Porsche Cayenne
Date of manufacture
2010 – 2014 (SUV)
Platform
PL72
Manufacturing locations
Bratislava, Slovakia
Leipzig, Germany
Designer
-
Tags
Large SUV
German cars
The Porsche Cayenne has been produced since 2010 and is only available as an SUV. The car can be built on the PL72 platform in countries such as Slovakia and Germany. The engine range includes petrol, diesel and hybrid versions. The most powerful model is the Cayenne Turbo S with 405 kW of power, which reaches a top speed of 283 km/h and a 0-100 km/h acceleration time of 4.5 seconds. The most economical version is the diesel engine with a combined fuel consumption of 7.2 l/100 km and CO2 emissions of 189 g/km. The luggage compartment volume is 670 l.
Car body style
SUV
Date of manufacture
2010 – 2014Internal designation
92AEngine size
Technical data
SUV
| Cayenne | Cayenne | Cayenne S | Cayenne GTS | Cayenne Turbo | Cayenne Turbo S | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 8/32 | 8/32 | 8/32 | 8/32 |
| Engine displacement [cm³] | 3598 | 3598 | 4806 | 4806 | 4806 | 4806 |
| Maximum output / speed [kW/min-1] | 220/6300 | 220/6300 | 294/6500 | 309/6500 | 368/6000 | 405/6000 |
| Maximum torque [Nm/min-1] | 400/3000 | 400/3000 | 500/3500 | 515/3500 | 700/2250-4500 | 750/2250-4500 |
| Bore and stroke [mm x mm] | 89,0 x 96,4 | 89,0 x 96,4 | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 |
| Compression ratio | 11,7:1 | 11,7:1 | 12,5:1 | 12,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 230 | 230 | 258 | 261 | 278 | 283 |
| Acceleration 0–100 km/h [s] | 7.5 | 7.8 | 5.9 | 5.7 | 4.7 | 4.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 15.9 | 13.2 | 14.4 | 14.8 | 15.8 | 15.8 |
| Out of town [l] | 8.5 | 8.0 | 8.2 | 8.5 | 8.4 | 8.4 |
| Combined [l] | 11.2 | 9.9 | 10.5 | 10.7 | 11.5 | 11.5 |
| CO2 emissions [g/km] | 263 | 236 | 245 | 251 | 270 | 270 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 2070 | 2105 | 2140 | 2160 | 2245 | 2290 |
| Overall weight [kg] | 2765 | 2800 | 2940 | 2940 | 2980 | 2880 |
| Maximum trailer weight unbraked/braked [kg] | 750/2700 | 750/3500 | 750/3500 | 750/3500 | 750/3500 | 750/3500 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 670 | 670 | 670 | 670 | 670 | 670 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1780 | -/1780 | -/1780 | -/1705 | -/1705 | -/1705 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | 100 | 100 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.36 | 0.36 | 0.36 | 0.37 | 0.36 | 0.36 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 255/55 R18 | 255/55 R18 | 255/55 R18 | 275/45 R20 | 265/50 R19 | 295/35 R21 |
| Tyre dimensions rear | 255/55 R18 | 255/55 R18 | 255/55 R18 | 275/45 R20 | 265/50 R19 | 295/35 R21 |
| Wheel size front | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 9.5J x 20 | 8.5J x 19 | 10.0J x 21 ET50 |
| Wheel size rear | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 9.5J x 20 | 8.5J x 19 | 10.0J x 21 ET50 |
| Brake dimensions front | 350 x 34 | 350 x 34 | 360 x 36 | 360 x 36 | 390 x 38 | 390 x 38 |
| Brake dimensions rear | 330 x 28 | 330 x 28 | 330 x 28 | 330 x 28 | 358 x 28 | 358 x 28 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | - | - | - | - | - | - |
| Overall length [mm] | 4846 | 4846 | 4846 | 4846 | 4846 | 4846 |
| Overall width without/including mirrors [mm] | 1939/2155 | 1939/2155 | 1939/2155 | 1954/2155 | 1939/2155 | 1954/2155 |
| Overall height [mm] | 1705 | 1705 | 1705 | 1688 | 1702 | 1702 |
| Wheelbase [mm] | 2895 | 2895 | 2895 | 2895 | 2895 | 2895 |
| Front wheel track [mm] | 1655 | 1655 | 1655 | 1660 | 1643 | 1661 |
| Rear wheel track [mm] | 1669 | 1669 | 1669 | 1678 | 1657 | 1675 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 215 | 215 | 215 | 204 | 215 | 215 |
| Wading depth [mm] | 500 | 500 | 500 | 482 | 500 | 500 |
| Approach angle front [°] | 26 | 26 | 26 | 24.8 | 26 | 26 |
| Approach angle rear [°] | 24.5 | 24.5 | 24.5 | 24 | 24.5 | 24.5 |
