Renault Talisman

Date of manufacture

2020 – to this day (Sedan)

2020 – to this day (Estate)

Platform

CMF-CD

Manufacturing locations

Douai, France

Busan (Pusan), South Korea

Designer

Alexis Martot

Car body style

Sedan

after upgrade (facelift)

Date of manufacture

2020 – to this day

Internal designation

Engine size

Petrol

Diesel

Estate (Grandtour)

after upgrade (facelift)

Date of manufacture

2020 – to this day

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Test year 2015

pre-facelift version (2015)

Technical data

Sedan

	TCe 140	TCe 160	Blue dCi 160	Blue dCi 190
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1332	1332	1997	1997
Maximum output / speed [kW/min-1]	103/5500	116/5500	118/3750	139/3500
Maximum torque [Nm/min-1]	260/1750	270/1800	360/1500	400/1750
Bore and stroke [mm x mm]	72.2 x 84.0	72.2 x 84.0	85.0 x 88.0	85.0 x 88.0
Compression ratio	-	-	-	-
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake and exhaust valves VVT Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged variable timing of intake and exhaust valves VVT Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front
Gearbox	6 gear manual	7 gear automatic	6 gear manual	6 gear automatic
Drive specifications	-	seven-speed dual-clutch automatic gearbox EDC	-	dual-clutch automatic gearbox EDC

Top speed [km/h]	201	210	210	224
Acceleration 0–100 km/h [s]	9.8	9.8	10.1	9.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	9.0	8.3	8.2	7.0

City [l]	-	-	-	-
Out of town [l]	-	-	-	-
Combined [l]	-	-	-	-
CO2 emissions [g/km]	-	-	-	-

Low speed [l]	-	-	-	-
Medium speed [l]	-	-	-	-
High speed [l]	-	-	-	-
Extra high speed [l]	-	-	-	-
Combined speed [l]	6.3-6.1	6.8-6.3	6.1-5.9	6.1-5.9
CO2 emissions [g/km]	143-138	154-142	161-154	161-154

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1413-1580	1439-1606	1658-1800	1658-1800
Overall weight [kg]	2043	2069	2263	2263
Maximum trailer weight unbraked/braked [kg]	750/1500	750/1500	750/1800	750/1800
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-

Boot volume [l]	600	600	600	600
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1014	-/1014	-/1014	-/1014
Boot length [mm]	1204	1204	1204	1204
Boot length with rear seats folded [mm]	2076	2076	2076	2076
Boot width between wheels/max [mm]	935/-	935/-	935/-	935/-
Boot height to headliner/ceiling [mm]	417/-	417/-	417/-	417/-
Loading edge height [mm]	718	718	718	718
Height of the open boot door [mm]	1752	1752	1752	1752
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	1038/1136	1038/1136	1038/1136	1038/1136

Number of doors	4	4	4	4
Number of seats	5	5	5	5
Fuel tank volume [l]	50 [45 4Control]	50 [45 4Control]	50 [45 4Control]	50 [45 4Control]
AdBlue tank volume [l]	-	-	18	18
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W
Tyre dimensions rear	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W
Wheel size front	-	-	-	-
Wheel size rear	-	-	-	-
Brake dimensions front	296 x 26	296 x 26	320 x 28	320 x 28
Brake dimensions rear	290 x 11	290 x 11	290 x 11	290 x 11
Steering	Electric power steering	Electric power steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	2,8 [2,4 4Control]	2,8 [2,4 4Control]	2,8 [2,4 4Control]	2,8 [2,4 4Control]
Turning diameter track/circumference [m]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]

Overall length [mm]	4849	4849	4849	4849
Overall width without/including mirrors [mm]	1868/2081	1868/2081	1868/2081	1868/2081
Overall height [mm]	1463	1463	1463	1463
Wheelbase [mm]	2808	2808	2808	2808
Front wheel track [mm]	1614	1614	1614	1614
Rear wheel track [mm]	1609	1609	1609	1609
Forward overhang [mm]	959	959	959	959
Rear overhang [mm]	1081	1081	1081	1081
Clearance [mm]	145	145	145	145
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	902	902	902	902
Headroom rear [mm]	854	854	854	854
Front elbow/shoulder width [mm]	1512/1485	1512/1485	1512/1485	1512/1485
Rear elbow/shoulder width [mm]	1461/1400	1461/1400	1461/1400	1461/1400
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	262/-	262/-	262/-	262/-

