Renault Captur
Date of manufacture
2017 – 2019 (Small SUV)
Platform
Renault B
Manufacturing locations
Valladolid, Spain
Designer
Laurens van den Acker
Tags
Small SUV
French cars
The Renault Captur is a small SUV that was first produced in 2017 in Spain. It is built on the Renault B platform and offers petrol and diesel engines with a maximum power of 110 kW (TCe 150). This model has a maximum speed of 210 km/h and the best acceleration 0-100 km/h in 9.5 seconds. The most economical version Energy dCi 110 has a consumption of 3.7 l/100 km and CO2 emissions of 98 g/km. The car's trunk has a volume of 377 l. The model successfully passed the EURONCAP 2013 safety tests, where it received a rating of 5 out of 5.
Car body style
Small SUV
after upgrade (facelift)
Date of manufacture
2017 – 2019Internal designation
J87
Technical data
Small SUV
| Energy TCe 90 | Energy TCe 120 | Energy TCe 120 | TCe 130 | TCe 150 | TCe 150 | |
|---|---|---|---|---|---|---|
| Date of sale | - | from to 2018 | from to 2018 | from 2018 to | from 2018 to | from 2018 to |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 898 | 1197 | 1197 | 1333 | 1333 | 1333 |
| Maximum output / speed [kW/min-1] | 66/5000 [71 overboost] | 87/5000 | 87/5000 | 96/4500 | 110/5500 | 110/5500 |
| Maximum torque [Nm/min-1] | 140/2250 [150 overboost] | 205/2000 | 205/2000 | 240/1600 | 250/1700 | 250/1700 |
| Bore and stroke [mm x mm] | 72,2 x 73,1 | 72,2 x 73,1 | 72,2 x 73,1 | 72,2 x 81,2 | 72,2 x 81,2 | 72,2 x 81,2 |
| Compression ratio | 9,5:1 | 10,0:1 | 10,0:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 6 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic |
| Drive specifications | - | - |
| - | - |
|
| Top speed [km/h] | 171 | 182 | 192 | 200 | 210 | 210 |
| Acceleration 0–100 km/h [s] | 13,0-13.1 | 9,9 | 10,6 | 10.2 | 9.8 | 9.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.9-6,0 | 6,8-7,0 | 6,8-7,0 | 7.1 | 6.8 | 6.6 |
| Out of town [l] | 4.8-4,5 | 4,7-4,9 | 4,7-4,9 | 4.8 | 4.8 | 4.8 |
| Combined [l] | 5.6-5,1 | 5,5-5,6 | 5,5-5,6 | 5.6 | 5.5 | 5.5 |
| CO2 emissions [g/km] | 128-113 | 125-127 | 125-127 | 128 | 126 | 125 |
| Emission standard | EU6 - Euro 6d-TEMP | EU6 | EU6 | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1248 | 1270 | 1277 | 1304 | 1304 | 1321 |
| Overall weight [kg] | 1671-1659 | 1727 | 1744 | 1729 | 1729 | 1746 |
| Maximum trailer weight unbraked/braked [kg] | 620/900 | 635/900 | 635/900 | 660/900 | 660/900 | 670/900 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 377 | 377 | 377 | 377 | 377 | 377 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1235 | -/1235 | -/1235 | -/1235 | -/1235 | -/1235 |
| Boot length [mm] | 884 | 884 | 884 | 884 | 884 | 884 |
| Boot length with rear seats folded [mm] | 1512 | 1512 | 1512 | 1512 | 1512 | 1512 |
| Boot width between wheels/max [mm] | 990/- | 990/- | 990/- | 990/- | 990/- | 990/- |
| Boot height to headliner/ceiling [mm] | 595/- | 595/- | 595/- | 595/- | 595/- | 595/- |
| Loading edge height [mm] | 723 | 723 | 723 | 723 | 723 | 723 |
| Height of the open boot door [mm] | 1920 | 1920 | 1920 | 1920 | 1920 | 1920 |
| Boot opening height [mm] | 685 | 685 | 685 | 685 | 685 | 685 |
| Boot opening width min/max [mm] | 905/1010 | 905/1010 | 905/1010 | 905/1010 | 905/1010 | 905/1010 |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 45 | 45 | 45 | 45 | 45 | 45 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar | torsion bar |
| Tyre dimensions front | 205/60 R16 92H | 205/55 R17 95V | 205/60 R16 92H | 205/55 R17 95V | 205/55 R17 95V | 205/55 R17 95V |
| Tyre dimensions rear | 205/60 R16 92H | 205/55 R17 95V | 205/60 R16 92H | 205/55 R17 95V | 205/55 R17 95V | 205/55 R17 95V |
| Wheel size front | 6.5J x 16 ET40 | 6.5J x 17 ET40 | 6.5J x 16 ET40 | 6.5J x 17 ET40 | 6.5J x 17 ET40 | 6.5J x 17 ET40 |
| Wheel size rear | 6.5J x 16 ET40 | 6.5J x 17 ET40 | 6.5J x 16 ET40 | 6.5J x 17 ET40 | 6.5J x 17 ET40 | 6.5J x 17 ET40 |
| Brake dimensions front | 258 x 22 | 280 x 24 | 280 x 24 | 280 x 24 | 280 x 24 | 280 x 24 |
| Brake dimensions rear | 9" drum | 9" drum | 9" drum | 9" drum | 9" drum | 9" drum |
| Steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.42/11.0 | 10.42/11.0 | 10.42/11.0 | 10.42/11.0 | 10.42/11.0 | 10.42/11.0 |
| Overall length [mm] | 4122 | 4122 | 4122 | 4122 | 4122 | 4122 |
| Overall width without/including mirrors [mm] | 1778/- | 1778/- | 1778/- | 1778/- | 1778/- | 1778/- |
| Overall height [mm] | 1566 | 1566 | 1566 | 1566 | 1566 | 1566 |