| Transition angle [°] | 20.5 | 20.5 | 20.5 | 19 | 20 | 20 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1005 | 1005 | 1005 | 1005 | 1005 | 1005 |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1496/1467 | 1496/1467 | 1496/1467 | 1496/1467 | 1496/1467 | 1496/1467 |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Cayenne S Hybrid | Cayenne Diesel | Cayenne Diesel | Cayenne S Diesel | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Petrol supercharged + Electric | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 8/32 | ||
| Engine displacement [cm³] | 2995 | 2967 | 2967 | 4134 | ||
| Maximum output / speed [kW/min-1] | 245/5500-6500 combustion 34/1150 el. 279/5500 total | 176/4400-4400 | 180/3800-4400 | 281/3750 | ||
| Maximum torque [Nm/min-1] | 440/3000-5250 combustion 300/1150 el. 580/1000 total | 550/2000-2250 | 550/1750-2750 | 850/2000-2750 | ||
| Bore and stroke [mm x mm] | 84,5 x 89,0 | 84,5 x 89,1 | 84,5 x 89,1 | 83,0 x 95,5 | ||
| Compression ratio | 10,5:1 | 16,8:1 | 16,8:1 | 16,4:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | ||
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 242 | 218 | 220 | 252 | ||
| Acceleration 0–100 km/h [s] | 6.5 | 7.8 | 7.6 | 5.7 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 8.7 | 8.7 | 8.4 | 10.0 | ||
| Out of town [l] | 7.9 | 6.6 | 6.5 | 7.3 | ||
| Combined [l] | 8.2 | 7.4 | 7.2 | 8.3 | ||
| CO2 emissions [g/km] | 193 | 195 | 189 | 218 | ||
| Emission standard | EU5 | EU5 | EU5 | EU5 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| System voltage [V] | - | - | - | - | ||
| Battery type and capacity | Nickel metal hydride, 1.7 kWh | - | - | - | ||
| Range with fully charged battery [km] | - | - | - | - | ||
| Charging time | - | - | - | - | ||
| Number of modules/cells | - | - | - | - | ||
| Battery weight [kg] | - | - | - | - | ||
| Charger | - | - | - | - | ||
| Standby weight [kg] | 2315 | 2175 | 2155 | 2270 | ||
| Overall weight [kg] | 2910 | 2860 | 2940 | 2935 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/3500 | 750/3500 | 750/3500 | 750/3500 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | ||
| Boot volume [l] | 580 | 670 | 670 | 670 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1690 | -/1780 | -/1780 | -/1780 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.36 | 0.36 | 0.36 | 0.36 | ||
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 255/55 R18 | 255/55 R18 | 255/55 R18 | 255/55 R18 | ||
| Tyre dimensions rear | 255/55 R18 | 255/55 R18 | 255/55 R18 | 255/55 R18 | ||
| Wheel size front | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | ||
| Wheel size rear | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | 8.0J x 18 | ||
| Brake dimensions front | 360 x 36 | 350 x 34 | 350 x 34 | 360 x 36 | ||
| Brake dimensions rear | 330 x 28 | 330 x 28 | 330 x 28 | 330 x 28 | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | - | - | - | - | ||
| Overall length [mm] | 4846 | 4846 | 4846 | 4846 | ||
| Overall width without/including mirrors [mm] | 1939/2155 | 1939/2155 | 1939/2155 | 1939/2155 | ||
| Overall height [mm] | 1705 | 1705 | 1705 | 1705 | ||
| Wheelbase [mm] | 2895 | 2895 | 2895 | 2895 | ||
| Front wheel track [mm] | 1655 | 1655 | 1655 | 1655 | ||
| Rear wheel track [mm] | 1669 | 1669 | 1669 | 1669 | ||
| Forward overhang [mm] | - | - | - | - | ||
| Rear overhang [mm] | - | - | - | - | ||
| Clearance [mm] | 215 | 215 | 215 | 215 | ||
| Wading depth [mm] | 500 | 500 | 500 | 500 | ||
| Approach angle front [°] | 26 | 26 | 26 | 26 | ||
| Approach angle rear [°] | 24.5 | 24.5 | 24.5 | 24.5 | ||
| Transition angle [°] | 20.5 | 20.5 | 20.5 | 20.5 | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1005 | 1005 | 1005 | 1005 | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | 1496/1467 | 1496/1467 | 1496/1467 | 1496/1467 | ||
| Rear elbow/shoulder width [mm] | - | - | - | - | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