Estate (Grandtour)

	TCe 140	TCe 160	Blue dCi 160	Blue dCi 190
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1332	1332	1997	1997
Maximum output / speed [kW/min-1]	103/5500	116/5500	118/3750	139/3500
Maximum torque [Nm/min-1]	260/1750	270/1800	360/1500	400/1750
Bore and stroke [mm x mm]	72.2 x 84.0	72.2 x 84.0	85.0 x 88.0	85.0 x 88.0
Compression ratio	-	-	-	-
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake and exhaust valves VVT Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection turbo-supercharged variable timing of intake and exhaust valves VVT Gasoline Particulate Filter start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	Front	Front	Front	Front
Gearbox	6 gear manual	7 gear automatic	6 gear manual	6 gear automatic
Drive specifications	-	seven-speed dual-clutch automatic gearbox EDC	-	dual-clutch automatic gearbox EDC

Top speed [km/h]	201	210	210	224
Acceleration 0–100 km/h [s]	9.8	9.8	10.1	9.2
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	9.0	8.3	8.2	7.0

City [l]	-	-	-	-
Out of town [l]	-	-	-	-
Combined [l]	-	-	-	-
CO2 emissions [g/km]	-	-	-	-

Low speed [l]	-	-	-	-
Medium speed [l]	-	-	-	-
High speed [l]	-	-	-	-
Extra high speed [l]	-	-	-	-
Combined speed [l]	6.3-6.1	6.8-6.3	6.1-5.9	6.1-5.9
CO2 emissions [g/km]	143-138	154-142	161-154	161-154

Emission standard	Euro 6d	Euro 6d	Euro 6d	Euro 6d
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1413-1580	1439-1606	1658-1800	1658-1800
Overall weight [kg]	2043	2069	2263	2263
Maximum trailer weight unbraked/braked [kg]	750/1500	750/1500	750/1800	750/1800
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	80/-	80/-	80/-	80/-

Boot volume [l]	564	564	564	564
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1673	-/1673	-/1673	-/1673
Boot length [mm]	1116	1116	1116	1116
Boot length with rear seats folded [mm]	2011	2011	2011	2011
Boot width between wheels/max [mm]	1100/-	1100/-	1100/-	1100/-
Boot height to headliner/ceiling [mm]	432/-	432/-	432/-	432/-
Loading edge height [mm]	736	736	736	736
Height of the open boot door [mm]	2111	2111	2111	2111
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	969/1075	969/1075	969/1075	969/1075

Number of doors	4	4	4	4
Number of seats	5	5	5	5
Fuel tank volume [l]	50 [45 4Control]	50 [45 4Control]	50 [45 4Control]	50 [45 4Control]
AdBlue tank volume [l]	-	-	18	18
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink
Tyre dimensions front	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W
Tyre dimensions rear	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W	225/55 R17 101W
Wheel size front	-	-	-	-
Wheel size rear	-	-	-	-
Brake dimensions front	296 x 26	296 x 26	320 x 28	320 x 28
Brake dimensions rear	290 x 11	290 x 11	290 x 11	290 x 11
Steering	Electric power steering	Electric power steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	2,8 [2,4 4Control]	2,8 [2,4 4Control]	2,8 [2,4 4Control]	2,8 [2,4 4Control]
Turning diameter track/circumference [m]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]	11.6/12.1 [10.8/11.3 4Control]

Overall length [mm]	4865	4865	4865	4865
Overall width without/including mirrors [mm]	1868/2081	1868/2081	1868/2081	1868/2081
Overall height [mm]	1456	1456	1456	1456
Wheelbase [mm]	2809	2809	2809	2809
Front wheel track [mm]	1614	1614	1614	1614
Rear wheel track [mm]	1609	1609	1609	1609
Forward overhang [mm]	959	959	959	959
Rear overhang [mm]	1097	1097	1097	1097
Clearance [mm]	145	145	145	145
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	902	902	902	902
Headroom rear [mm]	886	886	886	886
Front elbow/shoulder width [mm]	1512/1485	1512/1485	1512/1485	1512/1485
Rear elbow/shoulder width [mm]	1461/1400	1461/1400	1461/1400	1461/1400
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	262/-	262/-	262/-	262/-

Gallery

Renault Talisman Grandtour facelift 2020 wagon

Renault Talisman Grandtour facelift 2021 wagon

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
