Renault Espace
Date of manufacture
2015 – to this day (MPV)
Platform
CMF-CD
Manufacturing locations
Douai, France
Designer
François Leboine
Tags
Large MPV
French cars
Renault Espace is a unique MPV manufactured since 2015 in France. The car is built on the CMF-CD platform and offers a wide range of petrol and diesel engines. The most powerful model is the Energy TCe 225, which delivers 165 kW (224 hp) and the best 0-100 km/h acceleration in 7.6 seconds. The most economical variant, the Energy dCi 130, has a combined fuel consumption of 4.4 l/100 km and CO2 emissions of 116 g/km. The trunk capacity ranges from 680-785 liters. Renault Espace has successfully passed EURONCAP safety tests and has been rated 5 out of 5.
Car body style
MPV
Date of manufacture
2015 – to this dayInternal designation
Technical data
MPV
| Energy TCe 200 | Energy TCe 225 | Energy dCi 130 | Energy dCi 130 | Energy dCi 160 | Energy dCi 160 | |
|---|---|---|---|---|---|---|
| Date of sale | from to 2017 | from 2017 to 2020 | from to 2018 | from 2017 to 2018 | from to 2018 | from 2017 to 2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1618 | 1798 | 1598 | 1598 | 1598 | 1598 |
| Maximum output / speed [kW/min-1] | 147/5750 | 165/5600 | 96/4000 | 96/4000 | 118/4000 | 118/4000 |
| Maximum torque [Nm/min-1] | 260/2500 | 300/1750 | 320/1750 | 320/1750 | 380/1750 | 380/1750 |
| Bore and stroke [mm x mm] | 79,7 x 81,1 | 79,7 x 90.1 | 80,0 x 79,5 | 76.0 x 80.5 | 80,0 x 79,5 | 76.0 x 80.5 |
| Compression ratio | 9,5:1 | - | 15,4:1 | - | 15,4:1 | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 7 gear automatic | 7 gear automatic | 6 gear manual | 6 gear manual | 6 gear automatic | 6 gear automatic |
| Drive specifications |
|
| - | - |
|
|
| Top speed [km/h] | 211 | 224 | 191 | 191 | 202 | 202 |
| Acceleration 0–100 km/h [s] | 8.6 | 7.6-7.9 | 10.7 | 10.7 | 9.9 | 9.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 7.8 | 8.7 | 5.1 | 5.1 | 5.0-5.1 | 5.0 |
| Out of town [l] | 5.3 | 5.6 | 4.0-4.2 | 4.0 | 4.4 | 4.4 |
| Combined [l] | 6.2 | 6.8 | 4.4-4.5 | 4.4 | 4.6-4.7 | 4.6 |
| CO2 emissions [g/km] | 140 | 193-152 | 116-119 | 116 | 120-123 | 120 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | - | 8.4-8.3 | - | - | - | - |
| CO2 emissions [g/km] | - | 194-187 | - | - | - | - |
| Emission standard | EU6 | EU6 - Euro 6d-TEMP | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1684 | 1610-1770 | 1697 | 1697 | 1734 | 1734 |
| Overall weight [kg] | 2410 | 2393-2410 | 2353 | 2471 | 2471 | 2471 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | 80/- | 80/- | 80/- |
| Boot volume [l] | 680-785 | 680-785 | 680-785 | 680-785 | 680-785 | 680-785 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2101 | -/2101 | -/2101 | -/2101 | -/2101 | -/2101 |
| Boot length [mm] | 1075 | 1075 | 1075 | 1075 | 1075 | 1075 |
| Boot length with rear seats folded [mm] | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 |
| Boot width between wheels/max [mm] | 1090/- | 1090/- | 1090/- | 1090/- | 1090/- | 1090/- |
| Boot height to headliner/ceiling [mm] | 460/- | 460/- | 460/- | 460/- | 460/- | 460/- |
| Loading edge height [mm] | 710 | 710 | 710 | 710 | 710 | 710 |
| Height of the open boot door [mm] | 2106 | 2106 | 2106 | 2106 | 2106 | 2106 |
| Boot opening height [mm] | 800 | 800 | 800 | 800 | 800 | 800 |
