	2060 [2220 seven seats]	2074	2085 [2220 seven seats]
Maximum trailer weight unbraked/braked [kg]	690/1300	690/1300	720/1300	720/1300 [740/1200 seven seats]	730/1300	720/1300 [750/1200 seven seats]
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	75/-	75/-	75/-	75/-	75/-	75/-

Boot volume [l]	675	675	675	675	675	675
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2650	-/2650	-/2650	-/2650	-/2650	-/2650
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	4-5	5	4-5	4-5	4-5	4-5
Number of seats	5	5-7	5	5	5	5
Fuel tank volume [l]	60	60	60	60	60	60
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, lower triangular arms	MacPherson, lower triangular arms	MacPherson, lower triangular arms	MacPherson, lower triangular arms	MacPherson, lower triangular arms	MacPherson, lower triangular arms
Rear suspension	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms	twist beam axle with trailing arms
Tyre dimensions front	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T
Tyre dimensions rear	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T	205/65 R15 91T
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.0/11.5	11.0/11.5	11.0/11.5	11.0/11.5	11.0/11.5	11.0/11.5

Overall length [mm]	4380	4380	4380	4380	4380	4380
Overall width without/including mirrors [mm]	1810/2112	1810/2112	1810/2112	1810/2112	1810/2112	1810/2112
Overall height [mm]	1801	1801	1801	1801	1801	1801
Wheelbase [mm]	2728	2728	2728	2728	2728	2728
Front wheel track [mm]	1505	1505	1505	1505	1505	1505
Rear wheel track [mm]	1554	1554	1554	1554	1554	1554
Forward overhang [mm]	925	925	925	925	925	925
Rear overhang [mm]	727	727	727	727	727	727
Clearance [mm]	141	141	141	141	141	141
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Peugeo Partner Tepee B9 facelift 2015 boot

Peugeo Partner Tepee B9 facelift 2016 front seats

Peugeo Partner Tepee B9 facelift 2015 infotainment

Peugeo Partner Tepee B9 facelift 2017 interior

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
