Porsche Taycan
Date of manufacture
9/2019 – to this day (Sedan)
2021 – to this day (Estate)
Platform
J1
Manufacturing locations
Stuttgart, Germany
Designer
Michael Mauer
Tags
E-segment
German cars
Electric car
The Porsche Taycan model is available in both sedan and estate versions. The car has been produced since 2019 and is made in Germany. It is built on the J1 platform. The powertrain options are limited to electric motors. The highest power output is achieved by the Taycan Cross Turismo Turbo S (560 kW). The highest speed of the Taycan Turbo S is 260 km/h. The best acceleration from 0-100 km/h is 2.8 seconds for the Taycan Turbo S. The most fuel-efficient version is the Taycan with a combined consumption of 24.8 kWh/100 km. The sedan version has a boot capacity of 407 l, while the estate version has a boot capacity of 446 l. The model was tested for safety in 2019 and achieved a total rating of 5 out of 5 according to EURONCAP.
Car body style
Sedan
Date of manufacture
9/2019 – to this dayInternal designation
-Estate (Cross Turismo)
Date of manufacture
2021 – to this dayInternal designation
-
Technical data
Sedan
| Taycan | Taycan Plus | Taycan 4S | Taycan 4S Plus | Taycan Turbo | Taycan Turbo S | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Electric | Electric | Electric | Electric | Electric | Electric |
| Number of cylinders/valves | - | - | - | - | - | - |
| Engine displacement [cm³] | - | - | - | - | - | - |
| Maximum output / speed [kW/min-1] | 240 300 overboost | 280 350 overboost | 320 390 overboost | 360 420 overboost | 460 500 overboost | 460 560 overboost |
| Maximum torque [Nm/min-1] | 345 | 357 | 640 | 650 | 850 | 1050 |
| Bore and stroke [mm x mm] | - | - | - | - | - | - |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 2 gear automatic | 2 gear automatic | 2 gear automatic | 2 gear automatic | 2 gear automatic | 2 gear automatic |
| Drive specifications | - | - |
|
|
|
|
| Top speed [km/h] | 230 | 230 | 250 | 250 | 260 | 260 |
| Acceleration 0–100 km/h [s] | 5.4 | 5.1 | 4.0 | 3.8 | 3.2 | 2.8 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 3.0 | 2.7 | 2.3 | 2.3 | 1.9 | 1.7 |
| City [l] | - | - | - | - | - | - |
| Out of town [l] | - | - | - | - | - | - |
| Combined [l] | 28.0 kWh | 28.7 kWh | 26.2 kWh | 27.0 kWh | 28.0 kWh | 28.5 kWh |
| CO2 emissions [g/km] | - | - | - | - | - | - |
| Low speed [l] | 18.9 kWh | 22.6-19.7 kWh | 19.1 kWh | 23.8-19.8 kWh | 20.0 kWh | 21.4 kWh |
| Medium speed [l] | 18.1 kWh | 22.0-19.1 kWh | 17.8 kWh | 22.2-18.4 kWh | 19.2 kWh | 20.2 kWh |
| High speed [l] | 17.6 kWh | 21.6-18.2 kWh | 18.2 kWh | 22.3-18.3 kWh | 19.3 kWh | 21.0 kWh |
| Extra high speed [l] | 21.4 kWh | 26.3-22.1 kWh | 22.0 kWh | 27.4-22.3 kWh | 23.5 kWh | 26.0 kWh |
| Combined speed [l] | 24.8-20.4 kWh | 25.4-21.5 kWh | 25.6-21.0 kWh | 26.0-21.9 kWh | 26.6-22.9 kWh | 25.6-24.3 kWh |
| CO2 emissions [g/km] | - | - | - | - | - | - |
| Emission standard | - | - | - | - | - | - |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | Lithium-ion, 79.2 kWh (71 net) | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 79.2 kWh (71 net) | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 93.4 kWh (83.7 net) |
| Range with fully charged battery [km] | 354-431 | 407-484 | 335-408 | 389-464 | 383-452 | 390-416 |
| Charging time |
|
|
|
|
|
|