| Boot opening width min/max [mm] | 1140/- | 1140/- | 1140/- | 1140/- | 1140/- | 1140/- |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Fuel tank volume [l] | 58 | 58 | 58 | 58 | 58 | 58 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 235/60 R18 103V | 235/60 R18 103V | 235/65 R17 104V | 235/65 R17 104V | 235/60 R18 103V | 235/60 R18 103V |
| Tyre dimensions rear | 235/60 R18 103V | 235/60 R18 103V | 235/65 R17 104V | 235/65 R17 104V | 235/60 R18 103V | 235/60 R18 103V |
| Wheel size front | 7.5J x 18 ET39 | - | 7.0J x 17 ET37 | - | 7.5J x 18 ET39 | - |
| Wheel size rear | 7.5J x 18 ET39 | - | 7.0J x 17 ET37 | - | 7.5J x 18 ET39 | - |
| Brake dimensions front | 320 x 28 | 320 x 28 | 320 x 28 | 320 x 28 | 320 x 28 | 320 x 28 |
| Brake dimensions rear | 290 x 11 | 290 x 11 | 290 x 11 | 290 x 11 | 290 x 11 | 290 x 11 |
| Steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | Electric variable power steering |
| Number of steering wheel turns | - | 2.8 | - | 2.8 | - | 2.8 |
| Turning diameter track/circumference [m] | 11.9/12.4 | 11.9/12.4 | 11.9/12.4 | 11.9/12.4 | 11.9/12.4 | 11.9/12.4 |
| Overall length [mm] | 4857 | 4857 | 4857 | 4857 | 4857 | 4857 |
| Overall width without/including mirrors [mm] | 1888/2128 | 1888/2128 | 1888/2128 | 1888/2128 | 1888/2128 | 1888/2128 |
| Overall height [mm] | 1677 | 1677 | 1677 | 1677 | 1677 | 1677 |
| Wheelbase [mm] | 2884 | 2884 | 2884 | 2884 | 2884 | 2884 |
| Front wheel track [mm] | 1630 | 1630 | 1630 | 1630 | 1630 | 1630 |
| Rear wheel track [mm] | 1621 | 1621 | 1621 | 1621 | 1621 | 1621 |
| Forward overhang [mm] | 1034 | 1034 | 1034 | 1034 | 1034 | 1034 |
| Rear overhang [mm] | 939 | 939 | 939 | 939 | 939 | 939 |
| Clearance [mm] | 160 | 160 | 160 | 160 | 160 | 160 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 906 | 906 | 906 | 906 | 906 | 906 |
| Headroom rear [mm] | 874 | 874 | 874 | 874 | 874 | 874 |
| Front elbow/shoulder width [mm] | 1549/1494 | 1549/1494 | 1549/1494 | 1549/1494 | 1549/1494 | 1549/1494 |
| Rear elbow/shoulder width [mm] | 1543/1480 | 1543/1480 | 1543/1480 | 1543/1480 | 1543/1480 | 1543/1480 |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | 308/- | 308/- | 308/- | 308/- | 308/- | 308/- |
| Blue dCi 160 | Blue dCi 190 | Blue dCi 200 | ||||
|---|---|---|---|---|---|---|
| Date of sale | from 2018 to | from 2021 to | from 2018 to 2020 | |||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | |||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | |||
| Engine displacement [cm³] | 1997 | 1997 | 1997 | |||
| Maximum output / speed [kW/min-1] | 118/3750 | 139/3500 | 147/3500 | |||
| Maximum torque [Nm/min-1] | 360/1500 | 400/1750-3000 | 400/1750 | |||
| Bore and stroke [mm x mm] | 85.0 x 88.0 | 85.0 x 88.0 | 85.0 x 88.0 | |||
| Compression ratio | - | - | - | |||
| Oil volume [l] | - | - | - | |||
| Coolant volume [l] | - | - | - | |||
| Technical specifications |
|
|
| |||
| Drive axle | Front | Front | Front | |||
| Gearbox | 6 gear automatic | 6 gear automatic | 6 gear automatic | |||
| Drive specifications |
|
|
| |||
| Top speed [km/h] | 196-200 | 207 | 215 | |||
| Acceleration 0–100 km/h [s] | 10.5-11.0 | 10.6 | 9.1 | |||
| Acceleration 0–80 km/h [s] | - | - | - | |||
| Acceleration 80–120 km/h [s] | - | - | - | |||
| City [l] | - | - | - | |||
| Out of town [l] | - | - | - | |||
| Combined [l] | - | - | - | |||
| CO2 emissions [g/km] | - | - | - | |||
| Low speed [l] | - | - | - | |||
| Medium speed [l] | - | - | - | |||
| High speed [l] | - | - | - | |||
| Extra high speed [l] | - | - | - | |||
