Porsche Panamera
Date of manufacture
4/2009 – 2013 (Liftback)
Platform
-
Manufacturing locations
Leipzig, Germany
Designer
Michael Mauer
Tags
F-segment
German cars
Since 2009, the Porsche Panamera has been available as a liftback. This vehicle is manufactured in Germany and offers petrol, diesel and hybrid engines. The most powerful version, the Turbo S, has 405 kW, a top speed of 306 km/h and a 0-100 km/h acceleration time of 3.8 seconds. Despite its strength, the Panamera Diesel has the lowest combined fuel consumption of 6.5 l/100 km and CO2 emissions of 172 g/km. The luggage compartment has a capacity of 445 l.
Car body style
Liftback
Date of manufacture
4/2009 – 2013Internal designation
970Engine size
Technical data
Liftback
| Panamera | Panamera | Panamera 4 | Panamera S | Panamera S | Panamera 4S | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 8/32 | 8/32 | 8/32 |
| Engine displacement [cm³] | 3605 | 3605 | 3605 | 4806 | 4806 | 4806 |
| Maximum output / speed [kW/min-1] | 220/6200 | 220/6200 | 220/6200 | 294/6500 | 294/6500 | 294/6500 |
| Maximum torque [Nm/min-1] | 400/3750 | 400/3750 | 400/3750 | 500/3500-5000 | 500/3500-5000 | 500/3500-5000 |
| Bore and stroke [mm x mm] | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 |
| Compression ratio | 12,5:1 | 12,5:1 | 12,5:1 | 12,5:1 | 12,5:1 | 12,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | Rear | Rear | 4x4 |
| Gearbox | 6 gear manual | 7 gear automatic | 7 gear automatic | 6 gear manual | 7 gear automatic | 7 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 261 | 259 | 257 | 285 | 283 | 282 |
| Acceleration 0–100 km/h [s] | 6.8 | 6.3 [6.1 Sport Chrono Paket] | 6.1 [5.9 Sport Chrono Paket] | 5.6 | 5.4 [5.2 Sport Chrono Paket] | 5.0 [4.8 Sport Chrono Paket] |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 16.4 | 12.7 | 12.8 | 18.8 | 15.3 | 16.0 |
| Out of town [l] | 7.8 | 6.9 | 7.2 | 8.9 | 7.8 | 7.9 |
| Combined [l] | 11.3 | 9.3 | 9.6 | 12.5 | 10.5 | 10.8 |
| CO2 emissions [g/km] | 265 | 218 | 225 | 293 | 247 | 254 |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1805 | 1835 | 1895 | 1845 | 1875 | 1935 |
| Overall weight [kg] | 2335 | 2365 | 2400 | 2375 | 2405 | 2440 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 445 | 445 | 445 | 445 | 445 | 445 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1263 | -/1263 | -/1263 | -/1263 | -/1263 | -/1263 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 80 | 80 | 80 | 80 | 80 | 100 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.3 | 0.3 | 0.3 | 0.29 | 0.29 | 0.29 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 245/50 ZR18 | 245/50 ZR18 | 245/50 ZR18 | 245/50 ZR18 | 245/50 ZR18 | 245/50 ZR18 |
| Tyre dimensions rear | 275/45 ZR18 | 275/45 ZR18 | 275/45 ZR18 | 275/45 ZR18 | 275/45 ZR18 | 275/45 ZR18 |
| Wheel size front | 8.0J x 18 ET59 | 8.0J x 18 ET59 | 8.0J x 18 ET59 | 8.0J x 18 ET59 | 8.0J x 18 ET59 | 8.0J x 18 ET59 |
| Wheel size rear | 9.0J x 18 ET53 | 9.0J x 18 ET53 | 9.0J x 18 ET53 | 9.0J x 18 ET53 | 9.0J x 18 ET53 | 9.0J x 18 ET53 |
| Brake dimensions front | 360 x 36 | 360 x 36 | 360 x 36 | 360 x 36 | 360 x 36 | 360 x 36 |
| Brake dimensions rear | 330 x 28 | 330 x 28 | 330 x 28 | 330 x 28 | 330 x 28 | 330 x 28 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- |
| Overall length [mm] | 4970 | 4970 | 4970 | 4970 | 4970 | 4970 |
| Overall width without/including mirrors [mm] | 1931/2114 | 1931/2114 | 1931/2114 | 1931/2114 | 1931/2114 | 1931/2114 |
| Overall height [mm] | 1418 | 1418 | 1418 | 1418 | 1418 | 1418 |
| Wheelbase [mm] | 2920 | 2920 | 2920 | 2920 | 2920 | 2920 |
| Front wheel track [mm] | 1658 | 1658 | 1658 | 1658 | 1658 | 1658 |
| Rear wheel track [mm] | 1662 | 1662 | 1662 | 1662 | 1662 | 1662 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 965 | 965 | 965 | 965 | 965 | 965 |
| Headroom rear [mm] | 970 | 970 | 970 | 970 | 970 | 970 |
| Front elbow/shoulder width [mm] | -/1317 | -/1317 | -/1317 | -/1317 | -/1317 | -/1317 |
| Rear elbow/shoulder width [mm] | -/1313 | -/1313 | -/1313 | -/1313 | -/1313 | -/1313 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Panamera GTS | Panamera Turbo | Panamera Turbo S | Panamera S Hybrid | Panamera Diesel | ||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | |