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 2125 | 2205 | 2215 | 2295 | 2380 | 2370 |
| Overall weight [kg] | 2795 | 2795 | 2880 | 2880 | 2880 | 2870 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 407 | 407 | 407 | 407 | 366 | 366 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 4 | 4 | 4 | 4 | 4 | 4 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | - | - | - | - | - | - |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.22 | 0.22 | 0.22 | 0.22 | 0.22 | 0.25 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/55 R19 103Y XL | 225/55 R19 103Y XL | 225/55 R19 103Y XL | 225/55 R19 103Y XL | 245/45 R20 103Y XL | 265/35 ZR21 101Y XL |
| Tyre dimensions rear | 275/45 R19 108Y XL | 275/45 R19 108Y XL | 275/45 R19 108Y XL | 275/45 R19 108Y XL | 285/40 R20 108Y XL | 305/30 ZR21 104Y XL |
| Wheel size front | 8.0 J x 19 ET 50 | 8.0 J x 19 ET 50 | 8.0 J x 19 ET 50 | 8.0 J x 19 ET 50 | 9.0 J x 20 ET 54 | 9.5 J x 21 ET 60 |
| Wheel size rear | 10.0 J x 19 ET 47 | 10.0 J x 19 ET 47 | 10.0 J x 19 ET 47 | 10.0 J x 19 ET 47 | 11.0 J x 20 ET 60 | 11.5 J x 21 ET 66 |
| Brake dimensions front | 360 x 36 | 360 x 36 | 360 x 36 | 360 x 36 | 410 x 38 | 420 x 40 |
| Brake dimensions rear | 358 x 28 | 358 x 28 | 358 x 28 | 358 x 28 | 365 x 28 | 410 x 32 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.7/- | 11.7/- | 11.7/- | 11.7/- | 11.7/- | 11.2/- |
| Overall length [mm] | 4963 | 4963 | 4963 | 4963 | 4963 | 4963 |
| Overall width without/including mirrors [mm] | 1966/2144 | 1966/2144 | 1966/2144 | 1966/2144 | 1966/2144 | 1966/2144 |
| Overall height [mm] | 1395 | 1394 | 1379 | 1379 | 1381 | 1378 |
| Wheelbase [mm] | 2900 | 2900 | 2900 | 2900 | 2900 | 2900 |
| Front wheel track [mm] | 1710 | 1710 | 1710 | 1710 | 1702 | 1690 |
| Rear wheel track [mm] | 1694 | 1694 | 1694 | 1694 | 1667 | 1655 |
| Forward overhang [mm] | - | - | - | - | - | - |
| Rear overhang [mm] | - | - | - | - | - | - |
| Clearance [mm] | 127 | 127 | 127 | 127 | 128 | 126 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 11.0-11.2 | 11.0-11.2 | 11.0-11.2 | 11.0-11.2 | 11.0-11.2 | 11.0-11.2 |
| Approach angle rear [°] | 14.1-14.8 | 14.1-14.8 | 14.1-14.8 | 14.1-14.8 | 14.1-14.8 | 14.1-14.8 |
| Transition angle [°] | 10.5-10.6 | 10.5-10.6 | 10.5-10.6 | 10.5-10.6 | 10.5-10.6 | 10.5-10.6 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | - | - | - | - | - | - |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Estate (Cross Turismo)
| Taycan 4 Cross Turismo | Taycan Cross Turismo 4S | Taycan Cross Turismo Turbo | Taycan Cross Turismo Turbo S | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Electric | Electric | Electric | Electric | ||
| Number of cylinders/valves | - | - | - | - | ||
| Engine displacement [cm³] | - | - | - | - | ||
| Maximum output / speed [kW/min-1] | 280 350 overboost | 360 420 overboost | 460 500 overboost | 460 560 overboost | ||
| Maximum torque [Nm/min-1] | 357 | 650 | 850 | 1050 | ||
| Bore and stroke [mm x mm] | - | - | - | - | ||
| Compression ratio | - | - | - | - | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | ||
| Gearbox | 2 gear automatic | 2 gear automatic | 2 gear automatic | 2 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 220 | 240 | 250 | 250 | ||
| Acceleration 0–100 km/h [s] | 5.1 | 4.1 | 3.3 | 2.9 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | 2.6 | 2.3 | 1.9 | 1.7 | ||