| Combined speed [l] | 6.7-6.4 | 6.7-6.6 | 6.6-6.4 | |||
| CO2 emissions [g/km] | 175-169 | 175-172 | 175-169 | |||
| Emission standard | Euro 6d-TEMP - Euro 6d | Euro 6d | Euro 6d-TEMP | |||
| Standard for fuel consumption measurement | - | - | - | |||
| Energy class | - | - | - | |||
| Stationary vehicle noise [dB] | - | - | - | |||
| Driving noise [dB] | - | - | - | |||
| Standby weight [kg] | 1785-1961 | 1785-1961 | 1840-1879 | |||
| Overall weight [kg] | 2554-2568 | 2568 | 2554 | |||
| Maximum trailer weight unbraked/braked [kg] | 750/2000 | 750/2000 | 750/2000 | |||
| Maximum front/rear axle load [kg] | - | - | - | |||
| Maximum vertical load on the tow bar [kg] | - | - | - | |||
| Maximum load on roof/carrier [kg] | 80/- | 80/- | 80/- | |||
| Boot volume [l] | 680-785 | 680-785 | 680-785 | |||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2101 | -/2101 | -/2101 | |||
| Boot length [mm] | 1075 | 1075 | 1075 | |||
| Boot length with rear seats folded [mm] | 2020 | 2020 | 2020 | |||
| Boot width between wheels/max [mm] | 1090/- | 1090/- | 1090/- | |||
| Boot height to headliner/ceiling [mm] | 460/- | 460/- | 460/- | |||
| Loading edge height [mm] | 710 | 710 | 710 | |||
| Height of the open boot door [mm] | 2106 | 2106 | 2106 | |||
| Boot opening height [mm] | 800 | 800 | 800 | |||
| Boot opening width min/max [mm] | 1140/- | 1140/- | 1140/- | |||
| Number of doors | 5 | 5 | 5 | |||
| Number of seats | 5-7 | 5-7 | 5-7 | |||
| Fuel tank volume [l] | 58 | 58 | 58 | |||
| AdBlue tank volume [l] | 21.4-22.2 | 21.4 | 22.2 | |||
| Air resistance [Cd] | 0.3 | 0.3 | 0.3 | |||
| Front suspension | MacPherson | MacPherson | MacPherson | |||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |||
| Tyre dimensions front | 235/60 R18 103V | 235/60 R18 103V | 235/60 R18 103V | |||
| Tyre dimensions rear | 235/60 R18 103V | 235/60 R18 103V | 235/60 R18 103V | |||
| Wheel size front | - | - | - | |||
| Wheel size rear | - | - | - | |||
| Brake dimensions front | 320 x 28 | 320 x 28 | 320 x 28 | |||
| Brake dimensions rear | 290 x 11 | 290 x 11 | 290 x 11 | |||
| Steering | Electric variable power steering | Electric variable power steering | Electric variable power steering | |||
| Number of steering wheel turns | 2.9 | 2.9 | 2.9 | |||
| Turning diameter track/circumference [m] | 11.9/12.4 | 11.9/12.4 | 11.9/12.4 | |||
| Overall length [mm] | 4857 | 4857 | 4857 | |||
| Overall width without/including mirrors [mm] | 1888/2128 | 1888/2128 | 1888/2128 | |||
| Overall height [mm] | 1677 | 1677 | 1677 | |||
| Wheelbase [mm] | 2884 | 2884 | 2884 | |||
| Front wheel track [mm] | 1630 | 1630 | 1630 | |||
| Rear wheel track [mm] | 1621 | 1621 | 1621 | |||
| Forward overhang [mm] | 1034 | 1034 | 1034 | |||
| Rear overhang [mm] | 939 | 939 | 939 | |||
| Clearance [mm] | 160 | 160 | 160 | |||
| Wading depth [mm] | - | - | - | |||
| Approach angle front [°] | - | - | - | |||
| Approach angle rear [°] | - | - | - | |||
| Transition angle [°] | - | - | - | |||
| Climbing rate [°] | - | - | - | |||
| Maximum side tilt [°] | - | - | - | |||
| Headroom front [mm] | 906 | 906 | 906 | |||
| Headroom rear [mm] | 874 | 874 | 874 | |||
| Front elbow/shoulder width [mm] | 1549/1494 | 1549/1494 | 1549/1494 | |||
| Rear elbow/shoulder width [mm] | 1543/1480 | 1543/1480 | 1543/1480 | |||
| Legroom front knees/total [mm] | - | - | - | |||
| Legroom rear knees/total [mm] | 308/- | 308/- | 308/- |