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Diesel supercharged | |
| Number of cylinders/valves | 8/32 | 8/32 | 8/32 | 6/24 | 6/24 | |
| Engine displacement [cm³] | 4806 | 4806 | 4806 | 2995 | 2967 | |
| Maximum output / speed [kW/min-1] | 316/6700 | 368/6000 | 405/6000 | 245/5500-6500 combustion 34/1150 el. 279/5500 total | 184/3800-4400 | |
| Maximum torque [Nm/min-1] | 520/3500 | 700/2250-4500 | 750/2250-4500 | 440/3500-5250 combustion 300/1150 el. 580/1000 total | 550/1750-2750 | |
| Bore and stroke [mm x mm] | 96,0 x 83,0 | 96,0 x 83,0 | 96,0 x 83,0 | 84,5 x 89,0 | 84,5 x 89,1 | |
| Compression ratio | 12,5:1 | 10,5:1 | 10,5:1 | 10,5:1 | - | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | 4x4 | 4x4 | 4x4 | Rear | Rear | |
| Gearbox | 7 gear automatic | 7 gear automatic | 7 gear automatic | 8 gear automatic | 8 gear automatic | |
| Drive specifications |
|
|
|
|
| |
| Top speed [km/h] | 288 | 303 | 306 | 270 | 242 | |
| Acceleration 0–100 km/h [s] | 4.5 | 4.2 [4.0 Sport Chrono Paket] | 3.8 | 6.0 | 6.8 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 16.1 | 17.0 | 17.0 | 7.6 | 8.1 | |
| Out of town [l] | 8.0 | 8.4 | 8.4 | 6.8 | 5.6 | |
| Combined [l] | 10.9 | 11.5 | 11.5 | 7.1 | 6.5 | |
| CO2 emissions [g/km] | 256 | 270 | 270 | 167 | 172 | |
| Emission standard | EU5 | EU5 | EU5 | EU5 | EU5 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| System voltage [V] | - | - | - | - | - | |
| Battery type and capacity | - | - | - | Nickel metal hydride, 1.7 kWh | - | |
| Range with fully charged battery [km] | - | - | - | - | - | |
| Charging time | - | - | - | - | - | |
| Number of modules/cells | - | - | - | - | - | |
| Battery weight [kg] | - | - | - | - | - | |
| Charger | - | - | - | - | - | |
| Standby weight [kg] | 1995 | 2045 | 2070 | 2055 | 1955 | |
| Overall weight [kg] | 2480 | 2500 | 2500 | 2485 | 2500 | |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | |
| Boot volume [l] | 445 | 432 | 432 | 335 | 445 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1263 | -/1250 | -/1250 | -/1153 | -/1263 | |
| Boot length [mm] | - | - | - | - | - | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | - | - | - | - | - | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 4 | 4 | 4 | 4 | 4 | |
| Fuel tank volume [l] | 100 | 100 | 100 | 80 | 80 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | 0.29 | 0.29 | 0.29 | 0.29 | 0.29 | |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | |
| Tyre dimensions front | 255/45 ZR19 | 255/45 ZR19 | 255/40 ZR20 | 245/50 ZR18 | 245/50 ZR18 | |
| Tyre dimensions rear | 285/40 ZR19 | 285/40 ZR19 | 295/35 ZR20 | 275/45 ZR18 | 275/45 ZR18 | |
| Wheel size front | 9.0J x 19 ET60 | 9.0J x 19 ET60 | 9.5J x 20 ET65 | 8.0J x 18 ET59 | 8.0J x 18 ET59 | |
| Wheel size rear | 10.0J x 19 ET61 | 10.0J x 19 ET61 | 11.0J x 20 ET68 | 9.0J x 18 ET53 | 9.0J x 18 ET53 | |
| Brake dimensions front | 390 x 38 | 390 x 38 | 390 x 38 | 360 x 36 | 360 x 36 | |
| Brake dimensions rear | 350 x 28 | 350 x 28 | 350 x 28 | 330 x 28 | 330 x 28 | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 11.9/- | 11.9/- | 11.9/- | 11.9/- | 11.9/- | |
| Overall length [mm] | 4970 | 4970 | 4970 | 4970 | 4970 | |
| Overall width without/including mirrors [mm] | 1931/2114 | 1931/2114 | 1931/2114 | 1931/2114 | 1931/2114 | |
| Overall height [mm] | 1408 | 1418 | 1418 | 1418 | 1418 | |
| Wheelbase [mm] | 2920 | 2920 | 2920 | 2920 | 2920 | |
| Front wheel track [mm] | - | 1656 | 1656 | 1658 | 1658 | |
| Rear wheel track [mm] | - | 1646 | 1646 | 1662 | 1662 | |
| Forward overhang [mm] | - | - | - | - | - | |
| Rear overhang [mm] | - | - | - | - | - | |
| Clearance [mm] | - | - | - | - | - | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | - | - | - | - | - | |
| Approach angle rear [°] | - | - | - | - | - | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 965 | 965 | 965 | 965 | 965 | |
| Headroom rear [mm] | 970 | 970 | 970 | 970 | 970 | |
| Front elbow/shoulder width [mm] | -/1317 | -/1317 | -/1317 | -/1317 | -/1317 | |
| Rear elbow/shoulder width [mm] | -/1313 | -/1313 | -/1313 | -/1313 | -/1313 | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