| City [l] | - | - | - | - | ||
| Out of town [l] | - | - | - | - | ||
| Combined [l] | 28.1 kWh | 28.1 kWh | 28.7 kWh | 29.4 kWh | ||
| CO2 emissions [g/km] | - | - | - | - | ||
| Low speed [l] | 19.0 kWh | 19.3 kWh | 20.2 kWh | 20.5 kWh | ||
| Medium speed [l] | 18.3 kWh | 18.5 kWh | 18.8 kWh | 20.1 kWh | ||
| High speed [l] | 18.9 kWh | 19.1 kWh | 19.5 kWh | 21.1 kWh | ||
| Extra high speed [l] | 24.0 kWh | 24.1 kWh | 24.4 kWh | 26.6 kWh | ||
| Combined speed [l] | 26.4-22.4 kWh | 26.4-22.6 kWh | 25.9-22.6 kWh | 26.4-24.4 kWh | ||
| CO2 emissions [g/km] | - | - | - | - | ||
| Emission standard | - | - | - | - | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| System voltage [V] | - | - | - | - | ||
| Battery type and capacity | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 93.4 kWh (83.7 net) | Lithium-ion, 93.4 kWh (83.7 net) | ||
| Range with fully charged battery [km] | 389-456 | 388-452 | 395-452 | 388-419 | ||
| Charging time |
|
|
|
| ||
| Number of modules/cells | - | - | - | - | ||
| Battery weight [kg] | - | - | - | - | ||
| Charger | - | - | - | - | ||
| Standby weight [kg] | 2320 | 2320 | 2395 | 2395 | ||
| Overall weight [kg] | 2885 | 2885 | 2880 | 2880 | ||
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | ||
| Boot volume [l] | 446 | 446 | 405 | 405 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1212 | -/1212 | -/1171 | -/1171 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 4 | 4 | 4 | 4 | ||
| Fuel tank volume [l] | - | - | - | - | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.26 | 0.26 | 0.26 | 0.27 | ||
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 225/55 R19 103Y XL | 225/55 R19 103Y XL | 245/45 R20 103Y XL | 255/40 ZR20 101Y XL | ||
| Tyre dimensions rear | 275/45 R19 108Y XL | 275/45 R19 108Y XL | 285/40 R20 108Y XL | 295/35 ZR20 105Y XL | ||
| Wheel size front | 8.0 J x 19 ET 50 | 8.0 J x 19 ET 50 | 9.0 J x 20 ET 54 | 9.0 J x 20 ET 54 | ||
| Wheel size rear | 10.0 J x 19 ET 47 | 10.0 J x 19 ET 47 | 11.0 J x 20 ET 60 | 11.0 J x 20 ET 60 | ||
| Brake dimensions front | 360 x 36 | 360 x 36 | 410 x 38 | 420 x 40 | ||
| Brake dimensions rear | 358 x 28 | 358 x 28 | 365 x 28 | 410 x 32 | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 12.0/- | 12.0/- | 12.0/- | 11.4/- | ||
| Overall length [mm] | 4974 | 4974 | 4974 | 4974 | ||
| Overall width without/including mirrors [mm] | 1967/2144 | 1967/2144 | 1967/2144 | 1967/2144 | ||
| Overall height [mm] | 1409 | 1409 | 1412 | 1407 | ||
| Wheelbase [mm] | 2904 | 2904 | 2904 | 2904 | ||
| Front wheel track [mm] | 1718 | 1718 | 1710 | 1710 | ||
| Rear wheel track [mm] | 1698 | 1698 | 1672 | 1672 | ||
| Forward overhang [mm] | - | - | - | - | ||
| Rear overhang [mm] | - | - | - | - | ||
| Clearance [mm] | 146 | 146 | 148 | 143 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | 12.2-12.3 | 12.2-12.3 | 12.2-12.3 | 12.2-12.3 | ||
| Approach angle rear [°] | 16.2-16.5 | 16.2-16.5 | 16.2-16.5 | 16.2-16.5 | ||
| Transition angle [°] | 12.0-12.3 | 12.0-12.3 | 12.0-12.3 | 12.0-12.3 | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | - | - | - | - | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | - | - | - | - | ||
| Rear elbow/shoulder width [mm] | - | - | - | - | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