| Wheelbase [mm] | 2606 | 2606 | 2606 | 2606 | 2606 | 2606 |
| Front wheel track [mm] | 1531 | 1531 | 1531 | 1531 | 1531 | 1531 |
| Rear wheel track [mm] | 1516 | 1516 | 1516 | 1516 | 1516 | 1516 |
| Forward overhang [mm] | 866 | 866 | 866 | 866 | 866 | 866 |
| Rear overhang [mm] | 650 | 650 | 650 | 650 | 650 | 650 |
| Clearance [mm] | 170 | 170 | 170 | 170 | 170 | 170 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 905 | 905 | 905 | 905 | 905 | 905 |
| Headroom rear [mm] | 860 | 860 | 860 | 860 | 860 | 860 |
| Front elbow/shoulder width [mm] | 1380/1386 | 1380/1386 | 1380/1386 | 1380/1386 | 1380/1386 | 1380/1386 |
| Rear elbow/shoulder width [mm] | 1370/1330 | 1370/1330 | 1370/1330 | 1370/1330 | 1370/1330 | 1370/1330 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | 215/- | 215/- | 215/- | 215/- | 215/- | 215/- |
| Energy dCi 90 | Energy dCi 90 | Energy dCi 110 | ||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | from to 2018 | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/8 | 4/8 | 4/8 | |||
| Engine displacement [cm³] | 1461 | 1461 | 1461 | |||
| Maximum output / speed [kW/min-1] | 66/4000 | 66/4000 | 81/4000 | |||
| Maximum torque [Nm/min-1] | 220/1750 | 220/1750 | 260/1750 | |||
| Bore and stroke [mm x mm] | 76,0 x 80,5 | 76,0 x 80,5 | 76,0 x 80,5 | |||
| Compression ratio | 15,5:1 | 15,5:1 | 15,5:1 | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | Front | |||
| Gearbox | 5 gear manual | 6 gear automatic | 6 gear manual | |||
| Drive specifications | - |
| - | |||
| Top speed [km/h] | 171 | 172 | 180 | |||
| Acceleration 0–100 km/h [s] | 13,1 | 13,8 | 11,4 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | 4.6-4,0 | 4.5-4,0 | 4,0-4,1 | |||
| Out of town [l] | 4.0-3,4 | 4.2-3,7 | 3,6-3,7 | |||
| Combined [l] | 4.2-3,6 | 4.3-3,8 | 3,7-3,9 | |||
| CO2 emissions [g/km] | 111-95 | 113-99 | 98-101 | |||
| Emission standard | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1275 | 1365 | 1280 | |||
| Overall weight [kg] | 1755 | 1780 | 1762 | |||
| Maximum trailer weight unbraked/braked [kg] | 635/900 | 680/900 | 640/900 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | - | - | - | |||
| Boot volume [l] | 377 | 377 | 377 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1235 | -/1235 | -/1235 | |||
| Boot length [mm] | 884 | 884 | 884 | |||
| Boot length with rear seats folded [mm] | 1512 | 1512 | 1512 | |||
| Boot width between wheels/max [mm] | 990/- | 990/- | 990/- | |||
| Boot height to headliner/ceiling [mm] | 595/- | 595/- | 595/- | |||
| Loading edge height [mm] | 723 | 723 | 723 | |||
| Height of the open boot door [mm] | 1920 | 1920 | 1920 | |||
| Boot opening height [mm] | 685 | 685 | 685 | |||
| Boot opening width min/max [mm] | 905/1010 | 905/1010 | 905/1010 | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5 | 5 | 5 | |||
| Fuel tank volume [l] | 45 | 45 | 45 | |||
| AdBlue tank volume [l] | - | - | - | |||
| Air resistance [Cd] | - | - | - | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | torsion bar | torsion bar | torsion bar | |||
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/55 R17 95V | |||
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/55 R17 95V | |||
| Wheel size front | 6.5J x 16 ET40 | 6.5J x 16 ET40 | 6.5J x 17 ET40 | |||
| Wheel size rear | 6.5J x 16 ET40 | 6.5J x 16 ET40 | 6.5J x 17 ET40 | |||
| Brake dimensions front | 280 x 24 | 280 x 24 | 280 x 24 | |||
| Brake dimensions rear | 9" drum | 9" drum | 9" drum | |||
| Steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | |||
| Number of steering wheel turns | - | - | - | |||
| Turning diameter track/circumference [m] | 10.42/11.0 | 10.42/11.0 | 10.42/11.0 | |||
| Overall length [mm] | 4122 | 4122 | 4122 | |||
| Overall width without/including mirrors [mm] | 1778/- | 1778/- | 1778/- | |||
| Overall height [mm] | 1566 | 1566 | 1566 | |||
| Wheelbase [mm] | 2606 | 2606 | 2606 | |||
| Front wheel track [mm] | 1531 | 1531 | 1531 | |||
| Rear wheel track [mm] | 1516 | 1516 | 1516 | |||
| Forward overhang [mm] | 866 | 866 | 866 | |||
| Rear overhang [mm] | 650 | 650 | 650 | |||
| Clearance [mm] | 170 | 170 | 170 | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 905 | 905 | 905 | |||
| Headroom rear [mm] | 860 | 860 | 860 | |||
| Front elbow/shoulder width [mm] | 1380/1386 | 1380/1386 | 1380/1386 | |||
| Rear elbow/shoulder width [mm] | 1370/1330 | 1370/1330 | 1370/1330 | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | 215/- | 215/- | 215/- |
