Renault Wind

Date of manufacture

2010 – 2013 (Roadster)

Platform

Alliance B

Manufacturing locations

Novo Mesto, Slovenia

Designer

Car body style

Roadster

Date of manufacture

2010 – 2013

Internal designation

Engine size

1.2 TCe

1.6 16V

Technical data

Roadster

	1.2 TCe	1.6 16V
Date of sale	-	-
Engine type	Ignition supercharged	Petrol
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	1149	1598
Maximum output / speed [kW/min-1]	74/5500	98/6750
Maximum torque [Nm/min-1]	152/3500	160/4000
Bore and stroke [mm x mm]	69,0 x 76,8	79,5 x 80,5
Compression ratio	9,5:1	11,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	turbo-supercharged	variable timing of intake valves

Drive axle	Front	Front
Gearbox	5 gear manual	5 gear manual
Drive specifications	-	-

Top speed [km/h]	190	201
Acceleration 0–100 km/h [s]	10.5	9.2
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	8.0	9.1
Out of town [l]	5.3	5.7
Combined [l]	6.3	7.0
CO2 emissions [g/km]	145	165

Emission standard	EU5	EU4-EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1131	1173
Overall weight [kg]	1344	1383
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	270	270
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-/886	-/886
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	755	755
Height of the open boot door [mm]	1986	1986
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	2	2
Number of seats	2	2
Fuel tank volume [l]	40	40
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	torsion bar	torsion bar
Tyre dimensions front	195/45 R16	205/40 R17
Tyre dimensions rear	195/45 R16	205/40 R17
Wheel size front	-	-
Wheel size rear	-	-
Brake dimensions front	280 x 24	280 x 24
Brake dimensions rear	240 x 8	240 x 8
Steering	Electric variable power steering	Electric variable power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.55/10.95	10.55/10.95

Overall length [mm]	3833	3833
Overall width without/including mirrors [mm]	1689/1913	1689/1913
Overall height [mm]	1381	1381
Wheelbase [mm]	2368	2368
Front wheel track [mm]	1451	1451
Rear wheel track [mm]	1430	1430
Forward overhang [mm]	797	797
Rear overhang [mm]	668	668
Clearance [mm]	125	125
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	868	868
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	1224/1329	1224/1329
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
